Series 185/285 Smart Positioners
Specifications - Installation and perating Instructions
Bulletin V-185/285
DWYER INSTRUMENTS, INC. Phone: [phone] www.dwyer-inst.com
P. . B X 373 • MICHIGAN CITY, INDIANA 46360, U.S.A. Fax: [phone] e-mail: [email protected]
SPECIFICATI NS
Input Signal: 4 to 20 mA DC.
Input Impedance: 460 Ω max @ 20 mA DC.
Enclosure: Aluminum, SS.
Air Supply: 35 to 116 psi (2.4 to 9 bar).
Air Connection: 1/4˝ NPT.
Gage Connection: 1/8˝ NPT.
Conduit Connection: 1/2˝ NPT.
Linearity: ±0.5% S.
Hysteresis: ±0.5% S.
Sensitivity: ±0.2% S.
Repeatability: ±0.3% S.
Air Consumption: .0004 scfm (.01 LPM) at 20 psig (1.4 bar) supply.
Flow Capacity: 2.1 scfm (60 LPM) at 20 psig (1.4 bar) supply.
Stroke: 185: 0.5 to 6 in (10 to 150 mm); 285: 0 to 90°.
Enclosure Rating: NEMA 4X (IP66).
Temperature: Operating: -22 to 185° (-30 to 85°C).
Weight: 185: 3.3 lb (1.5 kg); 285: 6.4lb (2.9 kg).
Lever: 185: .39 to 1.57 in (10 to 40 mm); 285: NAMUR.
The Series 185 and 285 Smart Positioners control valve movements accurately
using an input signal of 4 to 20 mA from the controller. In addition, a highly efficient
microprocessing operator built into the product performs various functions such as
auto calibration, PID control, alarm and Hart®protocol.
Features
• LCD allows the user to directly check the positioner condition in the field.
• Endures severe vibration.
• Operates normally regardless of changes in supply pressure during operation.
• Simple to use auto calibration.
• Easily equipped on small actuators because of its small size.
• Low air consumption reduces operating cost.
• Can be used in low voltage (8.5 V), leaving no limitation in controller.
• HART®communication available for configurating parameters or monitoring the
valve position.
• Analog feedback signal (4 to 20 mA).
• The adjustment of valve characteristics (linear, quick open, equal percentage)
available.
• Tight shut-close and shut-open can be set in the programming menu.
• PID parameters can easily be adjusted in the field without additional
communicator.
• Split ranges such as 4 to 12 mA, with 12 to 20 mA available.
• The positioner can manually actuate the valve or damper.
• An air filter regulator can be mounted directly to the positioner.
LCD SCREEN
SMART POSITIONER
3-27/32
[97.50]
3-1/64
[76.50]
4-7/64
[104.20]
SUPPLY
1/4 NPT
2-33/64
[64.00]
2-11/32
[59.60]
4-13/32
[111.90]
STAINLESS STEEL
4-31/64
[113.8]
STANDARD
CONDUIT ENTRY
1/2 NPT
8-31/64
[215.70]
DOUBLE
ACTION
SINGLE
ACTION
3-47/64
[95.00]
Series 185
Series 285
HART® is a registered trademark of Hart Communication oundation

Structure
The structure of the 185 is shown below. The Series 285 structure is the same as
the linear model without the feedback lever.
Installation
Note: When the positioner is replaced or installed with the actuator, make sure of
the following:
-All inputs and supply pressure to the valve, actuator and other instruments must
be shut down.
-The control valve must be separated from the system with a bypass valve or other
equipment so that the entire system does not shut down.
-No pressure remains in the actuator.
Tools For Installation
• Hexagonal wrenches
• (+) Screw driver
• (-) Screw driver
• Spanners for hexagon head bolts
Series 185 Installation
Series 185 is used for linear motion valves such as Dwyer Instruments’ globe
valves using a spring return type diaphragm actuator or piston actuator. The Series
185 consists of the following components. Be sure that all the components are
included.
1. Series 185 main body
2. eedback lever and lever spring
3. lange nut (attached on the bottom of main shaft of Series 185 body)
4. our hexagon head bolts M8x1.25P
5. our M8 plate washers
Installing Series 185 with Bracket
It is necessary to make a proper bracket to attach on the actuator yoke.
The most important considerations in the design of the bracket are as follows:
- Series 185 feedback lever should be at 50% of valve stroke.
- eedback level connection bar of actuator clamp should be connected in the
position so that the valve stroke and the numbers carved on feedback lever are
fitted. If the bracket meets the above conditions, Series 185 can be installed very
easily.
2. Assemble Series 185 and bracket with bolts. Use standard bolts in bolt holes on
the backside of the unit.
Installing Series 185 with Bracket
3. After assembling Series 185 and bracket with bolts, attach it using bolt holes of
actuator yoke. Do not tighten completely, there must be some space.
4. Install bar connected with Series 185’s feedback lever on the actuator clamp.
The slot length between Series 185’s feedback lever is .26˝ (6.5 mm), so the
diameter of the connection bar should be less than .25˝ (6.3 mm).
5. Connect the air filter regulator with the actuator temporarily. Set supply pressure
of air filter so that the actuator clamp is positioned at 50% of valve stroke.
LCD SCREEN
SMARTPOSITIONER
0
100
50
LCD SCREEN
SMARTPOSITIONER

6. Insert the connection bar attached on the actuator clamp into the slot of Series
185’s feedback lever. In order to reduce hysteresis, it should appear as shown:
7. Check that the Series 185’s feedback lever is level at 50% of valve stroke. If not,
move bracket or feedback link until it is level. Product linearity becomes work if
Series 185 is installed without being level at 50% of valve stroke.
8. Check valve stroke. The numbers indicating stroke are carved in the Series 185’s
feedback lever. Set the connection bar attached on the actuator clamp to the
number on the feedback lever applicable to valve stroke as shown in the following
picture. To set the connection bar and the number, move the bracket attached on
Series 185 or connection bar from side to side.
NOTE: After installation, operate the valve from 0 to 100% stroke using an air filter
regulator on the actuator. When the stroke is both 0 and 100%, the feedback lever
should not reach to the lever stopper on the backside of the Series 185 unit. If the
feedback lever reaches the lever stopper, move attachment of Series 185 away
from the yoke center.
9. Once the Series 185 is installed according to the above procedures, tighten the
bolts and nuts of the bracket and feedback lever connection bar completely.
Series 285 Installation
Series 285 is designed for rotary motion valves such as Dwyer Instruments’ ball
and butterfly valves using rack and pinion, scotch yoke or complex type actuators
whose stem is rotated 90°. Series 285 positioners consist of the following
components:
Series 285 main body
ork lever and lever spring to attach on actuator
1 bracket
our hex bolts M8x1.25P
our M8 plate washers
Series 285 Installation Example of Fork Lever
605040
90°
50%
LCD SCREEN
SMART POSITIONER
3010 20 40 50 60 70 1501401301201101009080
402010 30 80 90 100 110 120 130 140 150706050
NoTouch!
Stroke 40 mm
Stroke 90 mm

Installing Series 285 with Bracket
Series 285 is supplied with a standard bracket. The bracket consists of two parts
and is used with a NAMUR shaft. The bracket is assembled in the factory based on
.79˝ (20 mm) of actuator stem height. If the actuator stem height is higher, such as
1.18˝ (30 mm), or 1.97˝ (50 mm), reassemble the bracket adjusting to the actuator
stem height. Refer to the table below to check hole positions.
Ex) If H is 30 mm, A-L should be locked in H:30 hole, B-L in H:20, 30, A-R in H:30,
and H:20, 30 with bolts.
1. Typically, actuator stem heights (H) are .79˝, 1.18˝, and 1.97˝ (20, 30, and 50
mm). After checking H, assemble brackets following previous guidelines. The
bracket is set at .79˝ (20 mm) in the factory.
2. Attach bracket to the actuator using hex bolts. The diameter of the bracket bolt
holes are .24˝ (6 mm). Use spring washers or thread lock compound so the bolts
will not be loosened by vibration or impact. The direction of the bracket varies by
operating conditions, but normal direction is depicted in the following picture. That
is, when the piping of actuator and Series 285 is as shown in direction A, the
bracket hole and indicator attached on the bottom of the Series 285 main shaft
should be mounted in the same direction.
3. Set the rotation position of the actuator stem as the initial zero point, which is 0%
stroke. or a spring return type actuator, the actuator stem is always rotated to the
zero point without supply pressure, making it easy to check the zero point. If the
actuator is double-acting, check whether the rotation direction of the actuator is
clockwise or counter-clockwise, or the rotation direction of the actuator is using
supply pressure.
4. Set the actuator stem as the initial zero point and install a fork lever as showing
in the following picture. Confirm the position of initial zero point when actuator stem
is turned clockwise and counter-clockwise. Installation angle of fork lever should be
about 45 degrees based on the linear shaft. But the angle is not related to NAMUR
shaft.
5.Once the fork lever position is set, lock the check nuts on the bottom of the fork
lever by turning clockwise. Set the upper height of the fork lever to .24˝ to .43˝ (6
to 11 mm) lower than the upper height of the bracket.
6. Attach Series 285 unit to the bracket. ix the clamping pin on the main shaft
center of the Series 285 into the hole of the fork lever. Insert the connection bar
attached on the main shaft lever into the fork lever slot to be locked by the fork lever
spring. This is to fit the main shaft of the Series 285 to the center of the actuator
stem. If they are not fitted correctly, too much force on the main shaft will greatly
reduce product durability.
7. Attach Series 285 base and the bracket with hex bolts and plate washers. It is
best to lock the bracket and Series 285 together by inserting four bolts after
checking the position.
PIPING C NNECTI N
Conditions of Supply Pressure
1. Dry air with a dew point that is at least 50° (10°C) lower than that of the ambient
temperature.
2. ree from solid particles. Result of being passed through 5 micron or finer filter.
3. Does not contain oil or lubricating oil.
4. Comply with ANSI/ISA-57.3 1975(R1982) or ISA S7.3-1975(R1981).
5. Not used beyond the range of 20 to 100 psi (140 to 700 kPa).
6. Set supply pressure of air filter regulator to 10% higher than operating pressure
of actuator.
Conditions of Pipe
Remove foreign objects from inside of pipe.
Do not use squeezed or broken pipe.
To maintain flow rate of Series 285, use a pipe with inner diameter of greater than
.24˝ (6mm) (outer diameter .39˝ (10 mm)).
20
450
6~11mm
Actuator Stem (H)
Actuator
Direction A
Attachment Direction of Bracket and Actuator
Counter-Clockwise
Clockwise
Bracket
Fork Lever
Actuator
Fitting the Pin on the Series 285 Main Shaft Into Fork Lever Hole
Actuator Stem
Height (H)
20 mm
30 mm
50 mm
B-L
H: 20, 30
H: 20, 30
H: 50
A-L
H: 20
H: 30
H: 50
A-R
H: 20
H: 30
H: 50
B-R
H: 20, 30
H: 20, 30
H: 50
Markings of Bolt Holes
450
1. To prevent ingress of moisture, oil and dust, give careful
consideration to the choice of supply pressure compressor
and piping.
2. It is recommended to attach filter or air filter regulator in front of the supply port
of the Series 285 unit.
N TICE

Piping Connection With Actuator
Series 185 and Series 285 can operate either single or double acting actuators.
Single Acting Actuator
To operate a single acting actuator, connect OUT1 port to actuator supply pressure
port. Close off the OUT2 port with the supplied 1/4˝ NPT plug.
Double Acting Actuator
or the Series 185 and 285 double acting types, OUT1 and OUT2 ports are used.
Power Connection
Terminal Connection of Current Input Signal
1. Open cover by loosening the four M4 bolts on positioner cover.
2. Loosen locking bolts of terminal plate.
3. Insert a cable through the cable connector in the positioner.
4. Use a ring type cable terminal so that it does not come out.
5. Insert terminal bolts in terminal holes of cable and lock them with (+) terminal and
(-) terminals on the terminal plate. Tighten terminal bolts with 1.1 lb-ft (15 kfgcm) of
torque.
6. Be sure not to change the polarity of the terminals.
Terminal Connection of Feedback Signal
1. Open cover by loosening the four screws on positioner cover.
2. Loosen locking bolts of terminal plate.
3. Insert a cable through the cable connector in the positioner.
4. Use a ring type cable terminal so that it does not come out.
5. Insert terminal bolts in terminal holes of cable and lock them with (+) terminal and
(-) terminals on the terminal plate. Tighten terminal bolts with 1.1 lb-ft (15 kfgcm) of
torque.
6. Be sure not to change the polarity of the terminals.
Inner Terminal Connection to Ground
1. The ground is necessary for the safety of the positioner and system.
2. The ground terminals are inside the terminal in the center of the terminal plate and
outside terminal beside outer cable entry. Use any ground terminal that is available.
Resistance must be less than 100 Ω.
Ground Terminal Connection
3. or use with inside ground, open cover by loosening the four screws of positioner
cover.
4. In order to maintain the ground connection, use a ring type ground cable terminal
to prevent it from coming out.
Variable rifice
Hunting can occur if the actuator volume is too small. In this case, adjust the variable
orifice using a (-) flathead screwdriver. Hunting is prevented by reducing the flow rate
of supply pressure transmitted to the actuator.
LCD SCREEN
SMART POSITIONER
LCD SCREEN
SMART POSITIONER
Piping Connection Example of Series 185 with Double Acting Actuator
Piping Connection Example of Series 285 with Double Acting Actuator
Terminal Plate of Series 185 and 285
Maximum pen
Minimum pen
1. Before connecting terminal, power must be shut off.
2. Use ring type terminal against oscillation, impact, etc.
3. Series 185 and 285 positioners use 4 to 20 mA DC for power. Minimum supply
current is 3.8 mA for all models. Maximum supply current must not exceed 24 mA.
4. In order to protect the Smart Positioner, the ground terminals should be
grounded.
5. Use twisted cable with conductor sectional area at least 0.0019 in2(1.25 mm2),
and suitable for 600 V as on conductor table of NEC Article 310. Outer diameter
of cable should be .25˝ to .39˝ (6.35 to 10 mm). Use shielded wire against
electromagnetic waves and noise.
6. Do not install the cable near equipment such as a high-capacity transformer or
motor.
CAUTI N

Auto Calibration and Basic perations
Buttons perations
Series 185 and 285 positioners perform various functions using four buttons. The
position of the buttons is shown below:
RUN mode
After connecting the power to the positioner, the following is displayed on the LCD
in 6 seconds.
RUN on the bottom line means that the Smart Positioner adjusts valve stroke based
on an outside signal (4 to 20 mA) and PV refers to the number on the LCD. In RUN
mode, valve stroke is changed according to input signal.
First Auto Calibration
irst auto calibration is usually used when the positioner has not been set, such as
the initial setting with valve at the valve company, or replacement with other product
in the field. In this case, all parameters are set by using AUTO2 calibration.
Notice: When the positioner is installed on the valve in the field after setting, we
recommend using AUTO1 calibration rather than AUTO2 calibration. This is
because the AUTO 2 calibration parameters have been factory set to the optimum
settings.
KP
This is a proportion constant value that is correction by error %. If this value is too
big, there can be hunting, even though it finds position by the input signal. If the
value is too small, accuracy gets worse.
KI
This is an integral constant value adding or subtracting the correction that is
corrected error % on the previous correction signal. If this value is too big, there
can be oscillation. If it is too small, the time to find the exact position increases.
KD
This is a differential constant value adding the previous correction signal with the
changing correction signal by the error % change rate.
RA/DA
Direct acting (DA) or Reverse acting (RA).
Auto Calibration Types
Auto 1 Calibration (AUT 1)
In this mode, all parameters necessary for valve operation are set except KP, KI,
KD and RA/DA. It is used to re-execute calibration by users in the field after being
supplied the positioner unit, whose parameters were set by the valve company.
1. Press and hold <ENTER> for 6 seconds in RUN mode and AUTO CAL
message should appear.
2. Push <ENTER> and AUTO CAL menu is displayed.
3. Push <ENTER> at AUTO1 mode and Auto 1 calibration is started.
4. When Auto 1 calibration is done, ‘COMPLETE’ message will appear on the
LCD. After 4 seconds the procedure returns to RUN mode.
Auto 2 Calibration (AUT 2)
All parameters necessary to operate valve are set. This calibration is used when
the positioner is first installed with valve. Refer back to irst Auto Calibration.
1. Press and hold <ENTER> for 6 seconds in RUN mode and AUTO CAL
message should appear.
2. Push <ENTER> and AUTO CAL menu is displayed.
3. Push <DOWN> at AUTO CAL and select AUTO 2.
4. Push <ENTER> at AUTO2 mode. Auto 2 calibration is started and the next
modes are displayed in order on the LCD. Normally it will take 3 to 5 minutes
for auto calibration in AUTO2 mode. Duration may vary based on actuators
volume.
5. When Auto calibration is done, ‘COMPLETE’ message appears on the LCD.
After 4 seconds the procedure is returned to RUN mode. Zero, Span, PID
parameters and RA/DA are automatically set when Auto 2 calibration is
completed. Below: Entire Modes and Functions
Auto 3 Calibration (AUT 3)
All parameters necessary to operate valve are set except zero and end point. This
function is used to re-execute auto calibration without changing the zero and end
point after adjusting them manually.
1. Press and hold <ENTER> for 6 seconds in RUN mode and AUTO CAL
message should appear.
2. Push <ENTER> and AUTO CAL menu is displayed.
3. Push <DOWN> at AUTO CAL and select AUTO 3.
4. Push <ENTER> and AUTO3 calibration is started.
5. When Auto calibration is done, ‘COMPLETE’ message appears on the LCD.
After 4 seconds the procedure is returned to RUN mode.
Manual Mode
Manual mode is used to raise or lower the valve stem manually. In this mode, valve
stroke is adjusted only by operating buttons, not by the current input signal. This
mode does not affect controlling data registered in the positioner. It only is used to
move the valve stem up and down.
1. Press and hold <ENTER> for 6 seconds in RUN mode until AUTO CAL
message is displayed.
2. Scroll with <DOWN> button until MANUAL mode is displayed.
3. Push <ENTER> to enter MANUAL mode. Two lines appear on the LCD. The
upper line indicates valve stroke by percentage and the lower line indicates
absolute value of inner resistance of the positioner. “MA” means that Manual
mode is in operation.
4. Push <UP> or <DOWN> and valve stem moves up or down. Regardless of
RA/DA, if <UP> is pushed, valve stem moves up (in case of linear valve). If
<DOWN> is pushed, valve stem moves down. To make the valve stem move
fast, push <ENTER> with <UP>, or <DOWN>.
5. Push <ESC> to exit MANUAL mode.
Button
<ENTER>
<ESC>
<UP> & <DOWN>
Functions
Enter to Main Menu and Sub-Menus, Save Adjusted
Parameter Values, etc.
Return to Previous Menu
Move to Next Menu, Change Parameter Values, etc.
Since this makes the valve or actuator move, before auto
calibration, the valve must be separated from the entire
system.
CAUTI N
1
2
3
4
5
6
Run PV
Run SV %
Run SV mA
Run MV
Run Vel
Run Err
Valve Stroke (%)
Input Signal (0 - 100%)
Input Signal (4 - 20 mA)
Motor/Piezo Valve Manipulate Valve (Digit)
Current Valve Stem’s Velocity (Digit)
Difference between SV and PV (%)
Process Value
Set Value
Set Value
Manipulate Value
Velocity
Error
AUTO1
AUTO2
AUTO3
Zero Point
°
°
x
End Point
°
°
x
KP, KI, KD
x
°
°
RA/DA
x
°
°
Increase stem value slowly
Increase stem value quickly
Decrease stem value slowly
Decrease stem value quickly
<UP> only
<UP> + <ENTER>
<DOWN> only
<DOWN> + <ENTER>
<ENTER>
6 seconds
<ENTER> <ENTER>
COMPLETED
<ENTER>
6 seconds
<ENTER> <DOWN>
COMPLETED
<ENTER>

Parameter Mode (PARAM)
Parameter Types
There are four parameter modes: Dead Zone, KP, KI, and KD.
These values are reflected as soon as they are changed, therefore the appropriate
values are found by checking the valve’s motion in real time.
Adjustment of Dead Zone (dEAdZ NE)
This is the range of error % that the positioner is not adjusted. Hunting or oscillation
due to friction between the stem and packing is prevented by this parameter.
1. Press and hold <ENTER> at RUN mode for 6 seconds and AUTO CAL
message appears.
2. Scroll with <DOWN> until PARAM mode is displayed.
3. Push <ENTER> and dEAdZONE mode is displayed.
4. Push <ENTER> again and *EAdZONE message appears.
5. Adjust dEAdZONE value by pushing <UP> or <DOWN>. Adjusted valued is
applied immediately without additional operation. Users can easily check its
adjustment by changing the current input signal to the positioner. Optimum
control value is found by adjusting values during the valve operation.
6. Push <ENTER> to save the value. +EAdZONE message appears on LCD.
7. Push <ESC> to exit dEAdZONE mode.
KP
1. Press and hold <ENTER> at RUN mode for 6 seconds and AUTO CAL
message appears.
2. Scroll with <DOWN> until PARAM mode is displayed.
3. Push <ENTER> and dEAdZONE mode is displayed.
4. Scroll with <DOWN> until KP mode is displayed.
5. Push <ENTER> at KP mode and *KP message appears on LCD.
6. Adjust KP value with <UP> or <DOWN>. Adjusted value is applied immediately
without additional operation. Users can easily check its adjustment by changing
the current input signal to the positioner. Optimum control value is found by
adjusting the values during valve operation.
7. Push <ENTER> to save the value and +KP message appears on LCD.
8. Push <ESC> to exit KP mode.
PT
1. Press and hold <ENTER> at RUN mode for 6 seconds and AUTO CAL
message appears.
2. Scroll with <DOWN> until PARAM mode is displayed.
3. Push <ENTER> and dEAdZONE mode is displayed.
4. Scroll with <DOWN> until PT mode is displayed.
5. Push <ENTER> at PT mode and *PT message appears on LCD.
6. Adjust PT value with <UP> or <DOWN>. Adjusted value is applied immediately
without additional operation. Users can easily check its adjustment by changing
the current input signal to the positioner. Optimum control value is found by
adjusting the values during valve operation.
7. Push <ENTER> to save the value and +PT message appears on LCD.
8. Push <ESC> to exit KP mode.
HAND CAL
When auto calibration is started, Series 185 and 285 positioners set zero points
and end points based on full stroke. HAND CAL allows for user defined zero and
end points.
Hand Calibration Types
PV_ZERO: Edit mode to change the zero point of valve.
PV_END: Edit mode to change the end point of a valve.
TR_ZERO: Edit mode to change the zero point of transmitter.
TR_END: Edit mode to change the end point of transmitter.
Adjustment of valve zero point (1 to 5) and end point (6 to 10).
PV_ZER
1. Press and hold <ENTER> at RUN mode for 6 seconds and AUTO CAL
message appears.
2. Scroll with <DOWN> until HAND CAL mode is displayed.
3. Push <ENTER> and PV_ZERO mode is displayed.
4. Push <ENTER> at PV_ZERO mode and *PZ mode is started. The valve stem
will move automatically to the current zero point. On the LCD, the valve stroke
is displayed as 0%. *PZ indicates the zero point is ready to be set.
5. Adjust valve stem by pushing <UP> or <DOWN>. When valve stem is at the
desired zero point, save it by pushing <ENTER>.
6. Push <ESC> to exit PV_ZERO mode.
PV_END
1. To change valve end point, scroll with <DOWN> at HAND CAL menu and select
PV_END.
2. Push <ENTER> at PV_END mode and *PE mode is displayed. The valve stem
will move automatically to the current end point. On the LCD, the valve stroke
is displayed as 100%. *PE indicates the end point is ready to be set.
3. Adjust valve stem by pushing <UP> or <DOWN>. When the valve stem is at
the desired end point, save it by pushing <ENTER>.
4. Push <ESC> to exit PV_END mode.
<ENTER>
6 seconds
<ENTER>
6 seconds
<ENTER>
<ENTER> <UP>/<DOWN>
then <ENTER>
<ESC>
3 times
COMPLETED
<ENTER> <DOWN>
3 times
<ENTER>
<UP>/<DOWN>
then <ENTER>
<ESC>
3 times
COMPLETED
<ENTER> <DOWN>
7 times
<ENTER>
<UP>/<DOWN>
then <ENTER>
<ESC>
3 times
COMPLETED
<ENTER>
6 seconds
<DOWN>
3 times
<ENTER>
<ENTER> <UP>/<DOWN>
then <ENTER>
<ESC>
<DOWN> <ENTER> <UP>/<DOWN>
then <ENTER>
<ESC>
COMPLETED

Valve Mode
This mode adjusts the various characteristics.
Action Type (ACT)
It can be set to Direct Action (DA) or Reverse Action (RA).
Adjustment of Acting Type (ACT)
1. Press and hold <ENTER> at RUN mode for 6 seconds and AUTO CAL
message appears.
2. Scroll with <DOWN> until VALVE mode is displayed.
3. Push <ENTER> and ACT RA (in case of Reverse Acting) is displayed.
4. Push <ENTER> and *ACT RA is displayed.
5. Adjust to *ACT DA by pushing <UP> or <DOWN> and save it with <ENTER>.
+ACT DA message appears.
6. Push <ESC> to exit ACT RA mode.
Characteristics (CHAR)
Set Characteristics. There are three types of valve characteristics: Linear (LIN),
EQ% (EQ), and Quick Open (QO). The following is the example of the three
characteristic curves.
Adjustment of Characteristics (CHAR)
1. To change linear characteristics, scroll with <DOWN> at VALVE menu and select
CHAR LIN (in case of linear characteristics).
2. Push <ENTER>. *HAR LIN mode is displayed and charactertistics can be set to
LIN, EQ, QO or USR.
3. Adjust characteristics (ex: EQ) by pushing <UP> or <DOWN> and save it with
<ENTER>. + HAR EQ is displayed.
4. Push <ESC> to exit CHAR LIN mode.
User Characteristics (USER SET)
When a specific characteristic is needed but not included in the above
characteristics, the user can make a specific characteristic curve by choosing 16
points voluntarily.
Adjustment of User Characteristics (USER SET)
1. Push <ENTER> at VALVE mode and scroll with <DOWN> to select USER SET.
2. Push <ENTER>. *PO SET mode is displayed. In this mode, users can adjust the
first point of characteristic in 16 points. the number on the LCD is the valve stroke
percentage set to P0.
3. Adjust the valve stroke percentage using <UP> or <DOWN>.
4. Save with <ENTER>. While P0 value is being saved, *P1 SET mode is
displayed.
5. *P1 SET mode is used to adjust the second point characteristic in 16 points.
Adjustment method is the same as P0* SET mode.
6. Continue steps from P2 to P15.
7. After adjusting valve stroke percentage at *P15 SET mode, save with <ENTER>.
8. +SER SET is displayed. All sixteen points of valve stroke percentage are set.
9. Push <ESC> to exit USER SET mode.
100%
Strok
0
420
mA
Quick Open
Linear
EQ%
<ENTER>
6 seconds
<DOWN>
3 times
<ENTER>
<ENTER> <UP>/<DOWN>
then <ENTER>
<ESC>
3 times
COMPLETED
<ENTER>
6 seconds
<DOWN>
3 times
<ENTER>
<UP>/<DOWN>
then <ENTER>
<ENTER> <UP>/<DOWN>
then <ENTER>
<ENTER> <ENTER>
6 seconds

Tight Shut pen (TSHUT P)
This allows the user to fully open valve at input values around 20 mA.
Adjustment of Tight Shut pen (TSHUT P)
1. To adjust Tight Shut Open, scroll with <DOWN> at VALVE menu and select
TSHUT OP.
2. Push <ENTER> and *SHUT OP mode is displayed. In this mode users can set
stroke at the time of Tight Open. Initial setting is done as 100% which means
the TSHUT option is disabled. Adjust the value (ex: 95.0%) by pushing <UP>
or <DOWN> and save with <ENTER>. +SHUT OP is displayed.
3. Push <ESC> to exit TSHUT OP mode.
Tight Shut Close (TSHUT CL)
This allows the user to completely close valve at input values around 4 mA.
Adjustment of Tight Shut Close (TSHUT CL)
1. To adjust Tight Shut Close, scroll with <DOWN> at VALVE menu and select
TSHUT CL.
2. Push <ENTER> and *SHUT CL mode is displayed. In this mode users can set
stroke at the time of Tight Close. Initial setting is done as 0.3%. 0% means
the TSHUT option is disabled. Adjust the value (ex: 0.5%) by pushing <UP>
or <DOWN> and save with <ENTER>. +SHUT CL is displayed.
3. Push <ESC> to exit TSHUT CL mode.
Split Range Control (SPLIT)
This allows the user to control entire stroke with input signals of 4 to 20 mA, 4 to
12 mA or 12 to 20 mA.
Adjustment of Split Range (SPLIT)
1. To change Split Range, scroll with <DOWN> at VALVE menu and select
SPLIT.
2. Push <ENTER>. *SPLIT mode is displayed. The numbers on the LCD are the
range of current signal input to the positioner. 4.20 indicates 4-20 mA, 4.12
indicates 4-12 mA, and 12.20 indicates 12-20 mA setting.
3. Select desired Split Range and save with <ENTER>.
4. Push <ESC> to exit SPLIT mode.
VIEW Mode
This mode provides users with various information about the Series 185 and 285
positioners. In this mode, users can change the valve stroke types displayed on
LCD to % or numbers. Refer to the next table for information and description
displayed on VIEW mode.
1. Press and hold <ENTER> at RUN mode for 6 seconds and AUTO CAL message
appears.
2. Scroll with <DOWN> and select VIEW menu.
3. Push <ENTER> and check information using <UP> or <DOWN>.
4. Push <ESC> to exit VIEW mode.
Information Checked on VIEW Mode
Error and Warning Code
If there are any problems during Series 185 and 285 positioner operation, you can
check the error and warning code at VIEW mode as follows:
Error Code
This code is displayed when the Series 185 and 285 positioner control becomes
impossible. Code C, D applies.
YT-2500L
VERSI N
HART V
PL AddR
bIAS VI
0Y 0d
FULL_ P
FULL_CL
VM N R
Erro
VALUE I
ABS
Description
Positioner model
Main software version
HART Protocol version
Channel address that is used in HART Protocol
bIAS value for motor/piezo valve control. Can be adjusted only by
manufacturer.
Total used time duration. If a unit was used less than 1 minute, the
time does not accumulate.
Time elapsed for valve to fully open.
Time elapsed for valve to fully close.
Display type of valve stroke on LCD (either in percentage or value).
Display error code or warning message < igure XX>.
Current I-Value. Can be adjusted only by manufacturer.
Display absolute resistance value.
Error Code
MT ERR L
MT ERR H
CHK AIR
RNG ERR
C
D
Code Description and Cause
Positioner is improperly installed.
Positioner lever is not parallel to
the ground at 50% point. Lever is
at lower position than actual 50%
point.
Positioner is improperly installed.
Positioner lever is not parallel to
the ground at 50% point. Lever is
at lower position than actual 50%
point.
Valve does not operate when
positioner receives “ ull Open”
signal during auto calibration.
Operating angle is too small due
to improper mounting of
positioner.
Error 10% or above persists more
than 1 minute.
No valve movement.
riction of valve is too large.
Setting pressure of actuator
changes.
I-Value reaches at maximum or
minimum limit point.
riction of valve changes.
Setting pressure of actuator
changes.
Action
Re-install/mount the positioner.
Make sure the feedback lever
does not touch the stopper at both
0 and 100%.
Re-install/mount the positioner.
Make sure the feedback lever
does not touch the stopper at both
0 and 100%.
Check if supply pressure is stable
and appropriate.
Adjust bracket so the positioner
can be mounted closer to actuator.
Perform BAS calibration.
Check setting pressure of actuator
and set the pressure as
recommended.
Perform AUTO calibration.
Check setting pressure of actuator
and set the pressure as
recommended.
<ENTER>
6 seconds
<DOWN>
3 times
<ENTER>
<ENTER>
6 seconds
<DOWN>
3 times
<ENTER>
<ENTER>
6 seconds
<DOWN>
4 times
<ENTER>
<UP>/<DOWN>
then <ENTER>
<ESC>
3 times
<ESC> 3 times
then <ENTER>
<ENTER>
6 seconds
<DOWN>
5 times
<ENTER>
<UP>/<DOWN>
then <ENTER>
<ESC>
3 times
<ESC> 3 times
then <ENTER>
<ENTER>
4 times
<ENTER> <UP>, <DOWN>
confirm the changes,
then <ESC>
<ESC>
COMPLETED

Warning Code
This code is displayed when the positioner control is available but there is a
possibility of malfunction or low accuracy. Code B, , G, H applies.
MAINTENANCE/REPAIR
Upon final installation of the Series 185/285, no routine maintenance is required.
The Series 185/285 is not field serviceable and should be returned if repair is
needed. ield repair should not be attempted and may void warranty.
WARRANTY/RETURN
Refer to “Terms and Conditions of Sales” in our catalog and on our website. Contact
customer service to receive a Return Goods Authorization number before shipping
the product back for repair. Be sure to include a brief description of the problem
plus any additional application notes.
DWYER INSTRUMENTS, INC. Phone: [phone] www.dwyer-inst.com
P. . B X 373 • MICHIGAN CITY, INDIANA 46360, U.S.A. Fax: [phone] e-mail: [email protected]
©Copyright 2014 Dwyer Instruments, Inc. Printed in U.S.A. 7/14 R# RV-443952-00 Rev. 3
Warning Code
B
F
G
H
Code Description and Cause
PV end-PV zero range is below
500. The angle of feedback
lever is too small.
Time elapsed for either full-open
or full-close is less than 1
second.
The size of the actuator is
too small.
Pv zero is below 100.
The angle of feedback lever
is too large.
Pv end is over 4000.
The angle of feedback lever
is too large.
Action
Re-install/mount the positioner.
Make sure the feedback lever
does not touch the stopper at
both 0 and 100%.
After re-installation, perform
AUTO1 calibration.
Use variable orifice.
Replace actuator with larger
capacity.
Re-install/mount the positioner.
After re-installation, perform
AUTO1 calibration.
Re-install/mount the positioner.
After re-installation, perform
AUTO1 calibration.
Used timeUser Set
ENT
: Enter button
Manual Mode
Auto 2
Auto cal
RUN Mode
ENT
(5 sec)
ESC
ESC
Auto 1
ENT
BIAS
Auto 3
ESC
ESC
V_O
ESC
ESC
Hart ver.CharacterK P End point
ViewValveHand calParameter
ESCESC ESC ESCESC
ESC
Start point
Dead Zone
ESC ESC
ENT ENT
ESC
Sof ver.
RA / DA
ENT ENT
BIAS
Tight shut onTR end point
K D
Tight shut oTR start point
K I
ESC ESC ESC
ESC ESCESC
Polling Add
ESC
ESC
ESC ESC ESC
ESC
I value
Split control
ESC
ESC
: Up button
ESC
: Down button
: Esc button
Error code
Full close time
ESC
Full open time
ESC
ESC
View method
ESC
ESC
ESC
ESC
ESC
K I_
K P_
ESC
K D_
Firmware MAP
