Axis T99A10 User manual

AXIST99A10PositioningUnit24VAC/DC
RepaintingInstructions

AXIST99A10PositioningUnit24VAC/DC
Impactonwarrant
Impactonwarrant
ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat
www.axis.com/warranty-implication-when-repainting
Riskswithrepainting
ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training
ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:
ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD
damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.
Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.
Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.
Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems
withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe
parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.
2

AXIST99A10PositioningUnit24VAC/DC
Howtorepainttheproduct
Howtorepainttheproduct
Preparations
•Maskcrucialpartsoftheproducttopreventpaintfromenteringinside.
•Cleantheareastoberepaintedfromgrease,dustandoil,andpretreatthedifferentpartsusingapplicablemethodsbased
onthepartmaterialsandthetypeofpaintappliedatthefactory
Important
Disassemblingtheproductforrepaintingpurposesmeansthatitsingressprotection(IP)ratingcannotbeguaranteed.
Disassemblywillresultinlapseofwarranty.
Masking
Maskthefollowingparts:
•Allvisiblescrewsandscrewholes
•Shaftopeningsinthepanunit
•Openingbetweenthebaseunitandthepanunit
•Labelsandfrontwindow

AXIST99A10PositioningUnit24VAC/DC
Howtorepainttheproduct
Pretreatmentofparts
Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentsshouldbedoneforthenewpaintto
adhereaswellaspossible.Forallvariantsthough,propercleaningtoremoveoil,greaseanddustisstronglyrecommended.
Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetatwww.axis.com
Powdercoatedparts-Usingnesandpaper,removetheoriginalpowdercoatingdowntothebasematerialandcleantheparts
beforepainting,oruseaprimer.
Anodisedandchromatedparts-Useaprimer.
Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.
Plastic-Useaprimer.
Repainting
1.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer,andletthepaintdry.
2.Ifyouwishtogetabettercoverageandclearercolor,applyasecondlayerofspraypaint.
3.Whenthepaintisdry,removethemasking.
4

RepaintingInstructionsVer.M1.8
AXIST99A10PositioningUnit24VAC/DCDate:April2018
©AxisCommunicationsAB,2017-2018PartNo.T1011 1376
