Duratech LINK Touch DLT10-RGB User manual

DLT10-RGB/TW
Manual
27-06-22
(Other languages available online www.duratech.be)

32
Table of contents
Technical specifications
Box contents
About the LinkTouchTM
Installation instructions
Control functions: pool lights
Control functions: heat pump & pool cover
Advanced control functions: pool lights
Display: Status icons
Safety information
First use
How to use the Settings Menu
Connecting to ...
Cover operation settings
Buzzer settings
Temperature units display setting
Aux setting
Factory reset
Caring for the LinkTouchTM
Troubleshooting
Link Controller compatibility
How to upgrade the Link Controller
control board
Resetting the LinkTouchTM
Environment / disposal of old equipment
Service & warranty
Regulatory compliance
Page 3
Page 4
Page 4
Page 5
Page 6
Page 7
Page 8
Page 9
Page 10-11
Page 11
Page 12
Page 13
Page 14
Page 15
Page 16
Page 17
Page 18
Page 19
Page 19
Page 20
Page 21
Page 22
Page 23
Page 23
Page 23
Technical specifications
General specifications
Input Voltage: 5 V DC 0,5A
Interface: LoRa 868 MHz
USB-C
Ambient Air Temperature: 0°C to +40°C
Humidity 10% to 90% RH - non condensing
Ingress protection rate: IP20
IEC Protection Class: Class II
Size (in mm): 89,5 (Height)
186,5 (Width)
17,5 (Depth)
Weight: 298 g

54
The LinkTouchTM is the remote of your pool control system. By using the
LinkTouch, you can control the lights, the heat pump and cover of your
swimming pool. The LinkTouchTM includes an integrated Li-Ion battery which
can be charged automatically when mounted onto the wall mount.
The LinkTouchTM connects wirelessly with a compatible Link Driver, Link
Controller, Link Master and with DURA-V, DURA-Vi and DURAPRO heat pumps.
Please check our website for latest information regarding compatibility with
heat pumps
The LinkTouchTM can operate in dierent modes:
- When the LinkTouchTM is inserted in the Wall Mount, it will charge till full
battery.
- When LinkTouchTM is removed from the Wall Mount, it will work instantly
when touched.
- When the LinkTouchTM is removed from the Wall Mount and it is not
touched for 15 seconds, it will turn into “Standby mode”. In this case the
display will be o. As soon as the touch panel is touched by the user, the
display will turn on again.
- When the battery is empty, the LinkTouchTM will no longer function. To turn
on the LinkTouchTM again, it needs to be inserted into the powered wall
mount. When inserted the display will be active again and the LinkTouchTM
will start communicating with the external devices.
Box contents
About the LinkTouchTM
Installation instructions
1.5m
The LinkTouchTM is powered using the included AC power adapter and USB
power cord
1. Plug the USB power cord into the power adapter
2. Plug the other end of the USB power cord into the USB-C connector
of the wall mount.
3. Plug the power adapter in a power outlet.
4. Mount the Link Touch onto the wall mount.

76
ON/OFF Lights:
Press to switch all Lights ON/OFF
Colour wheel:
Slide to change colour of Pool Lights
(only DLT10-RGB)
Colour program:
Press for previous colour program.
Colour program:
Press for next colour program.
Colour temperature:
Slide to the right to adjust the pool light
from “warm white” to “cool white”
Dimming level:
Slide to the right to increase
the brightness of the Pool Lights
Control functions: pool lights
Pool water Temperature UP:
Press to increase desired temperature
Pool cover OPEN:
IN DMS MODE: Press and hold to open
te pool cover. When finger is removed
from button the cover will stop imme
diately.
NOT IN DMS MODE: Press once after
calibration and cover fully opens.
Pool cover CLOSE:
IN DMS MODE: Press and hold to close
te pool cover. When finger is removed
from button the cover will stop imme
diately.
NOT IN DMS MODE: Press once after
calibration and cover fully closes.
*Depends on DMS mode, when AUX is set to
cover.
ON/OFF heat pump:
Press to switch pool heat pump
ON/OFF
Pool water Temperature DOWN:
Press to decrease desired temperature
NOTE:
Depending on AUX MODE, in settings
COVER OPEN/CLOSE or FUNC A/B.
Control functions: heat pump & pool cover

98
ON/OFF Lights:
Press and hold for 1 second ON/OFF to see the
current settings.
Activate the settings menu (*),
then use left the left arrow key to return
to the previous settings menu.
Activate the settings menu (*),
then use right arrow key to select the
desired setting.
(*) Touch the display for 3 seconds to
activate the settings menu.
Advanced control functions: pool lights How to use the Settings Menu
3
SEC
Tap
Tap
Tap
Touch the display on the LinkTouchTM
for 3 seconds to go into the settings
menu.
Use arrow keys to select the desired
setting.
Right: Next setting
Left: To parent menu
Touch the display once to confirm
the setting.
SETTINGS
SETTINGS
SETTINGS

1110
Battery:
Signal:
Heat pump:
Pool lights:
Relays A and B:
Pool cover:
Battery capacity
LinkTouchTM is communicating wirelessly
Pool heat pump is ON (idle)
Pool lights are connected
Relays A and B used, not the pool cover function
Pool cover is opening/closing
Pool cover is open
Pool heat pump is ON and heating/cooling
Pool lights are ON
There is an error with relays A and B (p.19)
Pool cover is closed
There is an error with the pool cover (p.19)
Pool heat pump has an error (p.19)
There is an error with the pool lights (p.19)
Battery is charging
Battery error (p.19)
Display: Status icons Safety information
Intended use
This device has been developed as a remote control for swimming pool
accessories. The LinkTouchTM should be used only for this purpose, as
described in this user guide.
Precautions for Setup
- The LinkTouchTM can only be mounted indoor. Do not mount outdoors.
- The power adapter is designed for 100 - 240V, 50/60 Hz. Verify if the
power outlet voltage is within this range before plugging in your power
adapter.
- Install the device close to an accessible power outlet. Make sure the
power/USB cable can be easily disconnected from the power outlet at
all times.
- Protect the power/USB cable and the power adapter from being strained
pinched or bucked.
- Place the power/USB cable out of walk ways to prevent tripping over
the cable.
- Use only the power adapter provided with the LinkTouchTM. Use of an
incorrect power adapter may cause overheating or fire.
- Do not bend or place a heavy object on the power/USB cable as it could
damage the cable and result in risk of electric shock or fire.
- Do not use the power/USB cable if damaged or frayed.
- Be sure to hold only the connector end of the power/USB cable when
disconnecting. Repeated pulling on the cable will damage the cable.
Precautions for Operation
- Protect the LinkTouchTM from moisture and do not operate if power/
USB cable or plug are defective.
- Never touch a power plug with wet hands.
- Do not place anything on top of the LinkTouchTM.
- Never spill liquid of any kind on the LinkTouchTM.
- Do not drop or hit the LinkTouchTM.

1312
Select “Pair Start”-mode from the
settings menu.
Touch the screen once to put the
LinkTouchTM in pairing mode.
Connecting to ...
This “Pairing”-mode will allow the LinkTouchTM to establish a wireless
connection with other devices such as :
- Link Controllers, Link Master, linking per functionality
lights, cover)
- The heat pump
Note : In case the Link Master is already linked with cover and lights and
heat pump, it will distribute the links to the LinkTouchTM automatically.
Make sure the LinkTouchTM is in close proximity (<2m) of the device which
you would like to pair with wirelessly. Select “Pair Start” on the LinkTouchTM.
Power on the device.
The device will be in pairing mode for about 2 minutes after switched on.
The LinkTouchTM will now be pairing with the device.
SETTINGS
Pair
start
Pairing
Cover operation settings
Go to “AUX SETTING” in the settings
menu.
Touch the screen and select “COVER”.
Go to “DEADMANSWITCH” in the
settings. Touch the screen to select
“DEADMANSWITCH ENABLED”.
There are 2 modes:
Deadman switch operation enabled:
The cover operation will run when pressing and holding the finger
on the button and will stop when releasing the finger from the button.
Deadman switch operation disabled:
The cover operation will run with a single touch of the button
and will stop when touching the button again.
SETTINGS
Aux setting
cover
SETTINGS
Aux setting
cover
SETTINGS
DeadManSwitch
enabled
Warning :
For safety reasons :
1. The cover can only be operated when the remote device is connected to the wall mount in
case the “Deadman switch” operation mode is enabled.
2. The wall mount should be installed in close proximity of the pool to make sure that when
operating the cover with the remote device, the pool is always in sight of the operator.
Note that the wall mount can only be mounted indoor. Do not mount outdoors.
3. The operator must ensure that the path for the cover is clear and nobody gets in-
jured, while operating the cover.Note that Propulsion systems cannot be
held responsible for any damage or injury during the operation of the cover.
Note that Propulsion systems cannot be held responsible for any damage or injury during the
operation of the cover.

1514
FW V2.1 Cover Calibration in combination with DLM or DLC-010
Go to “Cover settings enter” in the
settings menu touch screen to enter
SETTINGS
Cover settings
enter
Touch the screen and select “COVER
CALIBRATION START ”.
SETTINGS
Cover calibr
start
Press the on/o icon to confirm the
calibration settings
Press the cover close icon on the Link
Touch for direction forward. Verify
if the cover closes when pressing
the cover close symbol. If not press
the on/o button once “direction
forward” will change to “direction
reverse” this will change the polarity.
Press the right arrow to confirm and
go to the next setting.
Press the cover open logo on the Link
Touch until the cover is fully opened.
To confirm and go to the next setting
press the right arrow.
Press the cover close logo until the
cover is fully closed. To confirm and
go to the next setting press the right
arrow.
COVER CALIBRATION
CONFIRM ?
STORE
COVER CALIBRATION
DIRECTION
FORWARD
COVER CALIBRATION
POSITION
OPEN
COVER CALIBRATION
POSITION
CLOSE
Buzzer settings
Go to “BUZZER” in the settings menu.
Touch the screen to select the
required operation mode. (note that
default setting is set to “BUZZER
ENABLED”.
The buzzer sound can be set to ON or OFF. If set to ON, then the buzzer
will sound each time as confirmation for touching any of the active areas
of the LinkTouchTM. The beep will also sound when the House of Duratech’s
DuraCover is in operation. In case of a third party cover, the beeping sound
will not be active.
Warning :
It is advised to set the buzzer setting to “ON”, in order to have an audio
feedback during the operation of the cover.
SETTINGS
Buzzer
Enabled
SETTINGS
Buzzer
Enabled

1716
Temperature units display setting
Go to “TEMP °C/°F” in the settings
menu.
Touch the screen to select the
required units. (note that default
setting is set to “°C”.
The temperature units on the display can be set to Celsius or Fahrenheit
SETTINGS
Temp °C/°F
°C
SETTINGS
Temp °C/°F
°C
Aux setting
NOTE:
Repeat for “AUX MODE B”
Go to “AUX SETTING” in the settings
menu.
Touch the screen to select “AUX
SETTING AUXILIARY”.
Go to “AUX MODE A” in the settings
menu.
Touch the screen to select the
required mode “TOGGLE” or “PULSE”.
This setting will allow the installer to change the cover function to an
ON/OFF function for a dierent device.
The “Aux Setting” can be set to “Cover” or “Auxiliary”.
If set to “Cover” then the LinkTouchTM is considered to control a cover system.
If set to “Auxiliary” then the LinkTouchTM will control a dierent device with the
cover buttons and the buttons will act as an “ON” and “OFF” button.
SETTINGS
Aux setting
cover
SETTINGS
Aux setting
auxiliary
SETTINGS
Aux mode A
toggle

1918
Resetting the LinkTouchTM
You can reset (=reboot) the LinkTouchTM without loosing the preferred settings.
To reset the Link touch:
Press the “Reset” button on the back of the LinkTouchTM, using a paperclip.
RESET
Factory reset
Go to “FACTORY RESET” in the
settings menu.
Touch the screen to reset the
LinkTouchTM to factory settings.
You can reset the LinkTouchTM to the factory default settings.
Resetting the LinkTouchTM reverts all settings to the factory default
settings. Any settings, including wireless connections, that have
been changed are lost.
The factory reset can be found in the setting menu.
SETTINGS
Factory reset
reset
SETTINGS
Factory reset
reset

2120
Caring for the LinkTouchTM
Troubleshooting
The LinkTouchTM requires very little maintenance
- You may occasionally need to clean the exterior of the housing.
To clean the exterior of the LinkTouchTM, wipe the exterior with
a soft, damp cloth.
NOTE: Do not use cleaning tissues or chemical substances
which might damage the surface
- Don’t place the LinkTouchTM in direct sunlight
This section includes information about what to do if you encounter
a problem with your LinkTouchTM. If you need further assistance,
please contact your installer or distributor or go to the support
section of the House of Duratech website at
www.duratech.be/duracare
Battery error
remove from heat source or take out of sunlight
Heat pump error
consult manual of heat pump for trouble shooting
Pool light error
consult manual of pool light for trouble shooting
Aux error
consult manual of auxiliary connected device for trouble
shooting
Cover error
consult manual of cover for trouble shooting
Link Controller compatibility
NOT upgradable
control board
upgradable
control board
After the firmware upgrade of the Link Controller, the handheld remote
control is no longer compatible with the Link Controller. In case a compatible
handheld remote control is required, then this one can be ordered separately.
To control the lights and the cover system, the LinkTouch™ communicates
with the Link Controllers.
If your Link Controller has the sticker “ LinkTouch™ ready”, then you do not
need to take any action. In this case the LinkTouch™ can work with the Link
Controller.
In case the Link Controller does not have a “LinkTouch™ ready” sticker, then
your Link Controller-requires a firmware update.
See below picture of the control boards of the Link Controller, which
are upgradable with an SD card, that is included in the packaging of the
LinkTouch™.

2322
To upgrade the Link Controller, the following steps need to be taken:
1. Switch of the power of the Link Controller.
2. Remove the Lora module from the control board.
3. Insert the SD card into the SD Card slot on the control board.
4. Power up the Link Controller
5. The green LED will be lit and the blue led will start flashing.
6. When the green and blue led remain solid, the firmware has been
upgraded.
7. Power down the Link Controller.
8. Remove SD card from SD card slot.
9. Insert the Lora module again.
10. Power up the Link Controller.
11. The Link Controller is now LinkTouch™ compatible.
How to upgrade the Link Controller control board
Lora module
SD card slot
Safety information
First use
Do NOT drop
the LinkTouchTM
Fully charge the LinkTouchTM
before using the device
The LinkTouchTM
is NOT water
proof
The LinkTouchTM
is NOT dust proof
Precautions for Cleaning, Transport and Storage
- Use a soft, damp cloth to clean the exterior of the LinkTouchTM
Do not use cleaning tissues or chemical substances which might
damage the surface.
- This LinkTouchTM contains no user serviceable parts. Do not attempt to
service the LinkTouchTM yourself. Repair service should be performed by
a authorised technician.

2524
Environment / Disposal of old equipment
Service & warranty
Declaration of Conformity
This symbol of a crossed out waste bin on a product, its packaging and/or accompanying documents
means that the product is subject to the European Directive 2002/96/EC as well as national law for
implementation of the directive. Directive and law prescribe that electrical and electronic products
must not be disposed of with household waste. The customer must dispose of the product by
delivering it to a designated station for collection, treatment and recycling of waste electrical and
electronic equipment. The correct disposal of your old appliance is free of charge and will help
prevent potential negative consequences of the environment and human health.
For more information about disposing your old appliance, contact your city office, waste disposal
service, or the shop where you purchased the product.
If you need service or information or if you have a problem, please contact your local dealer. If needed they will contact
the manufacturer to solve your problem.
They are gladly willing to assist you!
You can find more information at www.duratech.eu
We warrant all parts to be free from manufacturing defects in materials and workmanship for a period of two years
from the date of retail purchase.
This warranty is limited to the first retail purchaser and is not transferable. The liability of the manufacturer shall not
exceed the repair or replacement of defective parts and does not include any costs for labour to remove and reinstall
the defective part, transportation to or from the factory, and any other materials required to make the repair. This
warranty does not cover failures or malfunctions resulting from the following:
1. Failure to properly install, operate or maintain the Link Touch in accordance with the installation guidelines
provided in this manual.
2. The workmanship of any installer of the product.
3. Abuse, alteration, accident, fire, flood, lighting, rodents, insects, negligence or acts of god.
4. Use of non-factory authorized parts or accessories in conjunction with the product.
LIMITATION OF LIABILITY
This is the only warranty given by the manufacturer, No one is authorized to make any other warranties on our behalf.
This warranty is in lieu of all other warranties, expressed or imlied, including but not limited to any implied warranty of
fitness for a particular purpose and merchantability. We expressly disclaim and exclude any liability for consequential,
incidental, indirect or punitive damages for breach of any expressed or implied warranty.
This warranty gives you specific legal rights, which may vary, by country.
WARRANTY CLAIMS
For prompt warranty consideration, contact your dealer and provide the following information: proof of purchase,
model number, serial number and date of installation. The dealer will contact the manufacturer for instructions
regarding the claim and determine the location of the nearest service point.
Declarations of conformity covering this product are available for download from the House of Duratech website:
www.duratech.be
VISION Moonlight
VISION Spectra
VISION Adagio Pro
VISION Wall Conduits
VISION Faces Plates
VISION Specials
COVER Tube
COVER Wall Duct
COVER Motor
VISION Pro
HEAT Hot Splash
HEAT Sun Spring
HEAT Dura +i
HEAT Dura Vi
HEAT Dura V
HEAT Dura Pro
HEAT Accessories
LINK Touch
LINK Driver
LINK Master
LINK Controller
LINK Accessoires
LINK Cover
FLOW Inverter
COVER Hanging System
COVER Cable Duct

26
Contact details
Propulsion Systems bv
Dooren 72
1785 Merchtem, Belgium
Tel [phone]
www.duratech.be
[email protected]
We reserve the rights to change all or part of the contents of this document without prior notice
402-0235-2
