Dust Right 42401 User manual

4" Through-the-Wall Port Kit Instructions
Effective July 2022
Review full instructions prior to use for important safety information.
Always check Rockler.com to confirm that you are using the most
recent version of instructions for your product.

2
GENERAL SAFETY WARNINGS
This product is designed only for specific applications as defined in the instructions and should not
be modified or used for any manner not described in these instructions. Use only recommended
accessories. Before using the 4" Through-the-Wall Port Kit Instructions: READ, UNDERSTAND
AND FOLLOW ALL INSTRUCTIONS AND SAFETY WARNINGS. KEEP THESE
INSTRUCTIONS READILY AVAILABLE FOR FUTURE REFERENCE.
>Always confirm that you are using the most
recent version of the Instructions and safety
warnings for your product (see the
Instructions link on the product
page at Rockler.com).
>Before using another tool with this product,
always read, understand and follow the
instructions and safety warnings in the
owner’s manual for that tool. If you do not
have the owner’s manual, obtain one from
the tool’s manufacturer before using it with
this product.
>Before using any chemical with this
product, always read, understand and
follow all safety warnings and guidelines
in the manufacturer’s Safety Data
Sheet (SDS; formerly called “MSDS”),
especially regarding:
• How to safely use the chemical,
including potential hazards and
recommended first aid measures;
• Personal safety equipment required
to safely use the chemical (e.g. gloves,
eye protection, mask/respirator, etc.);
• Proper and safe handling, storage
and disposal of the chemical.
>Before using this product, review and verify
that all tools to be used with it have safety
equipment installed and are in proper
working order as defined by the tool’s
owner’s manual.
>Do not use this product until you have read
and are confident you understand:
• Product Specific Safety Warnings (p. 3);
• Installation (p. 4).
>The user assumes all risk and responsibility
for the proper and safe use of this product
and for ensuring product suitability for the
intended application.
>It is the sole responsibility of the purchaser
of this product to ensure that anyone you
allow to use this product reads and
complies with all instructions and safety
precautions outlined in this manual
prior to use.
>Follow all standard shop safety
practices, including:
• Keep children and bystanders away
from the tool operating area;
• Do NOT use power tools in explosive
environments, or in the presence of
flammable liquids, fumes or dust;
• TURN OFF AND UNPLUG all power
tools BEFORE making any adjustments
or changing accessories;
• Remain alert and use good judgment.
Do not use this product if you are in any
way impaired by medications, alcohol,
drugs or fatigue;
• Keep your work area well lit and clean;
• Dress appropriately. Secure loose
clothing, remove all jewelry and tie
up long hair before using this product;
• ALWAYS wear safety glasses, hearing
protection and respiratory protection
that complies with NIOSH/OSHA/ANSI
safety standards;
• Use dust collection tools and dust face
masks to reduce exposure to dust;
• Use safety equipment such as
featherboards, push sticks and push
blocks, etc., when appropriate;
• Maintain proper footing at all times
and do not overreach;
• Do NOT force woodworking tools.
>These warnings and instructions do
NOT represent the total of all information
available regarding tool safety, use and
technique. Always seek out opportunities
to learn more and improve your skills
and knowledge.
Drilling, sawing, sanding
or machining wood products can expose
you to wood dust, a substance known to
the State of California to cause cancer.
Avoid inhaling wood dust or use a dust
mask or other safeguards for personal
protection. For more information go to
www.P65Warnings.ca.gov/wood.
BP0222

Danger indicates a hazardous situation that, if not avoided,
will result in death or serious injury.
Warning indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
Caution indicates a hazardous situation that, if not avoided,
may result in minor or moderate injury or property damage.
Notice indicates important or helpful information and/or user tips.
3
PRODUCT SPECIFIC SAFETY WARNINGS
> The mounting location MUST NOT
intersect any wall studs, plumbing,
electrical wiring or ductwork.
> Do NOT run electrical wiring or
plumbing through the Dust Right
Through-The-Wall Port Kit.
> Understand and follow all relevant
building and electrical codes. If you
are not confident you can install the
Dust Right Through-The-Wall Port
Kit in compliance with building and
electrical codes, have a qualified
professional complete the installation.
> Do NOT use the Dust Right Through-
The-Wall Port Kit to install a dust
collector outside the work area if the
work area contains a gas-fueled
appliance. In drawing the air
outside, the dust collector could lead
to a buildup inside the work area of
combustion gases – including
deadly carbon monoxide – that
normally are vented from
gas-fueled appliances.
> Make sure that the dust collector is
protected from elements of the
weather, especially moisture.
> Follow all safety warnings and
guidelines for any product used
in conjunction with the Dust Right
Through-The-Wall Port Kit.

Distributed by Rockler Companies, Inc.
4365 Willow Dr. Medina, MN 55340
42401
Rev 07/22
1-800-279-4441
www.rockler.com
Check Rockler.com for updates to these
instructions. If you have further questions, please
contact our Technical Support Department at
1-800-260-9663 or [e-mail]
screws or larger holes for wall
anchors. (Screws and wall anchors
not included.)
9. At the second wall, make sure the
tube is extending as far as it will go.
Then make a mark on the tube
11⁄2" out from the wall. Remove the
4" diameter tube from the wall and
carefully cut it to the length you
just marked.
10. Reinsert the tube in the hole and
advance it until the combo port is
flush against the wall. Attach the
combo port to the first wall
with screws.
11. At the second wall, fit the remaining
combo port onto the 4" diameter
tube and position it square. Then
use the holes you drilled earlier in
the combo port flange to mark
drilling locations in the wall for
screws or wall anchors (not
included). Drill the pilot holes.
12. Remove the combo port; apply
silicone adhesive or ABS pipe
cement and fit the combo port back
onto the 4" diameter tube, squaring
it so the holes in the flange line up
with the holes or anchors in the wall.
Press the combo port flush against
the wall.
13. Drive screws to attach the combo
port to the wall. Allow the adhesive
to cure as specified in the
product instructions.
1. Decide on a location for the Dust
Right®Through-The-Wall Port Kit.
Make sure that the mounting
location will not intersect any
wall studs, plumbing, electrical
wiring or ductwork. Also make
sure it will be possible to create
aligned openings on both sides of
the wall; if the holes are misaligned,
the wall-mount combo ports will not
mount flush against the wall.
2. Mark and carefully cut a 4" diameter
hole in one wall. Options for making
this cut include a hole saw, a jigsaw,
a rotary tool or a jab saw.
3. Mark a corresponding hole on the
opposite wall. Make sure that the
hole will align with the hole you cut
in the first wall.
4. Carefully cut a 4" diameter hole
in the second wall and spread or
cut through any insulation in the
installation area.
5. Drill a hole in all four corners of
each wall-mount combo port for a
mounting screw (not included).
6. Attach the 4" diameter tube to one
of the wall-mount combo ports with
silicone adhesive or ABS pipe
cement. Allow the adhesive to
cure as specified in the
product instructions.
7. Fit the 4" diameter tube into the hole
in the first wall and out the hole in
the second wall. Advance the tube
until the combo port is flush against
the wall.
8. Square up the wall-mount combo
port and use the holes you drilled
in the flange to mark drilling
locations on the wall. Drill the holes.
Depending on your application, you
might need small pilot holes for
Installation
