DURHAND 845-867V70 User manual

1
User Manual
IN221100531V01_UK
845-867V70
High Pressure Washer User's Manual
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

2
SAVE THESE INSTRUCTIONS
Please read and follow all instructions before use. Keep this manual for future
reference.
All warnings and notes in this manual ensure the safe use of this product.
IMPORTANT SAFETY INSTRUCTIONS
Hazard levels
DANGER
Warning of immediate danger, which can lead to serious injury or death if not avoided.
WARNING
Warning of a potentially dangerous situation, which can lead to injury or death if not
avoided.
CAUTION
Warning of a potentially dangerous situation, which can lead to minor injuries if not
avoided.
ATTENTION
Warning of a potentially dangerous situation, which can lead to property damage if not
avoided.
Electric components
DANGER
Risk of electric shock.
Never touch the mains plug and the socket with wet hands.
Check the power cord for damage prior to every use. Do not use the machine if the supply
cord or parts are damaged, e.g. safety devices, high pressure hoses or trigger gun.
Keep all conducting parts away from water.
The mains plug and the coupling of an extension cable must be watertight and kept away
from water. Keep extension cables at least 60mm above the ground – never lay them on
the ground.
Always check the power cord or extension cable, ensuring there are no damages. Keep
power cords away from heat, oil and sharp edges.
Ensure the appliance is off and unplugged when unattended.
WARNING
Only connect this appliance to an electric supply, which has been installed by an
electrician in accordance with IEC 60364.
Only connect this appliance to an alternate current. The voltage must match the plate on
the appliance.
For safety reasons, it is recommended to use the appliance via a residual current device
(max. 30mA).
An unsuitable electrical extension cable can be hazardous. Only use an electrical
extension cable, which has been approved and labeled for this purpose and has an

3
2 2
adequate cable cross-section outdoors: 1 - 10 m:1.5 mm ;10 - 30 m:2.5 mm .
Always fully unreel the extension cable from the drum.
An unsuitable electrical extension cable can be hazardous.
DANGER
Only use this appliance as intended by the manufacturer.
Be cautious of your surroundings when using this appliance, paying attention to other
persons in the vicinity.
Before every use, check important components, such as the high-pressure hose, hand
spray gun and safety installations for damage. Replace damaged components
immediately – do not use the appliance.
Only use this appliance with the cleaning agent supplied or recommended by the
manufacturer. Using other cleaning agents or chemicals could damage the appliance.
High-pressure jets can be dangerous if misused. The jet must not be directed at persons,
live electrical equipment or the machine itself.
Do not direct the jet against yourself or others to clean clothes or footwear.
Do not use the appliance within range of persons, unless they wear protective clothing.
Wear appropriate personal protection equipment (PPE) while operating the appliance.
WARNING
The appliance must not be operated by children or untrained personnel.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capacities, or lacking experience and knowledge.
Children must not play with this appliance.
Supervise children to prevent them from playing with the appliance.
Ensure the appliance is stable prior to any work on or with the appliance to prevent
damage.
The water jet that is emitted from the high-pressure nozzle results in a repulsion power
acting on the hand spray gun. Make sure that you have a firm footing and are also holding
the hand spray gun and spray lance firmly.
Never leave the appliance unattended when in use.
ATTENTION
If you leave the appliance, ensure it is switched off and unplugged.
Do not operate the appliance at temperatures below 0ºC.
Other risks
DANGER
The appliance may not be operate in explosive atmospheres.
Risk of explosion-Do not spray flammable liquids.
Never draw in fluids containing solvents or undiluted acids and solvents! This includes
petrol, paint thinner and heating oil. The spray mist is highly inflammable, explosive and
poisonous. Do not use acetone, undiluted acids and solvents, as they corrode the
materials used on the appliance.
Never use the product with inflammable or toxic liquids, or liquids with characteristics
incompatible with its proper operation.
Keep packaging films away from children, there is a risk of suffocation!
Safe handling

4
WARNING
According to applicable regulations, the appliance must never be used on the drinking
water net without a system separator. Ensure that the connection of your building water
installation on which the high pressure cleaner is operated is equipped with a system
separator pursuant
Water that has flown through backflow preventers is considered to be non-potable.
High-pressure hoses, fittings and couplings are important for the safety of the appliance.
Only use high-pressure hoses, fittings and couplings recommended by the manufacturer.
To ensure applicable safety, use only original spare parts from the manufacturer or
approved by the manufacturer.
Switch the product off and disconnect it from the power supply removing the power plug
from the socket outlet before assembly, cleaning ,adjustments, maintenance, storage and
transportation or converting the product to another function.
CAUTION
Mind the weight of the appliance when selecting the storage location and during transport
to prevent accidents or injuries.
Several hours of continuous use of the appliance can lead to numbness in the hands in
rare cases.
● Wear gloves.
● Keep hands warm.
● Take breaks at regular intervals. Working with detergent
WARNING
The improper use of detergents can cause severe injuries or oxidation.
Store cleaning agent away from the reach of children.
Discharge residual pressure before disconnecting the hose from the product.
Check before each use , and at regular intervals, that all metal fasteners are tight and the
product’s components are in good condition; inspect for broken or worn parts.
Be aware of kick-back: Hold With Both Hands.
Residual risks
Even if you are operating this product in accordance with all the safety requirements,
potential risks of injury and damage remain. The following dangers can arise in
connection with the structure and design of this product:
Health defects resulting from vibration emission if the product is being used over long
periods of time or not adequately managed and properly maintained.
Danger of injury and property damage caused by flying objects.
Injuries and damage to property due to broken accessories or the sudden impact of
hidden objects during use.
CAUTION
Safety installations serve the protection of the user and may not be modified or by past.
Safety Devices
Power switch
The appliance switch prevents unintentional operation of the appliance.

5
If the lever on the trigger gun is released the pressure switch turns off the pump, the high
pressure jet is stopped. If the lever is pulled the pump is turned on again.
Lock trigger gun
This lock locks the lever of the trigger gun and prevents the inadvertent start of the
appliance. Overflow valve with.
Water that has flowed through backflow preventers is considered to be non-potable.
Pressure switch
Motor protection switch
The motor protection switch off the device if the power consumption is high.
Personal protective equipment
CAUTION
Wear protective clothing and safety goggles to protect against splash back containing
water or dirt.
During the use of high-pressure cleaners aerosols can develop. Inhaling aerosols can
cause health damage.
● Depending on the application, completely shielded nozzles(e.g. surface cleaner)that
significantly reduce the emission of aqueous aerosols can be used for high-pressure
cleaning.
● The use of such shielding is not possible with all applications.
The high pressure jet must not be directed at persons, animals, live electrical
equipment or at the appliance itself.
The appliance must not be directly connected to the public drinking water
network.
For protection against injury, wear ear defenders and safety goggles.
Wear safety gloves during use to protect hands.
Symbols on the machine
Sound power level is 86dB(A)
Wear non-slip footwear that will protect your feet and improve your
balance on slippery surfaces.
Use this pressure washer for private households only:
If connection is made to a potable water system, the system shall be protected against
backflow.
This high pressure cleaner is designated with a rated input current. The intended use of
this product covers the cleaning of vehicles, buildings, terraces, facades and garden
Proper use

6
equipment using clean water and biodegradable chemical detergents. Likewise the
product can be used to clean paving slabs or rain gutters.
This product may not be used to clean clothing, shoes and other textiles. The water jet
should not be directed against persons. Animals, any electrical equipment or on the
product itself. Do not flush any objects which contain health hazardous materials. The
product must not be run with inflammable, explosive and toxic liquids.
For safety reasons it is essential to read the entire instruction manual before first
operation and to observe all the instructions there in.
Description of the Appliance
1.Handle
2.High-pressure hose reel
3.Power cord hook
4.Adjust switch0/1
5.Power cord
6.Water inlet
7.Trigger gun holder
8.Spray wand holder
9.Water outlet
10.Wheel
11.Spray handle
12.Spray lance
13.Nozzle
14. High pressure hose
15.Water inlet connector
16.Nozzle cleaning tool
17.Detergent Bottle
Technical specifications
Voltage
Frequency
50/60Hz
Watt
1800W
Protection Class
II
Degree of protection
IPX5
Rated pressure
10 MPa
Allowable pressure
15 MPa
Rated flow
6.0 L/min
Max. flow
8.5 L/min
220V-240V~
17

7
Assembly
Mount loose parts delivered with appliance prior to start-up
1. Install the Hose Reel Handle with two screws
5. Slide the power cord hook into the right position of the unit.
4. Install the spray wand
●Fit the spray wand into the gun and rotate until the two parts are completely locked.
Insert the desired nozzle in the spray lance until heard a click.
3. Slide the power cord hook into the
right position of the unit.
2. Slide the trigger gun holder into the
left position of the unit.

8
7. Connect the garden hose to the water inlet
Connect the garden hose adaptor (female coupler) to the water inlet of the pressure
washer, then thread your garden hose(male end) into the garden hose adaptor.
6. Connect the high-pressure hose to the water outlet
Connect the other end of the high-pressure hose to the water outlet on the washer and
twist the black rotatable end-piece as indicated to secure the connection.
8.TO WASH WITH DETERGENT
Screw out the bottle and fill bottle with detergent. Connect Detergent Bottle to Spray
Handle.

9
Start up
Park the appliance on an even surface.
Insert the mains plug into the socket.
Water supply
For connection values, see type plate.
ATTENTION
Impurities in the water can damage the high-pressure pump and the accessories.
Water supply from mains
Drawing in water from the open reservoirs
This high-pressure cleaner is suited to work with the YILI suction hose with backflow vale
to draw in surface water, e.g. from water butts or ponds.
Fill the suction hose with water.
Screw the suction hose into the water connection of the appliance and insert it into the
water source (e.g. rainwater drum).
Bleed the device as follows prior to operation:
● Turn on the appliance “0/1”
● Unlock the lever of the trigger gun.
● Push the lever of the trigger gun, the device will switch on.
● Let the device run (max. 2 minutes) until the water exits the trigger gun without bubbles.
● Release the lever of the trigger gun.
● Lock the lever of the trigger gun.
CAUTION
Keep a distance of at least 30 cm when using the jet for cleaning painted surfaces to
avoid damage.
Operation
ATTENTION
Dry running of more than 2 minutes leads to damage of the high-pressure pump. If the
appliance does not build up pressure within 2 minutes, switch the appliance off and
proceed in accordance with the instructions in Chapter “Troubleshooting”
High pressure operation
CAUTION
Make sure the on/off switch is set to ‘OFF/ON’ and insert the plug into a properly
installed socket.
ATTENTION
● The washer must be used on a secure and
stable surface in a standing, upright
position
Connect the product to power and water
supply as described.

10
● Open the water supply
● Hold the spray gun with both hands.
● Direct the nozzle of the chosen accessory away from you towards the surface to be
cleaned.
● Unlock the trigger and press it until a constant amount of water flows through the
nozzle, to allow air trapped in the hose to escape.
● Release the trigger.
● Turn on the switch “0/1”.
● Hold the spray gun with both hands. Direct the water jet to the object to be cleaned and
press the trigger.
Release the lever of the trigger gun; the device will switch off again and stop the water jet.
High pressure remains in the system.
WARNING! Beware of kickback when pressing the trigger!
Operation with detergent
Detergent can only be added when the device is operated in low pressure mode.
DANGER
When using detergents, the material data safety sheet issued by the detergent
manufacturer must be adhered, especially the instructions regarding personal protective
equipment.
Remove the cap of the clean detergent bottle. Gently pull the onboard detergent tank out
of its storage position.
Fill the tank with detergent designed specifically for use with pressure washers.
Push the detergent bottle with the opening pointing downwards into the connection for
the hose clean detergent.
Recommended cleaning method
● Spray the detergent sparingly on the dry surface and allow it to react, but not to dry.
● Spray off loosened dirt with the high pressure Met.
After operation with detergent
● Remove the hose clean detergent bottle from the intake and close it with the lid.
● For storage, put the detergent bottle into the retainer with the cap pointing up.
Interrupting operation
● Release the lever of the trigger gun.
● Lock the lever of the trigger gun.
● Put the trigger gun with the spray lance into the parking position.
● During longer breaks(more than 5 minutes), also turn the appliance off using the “0/1”
switch.

11
Finish operation
● Release the lever of the trigger gun.
● Turn off the appliance "0/1”.
● Disconnect the mains plug from the socket.
● Only separate the high-pressure hose from the trigger gun or the device when there is
no pressure in the system.
TURN OFF TAP
● Pressure the lever of the trigger gun to release any remaining pressure in the system.
● Release the lever of the trigger gun.
● Lock the lever of the trigger gun.
ATTENTION
● When disconnecting the supply or high pressure hose, warm water may leak from the
connection after operation.
● Detach the appliance from the water supply.
Transportation
CAUTION
Risk of personal injury or damage!
Mind the weight of the appliance during transport.
When transporting by hand
● Switch the product off and disconnect it from the water and power supply.
● Pull out the transport handle until it audibly snaps into place. Attach transportation
guards, if applicable.
● Pull the appliance by its transport handle.
When transporting in vehicles
● Prior to horizontal transport: close the cap of clean detergent bottle.
● Tilt the product towards you until it balances on the wheels. Then move it by its
transportation handle.
● Protect the product from any heavy impact or strong vibrations which may occur during
transportation in vehicles.
● Secure the appliance against shifting and tipping over.
Storage
CAUTION
Risk of personal injury or damage!
Consider the weight of the appliance when storing it.
Storing the appliance
● Park the machine on an even surface.
● Detach spray lance from the trigger gun.
● Push the disconnect button on the trigger gun and pull the high-pressure hose out of
the trigger gun.
● Place the trigger gun into the storage for the trigger gun.

12
ATTENTION
Appliance and accessories that are not completely drained can be destroyed by frost.
Completely drain appliance and accessories and protect them against frost. To avoid
damage:
● Detach the appliance from the water supply.
● Detach spray lance from the trigger gun.
● Turn on the appliance “ON/OFF”.
● Push the lever of the trigger gun until no more water is escaping .
● Release the lever of the trigger gun.
● Lock the lever of the trigger gun.
● Turn off the appliance “0/1”.
● Store the appliance and the entire accessories in a frost free room.
Care and maintenance
DANGER
Risk of electric shock
Prior to all work on the appliance, switch off the appliance and pull the power plug.
Frost protection
● Put both spray lances into the storage for the spray lance.
● Dirt grinder spray lance: Nozzle towards the bottom.
● Coil the high-pressure hose and hang it over the hose storage.
● Store the mains connection in the accessory compartment.
● Prior to extended storage periods, as during the winter, also observe the instructions in
the care section.
● Always store the pressure cleaner, parts, and accessories in a place that is inaccessible
to children. The ideal storage temperature is between 10 °C and 30 °C. Store the power
washer indoors to prevent the water in the unit from expanding under freezing
conditions.
● We recommend using the original package for storage or covering the product with a
suitable cloth or enclosure to protect it against dust.
High-pressure hose
The high pressure hose is specially constructed with reinforced walls it can be easily
damaged and should be stored carefully.
● Do not kink.
● Do not drive vehicles over the hose.
● Do not expose the hose to sharp edges or corners.

13
Clean the sieve in the water connection
Clean the sieve in the water connection
regularly.
Remove coupling from the water
connection, and rinse with warm water to
prevent any foreign matter from clogging the
pump.
Clean the nozzle with the needle clean-out tool provided .
Remove the spray wand from the gun. Remove any dirt
from the nozzle hole and rinse.
ATTENTION
● The sieve must not be damaged.
● Pull the sieve out using flat pliers.
● Clean the sieve under running water.
● Reinsert the sieve into the water connection.
DANGER Risk of electric shook.
Turn off the appliance and remove the main plug prior to performing any care and
maintenance work. Repair work and work on the electrical components may not only be
performed by an authorized customer service. You can rectify minor faults yourself with
the help of the following overview. If in doubt, please consult the authorized customer
service.
Troubleshooting
Symptom Cause Recommended action
Machine refuses
to start
Plug in machine
Try another socket.
Replace fuse. Switch off other
machines.
Try without the extension cord.
Machine not plugged in
Defective socket
Fuse has blown
Defective extension cord
Fluctuating
pressure
Check that hoses and
connections are airtight.
Clean and replace or refer to
local distributor
Clean and replace or refer to
local distributor
Pump sucking air
Valves dirty, worn out or stuck
Pump seals worn ou

14
Incorrect mains voltage
Thermal sensor activated
Nozzle partially blocked
Machine stops
Check that the mains voltage
corresponds to specification on
the model tag.
Leave the washer for 5 minutes
to cool down. Clean the nozzle
Allow machine to run with open
trigger until regular working
pressure resumes.
Check that the water supply
corresponds to specifications
required
NB! Avoid using long, thin
hoses (min. 1/2").Clean the
nozzle /Clean the filter
Straighten out hose.
Air in inlet hose
Inadequate supply of mains
water
Nozzle partially blocked
Water filter blocked
Hose kinked
Machine
pulsating
Wait for pump/hoses or
accessory to thaw. Connect
inlet water.
Clean the filter /Clean the
nozzle
Pump/hoses or accessory
frozen
No water supply
Water filter blocked /Nozzle
blocked
Machine starts,
but no water
comes out.
Accessories
A choice of accessories is supplied in the scope of the delivery of this product. Please
check the technical specification of any accessories that you purchase to ensure they
are compatible with this product.
If you have any questions, please contact our customer
care center.
Our contact details are below:
0044-800-240-4004
[e-mail]
IMPORTER ADDRESS:
MH STAR UK LTD
Unit 27, Perivale Park,
Horsenden lane South
Perivale, UB6 7RH
MADE IN CHINA

15
Manual de usuario
Limpiadora de alta presión
IMPORTANTE, CONSERVAR PARA FUTURAS CONSULTAS: LEER
DETENIDAMENTE.
845-867V91
IN221100531V01_ES

16
GUARDE LAS INSTRUCCIONES
Lea y siga estas instrucciones de seguridad antes de operar su dispositivo por
primera vez y guárdelas para uso futuro o propietarios posteriores.
Además de las notas contenidas en este documento, se deben observar las
disposiciones generales de seguridad y las normas para la prevención de accidentes.
Las advertencias y notas adjuntas al dispositivo brindan información importante para una
operación segura.
Niveles de peligro
PELIGRO
Indicación de peligro inmediato, si no se evita, que provocará lesiones graves o la
muerte.
ADVERTENCIA
Indicación de una situación potencialmente peligrosa que, si no se evita, podría provocar
lesiones graves o la muerte.
CUIDADO
Indicación de una situación potencialmente peligrosa que, si no se evita, podría provocar
lesiones leves.
ATENCIÓN
Indicación de una situación potencialmente peligrosa que podría provocar daños
materiales.
Composants électriques
PELIGRO
Riesgo de shock eléctrico.
Nunca toque el enchufe y la toma de corriente con las manos mojadas.
Compruebe el cable de alimentación y el enchufe antes de cada uso. No utilice la
máquina si el cable de alimentación o partes importantes de la máquina están dañadas,
por ejemplo, dispositivos de seguridad, mangueras de alta presión o pistola de
chorro.Todas las partes activas en el área de trabajo deben estar protegidas contra el
chorro de agua.
El enchufe de red y el acoplamiento del cable de extensión nunca deben dejarse en el
agua. Además, el acoplamiento nunca debe descansar en el suelo. Se recomienda
utilizar bobinas de cable que aseguren que las tomas estén al menos a 60 mm del suelo.
Asegúrese de que el cable de alimentación o el cable de extensión no se dañen al ser
atropellados, pellizcados, arrastrados o similares. Proteja los cables de alimentación del
calor, el aceite y los bordes afilados.
Apague siempre el interruptor de desconexión de la red cuando deje el dispositivo
desatendido.
ADVERTENCIA
El dispositivo sólo se puede conectar a un fuente de alimentación que ha sido instalada
por un electricista de acuerdo con IEC 60364.
INSTRUCCIONES DE SEGURIDAD IMPORTANTES

17
El dispositivo solo se puede conectar a corriente alterna. La tensión debe corresponder a
la placa de características del dispositivo.
Por razones de seguridad, recomendamos que el dispositivo se utilice únicamente a
través de un dispositivo de corriente residual (máx. 30 mA).
Un cable de extensión inadecuado puede ser peligroso. Utilice únicamente un cable de
extensión eléctrica que haya sido aprobado y etiquetado para este propósito y que tenga
2 2
una sección de cable exterior adecuada:1 - 10m:1,5 mm ; 10 - 30m:2,5 mm
Desenrolle siempre completamente el cable de extensión del tambor del cable.
Un cable de extensión eléctrico incorrecto puede ser peligroso.
Manejo seguro
PELIGRO
El usuario debe utilizar el dispositivo según lo previsto. La persona debe tener en cuenta
las condiciones locales y debe prestar atención a otras personas en las inmediaciones
cuando trabaje con el dispositivo.
Antes de cada operación, compruebe los componentes importantes, como la manguera
de alta presión, la pistola rociadora manual y los accesorios de seguridad, en busca de
daños. Reemplace inmediatamente los componentes dañados. No utilice el dispositivo
con componentes dañados.
El aparato está diseñado para ser utilizado con el agente de limpieza suministrado o
recomendado por el fabricante. El uso de otros agentes de limpieza o productos
químicos puede afectar negativamente a la seguridad del aparato.
Los chorros de alta presión pueden ser peligrosos si se someten a un mal uso. El chorro
no debe dirigirse a personas, equipos eléctricos activos o la propia máquina.
No dirija el chorro hacia usted mismo o hacia otras personas para limpiar ropa o zapatos.
No utilice el dispositivo al alcance de las personas a menos que lleven ropa protectora.
Use equipo de protección personal (EPI) apropiado cuando opere el dispositivo.
ADVERTENCIA
El dispositivo no debe ser operado por niños o personal no capacitado.
Este aparato no está diseñado para ser utilizado por personas (incluidos niños) con
capacidades físicas, sensoriales o mentales reducidas, o falta de experiencia y
conocimiento.
Los niños no deben jugar con este aparato.
Supervise a los niños para evitar que jueguen con el aparato.
Instale el dispositivo antes de cualquier trabajo en el dispositivo o con el dispositivo para
evitar daños accidentales.
El chorro de agua que sale de la boquilla de alta presión genera un poder de repulsión
que actúa sobre la pistola de pulverización manual.Asegúrese de tener una base firme y
también sujeta firmemente la pistola pulverizadora manual y la lanza pulverizadora.
Nunca deje el aparato desatendido mientras esté en funcionamiento.
ATENCIÓN
En caso de pausas prolongadas, apague el aparato con el interruptor principal o
desenchúfelo de la red eléctrica.
No utilice el aparato a temperaturas inferiores a 0°C.

18
Otros riesgos
PELIGRO
El aparato no puede funcionar en atmósferas explosivas.
Peligro de explosión - No pulverizar líquidos inflamables.
¡Nunca ingiera líquidos que contengan solventes o ácidos y solventes sin diluir! Esto
incluye gasolina, diluyente y aceite de calefacción. La neblina de rocío es altamente
inflamable, explosiva y venenosa. No use acetona,
ácidos y disolventes sin diluir, ya que corroen los materiales utilizados en el dispositivo.
Nunca utilice el producto con líquidos inflamables, tóxicos o con características
incompatibles con su correcto funcionamiento.
Mantenga el plástico y los envases fuera del alcance de los niños, ¡peligro de asfixia!
ADVERTENCIA
De acuerdo con la normativa aplicable, el dispositivo nunca debe utilizarse en la red de
agua potable sin un separador del sistema. Asegúrese de que la conexión de la
instalación de agua de su edificio en la que se utiliza el limpiador de alta presión esté
equipada con un separador de sistema compatible.
El agua que ha pasado por no retornos se considera no potable.
Las mangueras de alta presión, los accesorios y los acoplamientos son importantes para
la seguridad del aparato. Utilice únicamente mangueras,
accesorios y acoplamientos de alta presión recomendados por el fabricante.
Para garantizar la seguridad aplicable, utilice únicamente repuestos originales del
fabricante o aprobados por el fabricante.
Apague el producto y desconéctelo de la fuente de alimentación quitando el enchufe de
la toma de corriente antes del montaje, limpieza, ajustes, mantenimiento,
almacenamiento y transporte o conversión del producto a otra función.
CUIDADO
Preste atención al peso del dispositivo al seleccionar el lugar de almacenamiento y
durante el transporte para evitar accidentes o lesiones.Varias horas de uso continuo del
dispositivo pueden provocar entumecimiento de la mano en casos raros.
● Use guantes.
● Mantenga sus manos calientes.
● Tome descansos y descansos regulares.
ADVERTENCIA
El uso inadecuado de los detergentes puede causar lesiones graves u oxidación.
Guarde los productos de limpieza fuera del alcance de los niños.
Descargue la presión residual antes de desconectar la manguera del producto.
Compruebe antes de cada uso, y a intervalos regulares, que todas las fijaciones
metálicas están apretadas y que los componentes del producto están en buen estado;
inspeccione si hay piezas rotas o desgastadas.
Tenga en cuenta el retroceso: sujete con ambas manos.
Riesgos residuales
Incluso si usted está operando este producto de acuerdo con de acuerdo con todos los
requisitos de seguridad, siguen existiendo riesgos potenciales de lesiones y daños. Los
siguientes peligros pueden surgir en relación con la estructura y el diseño de este
producto:
Defectos de salud derivados de la emisión de vibraciones si el producto se utiliza durante

19
largos periodos de tiempo o no se gestiona y mantiene adecuadamente.
Peligro de lesiones y daños materiales por objetos voladores.
Lesiones y daños materiales debidos a la rotura de accesorios o al impacto brusco de
objetos ocultos durante el uso.
Este bloqueo bloquea la palanca de la pistola de disparo y evita que el aparato se ponga
en marcha de forma involuntaria.
El agua que ha pasado por los desconectores se considera no potable.
Dispositivos de seguridad
Las instalaciones de seguridad están al servicio de la protección del usuario y no pueden
ser modificadas ni transmitidas.
Interruptor de alimentación
El interruptor del dispositivo evita el funcionamiento involuntario del mismo.
Pistola de disparo con bloqueo
Interruptor de presión
Si se suelta la palanca de la pistola de disparo, el presostato desconecta la bomba y el
chorro de alta presión se detiene. Si se tira de la palanca, la bomba se conecta de nuevo.
Equipo de protección personal
CUIDADO
Utilizar ropa de protección y gafas de seguridad para protegerse de las salpicaduras que
contengan agua o suciedad.
Pueden formarse aerosoles cuando se utilizan limpiadores de alta presión. La inhalación
de aerosoles puede causar daños a la salud.
-Según la aplicación, se pueden utilizar boquillas completamente protegidas (por
ejemplo, limpiadores de superfície) que reducen significativamente la emisión
deaerosoles acuosos para la limpeza a alta presión.
-El uso de dicho blondaje no es posible con todas las aplicaciones.Símbolos de la
máquina
CUIDADO
Interruptor de protección del motor
La protección del motor desconecta el aparato si el consumo de energía es elevado.
El chorro de alta presión no debe dirigirse a personas, animales,
equipamento eléctrico bajo tensión ni al propio aparato.
El aparato no debe conectarse directamente a la red pública de agua
potable.
Para protegerse contra lesiones, use protectores para los oídos y gafas de
protección.
Use guantes de seguridad durante el uso para proteger sus manos.
Use calzado antideslizante que
protegerá sus pies y mejorará su equilibrio en superficies resbaladizas.

20
Descripción del aparato
El nivel de potencia sonora es 86dB(A).
Utilice esta limpiadora a presión únicamente para casas particulares y uso doméstico.
Si se conecta a un sistema de agua potable, el sistema debe protegerse contra el reflujo.
Este limpiador de alta presión está diseñado con una corriente de entrada nominal. El
uso previsto de este producto incluye la limpieza de vehículos, edificios, terrazas,
fachadas y equipamientos de jardín utilizando agua limpia y detergentes químicos
biodegradables. Asimismo, el producto se puede utilizar para la limpieza de losas de
pavimento o canaletas de lluvia.
Este producto no se puede utilizar para limpiar ropa, zapatos y otros textiles. El chorro de
agua no debe dirigirse a personas, animales, ningún equipo eléctrico ni al propio
producto. No descargue ningún objeto que contenga materiales peligrosos para la salud.
El producto no debe utilizarse con líquidos inflamables, explosivos y tóxicos.
Por motivos de seguridad, es imprescindible leer todo el manual de instrucciones antes
de la primera operación y observe todas las instrucciones contenidas en el mismo.
Uso correcto
1. Manipulación
2. Carrete de manguera de alta
presión
3. Gancho para el cable de
alimentación
4. Ajustar el interruptor 0/1
5. Cable de alimentación
6. Entrada de agua
7. Soporte de la pistola
8. Soporte para varilla
pulverizadora
9. Salida de agua
10. Rueda
11. Mango de pulverización
12. Lanza de pulverización
13. Boquilla
14. Manguera de alta presión
15. Conector de entrada de agua
16. Herramienta de limpieza de
boquillas
17. Botella de detergente
17
