Dyna-Glo Signature Series User manual

1
Wood Pellet Grill
and Smoker
MODEL # DGSS700BPW / DGSS700BPW-D
DGSS700SPW / DGSS700SPW-D
DGSS700BRPW / DGSS700BRPW-D
Español p. 74
Français p. 37
ATTACH YOUR RECEIPT HERE
Serial Number ________________________________ Purchase Date _________________________________
70-10-729 Rev. 07/26/21
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-877-447-4768, 8:00 a.m. – 4:30 p.m. CST,
Monday – Friday or e-mail us at [email protected].
FOR OUTDOOR
USE ONLY
Use only with Class A GFI
(Ground Fault Interrupter)

2
TABLE OF CONTENTS
Safety Information ...................................................................................................................... 3
Package Contents ...................................................................................................................... 8
Hardware Contents ..................................................................................................................... 9
Assembly Instructions ................................................................................................................ 10
Operating Instructions ................................................................................................................. 21
Tips On Smoking ......................................................................................................................... 28
Care and Maintenance ................................................................................................................ 30
Troubleshooting ........................................................................................................................... 31
Replacement Parts List .............................................................................................................. 34
Warranty ...................................................................................................................................... 36
Please read this entire manual before installation and use of the pellet fuel-burning appliance.
Failure to follow these instructions could result in property damage, bodily injury or even death.
Contact local building or re ofcials about restrictions and installation inspection requirements in
your area.
Assembler/Installer: This instruction manual contains important information necessary for the
proper assembly and safe use of this appliance. Read and follow all warnings and instructions
before assembling and using this appliance. Leave these instructions with the consumer.
Consumer/User: Follow all warnings and instructions when using this appliance.
SAVE THESE INSTRUCTIONS
A MAJOR CAUSE OF FIRES IS FAILURE TO
MAINTAIN REQUIRED CLEARANCES (AIR
SPACES) TO COMBUSTIBLE MATERIALS.
IT IS OF UTMOST IMPORTANCE
THAT THIS PRODUCT BE INSTALLED
ONLY IN ACCORDANCE WITH THESE
INSTRUCTIONS.

3
IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS, PRIOR TO USING THIS APPLIANCE
• DO NOT use this product for anything other than its intended purpose. It is NOT intended for
commercial use. It is NOT intended to be installed or used in or on a recreational vehicle and/or boat.
• DO NOT operate this appliance with a damaged cord or plug or after the appliance malfunctions,
has been dropped, or is damaged in any manner. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualied person in order to avoid a hazard.
• DO NOT use appliance within 10 ft. (3 m) of a swimming pool, puddle, pond or other body of water.
• Keep appliance and electric controller dry and out of rain at all times.
• A minimum clearance of 36 in. (92 cm) to
combustible material is required on the front,
sides and back. It is very important to always
maintain proper clearances to combustibles.
• This appliance is for outdoor use only in well-
ventilated areas. DO NOT operate it under a roof,
in a building, garage or any other enclosed area,
or under overhead construction.
Please read and understand this entire manual before attempting to assemble, operate or install the
product. If you have any questions regarding the product, call our customer service department at
1-877-447-4768, 8:00 a.m.- 4:30 p.m. CST, Monday - Friday.
SAFETY INFORMATION
CAUTION
• When using electrical appliances, basic precautions should always be followed to
reduce the risk of re, electrical shock, and injury to persons.
DANGER
• Failure to follow these instructions could result in re or burn hazard which could
cause property damage, personal injury or death.

4
• DO NOT load pellets into the re pot by hand. This will create an unsafe condition and could cause
bodily harm or damage to your appliance.
• DO NOT use the appliance during an electrical storm.
• This unit requires 120 volt, 60hz, 200w, 1.7 amp service.
• The appliance is to be connected to a three pronged, socket-outlet having an earthing contact.
• The appliance should be supplied through a residual current device (RCD) having a rated residual
operating current not exceeding 30 mA. Use only with Class A GFI (Ground Fault Interrupter)
protected circuit.
• Arrange the power cord away from trafc areas to ensure that it is not tripped over.
• To disconnect the power, turn the appliance off by pressing and holding the Power button ( ). Wait
for the appliance to complete the shut down cycle, then remove the plug from the outlet.
• DO NOT obstruct the ow of ventilated air for the appliance.
• DO NOT use this appliance as a heater.
• DO NOT use charcoal or similar combustible fuels with this appliance. This appliance is not
designed for use with charcoal and a re will result if charcoal is used during operation. The re will
create an unsafe condition and damage the appliance.
• For use with natural hardwood pellets for grilling. Never use heating pellets, charcoal pellets, or fuel
with additives.
• Use caution when opening the lid of the appliance while in operation. Keep hands, face and body
safe from hot steam or are-ups. DO NOT inhale smoke.
• DO NOT wear loose clothing while operating the appliance. Tie back long hair while operating the
appliance.
• ALWAYS wear shoes that fully cover your feet while operating the appliance.
• DO NOT touch hot surfaces. Use handles or knobs.
• To protect against electrical shock do not immerse cord or plugs in water or other liquid.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off
parts.
• The use of accessory attachments not recommended by the appliance manufacturer may cause
injuries.
•DO NOT use indoors.
• DO NOT let cord hang over edge of table or counter, or touch hot surfaces.
• DO NOT place on or near a hot gas or electric burner, or in a heated oven.
• Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
SAFETY INFORMATION

5
• DO NOT use appliance for other than intended use.
• Use extreme caution when removing the cooking grates or grease pan or disposing of hot grease.
•DO NOT clean with metal scouring pads. Pieces can break off the pad and touch electrical parts,
creating a risk of electric shock.
• Fuel, such as charcoal briquettes, is not to be used with appliance.
• Use only on properly grounded outlet.
• Be sure that handles are assembled and fastened properly. See instructions regarding handles on
Page 15.
SAVE THESE INSTRUCTIONS.
SAFETY INFORMATION
WARNING
• DO NOT use 16 or 18 gauge extension cords. Damage to household wiring and/or
re could result.
THE USE OF AN EXTENSION CORD IS NOT RECOMMENDED.
READ ALL INSTRUCTIONS PRIOR TO USING AN EXTENSION CORD WITH THIS APPLIANCE
• Use only OUTDOOR type with 3 prong grounding plug, rated for 15 amperes or more, approved by
UL, marked with a W-A and a tag stating “Suitable for Use with Outdoor Appliance”.
• Use the shortest length extension cord required. Do not connect 2 or more extension cords
together.
• Do not let cord hang over edge of table top or other items where it can be pulled by children or
tripped over.
Ground Fault Interrupter
• Since 1971, the National Electric Code (NEC) has required Ground Fault Interrupter
devices on all outdoor circuits.
• If your residence was built before 1971, check with a qualied electrician to determine if
a Ground Fault Interrupter protector exists.
• Do not use this appliance if the circuit does not have Class A GFI protection.
• Do not plug this appliance into an indoor circuit.

6
SAFETY INFORMATION
GENERAL SAFETY
READ ALL INSTRUCTIONS PRIOR TO USING THIS APPLIANCE
• This appliance is for outdoor use only in well-ventilated areas. DO NOT operate it under a roof, in a
building, garage or any other enclosed area, or under overhead construction.
• Before each use, check that no dead leaves or debris are under the appliance.
• Keep a re extinguisher near this product at all times.
• Always unplug the appliance when not in use.
• Allow the appliance and its components to cool completely before conducting any routine cleaning
or maintenance.
• DO NOT use water or other liquid spray to clean the appliance without rst unplugging the unit.
• Allow the appliance to cool to 115°F (45°C) before moving or storing. Use caution when lifting and
moving the appliance to avoid back strain or back injury.
• DO NOT move the appliance while it is in use.
• When not in use, the appliance should be kept out of the elements or protected with a waterproof
cover. Allow the appliance to completely cool before placing the cover. Store this appliance in a dry,
protected location when possible.
• DO NOT store pellets inside the cabinet of this appliance.
• Always store wood pellets away from heat-producing appliances and other fuel containers.
• Use of accessory attachments not recommended by the appliance manufacturer may lead to injury
or property damage.
• Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter uid, or similar liquids to
start or ’freshen up’ a re in this appliance. Keep all such liquids well away from the appliance
when in use.
CAUTION
NEVER use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter uid, or
similar liquids to start or ’freshen up’ a re in this appliance. Keep all such liquids
well away from the appliance when in use.

7
SAFETY INFORMATION
WARNING
To avoid serious injury:
• Always keep a re extinguisher nearby, in case an unexpected re occurs.
• While cooking, the appliance must be on a level, stable, noncombustible surface in an area clear
of combustible material, including long or dry grass.
• The use of alcohol, prescription or nonprescription drugs may impair the user’s ability to properly
assemble and safely operate this appliance.
• DO NOT move the appliance while it is in use.
• DO NOT store and use this appliance near gasoline or other combustible liquids or where other
combustible vapors may be present.
• The appliance should only be used in well-ventilated areas.
• DO NOT use this appliance as a heater.
• When using the direct cook ywheel, DO NOT leave the appliance unattended while in use.
Keep children and pets away from the appliance at all times.
• This appliance will be hot during and after use. Use insulated oven mitts or gloves for protection
from hot surfaces or splatter from cooking liquids.
• DO NOT load pellets into the re pot by hand.
• DO NOT keep the lid closed for longer than 1 minute when the grease tray ywheel is fully open.
WARNING
This product and the fuels used to operate this product (only wood pellet), and the products
of combustion of such fuels, can expose you to chemicals including carbon black, which is
known to the State of California to cause cancer, and carbon monoxide, which is known to
the State of California to cause birth defects or other reproductive harm.
For more information go to www.p65Warnings.ca.gov
DANGER
In case of re, unplug appliance from outlet and allow re to burn out. Do not use
water to put out a re in this appliance.
To avoid electrical shock, disconnect electric cord before cleaning the appliance.
Never immerse electric controller or heating element in any liquid.
To avoid the possibility of burns, make sure the appliance is completely cooled be-
fore removing and/or cleaning internal cooking components.
DO NOT use steel wool or wire brushes to clean the inside of the appliance. Pieces
can break off and touch electrical parts creating a risk of electric shock.
CALIFORNIA PROPOSITION 65

8
PACKAGE CONTENTS
L
SR Q PO
N
M
K
A1
B1
C1
D1
E1
F1
H
G
V
W
X
Y
Z
F
E
DCBA
U T
J
I
Part Description Quantity
AAnalog Temp Gauge 1
BLid Handle Bezels 2
C Lid Handle 1
D Main Grill Body (Without Lid) 1
E Smoke Stack Cap 1
F Smoke Stack Insulation 1
G Smoke Stack 1
H Grease Pail 1
I Cart Panel - Right Side 1
J Front Cart Support 1
K Cart Panel - Rear 1
LDoor Handle Bezel 4
M Door Handle 2
N Cabinet Door - Right Side 1
O Caster (Locking) 2
P Caster (Non-Locking) 2
Part Description Quantity
Q Magnet 4
R Magnet Base 1
S Cabinet Base 1
T Cabinet Door - Left Side 1
U Cart Panel - Left Side 1
VGrease Tray 1
W Cooking Grates 3
X Warming Rack 1
Y Lower Hopper & Firepot Assembly 1
Z Side Handle 1
A1 Control Wire Shield 1
B1 Hopper Safety Grate 1
C1 Digital Control Panel 1
D1 Upper Hopper Assembly 1
E1 Meat Probes 2
F1 Internal Temperature Probe 1

9
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not
attempt to assemble the product. Please read and understand this entire manual before at-
tempting to assemble, operate or install the product. If you have any questions regarding the
product, call our customer service department at 1-877-447-4768, 8:00 a.m.- 4:30 p.m. CST,
Monday - Friday.
Estimated Assembly Time: 45 minutes
PREPARATION BEFORE ASSEMBLY
HARDWARE CONTENTS
AA
FF
BB
GG
CC
HH
DD
II
EE
JJ
1/4"
Washer Qty. 8
1/4"
Hexagon Nut
Qty. 2
8#x3/8
Bolt
Qty. 4
1/4"x2-3/8"
Bolt
Qty. 2
Open End Wrench
Qty. 2
Screwdriver
Qty. 1
1/4"x3/5"
Hexagon Bolt
Qty. 8
ST3.9x8mm
Bolt
Qty. 5
8#
Hexagon Nut
Qty. 4
1/4"x1/2"
Bolt
Qty. 18

10
ASSEMBLY INSTRUCTIONS
Attach Casters (O & P), Magnet Base (R)
& Magnets (Q)
Attach Left Cabinet Panel (U)
Hardware Used
Hardware Used
1
2
II Open End Wrench
O
P
S
O
P
R
Q
EE 1/4"x1/2" Bolt x 2
U
S
EE
Preinstalled Hardware

11
EE
Hardware Used
Hardware Used
1/4"x1/2" Bolt x 2
ASSEMBLY INSTRUCTIONS
Attach Right Cabinet Panel (I)
Attach Rear Cabinet Panel (K)
3
4
I
EE
EE K
I
S
S
U
U
EE 1/4"x1/2" Bolt x 6

12
I
D
EE
U
ASSEMBLY INSTRUCTIONS
Attach Front Cabinet Support (J)
Attach Main Grill Body (D)
5
6
Hardware Used
Hardware Used
EE 1/4"x1/2" Bolt x 4
EE
J
IU
EE 1/4"x1/2" Bolt x 4

13
C1
ASSEMBLY INSTRUCTIONS
Attach Upper Hopper Assembly (D1) and Thread
Control Panel (C1) Through Opening
Secure Control Panel (C1) and Wire Shield (A1)
7
8
Y
CC
Hardware Used
ST3.9x8mm Bolt x 5
Y
D1
D1
C1
A1
CC
CC

14
Y
Z
B1
D1
ASSEMBLY INSTRUCTIONS
Attach Safety Grate (B1) & Side Handle (Z)
Attach Temperature Gauge (A) NOTE: Before attaching the temp
gauge, adjust the gauge nut to
assist with centering the gauge
facing.
9
10
D
A
HH
Hardware Used
1/4"x2-3/8" Bolt x 2
DD
DD
HH
8# Hexagon Nut x 4
GG
GG
8#3/8" Bolt x 4

15
CBD
AA
BB
ASSEMBLY INSTRUCTIONS
Attach Lid Handle (C) and Handle Bezels (B)
Attach Internal Probe (F1) with Pre-Installed
Hardware
11
12
F1
Hardware Used
AA 1/4" Washer x 2
BB 1/4"x3/5" Bolt x 2

16
Y
D
ASSEMBLY INSTRUCTIONS
Attach the Hopper Assembly to Main Grill Body and Connect
the Probe (F1) Harness
Attach Smoke Stack (G), Smoke Stack Cap (E)
and Insulation (F)
13
14
D
G
E
F
AA
BB
FF
FF
Hardware Used
Preinstalled Hardware Used
1/4" Hexagon Nut x 2
AA 1/4" Washer
1/4" Washer
x 2
x 4
BB 1/4"x3/5" Hexagon
Bolt
1/4"x3/4"
Hexagon Bolt
x 2
x 4

17
NT
M ML L
AA AA
BB BB
ASSEMBLY INSTRUCTIONS
Attach Cabinet Door Handles (M)
Attach Cabinet Doors (T & N)
15
16
T
N
D
S
Hardware Used
AA 1/4" Washer x 4
BB 1/4"x3/5" Bolt x 4

18
V
D
ASSEMBLY INSTRUCTIONS
Insert Grease Tray (V)
Insert Grease Tray (V)
17
18
D
V

19
W
D
ASSEMBLY INSTRUCTIONS
Insert Cooking Grates (W)
Insert Warming Rack (X)
19
20
X
D

20
ASSEMBLY INSTRUCTIONS
Install Grease Pail (H)
Connect Meat Probes (Optional)
21
D
C1
E1
H
