Dymag BOXSTROM User manual

www.dymag.com
DYMAG®BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
FITTING AND CARING FOR YOUR WHEELS
MANUFACTURER’S WARRANTY AND CLAIM PROCEDURE
PRODUCT REGISTRATION AND CERTIFICATE OF OWNERSHIP
TECHNICAL WHEEL FITMENT GUIDE
Congratulations on your purchase!
Your wheels were manufactured using the finest materials and
tested to the highest quality standards in the industry.
PLEASE READ AND FOLLOW THESE INSTALLATION AND
CARE INSTRUCTIONS CAREFULLY
www.dymag.com

DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
2www.dymag.com
CONTENTS
P3 FITTING AND CARING FOR YOUR WHEELS
P6 MANUFACTURER’S WARRANTY AND CLAIM PROCEDURE
P11 PRODUCT REGISTRATION AND CERTIFICATE OF OWNERSHIP
P12 TECHNICAL WHEEL FITMENT GUIDE
FITTING AND CARING FOR YOUR WHEELS
1. INSPECTING YOUR WHEELS BEFORE FITTING TYRES
Before you fit tyres/tires or mount your wheels onto the vehicle you must check
the following:
1.1. Inspect the wheels immediately upon receipt for damage in transit, especially
if there is damage to the packing. Take photographs of any damage to packaging
or wheels
1.2. Check the max. static load, bolt pattern, bore diameter, offset/backspace, brake
caliper clearances and body work clearances are all as ordered. Any error in the
order is the responsibility of the customer or dealer
1.3. It is the company’s policy not to replace or credit wheels that have been fitted with
tyres or mounted on the vehicle
1.4. Check that the tyres to be fitted comply with the vehicle manufacturer’s
recommended rolling diameter for your vehicle, speed rating, static loading and
the wheel size you have chosen
IMPORTANT SAFETY NOTICE
Using tyres that do not conform to the vehicle or tyre manufacturer’s recommendations
may result in serious safety issues related to undersized or oversized fitments and/or may
adversely affect your vehicle’s driving systems such as all-wheel drive, anti-lock braking
systems (ABS), etc.
2. FITTING INSTRUCTIONS
Having inspected your wheels, the wheels should be fitted as follows:
2.1. Before mounting tyres, the tyre bead seat area should be generously lubricated
with tyre fitting paste or liquid. With very low profile tyres the use of a proprietary
bead sealing compound is recommended to assure good initial sealing

DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
4www.dymag.com
2.2. When mounting the tyres the wheels should be clamped externally onto the rim
using rubber protectors on the clamping surface
2.3. Mount the tyres using only wheel hub support tyre fitting machines being
careful to ensure that the tyre bead is pushed into the wheel well, as the
machine rotates to fit the tyre. Machines that clamp the rim may damage
the rim finish
2.4. If tyre pressure monitor systems are either bolted directly into the valve hole or
bonded onto the wheels, use caution to not break the sensor when mounting
the tyres
2.5. Use STICK-ON WEIGHTS ONLY. Clip-on weights can cause damage to the wheels
and their use may void the warranty. To maintain the appearance of your wheels,
weights should be placed inside the wheel barrel not on the outer face of the rim
2.6. Bolt the wheel lug nuts using the vehicle manufacturer’s recommended torque
settings in the vehicle handbook, unless otherwise instructed by Dymag
2.7. After the wheels and tyres have been fitted to the vehicle, take for a short
test drive
2.8. Re- check the torque values of each lug nut/bolt and make sure that they are
torqued to the manufacturer’s recommended specifications
3. USING YOUR ORIGINAL WHEEL AS A SPARE
If you intend to use one of your original equipment wheels as a spare, make sure that you
keep a set of the correct lug nuts/bolts and a properly sized spanner or wrench in the car
at all times. In most cases, Dymag wheels utilise the original equipment lug nuts/bolts;
however, this may not be true in all cases.
4. TAMPERING WITH WHEEL ASSEMBLY
Under no circumstances should the fastening systems between the rim and centrepiece be
tampered with. Do NOT attempt to tighten or loosen the wheel assembly bolts.
WARNING: TAMPERING WITH THE ASSEMBLY BOLTS WILL AUTOMATICALLY VOID THE
WARRANTY.
5. WHEEL CLEANING
In order to keep your wheels looking like new, regular cleaning is highly recommended
particularly in climates where salt or chemicals are used on the roads or likely to come into
contact with your wheels.
Please follow these wheel cleaning guidelines:
5.1. Never use any non-water based solvent chemical based cleaners or harsh cleaning
solutions
5.2. Use only mild soap and water with a soft, non-abrasive brush or cloth rag to clean
the wheels of dirt and debris
5.3. Spray-on, hose off type cleaners are strictly prohibited
5.4. Do not clean the wheels when they are still warm from operation of the vehicle.
Allow them to cool before attempting to hose off with water
5.5. Never use pressure washers for cleaning high performance wheels
5.6. A soft paste protective wax may be applied to your wheels to ease maintenance
and improve wheel appearance on clear-coated or painted wheels
N.B. Wheels that have not been kept clean, or have incorrect wheel cleaner applied,
will not be covered by warranty.

DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
6www.dymag.com
MANUFACTURER’S WARRANTY AND
CLAIM PROCEDURE
6. WARRANTY CONDITIONS
Dymag Group Limited (“Dymag”) provides a Limited Warranty (“Warranty”) on wheels
designed and manufactured in our UK factory, subject to the conditions and limitations:
6.1. The Warranty is given only to the original consumer or purchaser of Dymag Group
Ltd Wheels (Dymag) products. For avoidance of doubt, any claim must be made
by the party invoiced by Dymag, which includes dealers and distributors on behalf
of end users
6.2. Proof of Purchase is required to support all warranty claims – preferably providing
the original invoice
6.3. Dymag warrants that products manufactured and distributed by Dymag will be
free of any defects in materials or workmanship for a period of 1 year from the
date of purchase, except that Dymag warrants that the wheel finish will be able
to withstand non-hazardous weather and climatic conditions, non-hazardous
paved road conditions and typical operating temperatures and parameters for
normal driving for a period of one (1) year from the date of purchase. As
used herein, the “date of purchase” shall be interpreted to mean the date the
original purchaser/consumer first receives the product. Any product that is
properly installed and operated pursuant to the specifications provided by
Dymag and found by Dymag under normal use and service to malfunction during
the warranty period, solely as a result of material defects in materials or
workmanship, will be repaired or replaced by Dymag or an authorized agent of
Dymag, at Dymag’s option. The foregoing states Dymag’s sole and entire
obligation with respect to Warranty repairs and claims
6.4. Repaired and replaced products shall be warranted for the remainder of the
original Warranty period or thirty (30) days, whichever is longer. The Warranty
is granted exclusively to the original purchaser/consumer and is non-transferable.
The Warranty is subject to the terms, conditions, exclusions and disclaimers set
forth herein
7. WARRANTY CONDITIONS
The Warranty only covers products that (A) are properly inspected and installed
(including, but not limited to, using specified lug nuts/bolts or other hardware that may
be supplied by Dymag for such installation) on a vehicle for which the products are
intended, (B) are operated and cared for pursuant to the specifications provided by
Dymag, including but not limited to, the “Dymag Wheel Installation and Long Term Care”
specifications attached hereto, and (C) are found by Dymag to malfunction under normal
use and service. In addition, the tyres that are mounted on the products must have been
purchased and installed new and must be proper for the vehicle. The Warranty coverage
includes replacement parts and reasonable labour expenses.
8. WARRANTY EXCLUSIONS
This warranty does not cover repairs to, damage to, or any failure of, a Dymag product
caused in whole or in part by any of the following:
8.1. Modifications, repairs or alterations to Dymag products that have been performed
by anyone other than a Dymag employee or authorized agent of Dymag
8.2. Failure to properly use or care for the products, the vehicle on which the products
are installed or the tyres which are mounted on the products
8.3. Use of the products off-road or on unpaved roads, or in hazardous conditions
8.4. Use of the products under race conditions on street courses or race tracks,
including track days with road cars
8.5. Improper servicing or configuration of the products, vehicle or tyres (for example,
improper inflation of tyres, loading the vehicle beyond its capacity, misalignment
of tyres and wheels, imbalance of tyres and wheels and/or the use of incorrect
tyres and wheels)
8.6. Any kind of impact, damage or abuse resulting from collision, flat tyres, curbing,
racing, accident, fire, vandalism, road conditions, road hazards, weather,
exposure to road salt or other hazardous chemicals used on roadways, rubbing
due to projection from the wheel well or any so-called acts of god or nature

DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
8www.dymag.com
8.7. The application to the products of any type of weights other than tape-on weights
(including, but not limited to, clip-on weights) or other unapproved accessories
8.8. The continued use of the products after the discovery or the manifestation of
a problem
8.9. Damage that occurs in transit or otherwise while the products are outside the
control of Dymag
8.10. Infrequent or improper cleaning of Dymag products will void the finish warranty
Advice on wheel cleaning: Only a mild soap applied with a hose or soft cloth
should be used to clean Dymag products. Cleaning Dymag products with a hard
or coarse brush or fabric, chemical based cleaners or acid sprays, or pressure
washers may cause damage to the finish and will void the warranty. Many car
washes use acid spray to clean road wheels, which should be avoided.
9. WARRANTY DISCLAIMERS
THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESSED OR IMPLIED WARRANTIES.
DYMAG HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING THE
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
AND NON-INFRINGEMENT.
9.1. Some USA states do not allow disclaimers or limitations on implied warranties,
so the above may not apply to you. Dymag makes no other warranty, express
or implied, beyond that set forth in this Warranty. Except for those warranties
that are implied by law that cannot be legally disclaimed, any and all other
warranties are hereby expressly disclaimed
9.2. No other representation, by any officer, employee or agent of Dymag will
be binding upon the company. Dymag’s Warranty shall not be enlarged by, nor
shall any obligation or liability arise due to, Dymag providing service, advice or
facilities in connection with any product
9.3. Under no circumstances will Dymag be liable for any incidental, consequential,
special, indirect or punitive damages, whether arising out of contract, tort, or
under this Warranty, or otherwise (including, but not limited to, inconvenience,
loss of use of the vehicle or replacement expenses). Some USA states do not allow
the exclusion of certain types of damages, so the above limitations or exclusions
may not apply to you
10. WARRANTY CLAIM PROCEDURE
In the event of an intention to make a warranty claim, the following procedure should
be followed:
10.1. Contact Dymag by telephone [phone] or by email [email protected] to
register the claim with Dymag
10.2. At this time an official Return Authorization Number (RA#) will be issued that must
be clearly marked on all shipping materials and supporting paperwork
10.3. Wheels that are received by Dymag without a clearly identifiable RA# may be
refused
10.4. Arrange to have the wheels shipped to: Dymag Group Ltd, Bumpers Farm
Industrial Estate, Chippenham, Wiltshire, SN14 6QA, United Kingdom or a
nominated Dymag agent
10.5. If the damage is determined to be under warranty, Dymag will reimburse you for
shipping charges for standard ground shipping, Dymag will NOT reimburse for
expedited delivery such as FedEx overnight
10.6. You are responsible for packaging the products appropriately so that no damage
will occur in transit to Dymag or Dymag’s nominated agent. Be certain that the
boxes are free of loose items such as lugs, caps, etc. The company is not
responsible for damage that occurs in transit to Dymag or its agent
10.7. Include the following items:
10.8. A copy of the original invoice for the warranted products
10.9. A written statement signed by you explaining the problem you have encountered,
the circumstances in which the problem occurred, and the year, make and model
of the vehicle on which the wheels were initially installed. In addition, indicate the
year, make and model of the vehicle including tyre size on which the product was
installed at the time of the warranty event occurrence

DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
10 www.dymag.com
10.10. Reference the RA# on all documents included with the product
10.11. Upon receipt of returned goods, Dymag or its agent will inspect the products
per the warranty claim and contact the customer to determine the appropriate
course of action
10.12. If it is determined that the returned products qualify under the terms of this
Warranty, Dymag will, at its own expense, either repair or replace the warranted
product(s) at its sole discretion
10.13. Dymag assumes no responsibility to remove or install wheels on the vehicle
PRODUCT REGISTRATION AND CERTIFICATE
OF OWNERSHIP
Your wheels are serial numbered as part of our quality assurance system. The number is
unique to your wheel and can also be used as a security identification number.
THE CARBON RIM IN THIS PACKAGE IS NUMBER:
THE FORGED ALUMINIUM SPOKE SYSTEM IN THIS PACKAGE IS NUMBER:
YOUR WHEEL WAS ASSEMBLED AND INSPECTED BY:
To register your product to ensure your warranty is registered please go to
www.dymag.com/warranty
• Enter your personal details
• Enter your wheel Carbon Rim Registration number from above

DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
12 www.dymag.com
TECHNICAL WHEEL FITMENT GUIDE
Tyres should always be fitted by qualified or trained fitters using the correct equipment,
with experience of fitting premium wheels and tyres.
11. PRE-INSTALLATION CHECKS
11.1. Studs and mounting surfaces
Clean and inspect all stud threads and mounting surfaces. Threads must not be damaged
and must be free of corrosion, burrs and fractures. Replace any studs that are corroded or
damaged.
WARNING: DO NOT LUBRICATE THREADS UNDER ANY CIRCUMSTANCES
11.2. Hub Fasteners (lug nuts or lug bolts)
Always use new hub fasteners when installing new wheels. Be certain that the fasteners
are correct for the application. It is critical that the fasteners match the thread diameter,
pitch and seat type; otherwise the installation will be incorrect, which could cause a
dangerous condition.
Types of fastener seats used for different wheel options are:
• Conical seat - Fastener has a tapered seat engagement into the wheel
• Flat seat - Fastener has a flat bottomed seat engagement into the wheel
• Radius seat - fastener has a radius seat engagement into the wheel
The “seat” means the area on the wheel where the fasteners will clamp down.
Thread diameter refers to the diameter of the stud measured at the outer edges of the
threads.
Thread pitch refers to:
• The number of threads per inch (imperial)
• The distance between the threads in millimetres
Check the thread engagement. Every stud or bolt must be long enough to thread a length
at least equal to the stud or bolt diameter. For example, a 0.5” thread diameter, must
thread into the lug nut at least 0.5”. Check for this problem on every stud as lengths may
vary. Less than one stud thread diameter engagement is unsafe and will cause loss of
torque and should not be used under any circumstances.
WARNING: DO NOT INSTALL THE WHEELS IF YOU FIND A PROBLEM. IF IN ANY
DOUBT WHATSOEVER AS TO THE SUITABILITY OF THE FASTENER, CONSULT YOUR
DEALER OR DYMAG DIRECTLY FOR TECHNICAL SUPPORT
11.3. Maximum Load Rating
The maximum load rating of the wheel has been determined by Dymag and is marked
on the back of the spokes and is also shown in the product literature. Wheel load rating
requirements are determined by dividing the vehicle’s gross axle weight rating (G.A.W.R)
by two. The axle weight rating for most vehicles is shown on the identification label
located on the driver’s side door jamb, petrol tank door, boot lid or glove compartment.
WARNING: IF SUCH A LOAD RATING IS UNKNOWN OR UNAVAILABLE THE WHEEL
SHOULD NOT BE USED ON THE VEHICLE
WARNING: REGARDLESS OF THE TYRE’S MAXIMUM LOAD RATING, DO NOT EXCEED
THE MAXIMUM LOAD RATING OF THE WHEEL
IF IN ANY DOUBT WHATSOEVER, CONSULT YOUR DEALER OR DYMAG DIRECTLY FOR
TECHNICAL SUPPORT
12. WHEELS FITMENT CHECK
Before mounting the tyres, perform a wheel fitment check at each wheel mounting
location using the following steps:
12.1. Remove front wheels from vehicle
12.2. Wire brush the wheel mounting surface and threaded studs on the vehicle
12.3. If applicable, remove any retaining clips. If not removed, they will prevent the

DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
14 www.dymag.com
wheel from sitting flush against the mounting surface. This will give a false torque
reading, which could cause the fasteners to loosen and result in the loss of
a wheel
12.4. Hold the new custom wheel on the vehicle hub and check for a flush mount of the
wheel to the mounting surface of the vehicle. The mounting surface of the wheel
must fit flush to the vehicle’s hub mounting surface. Whilst the wheel is held
in position, check that no part of the wheel rests, touches or obstructs the brake
drum, balancing weights, brake caliper, suspension component, rivets or any other
part
12.5. Install three fasteners finger tight and rotate the wheel to check caliper clearance
and suspension clearance and to find bent flanges or axles
12.6. Perform the same check on the remaining three wheels on the vehicle
13. TYRE CLEARANCE CHECK
The wheel manufacturing warranty does not cover tyre to fender clearance or tyre to
suspension clearance. This clearance must be fit-checked before mounting all of the tyres,
using the following procedure:
13.1. Mount one tyre on a wheel intended for use on the front of the vehicle (see tyre
fitting guide below)
13.2. Install the tyre/wheel assembly on the front hub and with the vehicle still on
the lift, turn the steering from extreme right to extreme left, whilst checking for
any interference with fender well, or suspension components
13.3. Lower the vehicle and repeat step two with the weight of the vehicle applied
13.4. Whilst observing the tyre/fender clearance, gain assistance to ”bounce” the front
of the vehicle to check that suspension travel does not cause tyre rub. Also check
that the wheel balance weights do not contact suspension components
13.5. Repeat process for the rear tyre/wheel assembly
WARNING: DO NOT PUT HANDS, FINGERS OR ANY BODY PART BETWEEN TYRE AND
VEHICLE WHILST CONDUCTING THESE CHECKS
14. TYRE FITTING GUIDE
14.1. Wheels and tyres are clearly marked with their sizes. Ensure that the wheel and
tyre sizes match before mounting
14.2. The tyre manufacturer’s rim width recommendations must be followed when
selecting wheel size
14.3. Mount all tyres according to the tyre manufacturers and the tyre machine
manufacturers recommended procedures. To avoid scratching or damaging a
wheel during mounting/dismounting of tyres, make sure that the tyre machine
is properly adjusted and all necessary protective covers are used where metal to
wheel contact is made. Mount the tyres using only wheel hub support tyre fitting
machines being careful to ensure that the tyre bead is pushed into the wheel well,
as the machine rotates to fit the tyre. Machines that clamp the rim may damage
the rim finish
14.4. Use tyre fitting lubricant generously on all bead surfaces of the wheel and tyre. It
is strongly recommended that a quality proprietary bead sealing compound is
used on all very low profile tyres (below 35% aspect ratio). This ensures a good
initial seal of the tyre bead to the wheel
14.5. Do not exceed 40 psi (pounds per square inch) of pressure when seating the tyre
to the head of the rim. If the tyre bead does not seat on the wheel at this
pressure, deflate the tyre, rotate the tyre 180 degrees on the rim, relubricate and
check for tyre/wheel size match before re-inflation
14.6. Once beads are seated, install valve core, reconnect the air chuck and inflate
the tyre until the correct pressure is reached according to the tyre manufacturer’s
recommendation. Check the bead edges and the valve for leaks, and then install
the valve cap
14.7. Protective eyewear should be used at all times during the mounting/dismounting,
installation and servicing of wheels
WARNING: DO NOT INFLATE THE MOUNTED TYRE WITH THE CENTRE-POST HOLD-
DOWN CONE, OR RIM CLAMPS TIGHTENED ON THE WHEEL.
LOOSEN THE HOLD-DOWN CONE, BUT DO NOT COMPLETELY REMOVE, AND
RELEASE THE RIM CLAMPS TO LET THE TYRE EXPAND.

DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
16 www.dymag.com
14.8. Balance the tyre/wheel assembly according to the balancing machines
recommended procedures, following ALL safety precautions
14.9. To reduce tyre wear, road noise and vibration, all four wheels should be balanced
dynamically
14.10. Wheels are checked for lateral and radial run-out before leaving the factory to
minimize balancing problems. Some balancing problems may be remedied by
deflating the tyre and rotating it through approximately 180 degrees on the rim,
re- inflating the tyre and rebalancing
15. WHEEL INSTALLATION
15.1. Hold the new custom wheel on the vehicle hub and tighten each fastener finger tight
15.2. Fasteners must be tightened in a crisscross pattern to ensure uniform pressure
and alignment. Apply torque evenly by repeating the crisscross pattern until the
desired torque is reached
15.3. During installation, gravity causes the wheel to rest upon the highest stud. If the
wheel is clamped down off-centre, it can be dangerous and damaging to your
wheel and tyres
15.4. A calibrated torque device must be used to achieve the correct torque setting,
as specified by the Original Equipment Manufacturer. If it is not specified in the
vehicle owner’s manual, contact the vehicle manufacturer
16. GENERAL NOTES
WARNING: IF YOU ARE IN ANY DOUBT WHATSOEVER REGARDING ANY ASPECT OF
THE INSTALLATION PROCESS, DO NOT INSTALL THE WHEELS.
INSTEAD CONSULT YOUR DEALER OR DYMAG DIRECTLY FOR TECHNICAL SUPPORT
16.1. Read the owner’s manual and warnings in conjunction with these guidelines
16.2. Do not allow the lug nut to bottom out on the stud. If using lug bolts, do not allow
the bolt to bottom out on the mounting surfaces. Either condition is extremely
dangerous and unsafe because the clamping force of the fastener is not being
applied to the wheel. Check each stud individually for these problems as some
lengths may vary
16.3. Never use fewer fasteners than the wheel and vehicle was designed for. If the
wheel has 5 holes, then use 5 fasteners
16.4. When placing the wheel on the studs, there may be an apparent looseness of fit
until the fasteners are applied
17. AFTER INSTALLATION
17.1. Wheel hub fasteners should be retorqued at approximately 25 miles
17.2. Retorquing must be carried out any time the wheel hub fasteners are removed
for any reason
17.3. Routinely check and maintain recommended tyre pressures

DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
OWNERS GUIDE
18 www.dymag.com
NOTES:

Dymag Group Limited
Unit 18, Bumpers Enterprise Centre, Vincients Rd
Bumpers Farm Industrial Estate, Chippenham, Wiltshire, SN14 6QA. UK
Email: [email protected] Tel: [phone]
Registered in England No. 08336642 VAT No. GB 196 3034 00
Registered address 4th Floor, Portwell Place, Portwall Lane, Bristol BS1 6NA
www.dymag.com
#dymagwheels
DYMAG® BOXSTROM™
CARBON HYBRID AUTOMOTIVE WHEELS
