Coaxial Cable

Preparation Tool Kits

DXE-UT-CASE / KIT1 / KIT2

DXE-UT-COMPLETE-KIT-INS-Revision 0b

DXE-UT-CASE –Custom Made Case with High Density Foam

DXE-UT-KIT1 –Basic Coaxial Cable Tool Kit

1 - DXE-UT-CASE Custom Tool Case

1 - CNL-911 Cable Cutter

1 - DXE-UT-8213 Cable Prep Tool

1 - DXE-UT-80P PL-259 Tool

DXE-UT-KIT2 –Complete Coaxial Cable Tool Kit

1 - DXE-UT-CASE Custom Tool Case

1 - CNL-911 Cable Cutter

1 - DXE-UT-8213 Cable Prep Tool

1 - DXE-UT-80P PL-259 Tool

1 - DXE-UT-808X Cable Prep Tool

1 - DXE-UT-80N Type N Tool

1 - DXE-170M Precision Shear Cutter

1- DXE-UT-RB-HD Replacement Blade Set

Using the DXE-UT-8213 & UT-80P

A. Cut the end of the coaxial cable with the CNL-911 Coax Cable

Cutter to get a good flush cut.

B. Place the prepared coaxial cable end into the body of the DXE-UT-8213

labeled "1st CUT". Firmly grip the coaxial cable and the DXE-UT-8213, turn

the DXE-UT-8213 in a clock wise direction while applying steady and

slightly firm pressure. Grip the coaxial cable between your thumb and first

finger, close to the tool.

C. As you turn the tool clockwise, the DXE-UT-8213 will

begin cutting. Keep turning the tool in a clockwise

direction until it will not cut anymore, the tool will eject

the cut parts and stop cutting at the proper length.

D. Turn the DXE-UT-8213 around for the second cut. Insert the coaxial

cable into the tool again.

E. Grip the cable between your thumb and first finger close to

the tool and turn the tool in a clock wise direction. The

DXE-UT-8213 will begin cutting as you turn it. Keep

turning the tool in a clockwise direction until it will not cut

anymore, the tool will eject the cut outer insulation and stop

cutting at the proper length.

F. You may want to trim back some of the braid on the coaxial cable slightly using the DXE-170M precision shear side cutters

prior to installing the DXE-PL259 PL-259 connector.

G Place the PL-259 Collar on the coaxial cable and slide it out of the way.

Gently install the PL-259 on the prepared coaxial cable ensuring the center

conductor strands go into the center conductor of the PL-259.

H. Screw the patent pending DXE-UT-80P Connector Assembly Tool onto

the PL-259. Grip the coaxial cable firmly and turn the DXE-UT-80P

Assembly Tool clockwise until the coaxial cable center conductor is visible

at the end of the PL-295 as shown below.

I. Remove the DXE-UT-80P Connector Assembly Tool and you're ready to solder the PL-259. This combination of DXE tools

allows perfect and easy connector installation every time!

Trimming for 2-Piece N Connector

If you are using the DXE-N1001-S DX Engineering 2-piece N Connectors, you will

need to trim the center conductor to a length of approximately 0.441”. This will allow

the center conductor to seat properly in the gold center pin of the 2-piece N Connector

Using the DXE-UT-808X

A. Cut the end of the coaxial cable with the CNL- 911 Coax Cable Cutter to

get a good flush cut.

B. Install the PL-259 shell and the Reducer on the coaxial cable and slide them out of the

way. Place the prepared coaxial cable end into the body of the DXE-UT-808X

labeled "1st CUT".

C. Firmly grip the coaxial cable and the DXE-UT-808X, turn the DXE-UT-808X in a clock wise

direction while applying steady and slightly firm pressure. Grip the coaxial cable between your

thumb and first finger, close to the tool.

D. As you turn the tool clockwise, the DXE-UT-808X will begin cutting the outer

insulation. Keep turning the tool in a clockwise direction until it will not cut

anymore, the tool will eject the cut outer insulation and stop cutting at the proper

length.

E. Remove the coaxial cable from the DXE-UT-808X. Fold the shield back over the

outer insulation.

F. Turn the DXE-UT-808X around for the second cut. Insert the coaxial cable into the DXE-UT-808X tool.

G. Firmly grip the cable between your thumb and first finger close to the

tool and turn the tool in a clock wise direction while applying steady

and slightly firm pressure. The DXE-UT-808X will begin cutting as

you turn it. Keep turning the tool in a clockwise direction while

applying steady and slightly firm pressure until it will not cut anymore, the tool will eject the cut insulation and stop cutting at

the proper length.

H. Slide the reducer up the coax to the end

of the cut off outer insulation. Fold back

the shield over the reducer as shown.

Using the DXE-170M precision shear

side cutters, trim the shield even with the first thread on the reducer as show.

I. The PL-259 is now ready for installation. Gently screw the PL-259 on the

reducer ensuring the center conductors go into the center conductor of the PL-

259. The assembly is now ready to be soldered. This combination of DXE

tools allows perfect and easy connector installation every time!

----------------------------------------------------------------------------------------------------------------

N Connector Installation Tool

DXE-UT-80N Patent Pending

For the DXE-N1001-S and similar Two-Piece N Connector

First properly prepare the coaxial cable with the DXE-UT-8000 or DXE-UT-8213 Cable Stripping Tool. Place the prepared coaxial

cable end into the body of the N connector (DXE-N1001-S or similar) and make sure all the strands of the center conductor of the cable

are inserted into the center pin. Then, use this simple hand-gripped tool - forget about those pliers that scarred the connector and ripped

off chunks of metal - and thread the N connector body onto the stripped cable end. Tighten the N Connector onto the coaxial cable.

When the coaxial cable is fully seated, remove the tool. Check to see that the coaxial cable is fully seated in the N connector by ensuring

the shield is visible through the larger holes and the center strands are visible in the small hole of the center pin. If all is okay, you're

ready to solder the connections. This tool allows a perfect and easy connector installation every time!

Coaxial cable properly prepped DXE-N1001-S N-Connector into DXE-UT-80N Ready for soldering



Complete and detailed instructions with extra tips and videos

showing the tools being used can be found on the

DX Engineering web site at:

www.dxengineering.com

Technical Support

If you have questions about this product, or if you experience difficulties during the installation, contact DX Engineering at (330) 572-3200. You can

also e-mail us at: [email protected]

For best service, please take a few minutes to review this manual before you call.
