DW DWC-MB421TIR User manual

Before installing and using the MEGApix Camera, please read this manual carefully.
Be sure to keep it handy for future reference.
02222013
IP 2.1MP Bullet IR Camera
DWC-MB421TIR
DWC-MB421TIR650

2
PRECAUTIONS
Do not open or modify.
Do not open the case except during maintenance and installation, for it may be dangerous and can cause
damages.
Do not put objects into the unit.
Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits, or
other damages.
Be careful when handling the unit.
To prevent damages, do not drop the camera or subject it to shock or vibration.
Do not install near electric or magnetic fields.
Protect from humidity and dust.
Protect from high temperature.
Be careful when installing near the ceiling of a kitchen or a boiler room, as the temperature may rise to high
levels.
Cleaning: To remove dirt from the case, moisten a soft cloth with a soft detergent solution and wipe.
Mounting Surface: The material of the mounting surface must be strong enough to support the camera.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference, when the
equipment is operated in a residential environment. This equipment generates, uses, and radiates radio frequency
energy, and if it is not installed and used in accordance with the instruction manual, it may cause harmful interference
to radio communications.
WARNING: Changes or modifications are not expressly approved by the manufacturer.
FCC COMPLIANCE

TABLE OF CONTENTS*
Introduction.......................................................................................................................................................4
Features........................................................................................................................................................4
Inside the Box...............................................................................................................................................5
Parts & camera Control Board ....................................................................................................................6
Camera Control Board ................................................................................................................................7
Dimensions...................................................................................................................................................8
Installation.........................................................................................................................................................9
Network Connection................................................................................................................................9-10
Mounting the Camera...........................................................................................................................11-12
Adjusting the Camera’s Angle...................................................................................................................13
Storage Device Installation........................................................................................................................14
MEGApix Camera Setup...............................................................................................................................15
Installing the IP Finder...............................................................................................................................15
Using IP Finder Software......................................................................................................................16-17
Network Options.........................................................................................................................................18
Camera Reboot..........................................................................................................................................19
MEGApix Camera Web Viewer.....................................................................................................................20
Accessing the Web Viewer via Internet Explorer.......................................................................................20
Accessing the Web Viewer via Google Chrome, Mozilla Firefox and Safari............................................21
First & Second Stream...............................................................................................................................22
Export Image..............................................................................................................................................23
Print Image.................................................................................................................................................24
Panic Recording....................................................................................................................................25-26
MEGApix Camera Setup...............................................................................................................................26
Video & Audio ......................................................................................................................................26-31
Event.....................................................................................................................................................32-35
Network.................................................................................................................................................36-41
Record & Remote Backup....................................................................................................................42-45
System..................................................................................................................................................46-53
Specifications............................................................................................................................................54-55
Troubleshooting........................................................................................................................................56-59
Warranty..........................................................................................................................................................60
Limits & Exclusions.......................................................................................................................................61
3

ONVIF Compliant
2.1 MEGApixels (1080P, 30fps)
Triple Codecs (H.264, MJPEG, MPEG4) with Dual-Stream
1/2.8” CMOS Sensor (7% Larger Than 1/3” CMOS Sensor)
3.5~16mmAuto Focus Lens [DWC-MB421TIR]
5~50mm Remote Auto Focus Lens [DWC-MB421TIR650]
4X Digital Zoom, 4.5X Optical Zoom [DWC-MB421TIR]
4X Digital Zoom, 8X Optical Zoom [DWC-MB421TIR650]
100ft IR with Intelligent Camera Sync
TDN (True Day and Night)
Power over Ethernet [PoE] & DC12V
Two-WayAudio
Micro SD/SDHC Class 10 Card for Emergency Backup
IP66 Certified (Weatherproof)
No Fog or Condensation under Any Weather Conditions
Web Server Built-in
WDR (Wide Dynamic Range)
3D-DNR (3D Digital Noise Reduction)
Programmable Privacy Zones (30) & Motion Detection
4
FEATURES*

The following items are included with the MEGApixEL Camera:
5
INSIDE THE BOX*
1. Quick Start Guide
2. Mounting Template
3. Mini- CD (Including
Manual, QSG, & IP Finder
Software)
4. Four (4) Screws and Four
(4) Dry WallAnchors
5. Second BNC Video Jack
6. L-Key
7. Double Sided TROX-T20
Hex Key
8. Bullet Camera
4
5 6
31
7
8
2

6
PARTS & DESCRIPTIONS*
1. Front Case
2. Sunshield
3. Lens
4. Rear Case
5. Control Board
6. Con Cap
7. Ball Neck Bracket
8. RS-485 Connection Cable
9. Alarm In/ Out Connection Cable
10. Audio In/ Out Connection Cable
11. RJ45 Network Connection Cable
12. Power Connection Cable (Max 2.2[W])
13. IP Board
14. Set Screw
15. Assembly Screw
16. Fixing Screw

7
CAMERA’S CONTROL BOARD*

DIMENSIONS*
8

NETWORK CONNECTION*
Two Options
Use a PoE-enabled switch to connect data and power through a single cable
and begin viewing and recording images instantly. A non-PoE switch will
require an adaptor for power transmission.
1. Using a PoE-Enabled Switch
The MEGApix Camera is PoE-Compliant, allowing transmission of power and data via a single Ethernet cable. PoE
eliminates the need for the different cables used to power, record, or control the camera. Follow the illustration below to
connect the camera to a PoE-enabled switch using an Ethernet cable.
9

NETWORK CONNECTION*
2. Using a Non-PoE Switch
If a PoE-enabled switch is not used, use a power adaptor for power transmission and non-PoE switch for data
transmission. Follow the illustrations below to connect the camera without a PoE-Enabled Switch.
10

INSTALLATION*
1. Using the mounting template or
your own camera, mark and drill the
necessary holes to mount the
bracket to a wall or ceiling.
2. Pull wires through and make all necessary
connections.
3. Connect the RJ45 to a CAT5 Cable.
4. Connect the Audio and Relay Control cables.
6. Use the four (4) mounting screws to
install the cameras on the wall or ceiling.
5. Check the LED light. Green light flickers for
booting. Red light turns on when booting is
complete.
11

INSTALLATION*
Junction Box for Bullet Housing
*Note: Electrical junction box and required screws are sold separately.
1. Using the mounting template or your own junction box, mark and drill the necessary holes
and secure the junction box to a wall or ceiling.
2. Align the camera with the junction box.
3. Secure the camera to the junction box with the included screws.
12

13
A d j u s t i ng t h e C a m e r a ’ s A n g l e
The MB4 21 S e r ies i s eq uipp ed with 360 °R o t a ti n g Came r a b o a r d and a 90 °T ilt i n g
and 360°Rot a t ing Ba l l N e c k Brac ket .
To Adjust the Camera’s Panning Angle (360°) and Tilting Angle (90°):
1. Use the L-Wrench to loosen the Locking Screw at the base of the camera’s Bracket by turning it counter clock-
wise.
2. Holding the camera’s body, rotate the camera 360°.
3. To adjust the Bracket’s tilting angle, move the camera up or down.
4. When all adjustment are complete, tighten the Locking Screw by rotating it clockwise.
INSTALLATION*

S t o r a g e D e v i c e
The M B42 1 T I R ME G Apix S er ies o f f e r t h e opt i o n o f loc al e m er gen c y back up in c as e
of ne t w o r k loss .
To install the SD card:
1. Unscrew the Locate the Con Cap on the side of the camera to locate the camera’s SD Card slot.
2. Insert the SD card in the slot and push it down, until you hear a ‘click’ sound.
3. To remove SD card, press the SD card down until you hear a ‘click.’ The SD card will eject from the slot.
4. Upon completion, go to the camera’s Webviewer. (See page 44 for more information.)
INSTALLATION*
14

15
I n s t a l l i n g I P F i n d e r S o f t w a r e
IP Finder searches for all the available Digital Watchdog devices currently connected to your network.
1. Install IP Finder to find the MEGApix camera on your local network. The software can be found on the included
User Manual CD. Run IP Finder and install onto your PC.
2. When setup is complete, launch IP Finder .
3. To find your MEGApix camera, click the Search button. Your MEGApix camera will appear as ”DWC-
MB421TIR” or “DWC-MB421TIR650”.
4. Select the desired device and select Web Connect to access the camera directly via Internet Explorer.
IP FINDER SOFTWARE*
*Be sure to install the IP Finder to a computer located on the same network segment (Subnet Mask) as the MEGApix camera.

16
U s i n g I P F i n d e r S o f t w a r e
Use IP Finder to change the basic settings of your MEGApix camera or to connect to your MEGApix camera.
1. Configuration: Change the device’s connection type and/or IP address information. Please see the next page
for further explanation.
2. Upgrade: Upgrade the device’s firmware.
3. Time Zone: Change the time zone.
4. Import Config: Import setup configuration for a specific device.
5. Web Connect: Connect to the MEGApix camera through Internet Explorer.
IP FINDER SOFTWARE*
1 2 3 4 5

17
U s i n g I P F i n d e r S o f t w a r e
Use IP Finder to set the connection type and the IP address information for your MEGApix camera.
1. DHCP: Select DHCP to access the camera within the same internal network.
2. PPPoE: Use this option when using WAN service. To use WAN service, a User ID and Password from your
internet service provider is required.
3. Static IP: Select Static to connect to the camera from an external network.
4. Use DDNS: Check this option to use DDNS service.
5. Port: Displays the port numbers that are required for communication. User can use IP Finder to change other
basic settings for the MEGApix camera. (The menu will be different depending on the model.)
IP FINDER SOFTWARE*
*If you decide to change the camera’s IP, write down the camera’s MAC Address for identification in the future.
1
2
3
4
5

18
DHCP
The Dynamic Host Configuration Protocol (DHCP) is a network configuration protocol that allows a device to configure
automatically according to the network it is connected to.
If your network supports DHCP, and your MEGApix camera is setup as DHCP; then once you search for your camera
using IP Finder, the search results will display your MEGApix camera with already set network settings that correspond
to your network requirements.
Static
Static IP addresses are recommended when using a network that does not support DHCP. If Static is selected, then
you must manually enter all the network settings for your MEGApix camera that would correspond with your network.
Static IP addresses are recommended if you want to setup your device to be accessed externally via the internet. For
each setup of the camera to a static IP address, it is recommended that you first setup the camera to DHCP, allow it to
configure itself according to your network, and then change the settings to a static IP address.
1. To set your MEGApix camera to static, highlight the desired device from the search results list, and click on
Configuration. In the new setup window, make sure static is selected.
2. Enter the following information: IP Address, Netmask, Gateway, Preferred DNS.
3. Click Apply and System Reboot to save all changes.
DDNS
Dynamic Domain Server is a feature that allows you to use a URL instead of an IP address to access your MEGApix
camera. The feature is optional, for it may require subscription and payment.
1. To use the DDNS feature, check the box next to Use DDNS.
2. Select the server you wish to use. *Some servers may require subscription and payment.
3. Enter the desired Hostname.
4. If applicable, enter the User ID and Password.
5. Click Apply and System Reboot to save all changes.
IP FINDER SOFTWARE*

19
R e s e t t i n g t h e C a m e r a
Pressing the reset button on the camera’s control board for five (5) seconds will initialize all environmental variables to
factory default. Previous setup for IP default, time, etc. will be deleted. If a system’s IP address is lost, reset the camera
back to factory default.
The following are the default network settings.
CAMERA REBOOT*
*Frequent use may cause system error.
IP Mode DHCP
IP Address 192.168.1.123
Subnet Mask 255.255.255.0
Gateway 192.168.1.123
Base Port 7000
HTTP Port 80

R e m o t e V i d e o M o n i t o r i n g V i a I n t e r n e t E x p l o r e r
Monitor and configure the MEGApix camera through a built-in Webviewer.
1. Type the IP address of the camera on the Internet Explorer window.
Example: http://192.168.1.123 (Factory Default)
2. Enter Username and Password.
Username: admin | Password: admin
3. The web browser will ask to install Active-X Control. Once it has been installed, Internet Explorer will display
video images from the camera.
WEBVIEWER*
20
