DURATRAX Evader BX Quick Start Guide
http://www.manuallib.com/file/2713274
From ManualLib.com
ManualLib.com collects and classifies the global product
instrunction manuals to help users access anytime and
anywhere, helping users make better use of products.
Home: http://www.manuallib.com/ Chinese: http://www.shuomingshuku.com/
This Manual: http://www.manuallib.com/file/2713274

Charge your 6 or 7-cell battery with your battery charger.Be
sure to follow the instructions supplied with your charger.
1.
1.
4.
4.
2.
2.
3.
3.
READTHE INSTRUCTION MANUAL ANDWATCHTHEVIDEO FOR FURTHER DETAILS ON RUNNING AND MAINTAININGYOUR EVADER BX.
Screw in the transmitter antenna and install the “AA”
batteries. Check to make sure the red power light glows
when turning the switch “on”.
ON/OFF
POWER
LIGHT
STEERING
TRIM
ADJUSTABLE
STEERING
RATE
THROTTLE
TRIM
Install (8) new "AA" batteries
Install the antenna to the chassis.Secure excess wire to the
tube using tape. DO NOT CUTTHE ANTENNA WIRE!!!
Route the antenna
through the chassis
and then through
the tube.
Remove the clip and lift the battery strap. Install the
charged battery pack into the chassis and reinstall the
battery strap and clip. Plug the battery into the connector
on the Electronic Speed Control.ALWAYS DISCONNECT
THE BATTERY PLUGS WHEN FINISHED RUNNING.
Remove the pin and lift
the strap to install/remove
the battery pack.
Install the strap
between the bumps.
Charge the Battery Pack.
Prepare theTransmitter
Install the Antenna Tube
Install the Battery Pack
RTR ASSEMBLY
5.
5.
Place the body onto the chassis. Use clips to secure the
body in place. Install the wing into the rear shock tower.
Install the Body
™
®
This Manual: http://www.manuallib.com/file/2713274

RUNNING THE EVADER BX
2.
2.
1.
1.
3.
3.
DTXZ1073 for DTXD22**
COPYRIGHT © 2002
The power light should glow. ALWAYS TURN ON THE
TRANSMITTER BEFORE THE BUGGY.
Turn on the Transmitter
Turn on the switch in the chassis located on the right
side of the chassis.
Turn on the Buggy
ELECTRONIC SPEED
CONTROL (ESC) SWITCH
Hold up the rear wheels and squeeze the trigger. The
rear wheels should spin forward. Push the trigger back.
The rear wheels should spin backwards. If the wheels
spin with the trigger in the neutral position, adjust the
throttle trim knob located on the transmitter.
Adjust the Throttle
Squeeze for
forward
Push for
reverse
4.
4.
To make your Evader drive in a straight line, you may
need to adjust the steering trim knob located on the
transmitter. Adjust the dual rate knob to increase or
decrease the steering travel.When first learning to drive,
adjust the dual rate knob for less steering travel. As you
get to be a better driver, adjust the dual rate knob for
more steering travel.
Adjust the Steering
STEERING
TRIM
THROTTLE
TRIM
ADJUSTABLE
STEERING
RATE
5.
5.
Depending on the type, condition and charge of your
battery pack, your run time may vary. The Evader will
slow down towards the end of the battery charge. Stop
before the battery is completely dead. Allow the battery
to cool before recharging.
When Running...
If you have any questions, contact
Duratrax Product Support at
217-398-8970
Monday - Friday 8am-5pm CST or
[email protected]
HAVE FUN!!!
