Dwin TransVision TransVision User manual

TransVision™
Operating Instructions
Read these instructions completely before operating this unit.
Contents subject to change without notice or obligation.
Printed in USA TransVision™
Rev. 7

- 2 of 23 -
Table of Contents
Safety Instructions……………………………………………………………………………………… 3
Introduction ............................................…………………………………………………………….. 5
Programming SL-8000 Remote Control to Operate TransVision™…………………………….. 6
Installation of the Controller……………….…………………………………………………………..
Installation of the Projector…………………………………………………………………………….
6
8
Quick Reference Remote Control Operation ................…………………………………………… 9
The Front Panel Controls................................……………………………………………………….. 10
Using The Control Menus.................................……………………………………………………… 10
Main Menu ..........................................…………………………………………………………. 10
Input Option.........................................…………………………………………………………. 10
Aspect Ratio Option..................................……………………………………………………… 11
Video Control Menu..................................……………………………………………………… 11
Setup Menu .........................................…………………………………………………………. 12
Menu Timeout.....................................……………………………………………………….. 12
Rename Inputs....................................……………………………………………………….. 12
Rename Ratios………...............................…………………………………………………… 13
Screen Setup....................................…………………………………………………………. 13
Image Setup..............................………………………………………………………………. 14
New Video Source……………………………………………………………………………… 14
Relay Setup......................................…………………………………………………………. 14
Lamp Hours......................................…………………………………………………………. 15
Physical Mounting Instructions……………………………………………………………………….. 16
Pre Installation Planning………………………………………………………………………………… 16
Throw Distance Calculation……………………………………………………………………………. 17
Screen Offset……………………………………………………………………………………………… 17
Ceiling Mount Preparation……………………………………………………………………………… 18
Ceiling Mount Installation & Projector Mounting…………………………………………………... 18
Physical Dimensions……………………………………………………………………………………. 20
TransVision™ RS-232 Control..........................…………………………….……………………….. 21
Specifications ..........................................…………………………………………………………….. 22
Warranty ................................................………………………………………………………………. 23

- 3 of 23 -
Safety Instructions
WARNING
HAZARDOUS VOLTAGE
DO NOT OPEN
ATTENTION
COURANT ELECTRIQUE
NE PAS OUYRIR
CAN SHOCK, BURN OR CAUSE SEVERE INJURY OR DEATH. DO NOT
REMOVE THE TOP COVER. REFER SERVICING TO QUALIFIED PERSONNEL.
!.
1. Read and apply all of the safety and operating instructions provided with your video equipment.
2. Keep all safety and operating instruction for future reference.
3. Unplug this video equipment from the wall outlet before cleaning. Never use liquid or aerosol
cleaners. Use only a damp cloth for cleaning.
4. Do not use any attachments or accessories not recommended by the manufacturer as they may
cause hazards.
5. Do not use this video equipment near water. Avoid placing it near a bathtub, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool.
6. Do not place this video equipment on an unstable cart, stand, or table. The video equipment
may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use
only with a cart or stand recommended by the manufacturer. Wall or shelf mounting should
follow the manufacturer's instructions, and should use a mounting kit approved by the
manufacturer.
6A. Move any appliance and cart combination with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and a cart to overturn.
7. Side openings in the cabinet are provided for ventilation, and to insure reliable operation of the
video equipment and protect it from overheating. These openings must not be blocked or
covered. Never place the video equipment on a bed, sofa, rug, or other similar surface that may
block ventilation openings. Never place this product near or over a radiator or heat register. Do
not place this product in a built-in installation such as a bookcase or rack unless proper
ventilation is provided.
8. Operate only from the type of power source indicated on the marking label. If you are not sure of
the type of power supply to your home, consult your appliance dealer or local power company.
9. This unit is equipped with a three conductor polarized alternating-current line plug. This plug will
fit into the power outlet only one way. This is a safety feature. If you are unable to insert the
plug fully into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the polarized plug.
10. Route power-supply cords so that they will not be walked on or pinched by items placed on or
against them. Pay particular attention to cords at plugs, convenience receptacles, and the points
where they exit the products.
11. Protect your video equipment from lightning during a storm or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the
unit due to lightning and power-line surges.
12. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
13. Never push objects of any kind into this video equipment through cabinet slots as they may touch
dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the video equipment.
14. Do not attempt to service this unit yourself as opening or removing cover may expose you to
dangerous voltages or other hazards. Refer all servicing to qualified service personnel.
15. Unplug this video equipment from the wall outlet, and refer servicing to qualified service
personnel under the following conditions:

- 4 of 23 -
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the video equipment.
c. If the video equipment has been exposed to rain or water.
d. If the video equipment does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as improper
adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the video equipment to normal operation.
e If the video equipment has been dropped or the cabinet has been damaged.
f. When the video equipment exhibits a distinct change in performance.
16. When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
17. Upon completion of any service or repairs to this video equipment, ask the service technician to
perform routine safety checks to determine that the system is in safe operating condition.
18. Do not place anything on the video equipment. heavy objects placed on any part of this system
will cause damage.
19. WARNING: To prevent fire or shock hazard, do not expose this appliance to rain or
moisture.
To prevent electric shock do not use this (polarized) plug with an extension
cord, receptacle or other outlet unless the blades can be fully inserted to
prevent blade exposure.
NOTE 1: This equipment is designed to operate in the USA, Canada and other countries where the
broadcasting system and AC house current is exactly the same as in the USA and Canada.
IMPORTANT INFORMATION FOR THE USER
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. The limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communication. However, there is no guarantee that
harmful interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or and experienced radio/TV technician for help.

- 5 of 23 -
Introduction
TransVision™ is a high quality video projection system comprised of two complementary components,
a DLP™ Projector and Controller.
The Controller unit provides source switching for nine different video inputs, including three component,
two composite, two S-video and two RGB H & V Sync inputs and should be installed near its video
component sources.
The DLP™ Projector may be mounted on either floor or ceiling, and may be configured for front or rear
projection.
Signal connections between the Controller unit and the DLP™ projector is made by industry standard
five 75 ohm coaxial cables with BNC connectors for RED, GREEN, BLUE, SYNC AND CONTROL
signals. The CONTROL cable is used to transmit bi-directional control signals between the DLP™
projector and the Controller unit. The CONTROL cable must be connected in order the system to
function properly.
Two composite video inputs (V1, V2) and two S-Video inputs (S1, S2) are provided for NTSC (480i) or
PAL (580i) video sources, such as off-air tuners, satellite systems, cable boxes, VCR and DVD players.
S-Video inputs are highly recommended for use with DVD players and satellite systems.
Three component video inputs (Y,Cr, Cb) are provided for regular DVD players (480i, 580i), progressive
DVD players (480p, 580p) and HD (480p, 540p, 720p, 1080i) sources.
Two RGB inputs are provided for HD (480p, 580p, 720p, 1080i ) sources and computer graphics with
VGA, SVGA, and XGA resolution.
An infrared wireless remote control with on-screen graphics selects the input source and adjusts all of
the operating controls. The system may also be controlled from the front panel or from a RS-232 serial
port.
Both units, the projector and the controller, have IR sensors, allowing the system to be controlled from
either unit.
Video and Image settings for each individual video input may be adjusted and stored separately in the
system's memory. These settings are restored for each input when selected.
The TransVision™ determines the video signal type by measuring horizontal and vertical scanning
frequencies. If the video signal matches a predefined video source, the TransVision™ selects video
and image settings from the system’s memory. The predefined video sources include: 480i, 480p, 580i,
580p, 1080i, 540p, and 720p.
In addition to predefined video sources, the TransVision™ allows the user to create up to three new
video source memory locations per video input.
For more details on how to create memory location for new video sources refer to “Image Setup menu”.
Two 12 V screen trigger outputs are also provided to trigger a relay in an electric screen, projector lift,
or other relay activated device.

- 6 of 23 -
Programming SL-8000 Remote Control to Operate the TransVision™
The TransVision™ is shipped with a factory pre-programmed remote control.
qTo program the SL-8000 for TransVision™:
1. Press the TV and the MUTE buttons simultaneously. SET will appear on the LCD.
2. Enter the TransVision™’s brand code: 177.
3. Press TV to complete the programming.
To operate other audio and video devices refer to the “SL-8000 Operating Manual.”
Installation of the Controller
115 VAC 60 Hz
65 WATTS MAX.
22
/
RED GREEN BLUE
+12 VDC
100 mA
TransVision™Controller Rear Panel
123
11
1
1
V1
V2
Y1
Y2
VIDEO INPUTS
4
RGBS 2
INPUT
2
11
1
1
Cr1
Cr2
Cb1
Cb2
57
6
RS232
CONTROL """"""""
S1 S2
/
RY1 RY2 22SYNC CONTROL
OUTPUTS 11
1
1
Y3
Y3
Cr3
Cb3
RGBS 1
INPUT """"
"""""
"""""
"""""
"""""
"""""
"""""
"""""
8
1. Switched +12VDC Outputs, RY1, RY2 2.5mm DC Plug
2. Red, Green, Blue, Sync and Control Outputs BNC
3. RGBS Computer Inputs 15 pin HD Socket
4. RS-232 Computer Input 9 pin D Plug
5. S-Video Inputs ( S1, S2 ) 4 pin Mini-Din
6. Composite Video Inputs ( V1, V2 ) RCA Type
7. Component Video Inputs (Y1, Cr1, Cb1) RCA Type
(Y2, Cr2, Cb2)
(Y3, Cr3, Cb3)
8. AC Power Receptacle .
1. SWITCHED +12VDC OUTPUTS
The TransVision™ has two switched +12 VDC outlets labeled as RY1 and RY2. These outlets may be
used to trigger a relay in an electric screen, projector lift or other relay activated device. See “Relay
Setup” menu for more details.
2. RED, GREEN, BLUE, SYNC & CONTROL OUTPUTS
The output video signal from the Controller to the DLP™projector is made by five 75 Ohm coaxial
cables with BNC connectors for RED, GREEN, BLUE, SYNC and CONTROL outputs. The CONTROL
cable is used to transmit bi-directional control signals between the projector and the Controller unit. The
CONTROL cable must be connected in order for the system to function properly.
qTo test the connection:
1. Press INFO on the remote.
The screen will display either “Controller connected” or “Controller not connected.”
3. RGBS INPUTS

- 7 of 23 -
The RGBS1 and RGBS2 inputs are provided for HD (480p, 580p, 720p, 1080i ) sources and computer
graphics with VGA, SVGA, and XGA resolution. For computer graphics with VGA, SVGA, or XGA, it is
recommended to set the computer to 60 Hz vertical frequency.
For these inputs, the system provides source switching, converts H & V Sync to composite Sync,
provides control of contrast and brightness, and amplifies RGB video signals to allow the use of longer
cable lengths.
The following are the pin assignments for the 15 PIN "D" connector:
1. Red
2. Green
3. Blue
13. Horizontal Sync
14. Vertical Sync
6-9. Ground
4. RS-232 COMPUTER INPUT
The RS-232C serial interface is provided for external control of the TransVision™from a central
controller, such as a Home Theater control computer, Smart Home automation system, etc.
For DB9 connector pin-out and RS232 command list, please refer to “TransVision™ RS232 Control”
section.
5. S-VIDEO INPUTS (S1, S2)
The S1 and S2 inputs are provided for NTSC (480i) or PAL (580i) video sources, such as off-air tuners,
satellite systems, cable boxes, SVHS VCR and DVD players. S-Video inputs, instead of composite
video inputs, are recommended for use with DVD players and satellite systems.
For these inputs, the system provides source switching, contrast, brightness, color, tint and sharpness
controls, and amplifies S-video signals to allow the use of longer cable lengths.
6. COMPOSITE VIDEO INPUTS (V1, V2)
The V1 and V2 inputs are provided for NTSC (480i) or PAL (580i) video sources, such as off-air tuners,
satellite systems, cable boxes, VCR and DVD players.
For these inputs, the system provides source switching, contrast, brightness, color, tint and sharpness
controls, and amplifies video signals to allow the use of longer cable lengths.
7. COMPONENT VIDEO INPUTS (Y-Cr-Cb)
Three component video Y, Cr, Cb inputs are provided for interlaced component video signals from
regular DVD players (480i, 580i), progressive component video signals from progressive DVD players
(480p, 580p), and progressive or interlaced HD signals (480p, 540p, 720p, 1080i) from HD sources.
The TransVision™ determines which type of component video signal is applied to its input and
processes it accordingly.
For these inputs, the system provides source switching, contrast, brightness and color controls, and
amplifies video signals to allow the use of longer cable lengths.
8. AC POWER RECEPTACLE
The AC power receptacle should be connected to a non-switched 120 VAC outlet using the power cord
provided with the TransVision™system.

- 8 of 23 -
Installation of the Projector
POWER
100-250 VAC
IR
SYNC
RED GREEN
BLUE
CONTROL
220 Watt
2
4
1
3
1. The AC power receptacle should be connected to a non-switched 100-250VAC outlet using the
power cord provided with the TransVision™ system.
2. The IR Sensor points toward the screen so that IR commands sent by the remote control are
received by the system. This sensor should not be covered to insure proper operation.
3. The RED, GREEN, BLUE, SYNC and CONTROL inputs should be connected to the matching
connectors on the TransVision’s Controller using high quality coaxial cables with BNC connectors.
Note that ALL FIVE connections must be made for proper operation regardless of the type of input
video sources used.
4. The POWER LED is a multi-purpose indicator:
•When the LED is dark the AC power to the unit is turned off.
•When the LED is flashing on and off, power is connected and the unit is in the standby
mode.
•When the LED is on the unit is powered on.
•When the LED is flashing fast, this indicates that the lamp is hot and the unit can not be
turned on. You need to wait approximately 1min to turn the unit on.

- 9 of 23 -
Quick Reference Remote Control Operation
CENTER SUR
GUIDE MENU
POWER
AUD CD TAPE AUX
SAT TV VCR CBL
TV
VOL CH
MUTE T/V
PAUSE
R
E
W
F
/
F
STOP
EXIT PRE.
CH
DELAY -- DELAY +
1 2 3
4 5 6
7 8 9
FAV
SLEEP
INFO
PRO.L
NEXT
3.CH
ALT
TEST
+10 0 ENTER
----------pip------- SHIFT
TUNER CD TAPE1 TAPE2 PHONO
VCR1 VCR2/SAT LDP AUX TV
M1 M2 M3 M4
LIGHT
HOME THEATER MASTER
SL-8000
SEL
PLAY
`
\
z
a
]
The remote control provided with the TransVision™is
a universal remote control capable of controlling eight
different devices.
qSelect TV device to control the TransVision™.
qPress TV to turn the TransVision™ ON.
qPress POWER to turn the TransVision™ ON or OFF.
qPress MENU to display the Main menu, or to
return to the previous menu.
qUse the numbered buttons for direct switching
of inputs.
To select a specific input, press a numbered button.
For Press
Video inputs 1& 2
S-Video inputs 3& 4
Component inputs 5, 6, & 7
RGB inputs 8 & 9
qPress up
\
or down
]
to sequences through the
on-screen menu options.
qPress left
`
or right
a
to adjust values or to
move to a sub-menu.
qPress SEL to move to a sub-menu.
qPress EXIT to clear the on-screen menus.
qPress ENTER to perform a selected function.
qPress INFO to display the system status.
qPress ALT followed by numbered buttons 1-3 to
select corresponding aspect ratio.
For Press
4:3 Std 1
Anamorphic 2
LetterBox 3
qPress FAV to perform automatic aspect ratio
selection.
The brand code for TransVision™ is “177.”

- 10 of 23 -
THE FRONT PANEL CONTROLS
POWER MENU FUNCTION VALUE
TransVision
a\`]
DWIN
The TransVision™’s front panel controls include:
qA POWER button to turn the system On or Off.
qA MENU button to display the Main menu, or to return to the previous menu.
qUp \ and down ]FUNCTION buttons to sequences through the on-screen menu options.
qLeft `and right aVALUE buttons to adjust values or to move to a sub-menu.
qAn indicator light which is lit when the unit is turned on and blinks when a valid IR command is
received. USING THE CONTROL MENUS
Main Menu
The Main menu offers a choice of input selection, aspect ratio
selection, video controls and set-up functions.
qPress MENU to display the Main menu.
qScroll up \or ]down the list to highlight desired option.
qPress left ` or right ato move to a sub-menu.
qPress EXIT on the remote to clear the screen immediately.
The "Time Out" feature will automatically clear the screen
unless another button is pressed.
DWIN® T ransVision™
Input
Setup
Video
Video 1
Aspect Ratio 4:3 STD

- 11 of 23 -
Input Option
qFrom the Main menu scroll up \ or down ]to highlight the “Input”
option.
qUse left `or right abuttons to sequentially select the input sources.
qOr use the numbered buttons 1 through 9 on the remote control for
direct switching of inputs.
For composite video inputs, press 1 and 2; for S-Video inputs, press 3
and 4; for component video inputs, press 5, 6 and 7; and for RGB
inputs, press 8 and 9.
1. Video 1
2. Video 2
3. S-Video 1
4. S-Video 2
5. Component 1
6. Component 2
7. Component 3
8. RGB 1
9. RGB 2
Aspect Ratio Option
qFrom the Main menu scroll up _ or down _to highlight the “Aspect
Ratio” option. This enables to select the aspect ratio.
qUse left _or right _buttons to sequentially select the aspect ratio.
qOr use the numbered buttons 1 through 3 on the remote control for
direct selection.
Press ALT 1 for 4:3 Std; press ALT 2 for anamorphic;
press ALT 3 for letterbox.
DWIN® TRANSVISION™
Input
Setup
Video
Video 1
Aspect Ratio Letterbox
1. 4 x 3 STD
2. Anamorphic
3. Letterbox
Once an aspect ratio is selected for a specific input, it will be entered into the system memory so that
the next time that input is selected, the same aspect ratio will appear.
Aspect ratio selection is only available for 480i, 480i, 480p or 580p signals. For 540p, 720p and 1080i
signals, the system will automatically select the 16:9 aspect ratio.
To automatically select the aspect ratio that best matches the input signal, press the FAV button on the
remote. The unit will then analyze the signal and adjust the aspect ratio accordingly.
Video Control Menu
qFrom the Main menu scroll up _ or down _to highlight the “Video” option.
qUse left _or right _buttons to advance to the “Video Control” menu.
Brightness
Color
Tint
Sharpness
Contrast
50
50
50
50
2
Contrast 50
DWIN® TRANSVISION™
Input
Setup
Video
Video 1
Aspect Ratio 4:3 STD
Video Controls

- 12 of 23 -
qUse the up _ or down _buttons to select the desired video control option.
qUse left _or right _buttons to adjust video settings.
Once you press the left _or right _buttons this menu will be replaced with a single line display at the
bottom of the screen. This allows you to see the picture while adjusting the control settings.
qTo restore the full menu, press MENU.
Picture setting changes made with the Video menu are saved in memory for each of the nine video
inputs. Many video sources are different enough to warrant this fine-tuning and these settings will be
recalled each time video input is switched.
Setup Menu
qFrom the Main menu scroll up \ or down ]to highlight the
“Setup” option.
qUse left `or right abuttons to advance to the “Setup
Options” menu.
Setup Options
Menu Timeout 30 sec
Rename Inputs ¡
Rename Ratios ¡
Screen Setup ¡
Image Setup ¡
Relay Setup ¡
Lamp Hours ¡
Menu Timeout
This feature selects the length of time before the on-screen menus disappear from the screen.
qUse left `or right abuttons to select “15”,”30”,”45” or ”60” seconds.
Rename Inputs
This feature is for changing Input names which appear
on the Main menu. A Default name is provided for each
input such as Video 1.
qScroll up \or down ]the Default list to highlight a
desired input.
qScroll right acursor key to the first character in the
New Names listing.
qWhen the first character is highlighted (as shown), use
the up \or down ]cursors to scroll through the alpha
numeric options.
Default New Names
Video 1 Video 1
Scrolling up \starts with the letter "A" and continues to the end of the alphabet followed by numbers
and punctuation marks. Scrolling down ]repeats the process in exactly the opposite order.
qChoose a character for the first space
qThen scroll right a again and select the next character.
Each name is comprised of eleven letters, numbers or spaces.
qWhen you have completed renaming the first input, scroll left `to exit the New Names column.
qScroll up \or down ]the Default list to repeat the process for all of the inputs you wish to relabel.

- 13 of 23 -
Rename Ratios
The "Aspect Ratio" refers to the format of played video
signal. For example, a DVD player which is connected to
the Y/Cr/Cb input may be used to playback either
standard 4:3 aspect ratio format or letterbox format. This
menu permits to rename the aspect ratios. A Default
name is provided for each aspect ratio such as 4:3 STD,
Letterbox or Anamorphic.
qTo enter a different name, use the cursor to highlight
Rename Aspect Ratios and follow the same
instructions as in the Rename Inputs menu.
Default New Names
4 x 3 STD 4 x 3 STD
Screen Setup
The Screen Setup menu is used to correctly position the
projected image onto the screen. A white field pattern is
generated upon entering the menu and is used to select
the desired screen aspect ratio, mounting position, and,
vertical position of the prospective projected image for the
16:9 or 15:9 screen aspect ratio.
To Select the Aspect Ratio of Your Screen:
qSelect the “Screen” option in the “Screen Options” menu.
qUse the left `or right abuttons to select either 4:3, 16:9, 16:9A, or 15:9 aspect ratio.
16:9A aspect ration should be selected when an optional anamorphic lens is used with the projector.
The mounting option allows you to choose from “Front Floor,” “Front Ceiling,” “Rear Floor,” or
“Rear Ceiling” configurations.
To Set the Mounting Position of Your Projector:
qSelect the “Mounting” option in the “Screen Options” menu.
qUse the left `or right abuttons to select the desired position.
For screens with a 16:9 or 15:9 aspect ratio, the vertical position can be adjusted.
To adjust the vertical position:
qSelect the “V. Position” option in the “Screen Options” menu.
qUse the left `or right abuttons to position the white field pattern with the screen.
Screen Options
Screen ¿16:9 ¡
Mounting ¿Front Ceiling¡
V. Position ¿60 ¡

- 14 of 23 -
Image Setup
The Image Setup menu allows you to position and adjust the
video image size. Video image parameters vary from different
video sources and must be adjusted to properly fit the screen.
To Adjust the Video Image Size and Position:
qSelect either the “H-Position,” “H-size,” “V-Position,” or
“V-size” option in the “Image Options” menu.
qUse the left `or right abuttons to set the desired image size
or position.
The “Auto Setup” option operates for RGB inputs only. The “Auto Setup” option measures the video
image boundaries and automatically positions and adjusts the projected image size to properly fit the
screen.
New Video Source
The TransVision™ determines the video signal type by measuring
horizontal and vertical scanning frequencies. If the video signal
matches a predefined video source, the TransVision™ selects
video image settings from the system’s memory.
The predefined video sources include: 480i, 480p, 580i, 580p,
1080i, 540p, and 720p.
In addition to predefined video sources, the TransVision allows the
user to create up to three new video source memory locations per
video input.
When a new video source is applied the TransVision™ displays
“New Video Source” message. To create a new source memory,
go to the Image Setup menu.
qUse left `or right abuttons, to select “Yes.”
qPress ENTER.
Relay Setup
The Relay Setup allows you to assign the TransVision™’s RY1 and RY2 screen trigger outputs to
particular aspect ratio for screen masking.
OFF - Relay is off.
Power - Relay is on when the unit is on.
4:3 - Relay is on when 4:3 Aspect Ratio is selected.
16:9 - Relay is on when Anamorphic or LetterBox Aspect Ratios are selected.
Relay 1 OFF Power 4:3 16:9
Relay 2 OFF Power 4:3 16:9
Image Options
Auto Setup ¡
H-Position 218
H-Size 1286
V-Position 22
V-Size 598
New Video Source
Highlight Yes
and press “ENTER”
to save
No Yes

- 15 of 23 -
Lamp Hours
The Lamp Hours must be reset to 0 when a bulb is replaced.
To Reset the Lamp Hours:
qScroll down ]to highlight the “Reset” option.
qUse left `or right abuttons to advance to the “Reset Lamp Hours” menu.
qUse left `or right abuttons, to select “Yes.”
qPress ENTER.
Lamp Hours
O Hours
Reset ¡
Reset Lamp Hours
Highlight Yes
and press “ENTER”
No Yes

- 16 of 23 -
Physical Mounting Instructions
Physical and electrical installation of the TransVision™must be performed only by a trained
professional who is knowledgeable about both the specifics of the TransVision™and the requirements
of the local building and electrical codes in your state.
Physical installation of the TransVision™may be divided into three steps:
1. Pre-installation planning, which includes plotting the projector-to-screen distance. This requires
knowledge of the screen size and placement. From this step you will determine where the projector
is located.
2. Location of the installation position and preparation, including drilling holes and assembling the
mounting hardware.
3. Installation of the ceiling mount bracket and placing the projector in the mount.
Once the physical installation is complete, the unit should be properly adjusted for focus using the lens,
for positioning using the physical adjustments made possible by the mounting hardware and for size
and centering using the electronic adjustments in the menu control system.
PRE-INSTALLATION PLANNING
Before starting the installation you will need to calculate the projector to screen distance and the ceiling
to picture-start offset. The throw distance and the precise center of the screen are then used to
determine the exact location for the physical installation of the projector.
Throw Distance O
H
W
Screen
Off Set
Screen Width

- 17 of 23 -
Throw Distance Calculation
The TransVision’s™zoom lens allows for a wide range of throw distance options – the distance from
the projector to the screen. For maximum flexibility in adjustment we recommend that, where possible,
the projector be installed in the middle range of the possible distances. However, the unit may be
installed at any point within the allowable range.
qTo obtain the minimum throw distance, multiply the screen width by 1.4.
qTo obtain the maximum throw distance, multiply the screen width by 2.2.
Screen Offset
The screen offset is the distance between the top of the picture area of the screen and the ceiling. This
distance is important and it should be calculated before the screen is installed to ensure proper
positioning of the projector in relation to the screen. Incorrect screen offset may cause image keystone
distortion and cannot be compensated either with the mounting system or electronically.
Screen offset will vary according to the aspect ratio of the screen and the screen width.
For screens with a 4:3 aspect ratio the offset is within a range of approximately six to eight inches.
For screens with a 16:9 or 15:9 aspect ratio the minimum offset is six to eight inches, and may be
increased using the “V.Position” setting option in the Screen Setup menu. The maximum screen offset
for wide aspect ratio screens may be calculated using the following formulas:
For 16:9 screens, multiply the screen width by 0.19 + 6”
For 15:9 screens, multiply the screen width by 0.15 + 6”
Note that the mounting system enables you to make small adjustments to the vertical tilt without
introducing visible keystone distortion.
For floor-mounted installations the picture offset is the distance between the mounting surface of the
projector and the bottom of the picture. In order to deliver pictures that are free of keystone distortion,
be certain to calculate the offset distance before ordering screens and/or cabinetry. Although some
adjustment range is available in floor mounted systems by using the adjustable feet, it is always better
to use the least amount of mechanical adjustment necessary.

- 18 of 23 -
Ceiling Mount Preparation
Once the throw distance has been calculated and the screen installed, the next step in the installation is
to locate the precise mounting position of the projector.
IMPORTANT NOTE: Before proceeding further with the installation, make certain that video
signal/control wiring and AC power have been run to the projector location. Keep in mind that the
connections to the projector are at the front of the unit, so you should place them slightly to the front
and right or left of the “A” point established above.
Also note: that the ceiling must be capable of safely supporting the weight of the projector and mount,
which is in excess of 25 pounds.
CEILING MOUNT INSTALLATION AND PROJECTOR MOUNTING
The ceiling mount kit consist of thee parts. Before
beginning the installation process, first identify
each of the three parts of the mounting system as
shown in the diagrams below.
qMount the part “A” to the ceiling, making
certain that the “FRONT” marking facing the
screen.
qPlace Part B inside Part A and then secure the
two pieces together using the four hex head
screws provided, making certain that the
“FRONT” marking facing the screen.
qPlace two center screws on both, left and right
sides of the part “B” and insert them only half
way.
qTurn the projector upside down and remove
the four feet attached to the projector.
qPlace Part C mounting bracket over the bottom
of the projector, with the “FRONT” marking
facing toward the lens.
qReplace the projector feet through the holes in
the Part C mounting bracket and hand tighten
them until they are secure against the plate
and so that there is no slippage between the
mounting plate and the projector.
qRaise the Part C/Projector assembly and hang
from part ”B” by sliding two center side screws
on part “B” into the “L” shaped groove at the
outer edges of the Part “C” mounting bracket.
Secure the two assemblies together using the
HEX screws on the left and right sides of the
projector.
The projector is now suspended from the ceiling
mount bracket.
Connect the AC Power Cord to the projector and
connect it to an unswitched AC outlet. Connect the
projector to the TransVision Controller using the
five-coax connections previously provided.
Ceiling Mount Kit
Ceiling bracket A
Ceiling bracket B

- 19 of 23 -
When the projector is floor mounted, the use of the mounting hardware is not required. However, you
will need to calculate the throw distance and screen offset as shown in the previous section.
For floor mount installations remember to
calculate the offset from the bottom of the picture
to the floor. If the projector is mounted inside a
cabinet and NOT placed directly on the floor, the
offset is the distance between the bottom of the
projector’s feet and the bottom of the picture.
When the unit is floor mounted, a 1” rubber tube
must be attached to the bottom of the projector in
order to block hot air circulation inside the unit.
Attach the supplied rubber tube near the “out” vent
on the right side of the projector so that exhaust
air is properly channeled out of the unit and away
from the floor.
When the unit is mounted inside a cabinet, be
certain that an exhaust vent is provided so that the
hot air generated by the projector may be safely
removed from the cabinet.
Air in
Air out
For Floor mount
Before completing the installation, double check all screws, mounting hardware and the projector feet to
make certain that they are securely tightened so that no further movement of the projector/mounting
assembly is possible.
After the physical mounting is complete, horizontal and vertical adjustments are made to center and
align the projected image to the screen. The white field pattern, as described in Screen Set-Up menu
section, is used to make the three dimensional adjustments.
Before these dimensional adjustments can be made, you must:
qTurn system on.
qAdjust the zoom and focus.
qOnce on screen menus can be clearly viewed, go to Screen Set-Up menu.
qSelect the proper screen aspect ratio.
Make the following horizontal and vertical adjustments to align the white field pattern to the screen:
Ceiling bracket C

- 20 of 23 -
qTo move image left to right, loosen all four feet to rotate the projector. Once desired position is
obtained, tighten all four feet.
qTo move image up and down, loosen hex screws on the left and right side of ceiling mount and tilt
projector. Once desired position is obtained, refasten all four hex screws.
qTo align image parallel to the screen, loosen hex screws on the front and rear of the ceiling mount
and level the projector. Once image is aligned, refasten all four hex screws.
PHYSICAL DIMENSIONS
AB
4.5”
4.5”
6”
.25”
15”
11”
2”
5”
15”
This manual suits for next models
1
Table of contents
Other Dwin Projector manuals
