Welcome to Dynalab
Thank you for selecting Dynalab Test Systems. The NX Tester is designed to run as a standalone wire
harness tester without a constant connection to a computer. Programs are created with the NX Editor
software application, then transferred to the NX Tester.
This User’s Guide describes the NX Tester’s user interface, hardware configuration, and interfacing.
Please refer to the NX System Getting Started Guide to learn how to quickly set up the NX Tester and
write a functional test program. Detailed information about how to write test programs is available in
the NX Editor User’s Guide.
Overview of the Dynalab NX Tester
The front panel of any NX Series Tester has the following features:
•Speaker – The speaker is used to produce a variety of sounds.
•Display – The 4 line x 20 character display provides useful information about the status of the test.
•User Buttons – The arrow buttons are used to scroll through menus. The green button is used to select
menu items and to start programs. The red button is used to stop program execution and to escape
from menus.
•Probe port – This accepts the Probe, a useful device for troubleshooting fixture wiring. When probing
a Test Point, the Tester will display the Test Point name.
•NX Memory Card Slot – This slot accepts an NX Memory Card for the purpose of transferring
programs from a PC to the NX Tester.
•Key Slot – This slot accepts a Supervisor Key
The Supervisor Key unlocks access to Setup Menus, allows program termination, activates the
control port, and allows advancing through errors. The Supervisor Key may also be used to satisfy a
test program’s requirement that a supervisor be present to continue. The Supervisor Key contains
data storage areas that can be programmed to contain the Supervisor’s ID and other useful data.
Probe Port
Speaker Display
User
Buttons
NX
Memory
Card Slot
Key Slot

Dynalab Test Systems NX Tester User’s Guide 3
Copyright 2011 Revised 04/27/2011
The rear panel of any NX Series Tester is designed to support the following features:
•Serial Ports – Two serial ports are supplied as a standard feature on every NX Series Tester. Serial
ports are used to connect to a Remote Display, Label or Receipt Printer, or Bar Code Scanner. Two
additional serial ports and a network interface are available with the optional Communications Board,
part number 5-4011.
•Power Supply Receptacle – this accepts the DC connection from the Power Supply.
•Control Port Interface – Connects to the Control Port Module. The Control Port Module provides one
set of contacts for output and one for input. This provides a mechanism to control an external device
such as a fixture clamp, or to receive input from an external device. For more detailed information
regarding the use of the Control Port Module, please refer to the NX Application Note entitled
Interfacing to External Devices.
•Extended Button Interface – In some cases, the test operator may not be able to easily reach the
control buttons on the front panel of the NX Tester. To solve this problem, the NX Tester can be
equipped with an Extended Button Pad - this provides the operator with complete control of the NX
Tester from a distance. The Extended Button Pad plugs into the Extended Button Interface.
•USB Port – The USB port is available to connect to a PC. A PC connection is used to support NX
View software, to upgrade the NX Tester’s firmware, or to download test programs from the PC.
Note: the USB port is a standard feature in NX Testers manufactured in 2011 and later. Older NX
Testers are not equipped with a USB port.
Standard
Serial Ports
Test Point
Boards
Power
Supply
Receptacle
Control Port
Interface
Power
Switch
Extended
Button
Interface
Optional
Serial Ports
Optional
Network
Interface
USB
Port

4 NX Editor User’s Guide Dynalab Test Systems
Revised 04/27/2011 Copyright 2011
© Dynalab, Inc. 2006
Version 2.1.91
SN 000000035
Test Points 256
SELECTED_PROGRAM
>RUN FILES
SELECT SETUP
PROBE
Powering Up the NX Tester
The NX Tester is provided with a power supply and cord. The power supply connector plugs into the
receptacle located on the rear of the NX Tester. The power supply’s power cord connects to a 3 prong
power receptacle. For proper operation and safety, an adequate ground is required. The power supply
may be connected to a 115VAC or 220VAC receptacle.
The power switch is also located on the rear of the cabinet. When the power switch is activated, the NX
Tester displays a power up message that includes the firmware version, the NX Tester’s serial number,
and the number of test points, as shown below:
During the power up phase, the NX Tester performs a diagnostic test for the test points. If successful,
the fourth line displays the total number of test points found as shown above. If the diagnostic test fails,
the fourth line will display a flashing message indicating failure.
Calibration
The NX Tester performs automatic calibration upon power-up and every time a Test Workflow item is
executed. Automatic calibration is based on readings made using a set of internal precision components
of known values. Calibration of any NX Tester is verifiable using Dynalab’s Calibration Verification
Device, part number 5-1040. The NX Tester calibration verification procedure is explained in detail in
the NX Application Note entitled “Calibration Verification”.
Using NX Tester Menus
A simple Main Menu is used to control basic operations of the NX Tester.
The “>” symbol is used to point to selected menu items as shown above. All menus use the four buttons
located on the front of the NX Tester.
•The Up and Down arrow buttons are used to move the pointer
•The GREEN button is used to select an item
•The RED button is used to return to a previous menu or to stop execution of a function.

Dynalab Test Systems NX Tester User’s Guide 5
Copyright 2011 Revised 04/27/2011
SELECTED_PROGRAM
RUN FILES
SELECT SETUP
PROBE
SELECTED_PROGRAM
>RUN FILES
SELECT SETUP
PROBE
SELECTED_PROGRAM
RUN FILES
>SELECT SETUP
PROBE
A7789008
1358 bytes
15-Jun-2004 12:34
13A53CD3 2/9
A7789008
1358 bytes
15-Jun-2004 12:34
13A53CD3 2/9
Program Name
Program Size
Date & Time Stamp
Checksum
Total number of programs in memory
Program number
Main Menu
The Main Menu is displayed when the NX Tester is powered up and when a program stops execution.
The first line displays the name of the selected program. If no program is selected, this line is blank.
The rest of the items are selectable menu items. To select an item, use the Up and/or Down arrow keys
to navigate to the desired item, then press the GREEN button to select the item. To return to the
previous level, press the RED button.
RUN
The RUN function executes the currently selected program (shown on the top line of the Main Menu).
To stop execution of the program, press the RED button.
SELECT
The SELECT function is used to select a program for execution from the NX Tester’s memory.
During selection, the NX Tester displays information about each program. This includes the program
name, the size of the program, the date and time the program was last saved, the checksum, the program
number in the list and the total number of programs. The checksum is a 8 character (4 hexadecimal
digits) value. This value is also visible in the NX Editor, providing a means of ensuring that the program
was not corrupted during file transfer.
The UP and DOWN arrow keys can be used to scroll through the program list. Once the desired
program is displayed, the selection is made by pressing the GREEN button. After selecting a program
by pressing the GREEN button, the NX Tester returns to the Main Menu.

6 NX Editor User’s Guide Dynalab Test Systems
Revised 04/27/2011 Copyright 2011
SELECTED_PROGRAM
RUN FILES
SELECT SETUP
>PROBE
PROBE ^C
[001-12]
B-2
W3(BLU)
MEM-CARD > TESTER
TESTER > MEM-CARD
SERVER > TESTER
MAINTENANCE
>MEM-CARD > TESTER
TESTER > MEM-CARD
SERVER > TESTER
MAINTENANCE
MEM-CARD > TESTER
>ONE FILE
ALL FILES
A7789008
1358 bytes
15-Jun-2004 12:34
2/9
SELECTED_PROGRAM
RUN >FILES
SELECT SETUP
PROBE
MEM-CARD > TESTER
>ONE FILE
ALL FILES
PROBE
The PROBE function places the NX Tester in the probe mode. This mode is especially useful for fixture
building and maintenance. In the probe mode, the NX Tester identifies which test point(s) the probe is
electrically connected to. The NX Tester also displays the symbolic information from the selected
program showing what connector and pin should be connected to the probed test point. If more than
one test point is connected to the probed point, an UP caret (^) is displayed in the upper right corner, and
pressing the Up Arrow button will scroll through all the connected points. If an LED is associated with
the probed point’s fixture block, the LED will be illuminated.
To use this mode a Dynalab probe must be connected to the probe jack on the front of the NX Tester.
FILES Menu
The FILES menu is accessed by selecting FILES from the Main Menu as shown above. Once selected,
the FILES menu is presented.
The FILES menu provides several functions for managing program files on the NX Tester and NX
Memory Card.
MEM-CARD > TESTER
The MEM-CARD > TESTER selection is used to transfer files from the NX Memory Card to the NX
Tester’s memory. After selection of this function, a menu is displayed prompting for ONE FILE or for
ALL FILES.
ONE FILE is used to transfer a single file from the NX memory Card to the NX Tester’s memory.
When ONE FILE is selected, the NX Tester displays information about each program. This includes
the program name, the size of the program, the date and time the program was last saved, the program
number in the list and the total number of programs. The UP and DOWN arrow keys can be used to
scroll through the program list. Once the desired program is displayed, the selection is made by pressing
the GREEN button.

Dynalab Test Systems NX Tester User’s Guide 7
Copyright 2011 Revised 04/27/2011
MEM-CARD > TESTER
ONE FILE
>ALL FILES
MEM-CARD > TESTER
>TESTER > MEM-CARD
SERVER > TESTER
MAINTENANCE
TESTER > MEM-CARD
>ONE FILE
ALL FILES
A7789008
1358 bytes
15-Jun-2004 12:34
13A53CD3 2/9
TESTER > MEM-CARD
ONE FILE
>ALL FILES
TESTER > MEM-CARD
>ONE FILE
ALL FILES
ALL FILES is used to transfer all the files on the NX Memory Card to the NX Tester’s memory.
TESTER > MEM CARD
The TESTER > MEM_CARD selection is used to transfer files from the NX Tester’s memory to the
NX Memory Card. After selection of this function, a menu is displayed prompting for ONE FILE or for
ALL FILES.
ONE FILE is used to transfer a single file from the NX Tester’s memory to the NX Memory Card.
When ONE FILE is selected, the NX Tester displays information about each program. This includes
the program name, the size of the program, the date and time the program was last saved, the checksum,
the program number in the list and the total number of programs. The UP and DOWN arrow keys can
be used to scroll through the program list. Once the desired program is displayed, the selection is made
by pressing the GREEN button.
ALL FILES is used to transfer all the files from the NX Tester’s memory
to the NX Memory Card.
NOTE:
Dynalab recommends use of the Memory Cards supplied by Dynalab, part number 5-1011.
All memory cards supplied by Dynalab are shipped with a FAT file system. Microsoft Windows will
allow the card to be re-formatted as FAT32 or as FAT. If it is necessary to re-format the card, do not
use FAT32 – the file system must always be formatted as FAT in order to operate properly with NX
Testers.

8 NX Editor User’s Guide Dynalab Test Systems
Revised 04/27/2011 Copyright 2011
MEM-CARD > TESTER
TESTER > MEM-CARD
SERVER > TESTER
>MAINTENANCE
MAINTENANCE
>TESTER
MEM-CARD
>DIR
DELETE ONE
DELETE ALL
INFO
MEM-CARD > TESTER
TESTER > MEM-CARD
>SERVER > TESTER
MAINTENANCE
SERVER > TESTER
The SERVER >TESTER selection is used to transfer files across the network from the NX Server to the
NX Tester.
MAINTENANCE
The MAINTENANCE selection is used to view the file directory, get information about file storage
memory capacity, and to delete files from memory.
After making the selection in the FILES menu, the MAINTENANCE menu shown above is presented.
Select TESTER to gain access to file maintenance function on the tester, or MEM-CARD to gain access
to file maintenance function on the memory card.
Next, the selections shown above are presented.
DIR
When DIR is selected, the NX Tester displays the directory information about each program. This
includes the program name, the size of the program, the date and time the program was last saved, the
checksum, the program number in the list and the total number of programs. The UP and DOWN arrow
keys can be used to scroll through the program list. Once the desired program is displayed, the selection
is made by pressing the GREEN button.
DELETE ONE
A7789008
1358 bytes
15-Jun-2004 12:34
13A53CD3 2/9
>DIR
DELETE ONE
DELETE ALL
INFO
A7789008
1358 bytes
15-Jun-2004 12:34
13A53CD3 2/9
DIR
>DELETE ONE
DELETE ALL
INFO

Dynalab Test Systems NX Tester User’s Guide 9
Copyright 2011 Revised 04/27/2011
29 FILES
168794 BYTES USED
1332458 BYTES FREE
DIR
DELETE ONE
DELETE ALL
>INFO
When DELETE ONE is selected, the NX Tester displays the directory information as previously
described. The UP and DOWN arrow keys can be used to scroll through the program list. Once the
program to be deleted is displayed, the selection is made by pressing the GREEN button. The NX Tester
will respond by requesting a confirmation – Press the GREEN button to confirm.
DELETE ALL
When DELETE ALL is selected, the NX Tester will respond by requesting a confirmation – Press the
GREEN button to confirm. All files will be deleted.
INFO
When INFO is selected, the NX Tester displays information about file storage capacity as shown above.
The number of files is displayed on the first line. The amount of used storage space is displayed on the
second line. The amount of free storage space is displayed on the third line.

10 NX Editor User’s Guide Dynalab Test Systems
Revised 04/27/2011 Copyright 2011
SELECTED_PROGRAM
RUN FILES
SELECT >SETUP
PROBE
CONFIGURATION
RESTRICTIONS
DIAGNOSTICS
AUTOLOEARN
>CONFIGURATION
RESTRICTIONS
DIAGNOSTICS
AUTOLOEARN
CONFIGURATION
VOLUME LANGUAGE
CLOCK SERIAL
ID MORE…
CONFIGURATION
VOLUME LANGUAGE
>CLOCK SERIAL
ID MORE…
TUESDAY
JUNE 08, 2004
10:09:48
CONFIGURATION
>VOLUME LANGUAGE
CLOCK SERIAL
ID MORE…
Volume
|** |
SETUP Menu
The SETUP menu is accessed by selecting SETUP from the Main Menu. Once selected, the SETUP
menu is presented. (NOTE: A Supervisor key must be inserted to gain access to the SETUP menus.)
CONFIGURATION
The CONFIGURATION menu is accessed by selecting CONFIGURATION from the SETUP menu.
Once selected, the CONFIGURATION menu is presented.
The CONFIGURATION menu provides access to the following setup options:
•Volume Control
•Setting the NX Tester’s clock
•Setting the NX Tester’s ID
•Selecting the language used in displaying menus
•Adjusting Serial Port settings
•Configuring the substring parameters for the Automatic Program Selection feature (under
MORE)
•Upgrading the NX Tester’s firmware from the memory card (under MORE)
VOLUME
Select VOLUME to adjust the NX Tester’s sound volume.
Use the UP Arrow button to increase volume, Use the DOWN Arrow button to decrease volume.
CLOCK
To see or change the NX Tester’s internal clock, select CLOCK from the CONFIGURATION menu.
After selection, the NX Tester displays the current clock setting.

Dynalab Test Systems NX Tester User’s Guide 11
Copyright 2011 Revised 04/27/2011
Month (1-12)
06
Day (1-31)
05
Year (1999-2070)
2004
Hours (0-23)
19
Minutes (0-59)
22
If the current clock settings are satisfactory, press the RED button to go back to exit this feature.
If the settings need to be changed, press the GREEN button.
The NX Tester first shows the 2-digit month setting. Use the Up/Down Arrow buttons to change the
first digit, then press the GREEN button. Then, use the Up/Down arrow buttons to change the second
digit, then press the GREEN button. If a digit does not need be changed, press the GREEN button to
skip.
Next, the NX Tester shows the 2-digit day of month setting. Use the Up/Down Arrow buttons to
change the first digit, then press the GREEN button. Then, use the Up/Down arrow buttons to change
the second digit, then press the GREEN button. If a digit does not need be changed, press the GREEN
button to skip.
Next, the NX Tester shows the 4-digit year setting. Use the Up/Down Arrow buttons to change the first
digit, then press the GREEN button. Repeat for each of the subsequent 3 digits. If a digit does not need
be changed, press the GREEN button to skip.
Next, the NX Tester shows the 2-digit hours setting. Use the Up/Down Arrow buttons to change the
first digit, then press the GREEN button. Repeat for the second digit. If a digit does not need be
changed, press the GREEN button to skip.

12 NX Editor User’s Guide Dynalab Test Systems
Revised 04/27/2011 Copyright 2011
Seconds (0-59)
03
TUESDAY
JUNE 08, 2004
10:09:48
CONFIGURATION
VOLUME LANGUAGE
CLOCK SERIAL
>ID MORE…
ADJUST TESTER ID
0004
ADJUST UNIT ID
0005
GREEN = YES
RED = NO
Next, the NX Tester shows the 2-digit minutes setting. Use the Up/Down Arrow buttons to change the
first digit, then press the GREEN button. Repeat for the second digit. If a digit does not need be
changed, press the GREEN button to skip.
Next, the NX Tester shows the 2-digit minutes setting. Use the Up/Down Arrow buttons to change the
first digit, then press the GREEN button. Repeat for the second digit. If a digit does not need be
changed, press the GREEN button to skip.
Finally, the NX Tester displays the result of the clock change. If satisfactory, press the RED button to
exit this function. If changes still need to be made, press the GREEN button and repeat the steps
described above.
ID
The NX Tester can be configured with an ID – settable between 0000 and 9999. The ID is typically
used to print a unique ID value on a label when a Dynalab label printer is used. It may also be used
when outputting reports or other functions that require identification of the NX Tester.
To see or change the NX Tester’s ID, select ID from the CONFIGURATION menu. After selection, the
NX Tester displays the 4-digit ID setting. Use the Up/Down Arrow buttons to change the first digit, then
press the GREEN button. Repeat for each of the subsequent 3 digits. If a digit does not need be
changed, press the GREEN button to skip.
After changing the last digit, the NX Tester prompts for a confirmation as shown below:
Press the GREEN button to accept the value as displayed. Press the
RED button to cancel the operation.

Dynalab Test Systems NX Tester User’s Guide 13
Copyright 2011 Revised 04/27/2011
CONFIGURATION
VOLUME >LANGUAGE
CLOCK SERIAL
ID MORE…
LANGUAGE
>*ENGLISH
SPANISH
CONFIGURATION
VOLUME LANGUAGE
CLOCK >SERIAL
ID MORE…
>1:RS-232
2:RS-232
3:NOT PRESENT
4:NOT PRESENT
PORT 1 SETTINGS
RS-232
RS-232 SETTINGS:
9600,8,N,1,HW
RED = KEEP
GREEN = CHANGE
BAUD RATE
9600
LANGUAGE
The menus on the NX Tester can be displayed in either English or Spanish. To change the language,
select LANGUAGE from the CONFIGURATION menu. Use the Up/Down arrow buttons to select the
desired language, the press the GREEN button to make the change. When finished, press the RED
button to return to the CONFIGURATION menu.
SERIAL
The NX Tester is supplied with two serial ports. Two additional serial ports are optionally available
with the purchase of the Communications Board. To adjust the settings for the serial ports, select
SERIAL from the CONFIGURATION menu. To adjust the RS-232 settings, use the Up/Down Arrow
buttons to select the desired port and press the GREEN button.
The NX Tester displays the information above, indicating that serial PORT 1 is currently configured for
RS-232. Press the GREEN button to accept RS-232 as the desired function.
The current RS-232 settings are displayed on the second line. If these settings are acceptable and do not
need to be changed, press the RED button. If any of the settings need to be changed, press the GREEN
button.
The first parameter displayed is the baud rate. Use the Up/Down Arrow buttons to scroll through the list
of valid values and press the GREEN button to select the desired baud rate. If the currently displayed
value is acceptable, press the GREEN button to skip.

14 NX Editor User’s Guide Dynalab Test Systems
Revised 04/27/2011 Copyright 2011
WORD LENGTH
8 bits
PARITY
EVEN
STOP BITS
1 bits
HANDSHAKING
HARDWARE
Next, the NX Tester displays the word length. Use the Up/Down Arrow buttons to scroll through the list
of valid values and press the GREEN button to select the desired word length. If the currently displayed
value is acceptable, press the GREEN button to skip.
Next, the NX Tester displays the parity. Use the Up/Down Arrow buttons to scroll through the list of
valid values and press the GREEN button to select the desired parity. If the currently displayed value is
acceptable, press the GREEN button to skip.
Next, the NX Tester displays the stop bits. Use the Up/Down Arrow buttons to scroll through the list of
valid values and press the GREEN button to select the desired stop bits. If the currently displayed value
is acceptable, press the GREEN button to skip.
Next, the NX Tester displays the handshaking. Use the Up/Down Arrow buttons to scroll through the
list of valid values and press the GREEN button to select the desired handshaking. If the currently
displayed value is acceptable, press the GREEN button to skip.

Dynalab Test Systems NX Tester User’s Guide 15
Copyright 2011 Revised 04/27/2011
CONFIGURATION
VOLUME LANGUAGE
CLOCK SERIAL
ID
>
MORE…
CONFIGURATION
>SUBSTRING
UPGRADE FIRMWARE
USB
SUBSTRING
>FIRST CHAR POSITION
MAXIMUM CHARACTERS
MORE: SUBSTRING
The SUBSTRING function specifies the parameters used by the Automatic Program Selection Using a
Bar Code Scanner feature. This feature is explained in detail in a subsequent section of this document.
The feature uses a bar code scanner to scan a part number or program name. When connected Serial
Port 2 the scanned barcode represents either a program name or a part number. The NX Tester will then
look for a match of the scanned data – it first will look for a program whose name matches the data. If it
cannot find a program whose name matches, it then looks for a defined part number in each program.
Once the first match is found, the NX Tester will automatically select and run the program.
The SUBSTRING function instructs the NX Tester to extract a substring from the scanned data, and use
the substring as the match criterion. There are two parameters to be set:
FIRST CHARACTER POSITION – using the up/down arrow keys, specify the first character
position of the substring, then press the green button to accept. The minimum value must be 01.
MAXIMUM CHARACTERS – using the up/down arrow keys, specify the maximum number of
characters for the substring. Note that if the remaining number of characters in the scanned data is
less than the specified MAXIMUM CHARACTERS, the substring will start at the FIRST
CHARACTER POSITION and end at the end of the scanned data. Note that even though this field
may be set to a value as high as 99, a maximum of 40 characters will be used, since this is the
maximum size of the Part Number variable. Anything beyond 40 characters will be truncated.
Examples:
Scanned barcode data is: AXRQ-9987465
FIRST CHARACTER POSITION = 06
MAXIMUM CHARACTERS = 04
SUBSTRING = 9987
FIRST CHARACTER POSITION = 06
MAXIMUM CHARACTERS = 99
SUBSTRING = 9987465
FIRST CHARACTER POSITION = 01
MAXIMUM CHARACTERS = 99
SUBSTRING = 9987465
FIRST CHARACTER POSITION = 01
MAXIMUM CHARACTERS = 4
SUBSTRING = AXRQ

16 NX Editor User’s Guide Dynalab Test Systems
Revised 04/27/2011 Copyright 2011
USB SETTINGS
NONE
USB SETTINGS
NXVIEW
MORE: UPGRADE FIRMWARE
Select this option to upgrade the NX Tester’s firmware from the memory card. The firmware upgrade
file must be present on the memory card. If more than one firmware upgrade file is present on the
memory card, the NX Tester will allow the user to scroll through the files using the up/down arrows to
select the desired file. When the desired upgrade file is displayed, press the Green button to proceed.
MORE: USB
If the NX Tester is equipped with a USB port, this selection provides the means to configure the USB
port for use with NX View. The UP arrow button is used to toggle between the two selections. The
selection is confirmed by pressing the green button. The NXVIEW selection enables the USB port to be
used to communicate with NX View on a PC.
UP arrow toggles
between selections

Dynalab Test Systems NX Tester User’s Guide 17
Copyright 2011 Revised 04/27/2011
CONFIGURATION
>RESTRICTIONS
DIAGNOSTICS
AUTOLEARN
RESTRICTIONS
>FILE ACCESS
FILE MODE
RESTRICTIONS
>FILE ACCESS
FILE MODE
FILE ACCESS
>*NO RESTRICTION
SUP KEY REQUIRED
RESTRICTIONS
FILE SELECTION
>FILE MODE
FILE MODE
>*MULTIPLE FILES
ONE FILE
ONE-DELETE ON END
Erase all files
Except the currently
Selected file ?
GREEN=YES RED=NO
RESTRICTIONS
The RESTRICTIONS function is accessible from the SETUP menu as shown above. Two selections are
available.
FILE ACCESS
This function is used to restrict (or un-restrict) access to the program SELECT menu based on the
presence of the Supervisor Key. Use the Up/Down Arrow buttons to select NO RESTRICTION if
access to the SELECT menu is unrestricted, or to select SUP KEY REQUIRED if access to the SELECT
menu is to be restricted based upon the presence of the Supervisor Key. Press the Green button to
confirm the selection. Press the Red button to exit.
FILE MODE
By default, the NX Tester can store as many program files as can fit into its 1.3Mb of program storage
area. This corresponds to the MULTIPLE FILES selection.
In some cases, it may be desirable to allow the NX Tester to store only one test program at a time. To
enable this capability, select ONE FILE in the FILE MODE menu. Press the Green button to confirm
the selection. If ENABLED, after pressing the Red button to exit, if there is more than one program
currently on the NX Tester, the following screen will appear:
Upon pressing the Green button, the NX Tester will delete all files except the currently selected file, and
will place the NX Tester into One File Mode. Upon pressing the Red button, the NX Tester will delete
no files, and the One File Mode will remain DISABLED.
The selection labeled ONE-DELETE ON END is similar to the ONE FILE mode, with the additional
feature of automatically deleting the program file after execution, providing that the program reaches a
END workflow item. This may be useful in conjunction with using the NX Server as source of all
program files, ensuring that program files are only available from the NX Server.

18 NX Editor User’s Guide Dynalab Test Systems
Revised 04/27/2011 Copyright 2011
CONFIGURATION
RESTRICTIONS
>DIAGNOSTICS
AUTOLEARN
TEST PTS RESET
SER 1&2 CALIBRATE
SER 3&4 INFO
SYSLOG MORE…
TEST PTS RESET
SER 1&2 CALIBRATE
SER 3&4 INFO
SYSLOG
TEST PTS >RESET
SER 1&2 CALIBRATE
SER 3&4 INFO
SYSLOG
TEST PTS RESET
>SER 1&2 CALIBRATE
SER 3&4 INFO
SYSLOG
TEST PTS RESET
SER 1&2 CALIBRATE
SER 3&4 INFO
>SYSLOG
DIAGNOSTICS
The DIAGNOSTICS menu is accessible from the SETUP menu as shown above.
TEST PTS
>
Select TEST PTS to perform a diagnosis of all test point boards. Before performing this check, be sure
that all test point boards are disconnected from the interface cabling.
SER 1&2 or SER 3& 4
Serial ports may be diagnosed in pairs. To execute a diagnosis of serial ports 1 and 2, select SER 1&2,
connect the two ports together using the download cable and press the Green button. Similarly, to
execute a diagnosis of serial ports 3 and 4, select SER 3&4, connect the two ports together using the
download cable and press the Green button.
SYSLOG
The SYSLOG selection causes the NX Tester to copy the contents of its internal system log file to the
memory card. A memory card must be inserted before selecting this function. This capability may be
useful for diagnostic purposes – this file may be emailed to Dynalab for analysis.
RESET
Select RESET to perform a reset of the NX Tester. Specifically, this function deletes all programs,
initializes all counter variables, and resets all configuration settings to the factory defaults (except the
time setting).
