Duronic CG421 User manual

CG421
2-in-1 Coffee & Spice Grinder
PLEASE READ ALL THE INSTRUCTIONS BEFORE USE

2

3
English Manual
Manuel d’utilisation en français
Gebrauchsanleitung auf Deutsch
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
Instrukcja obsługi. Polski
5
17
29
41
53
65
Contents

4

5
English Manual

6
1. Grinder cover
2. Cup lid
3. Wet ingredient cup
4. Dry ingredient cup
Features and Specications
Model
Number Capacity Dimensions Power Voltage
CG421 2 x 220ml cups 21 x 11.5 x
11.5cm 200W 220-240V / 50-60Hz
5. Activation touch sensors
6. Grinder motor unit
7. Power cable
8. Brush/Scoop
1
3
6
5
7
4
8
2

7
Capacity and Conversion Chart
*estimated amounts
220ml
160ml
1 scoop
80ml
Scoops Milliliters
(ml)
Fluid Ounce
(.oz)
11 220 7.7
8 160 5.6
4 80 2.8

8
PLEASE READ THIS MANUAL CAREFULLY AND RETAIN FOR FUTURE
REFERENCE
• This appliance is for indoor/household use only. Do not use outdoors.
• This appliance is not designed for commercial or industrial use; it is for
household use only.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
• Children should be closely supervised at all times to ensure that they do not
play with the appliance.
• Only use the grinder out of the reach of children because there are sharp
blades inside the grinder cups. Store the grinder cups safely out of reach of
children.
• Do not operate this appliance if the power cable or plug is damaged. If
either is damaged, return it to Duronic for service or repair by a professional
technician.
• Never try to replace the parts and repair the unit by yourself. Do not modify
the appliance in any way that is not described in the instructions for use. The
machine contains live parts. Repairs may only be carried out by Duronic,
using original spare parts and accessories.
• If an extension lead/cable is needed to reach the appliance to a mains power
socket that is too far away out of reach of the machine’s accompanying cable,
please ensure that:
- the marked electrical rating of the extension lead is at least as great as
the electrical rating of the appliance.
- the extension lead is of the grounded type.
- no other appliance is plugged into the same extension lead.
Safety Information

9
- the extension cable is safely positioned to avoid it being pulled on by
children or animals or being tripped over.
• Always operate the appliance on a dry, smooth, even and stable surface. Do
not place the grinder on or next to a hot surface.
• Position the grinder and its power cable to the rear of the work surface, well
out of reach of children.
• Disconnect the mains plug from the power socket if you are going to be
absent for long periods.
• Never disconnect the plug by pulling on the power cable.
•Unplug from the mains plug outlet when not in use and before cleaning.
• This appliance is not intended to be operated using an external timer or
separate remote-control system.
• Do not let the power cable hang over the edge of the table or counter, or
touch hot surfaces.
• Do not use the appliance for anything other than grinding.
• Do not operate the grinder with wet hands.
• To clean, wipe the machine body with a well-wrung wet cloth. Do not
submerge it in water or other liquids. Wash the cups and lids with warm water
and soap. Dry properly before placing the cups back into the machine.
• Do not switch the grinder on if the cups are empty or use the grinder for more
than 30 seconds at a time as this will overheat the motor.
Caution: The blades inside the grinder cups are sharp. Be careful
when emptying and cleaning the cups.

10
Grind your own coffee beans to create fresher and more aromatic coffee, or grind
up spices for better avour in your cooking and baking.
Grinding your own ingredients at home can save money, can eliminate
unnecessary excess packaging from store-bought jars and packets, and more
importantly, will enable you to create tastier ingredients to use in your kitchen!
The CG421 2-in-1 electric grinder will effortlessly grind through both dry and wet
ingredients. It comes with two cups equipped with different blades which are
suited for both coffee grinding and spice/herb grinding.
1. Remove all of the packaging materials. Check that there are no parts missing.
2. Clean the outside of the grinder body by wiping it with a wet well-wrung
sponge or cloth.
3. Wash the cups and lids with warm soapy water and dry thoroughly.
Introduction
Before First Use

11
1. Place your grinder base onto your kitchen countertop positioned to the rear of
the surface. Plug the power cable into the closest mains plug socket. Do not
switch it on yet.
2. Select which grinding cup to use and place it onto the machine base, turning
it clockwise to lock it in place.
3. Fill the cup with the ingredients you want to grind and place the lid on top.
Then place the grinder cover on top.
4. Switch the machine on at the plug. To start grinding, press down on the top of
the lid and release when you wish to stop. The contents can be ground nely
or coarsely depending on how long you run the grinder for.
Operating Instructions
Note: Do not use the grinder continuously for more than 30 seconds at a time.
The recommended run time is 30 seconds on, 3 minutes off. After 3 cycles of this,
leave the grinder to cool down for 30 minutes to avoid the motor overheating.
Caution:
• Do not add ingredients to the cup while the grinder is switched on
at the plug.
• If the rotation of the blade becomes obstructed, switch the grinder
off at the plug and unplug from the wall socket before attempting to
clean the obstruction.

12
Caution:
• Be careful when cleaning the blades as they are sharp and can
cause injury!
• The cups should not be washed in a dishwasher OR submerged in
very hot water.
• Do not reassemble the grinder when parts are wet as this may
create a re hazard. Ensure each part is dry before reassembling or
storing away.
It is essential to keep your grinder clean so that you can enjoy the best results
every time you use it.
Coffee beans and spices contain oils that will naturally collect in the grinder,
particularly around the blade, and these can quickly become stale. The stale oils
and residue can taint the taste of anything else you grind in the grinder, so it is
important to clean the cups regularly.
Switch off and unplug the grinder before cleaning.
1. To clean the motor unit, wipe the machine body with a well-wrung wet cloth.
Dry with a dry cloth or leave to air dry.
2. To clean the cups, use the brush to clean out any dry grounds or residue from
under the blades. Then use warm soapy water and a soft cloth to gently clean
the lid, inside of the cup and around the blade. Dry properly before placing a
cup back into the machine or before storing away.
3. Dry properly before placing a cup back into the machine or before storing
away.
Cleaning and Maintenance

13
Filling and Grinding Guidelines
(WET CUP)
Ingredients / Combinations Grinding
Time
Mint leaf 10g, cucumber slices 30g, yoghurt 20g,
water 15ml 20s
Pepper 10g, ginger 10g, curry powder 10g,
coriander leaf 10g, water 35ml 20s
Masala 20g, water 40ml 30s
Black pepper 20g, water 50ml 30s
Cardamom 10g, water 40ml 30s
Caraway 30g, water 30ml 30s
Caraway seed 10g, water 40ml 30s
Straight, sharp edge

14
Filling and Grinding Guidelines
(DRY CUP)
Ingredients / Combinations Grinding
Time
Soy beans 50g 30s
Dried peppers 20g 15s
Rice 60g 30s
Sichuan Pepper 20g 20s
Ginger 50g 20s
Coffee Beans 75g
For the perfect cup of coffee, we recommend 7-8g of ground
coffee for a small coffee/tea cup or 11-12g for a medium mug.
30s
Jagged, blunt edge

15
Problem Possible
Cause
Suggested
Solutions
The grinder does
not work after
being switched
on
The grinder lid was not
properly in place so it did
not connect with the power
activating buttons on the
motor unit.
Check the grinder lid and ensure it is
properly in place.
The 3 touch sensors on the
top of the motor unit may be
obstructed by something.
Check and clean/clear the 3 sensors
if they are dirty or have anything
obstructing them.
The grinder stops
working during
operation
Check if the power cable/
plug is loose.
If the power cable is loose, push it
back into the socket and switch it on.
Check if the motor unit is
too hot.
If the motor unit has overheated the
grinder will need to rest and cool down
before you can continue using it.
If it does not work after cooling down,
please contact Duronic for further
advice.
The machine
starts to make a
bad smell
With new products that
contain a motor it is normal
for it to emit a smell upon
rst use.
The smell should fade upon use of the
grinder. If the smell persists after a few
uses, contact Duronic for advice.
Abnormal
vibration or noise
Unstable positioning of the
grinder unit.
Reposition the grinder on a smooth
even surface.
The lid, grinding pot,
blade or base is loose or
damaged.
If any parts are damaged, do not use
the grinder. Contact Duronic directly
where you should be able purchase
the replacement part you need.
Troubleshooting Guide

16
Warranty
1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products.
NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A
CONSUMER
This product has been manufactured under the strictest or quality control procedures, and
using the highest quality of materials, to ensure excellent performance and reliability. It will
give very good and long lasting service, provided it is properly used and maintained. The
product is guaranteed for 1 years from the date of original purchase. If any defect arises due
to a faulty materials or poor workmanship, the faulty product must be returned to the original
place of purchase. Refund or replacement is at the discretion of that company.
Duronic Products are offered with a 1 year guarantee under the following conditions:
1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions
contained in this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect,
inexpert repairs or consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work,
under the guarantee
7. Valid in the UK only
This product is tted with CE:1363 plug and fuse
Imported by Shine-Mart Ltd, RM3 8SB
Information on waste Disposal for Consumers of
Electrical & Electronic Equipment.
This mark on a product and/or accompanying documents indicates that when it
is to be disposed of, it must be treated as Waste
Electrical & Electronic Equipment, (WEEE).
Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used.
For proper treatment, recovery and recycling; please take all WEEE marked
waste to your Local Authority Civic waste site,
where it will be accepted free of charge.
If customers dispose of Waste Electrical & Electronic Equipment correctly, they
will be helping to save valuable resources and preventing any potential negative
effects upon human health and the environment, of any hazardous materials that
the waste may contain.
Follow Us

17
Manuel d’utilisation en français

18
1.
2.
Couvercle du moulin
Couvercle
3.
du récipient
4.
Récipient pour ingrédients mouillés
Récipient pour ingrédients secs
Caractéristiques et Spécicités
Modèle CapacitéDimensions Puissance Voltage
CG421 2 récipients
x 220ml
21 x 11.5 x
11.5 cm 200W 220-240V / 50-60Hz
5. Capteurs d'activation tactile
Base
6.
7.
moteur
8.
Câble d'alimentation
Brosse/Cuillère
1
3
6
5
7
4
8
2

19
Capacitéet Tableau de Conversion
*quantités estimées
220ml
160ml
1 cuillérée
80ml
Cuillérées Millilitres
(ml)
Once Liquide
(.oz)
11 220 7.7
8 160 5.6
4 80 2.8

20
VEUILLEZ LIRE CE MANUEL ATTENTIVEMENT ET LE CONSERVER.
•Cet appareil est conçu pour un usage
•
intérieur. Ne l'utilisez pas à l'extérieur.
Cet appareil n'est pas conçu pour un usage commercial ou industriel,
il est uniquement conçu pour un usage domestique.
•Ce produit n'est pas conçu pour être utilisé par des personnes, y compris
des enfants, dont
•
les capacités physiques, sensorielles ou mentales sont
limitées ou qui manquent de savoir et d'expérience, à moins qu'elles ne
soient supervisées ou qu'elles aient reçu les instructions nécessaires à
l'utilisation de cet appareil par la personne responsable de leur sécurité.
Les enfants doivent être placés sous surveillance afin de s'assurer qu'ils
ne jouent pas avec l'appareil.
•Utilisez uniquement ce moulin hors de portée des enfants à cause des
lames à l'intérieur de l'appareil. Rangez les récipients hors de portée des
enfants.
•N'utilisez pas l'appareil si le câble ou la prise sont endommagés. Si l'un
des deux est endommagé, veuillez contacter Duronic ou faites réparer
l'appareil par un professionnel.
•N'essayez jamais de remplacer des éléments ou réparer l'appareil
vous-même. Ne modifiez pas l'appareil d'une façon qui n'est pas décrite
dans les instructions d'utilisation. L'appareil contient des éléments sous
tension. Les
•
réparations peuvent uniquement être réalisées par Duronic en
utilisant des pièces de rechange originelles ou des accessoires.
Si une rallonge est nécessaire pour brancher l'appareil à une prise qui est
trop loin ou hors de portée du câble de la machine, veuillez vous assurer
que:
-les caractéristiques électriques de la rallonge soient au moins aussi
élevées que les caractéristiques électriques de l'appareil.
-la rallonge a une mise à la terre.
-aucun
Safety Information
autre appareil n'est branché sur cette même rallonge.
