Duratool D03406 User manual

1
BATTERY TESTER - SLA & LITHIUM
Model: D03406

2
IMPORTANT SAFETY INFORMATION
FUNCTIONS
WHATs INCLUDED
SETTING UP
OPERATION
Please read these instructions carefully before use and retain for future reference.
• Check the test leads, clips and case insulation before using. If you nd any
breakage or abnormality, or you consider the device is broken, stop using the
device immediately.
• Always operate the vehicle in a well ventilated area.
• Wear suitable eye protection.
• Avoid causing sparking when connecting the clips to the battery terminals.
• Up / Down keys: Select options.
• Exit key: Exit to previous menu.
• ENTER key: Conrm the selection.
• FN Key: Multi-function.
• Mini-USB Socket (on the side of the product): used to connect to a PC to print data.
• Battery Tester
• User Manual
• USB cable
• CD
• The tool allows you to make the following adjustments and settings:-
• From main menu, select the System Setup and press ENTER.:
1. Language: Selects desired language.
2. Fn settings: Set the measurement function - Voltmeter / quick test
3. Contrast adjustment: Adjusts the contrast of the LCD display.
4. Shows rmware version of the tester.
• After connect the tools clips to vehicle battery noting the correct polarity (Red clip to
battery +) the tester displays the tester model and version, then the battery voltage.
• Press any key to display the test options.
• The tester will automatically adjust to the surface charge and will prompt you to turn
off any circuits on the vehicle that may be drawing power, then press the ENTER
key.
Battery Test
• Select BATTERY TEST: the tester will prompt to select Car/Scooter (Motorcycle)
battery.
• Press UP/DOWN key to select Car/Scooter, then press ENTER to conrm.
• Select BATTERY TYPE: the tester will prompt to select battery type, i.e. Regular
Flooded, Lithium Ion, AGM Flat Plate or AGM Spiral, Gel and EFB battery.
• Press UP/DOWN key to select the battery type, then press ENTER to conrm.
Note: Lithium Ion battery are Scooter (Motorcycle) battery types only.

3
Standard Description Lithium Range Wet AGM EFB
CCA: Cold Cranking Amps, specied by SAE & BCI 20-1000 100-2000
BCI: Battery Council International standard 20-1000 100-2000
CA: Cranking Amps standard, effective starting current
value at 0°C
20-1000 100-2000
MCA: Marine Cranking Amps standard, effective starting
current value at 0°C.
20-1000 100-2000
JIS: Japan Industrial Standard 26A17-150F51 26A17-245H52
DIN: German Auto Industry Committee Standard 20-700 100-1400
IEC: Internal Electro technical Commission Standard 20-700 100-1400
EN: European Automobile Industry Association Standard 20-1000 100-2000
SAE: Society of Automotive Engineers Standard 20-1000 100-2000
GB: China National Standard 2-120 30-220
Health:96% 490CCA
Charge:98% 12.64V
Internal R=6.1mΩ
Rated: 500A
GOOD BATTERY
Health:78% 440CCA
Charge:30% 12.20V
Internal R=7.2mΩ
Rated: 500A
GOOD, RECHARGE
Health:46% 490CCA
Charge:80% 12.68V
Internal R=18.1mΩ
Rated: 500A
REPLACE
Health:39% 310CCA
Charge:20% 12.08V
Internal R=30.1mΩ
Rated: 500A
CHARGE - RETEST
Health:0% 0CCA
Charge:20% 10.64V
Internal R=45.2mΩ
Rated: 500A
BAD CELL REPLACE
Cranking Test
• Select CRANKING TEST: the tester then displays the following:
Cranking Test
Start Engine
Cranking Test
RPM Detected
Cranking Test
Time 780ms
Cranking Low
9.12V
Cranking Test
Time 780ms
Cranking Normal
10.13V
Replace
Good
• Press UP/DOWN key to select according to the actual system standard and rating
marked on the battery itself.
• Batteries are marked with a variety of specications, the tester works with:
• Press ENTER to start the test.
• The test can take several seconds to before the result is shown on screen:

4
Charging System
• Select CHARGING TEST: with the engine running the tester displays the following:
Review Data
• Select REVIEW DATA: the tool displays all the test results:
Print Data (Windows only)
• Select PRINT DATA: the tool displays all the test results:
Charging Test
Loaded Testing
Charging Test
Test ing
- - -
Increase RPM to
2500 for 10s
Press ENTER to
continue
Charging Test
Loaded 14 .16V
Unloaded 14.39V
Replace OK
Charging Normal
Charging Test
Loaded 14 .16V
Unloaded 13.39V
Replace OK
Low
Charging Test
Loaded 14 .16V
Unloaded 15.39V
Replace OK
High
Charging Test
Loaded 12 .18V
Unloaded 12.18V
Replace OK
No Output
Good
Fault
Health:96% 490CCA
Charge:98% 12.64V
Internal R=6.1mΩ
Rated: 500A
GOOD BATTERY
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL
& ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical &
Electronics Equipment (WEEE). Any WEEE marked products must not be mixed with general
household waste, but kept separate for the treatment, recovery and recycling of the materials
used. Contact your local authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.0
• Connect the tool to the computer via USB cable.
• If the PC doesn’t automatically load the USB driver and recognise the tester, a USB
driver is included on the CD.
• Print software is also included to display the data from the tester and print to any
printer connected to the PC.
• Clear any previous data stored in the printer queue then connect the tester and the
data held in the tester will be displayed.
• Click on Print to send to the printer.
