Dynamic Displays 17C3 A/D Series User manual

LCD Monitor User Manual - QES1500
Progressive & Interlace Monitor
17C3 A/D Board Series

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #2 of 26
Table of Contents
INTRODUCTION............................................................................................................................................................................. 4
Product Description...................................................................................................................................................................... 4
Display Features............................................................................................................................................................................ 4
Display Options ............................................................................................................................................................................. 4
Unpacking the Monitor ................................................................................................................................................................ 5
NOTES:............................................................................................................................................................................................ 5
Product Safety Precautions ......................................................................................................................................................... 5
Package Contents ......................................................................................................................................................................... 5
Connecting the Monitor ............................................................................................................................................................... 5
MONITOR SETUP ........................................................................................................................................................................... 6
Signal Input Connections ............................................................................................................................................................. 7
VGA HIGH DENSITY HD15 CONNECTOR PIN OUT ................................................................................................................ 7
FEMALE BNC’S TO HD15 ADAPTOR CABLE (OPTIONAL)....................................................................................................... 7
HDMI (HIGH DEFINITION MULTIMEDIA INTERFACE) CONNECTOR PIN OUT .................................................................... 8
DVI (DIGITAL VISUAL INTERFACE) CONNECTOR PIN OUT .................................................................................................... 8
S- VIDEO 4 PIN CONNECTOR (OPTIONAL).............................................................................................................................. 8
CGA 9 PIN D-SUB CONNECTOR (OPTIONAL) ......................................................................................................................... 9
EGA 9 PIN D-SUB CONNECTOR (OPTIONAL).......................................................................................................................... 9
MDA 9 PIN D-SUB CONNECTOR (OPTIONAL) ........................................................................................................................ 9
Card Edge 10 Pin Connector:................................................................................................................................................. 10
Touch Screen 9 Pin D-Sub connector, Serial Port (Optional). ........................................................................................... 10
OSD CONTROLS & FUNCTIONS................................................................................................................................................. 11
Menu Operating Instructions: ................................................................................................................................................... 11
Menu OSD Control Buttons:...................................................................................................................................................... 11
Input Video Options Selection;.................................................................................................................................................. 12
OSD Interface buttons function: ............................................................................................................................................... 12
Membrane Direct Keys Adjustments: ...................................................................................................................................... 12
OSD STRUCTURE ......................................................................................................................................................................... 13
1. Picture .............................................................................................................................................................................. 13
2. Sound ............................................................................................................................................................................... 15
3. Option .............................................................................................................................................................................. 15
4. PC; (Available only VGA1/VGA2).................................................................................................................................... 16
5. Advance (Aspect Ratio needs to be set to “Full” to activate this adjustments) ...................................................... 17

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #3 of 26
Power Management (VESA): ...................................................................................................................................................... 17
TROUBLESHOOTING................................................................................................................................................................... 18
CLEANING INSTRUCTIONS......................................................................................................................................................... 20
Universal Video Input Unit Option............................................................................................................................................ 21
Connecting The Universal Video (UVI) Box .......................................................................................................................... 21
Universal Video Input Box Specification: ............................................................................................................................. 22
Factory Settings Mode................................................................................................................................................................ 23
Contact Information:
Dynamic Displays, Inc.
1625 Westgate Road
Eau Claire, WI 54703
USA
Phone: [phone]
Fax: [phone]
715-835-2436
E-mail: [email protected]
WEB: www.dynamicdisplay.com

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #4 of 26
Please read this manual to learn about the safety precautions and get the most out of the design features of your
new monitor.
INTRODUCTION
Thank you for purchasing the QES1500 Progressive & Interlace Series Color Monitor. We are confident that you will
be pleased with the performance and reliability of your new monitor. The QES1500 Progressive & Interlace Series
Color Monitor was designed to meet the screen performance requirements of today's demanding industrial and
military applications. While complying with a wide variety of industrial video formats, it delivers a larger screen
area, higher resolutions, and greater color accuracy than many monitors in its price range.
PRODUCT DESCRIPTION
The QES1500 Progressive & Interlace Series Industrial LCD Displays are high performance, Active Matrix
color/monochrome TFT LCD monitors designed for those demanding applications that require a rugged, high
quality computer display capable of sub-VGA through 1920x1200 resolutions. These premium displays accept a
broad range of standard signal formats, enabling them to function in most modern industrial environments. For
legacy or replacement applications, we can configure this LCD display to accept a wide variety of sub-VGA formats
and video signal inputs. Options available are; Tabletop (Desktop) Configuration, Open Frame Configurations, Rack
Mount Configurations, Wall/Arm Mount Configurations, Touch Screen, Vandal Protection Shield, Enhanced Sunlight
Readability, NEMA 4X stainless steel panel mount bezel. These computer display panels have all the features
necessary for use in those industrial, manufacturing, financial, transportation and other severe environments that
require bright, crisp computer imaging.
DISPLAY FEATURES
•Analog RGB Sync On Green (SOG) Capable
•HDMI Digital Input Signal Capable
•VESA 75/100 Standard Mounting –Specific Models.
•DDC2B Plug & Play
•Universal Power Supply with VESA Power Management
•User Friendly OSD interface
•High Brightness and Contrast
•Wide Viewing Angle
•Front Remote Controls on Specific Models
•Tilt and Swivel Base on Specific Models
•Heavy Duty Cold Roll Steel Chassis on Specific Models
DISPLAY OPTIONS
•RS-170A and RS-343 Video Signal Capable (Interlace Formats)
•TTL Input for EGA, CGA and MDA Timings
•RCA (NTSC/PAL) and Composite Video
•3/4/5 Wire BNC Inputs
•Universal Video Input Box
•Wireless Remote Control
•Anti-Reflective Protective Faceplate
•Touch Screen Option: Resistive, Capacitive and SAW (Surface Acoustic Wave)
•Differential Video Input Options for long cable lengths and/or high-noise factory environments

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #5 of 26
UNPACKING THE MONITOR
Your LCD monitor package will consist of the following components listed on the section below. Open shipping
container and lay all the components on a flat clean surface. If any component is missing, please contact Dynamic
Displays as soon as possible.
NOTES:
•We recommend you keep the packing box for transportation.
•In case of transporting and packing the unit in the packing box, carefully place it, in the packing box keeping
its panel from touching any objects
PRODUCT SAFETY PRECAUTIONS
Read all these instructions and save this manual for later use. Follow all warnings and instructions on the product.
These safety instructions must be followed to ensure your safety and prevent property damage.
•Do not cover or block the ventilation holes in the enclosure.
•Do not insert sharp objects or spill liquid into the monitor through the cabinet slots. This may cause
accidental fire, electric shock or failure.
•Unplug the unit when not in use for an extended period of time.
•Do not attempt to service this product yourself, since opening or removing the cover may expose you to
potential electric shock. Only a qualified technician should service this product.
PACKAGE CONTENTS
Before operating this monitor, please make sure that all items listed are present in your package:
•LCD Monitor
•AC/DC Adapter
•AC Power Cord
•VGA Cable
•User’s Manual
CONNECTING THE MONITOR
No tools are required to install the LCD monitor. Simply follow the instructions outlined in the next few steps.
Connectors for the signal and power are located on the back panel.
•Connect Signal Cable (VGA): Attached the VGA cable connector with the ferrite bead closest to it to the
graphics card adaptor on your computer system and attached the other end to the monitor. Be cautious in
inserting the cable properly into both connectors. If the cable does not fit it may be facing the wrong
direction. Turn the cable over and try to match the shape of the connector with that of the graphics adapter.
•Connect Power Adapter and Cable: Connect the round shape plug end of the AC/DC adapter to the DC
Power input connector of the LCD monitor. Connect the female end of the power cable to the AC power
input receptacle on the AC/DC adapter. Then plug the male end of the power cable into an AC outlet.

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #6 of 26
•Connect HDMI (High-Definition Multimedia Interface) Cable (Optional): If you have a DVI digital graphics card
adapter and a DVI cable, connect it to the DVI (IN) connector of the monitor. The optional DVI graphics
adapter and the DVI cable can be ordered by contacting Dynamic Displays.
•Connect Audio signal Cable (Optional): Connect Audio In connector of the LCD monitor and an Audio Out
device (PC. DVD, CD) with the attached stereo mini cable.
•Connect Touch Screen Cable (Optional): Connect the optional USB or RS 232 serial touch screen connection
to the driver card or system driving the touch screen controller.
•Turn ON your monitor and system. If your monitor displays an image, installation is complete. If it does not
display an image, please refer Troubleshooting.
If your computer was off, turn on your computer/system. Your display should now operate as a normal computer
display showing your windows or whatever video is being sent to the flat panel.
Note: If for any reason the display has a “Blue Screen” with a message “Out of Range” or “No Input Signal”, your
system source is putting out a signal that is out of range or non compatible with the LCD’s video A/D board. If
this happens, make sure you are inputting the correct signal. If the display doesn’t work properly, it may be
because:
•The resolution is too high or low for the LCD.
•The power source is incorrect.
MONITOR SETUP
Unlike CRT displays, the LCD panel has a fixed pixel format over a set area. So for best performance, the “native
resolution” setting is always recommended. Use the following notes as a reference to setup your display.
•8.4”, 10.4” and 12.1” monitors: The native resolution of the LCD panel is 800 X 600; Recommended
resolution is 800 X 600 @ 60 KHZ
•14.1” and 15” monitors: The native resolution of the LCD panel is 1024 X 768; Recommended resolution is
1024 X 768@ 60 KHZ
•17” and 19” monitors: The native resolution of the LCD panel is 1280 X 1024; Recommended resolution is
1280 X 1024 @ 60 KHZ or 1024 X 768 @ 60 Hz.
•24” Monitors: The native resolution of the LCD panel is 1920 x 1200; Recommended resolution is 1920 x
1200 @ 60 or 75 Hz.
RELATED DOCUMENTS:
•0046115 17C3 A/D MCU RE-PROGRAMMING PROCEDURE

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #7 of 26
SIGNAL INPUT CONNECTIONS
Following are the pin out descriptions for the standard and optional connectors provided on the monitor:
VGA HIGH DENSITY HD15 CONNECTOR PIN OUT
FEMALE BNC’S TO HD15 ADAPTOR CABLE (OPTIONAL)
BNC to HD15 Adaptor Connections
Video Signal Input
Available
Signal Description
Red
Green
Blue
Horz.
Sync or
C-Sync
(Gray
Cable)
Vertical
Sync
(Black
Wire)
Sync on Green
(SOG)
Composite Sync: Horizontal and
Vertical Sync signals are on the
Green Video Signal.
Connect
Connect
Connect
Composite Sync
(C-Sync)
Separate Composite Sync: Horizontal
and Vertical Sync signals are on the
Horizontal Sync Cable only.
Connect
Connect
Connect
Connect
Separate
Horizontal and
Vertical Sync
Separate Sync: Both signals
(Horizontal & Vertical) are on
individual cables as identified on the
chart.
Connect
Connect
Connect
Connect
Connect
PIN ASSIGNMENTS FOR VGA VIDEO HD15 INPUT CONNECTOR
PIN
CONNECTION
PIN
CONNECTION
1
RED VIDEO
9
KEY/PWR
2
GREEN VIDEO
10
GND
3
BLUE VIDEO
11
ID0/RES
4
ID2/RES
12
ID1/SDA
5
GND
13
HORIZONTAL SYNC
6
RED_RTN
14
VERTICAL SYNC
7
GREEN_RTN
15
ID3/SCL
8
BLUE_RTN

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #8 of 26
HDMI (HIGH DEFINITION MULTIMEDIA INTERFACE) CONNECTOR PIN OUT
DVI (DIGITAL VISUAL INTERFACE) CONNECTOR PIN OUT
S- VIDEO 4 PIN CONNECTOR (OPTIONAL).
PIN ASSIGNMENTS FOR HDMI INPUT CONNECTOR
HDMI TYPE A RECEPTABLE
PIN
CONNECTION
PIN
CONNECTION
1
TMDS DATA2+
11
TMDS CLOCK SHIELD
2
TMDS DATA2 SHIELD
12
TMDS CLOCK−
3
TMDS DATA2-
13
CEC
4
TMDS DATA1+
14
RESERVE (HDMI 1.0-1.3A)
5
TMDS DATA1 SHIELD
15
SCL
6
TMDS DATA1-
16
SDA
7
TMDS DATA0+
17
GND
8
TMDS DATA0 SHIELD
18
+5 V (UP TO 50MA)
9
TMDS DATA0-
19
HOT PLUG DETECT
10
TMDS CLOCK+
PIN ASSIGNMENTS FOR DVI INPUT CONNECTOR
PIN
CONNECTION
PIN
CONNECTION
1
TMDS DATA 2−
16
HOT PLUG DETECT
2
TMDS DATA 2+
17
TMDS DATA 0−
3
TMDS DATA 2/4 SHIELD
18
TMDS DATA 0+
4
TMDS DATA 4−
19
TMDS DATA 0/5 SHIELD
5
TMDS DATA 4+
20
TMDS DATA 5−
6
DDC SCL
21
TMDS DATA 5+
7
DDC SDA
22
TMDS CLOCK SHIELD
8
ANALOG VERTICAL SYNC
23
TMDS CLOCK+
9
TMDS DATA 1−
24
TMDS CLOCK−
10
TMDS DATA 1+
C1
ANALOG RED
11
TMDS DATA 1/3 SHIELD
C2
ANALOG GREEN
12
TMDS DATA 3−
C3
ANALOG BLUE
13
TMDS DATA 3+
C4
ANALOG HORIZONTAL SYNC
14
+5 V
C5
ANALOG RETURN GND
15
GND
PIN ASSIGNMENTS FOR S-VIDEO INPUT CONNECTOR
MINI-DIN 4
PIN
CONNECTION
1
GND (Y)
2
GND (C)
3
Y INTENSITY (LUMINANCE)
4
C COLOR (CHROMINANCE)

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #9 of 26
CGA 9 PIN D-SUB CONNECTOR (OPTIONAL)
EGA 9 PIN D-SUB CONNECTOR (OPTIONAL)
MDA 9 PIN D-SUB CONNECTOR (OPTIONAL)
PIN ASSIGNMENTS FOR 9 PIN OPTIONAL CGA COLOR GRAPHICS
ADAPTER - VIDEO TYPE: TTL
D-SUB9 FEMALE CONNECTOR
PIN
CONNECTION
DESCRIPTION
1
GND
GND
2
N/C
GND
3
RED
RED VIDEO (TTL)
4
GREEN
GREEN VIDEO (TTL)
5
BLUE
BLUE VIDEO (TTL)
6
INT.
INTENSITY (TTL)
7
RES
RESERVED
8
HSYNC
HORIZONTAL SYNC
9
VSYNC
VERTICAL SYNC
PIN ASSIGNMENTS FOR 9 PIN OPTIONAL EGA ENHANCED
GRAPHICS ADAPTER. - VIDEO TYPE: TTL
D-SUB9 FEMALE CONNECTOR
PIN
CONNECTION
DESCRIPTION
1
GND
GND
2
SR
SECONDARY RED (TTL)
3
PR
PRIMARY RED (TL)
4
PG
PRIMARY GREEN (TTL)
5
PB
PRIMARY BLUE (TTL)
6
SG/I
SECONDARY GREEN /
INTENSITY (TTL
7
SB
SECONDARY BLUE (TTL)
8
HSYNC
HORIZONTAL SYNC
9
VSYNC
VERTICAL SYNC
Pin Assignments for 9 Pin Optional MGA –Hercules Monochrome
Graphics Adapter - Video Type: TTL
D-SUB9 FEMALE CONNECTOR
PIN
CONNECTION
DESCRIPTION
1
GND
GND
2
N/C
GND
3
N/C
No Connection
4
N/C
No Connection
5
N/C
No Connection
6
I
Intensity
7
M
Monochrome Video (TTL)
8
HSYNC
Horizontal Sync
9
VSYNC
Vertical Sync

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #10 of 26
Card Edge 10 Pin Connector:
Touch Screen 9 Pin D-Sub connector, Serial Port (Optional).
Pin Assignments for 9 Pin Optional Touch Screen
PIN
CONNECTION
DESCRIPTION
1
CD
Carrier Detect
2
RDX
Receive Data
3
TXD
Transmit Data
4
DTR
Data Terminal Ready
5
GND
System Ground
6
DSR
Data Set Ready
7
RTS
Request to Send
8
CTS
Clear to Send
9
RI
Ring Indicator
Card Edge 10 Pin - Video Type: TTL or Analog
PIN
CONNECTION
DESCRIPTION
1
GND
System GND
2
N/C
Ext. Brite Control
3
N/C
Ext. Brite Control
4
N/C
Ext. Brite Control
5
N/C
Video Highlight
6
H
Horizontal Sync (TTL)
7
M
+12 VDC
8
HSYNC
Video Input (Analog or TTL)
9
VSYNC
Vertical Sync (TTL)
10
GND
System Ground

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #11 of 26
OSD CONTROLS & FUNCTIONS
The OSD interface is composed of 7 membrane switches (as shown below) and a Bi-color LED. All the adjustments
required for the monitor are done through these buttons which interface with the Menu selections on the OSD.
MENU OPERATING INSTRUCTIONS:
Your LCD monitor allows you to easily adjust the characteristics of the image being displayed. All these adjustments
are made using the OSD control buttons on the front or rear of the monitor. While you use these buttons to adjust
the controls, the OSD shows you their numeric values as they change.
MENU OSD CONTROL BUTTONS:
•Source: Input Video Source Selection.
•MENU: Activates OSD Screen or Return to previous menu.
•Left (-) / ◄: Moves selection to left or decreases function value.
•Right (+) / ►: Move selection to right or increase function value. Enter (OK)
•UP / ▲: Increase value.
•DOWN / ▼: Decreases value.
•LED: Green Light: Power ON
Orange Light: Power Saving or No Input Signal
•POWER: Power ON/OFF control. The monitor will enter into Auto Setup the first time the unit is first
turned on.
The monitor will enter “Auto Setup” automatically the first time the unit is first turned on. This option can be
disable, see “PC Setting” section “Auto Adjust Enable”).

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #12 of 26
INPUT VIDEO OPTIONS SELECTION;
•VGA1: Select VGA input connector, HD15.
•VGA2: Option. Set to Active on “Factory Settings Mode”.
•HDMI1: Select Digital Input Connector, HDMI1.
•HDMI2: Option. Set to Active on “Factory Settings Mode”.
•AV: Selects Composite Video Connector, RCA Jack.
•Component: Selects S-Video Input Connector.
•USB
OSD INTERFACE BUTTONS FUNCTION:
•Input Button: Push this button, to select the video input signal (VGA1, VGA2, HDMI1, HDMI2, AV,
Component, USB). With the adjust buttons▲or ▼, highlight the input required; then with the adjust
buttons ◄(-) or ►(+) confirm the selection.
•Menu button: Opens the OSD menu. Also used to exit the OSD menu or confirm adjustment settings and
return to the previous menu.
•Adjust Buttons: ◄(-), ►(+): These buttons have various functions.
oThey are used to navigate through the items on the OSD from left to right or right to left.
oThey are used to select menu item to be adjusted.
oThey are used to adjust the value of the menu item.
oThey are used to confirm the selection of the video input signal source.
oThey are used to increase or decrease the volume of the speakers.
•Adjust Buttons: ▲, ▼: These buttons used to navigate the OSD menu items from top to bottom or bottom
to top.
•Power Button: Push this button to turn the unit on or off.
MEMBRANE DIRECT KEYS ADJUSTMENTS:
➢Left/Right Key Brightness:
➢UP/Down Key Contrast:

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #13 of 26
OSD STRUCTURE
1. Picture
a. Picture Mode (Picture Quality):
b. Standard (Color: 50; Sharp 50; Tint 50)
i. Soft (Color: 40; Sharp 50; Tint 50)
ii. User (Color: 50; Sharp 50; Tint 50)
iii. Vivid (Color: 50; Sharp 60; Tint 60)
c. Brightness: Increases or decreases the brightness of the image.
d. Contrast: Increases or decreases video gain of the image.
e. Color: Only Available on AV/Component Video
f. Sharpness: Adjust picture sharpness. Only Available on AV/Component Video
g. Hue; Only Available on AV/Component Video
h. Color Temperature: Allows the user to adjust for desire White Color Balance to a predetermined
temperature colors or individual Red, Green and Blue Controls.
i. Warm: Recall Warm Color Temperature from EEPROM (6500K).
ii. Medium: Recall Medium Color Temperature from EEPROM (7500K).
iii. Cool: Recall Cool Color Temperature from EEPROM (9300K).
iv. User: When selecting “USER” you may adjust each individual color one at a time
1. Red: Allows the user to adjust the Red gain.
2. Green: Allows the user to adjust the Green gain
3. Blue: Allows the user to adjust the Blue gain.
i. Aspect Ratio (The following aspect ratio descriptions are based on a landscape format):
Note: The aspect ratio of a monitor, is a proportional representation expressed as two distinct numbers
separated by a colon. In the case of monitors, the aspect ratio describes the correlation between width
and height.

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #14 of 26
i. Full: Image is scale to fill LCD screen completely.
ii. UnderScan: Image is programmed to be approximately 10% smaller than “Full Screen”.
iii. PointToPoint: Screen image size represents the actual video input format resolution.
iv. Panorama: LCD screen is scale to 16:9 screen aspect ratio.
v. Zoom 2: Image is programmed to be approximately 20% larger than “Full Screen”.
vi. Zoom 1: Image is programmed to be approximately 10% larger than “Full Screen”.
vii. 4:3: The Horizontal size is maximized, and the vertical size is programmed to have the 4:3 ratio.
viii. 1:1: The vertical size is maximized, and horizontal size is programmed to be the same size as
vertical size.
j. 3D NR: Only Available on AV/Component Video
3-Dimensional Noise Reduction
i. Off
ii. Low
iii. Middle
iv. High
v. Default
k. MPEG NR: Only Available on AV/Component Video
Cleans up block noise around outlines and mosquito noise on the background.
i. Off
ii. Low
iii. Middle
iv. High
v. Default

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #15 of 26
2. Sound
a. Sound Mode
i. Standard
ii. Music
iii. Movie
iv. Sports
v. User
b. Treble: 0 to 100
c. Bass: 0 to 100
d. Balance: (-)50 to (+)50
e. Volume: 0 to 100
3. Option
a. OSD Language: Select the OSD language.
i. English
ii. Chinese

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #16 of 26
iii. France
iv. Deutsch
v. Japanese
vi. Español
b. OSD H Pos: Adjust the horizontal position of the OSD.
c. OSD V Pos: Adjust the vertical position of the OSD.
d. OSD Timeout: Adjust the OSD timeout.
e. OSD Transparency: In this function, user can adjust the transparency of OSD display.
i. Off
ii. Low
iii. Medium
iv. Hi
f. Restore Factory Default: Restore to factory settings
4. PC; (Available only VGA1/VGA2)
a. Auto Adjust
b. Horizontal Pos.: Adjusts horizontal screen positioning.
c. Vertical Pos.: Adjusts vertical screen positioning.
d. Clock: Adjust picture Clock to reduce Vertical-Line noise
e. Phase: Phase adjustment; the phase should be adjusted until the screen image is sharp.
f. ADC Tune
g. Auto Adjust Enable: On/Off

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #17 of 26
5. Advance
(Aspect Ratio needs to be set to “Full” to activate this adjustments)
a. H-Position: Adjusts horizontal screen positioning.
b. H-Size: Adjust horizontal screen size.
c. V-Position: Adjusts vertical screen positioning.
d. V-Size: Adjust vertical screen size.
POWER MANAGEMENT (VESA):
VESA DPMS DDC-2B Plug and Play standard is applied to power management control. With “Power Savings”
set to ON (Factory Setting Mode).
Mode
H Sync
V Sync
Video Signal
LED Indicator
Power Consumption
(Nominal)
On
Active
Active
Active
Green
27 Watts (19” LCD Typ.)
Stand-By
Inactive
Active
Active
Amber
<1 Watt (19” LCD)
Suspend
Active
Inactive
Active
Amber
Off
Inactive
Inactive
Active
Amber

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #18 of 26
TROUBLESHOOTING
LCD Pixel Statement - The LCD unit is produced with high-precision manufacturing techniques. Nevertheless, some
pixels may occasionally misfire or appear as black or colored dots. This has no effect on the recorded image and
does not constitute a malfunction.
Normally a 17” SXGA (1280 X 1024) display has nearly 4 million sub-pixels. Industry standard specification allows 8
non-performing pixels on the LCD screen, which is only 0.0002% of the total sub-pixels.
Troubleshooting
Symptom
Suggestion
There Is No Picture on Screen
1. Check the color of the LED indicator on the LCD
monitor.
•“GREEN”: During normal operation the LED
light will be green. If it is green and there is no
picture, contact the customer service line.
•“ORANGE”: Check the connection of the VGA
cable to the monitor and the connection to the
computer.
•“NO POWER”: Make sure the power cord is
securely connected to the adapter and the light
on the adapter is green.
2. The signal cable should be properly connected to
the display card and computer. Try disconnecting
the video cable from the display and connecting to
a known working display (if available) to confirm
the presence of proper video.
3. Check whether the LCD monitor and computer
power cords are connected and whether there is a
supply of power.
4. Make sure the resolution mode is supported by the
display and check settings of the display card.
5. Confirm that the video cable is not defective.
No Signal Input with Blue Screen
Check the signal connection between the computer
and LCD monitor.
Missing Colors
If the red, green or blue colors are missing, check the
signal cable to make sure it is plugged correctly. The
pins in the cable could be loose and cause a bad
connection.
Image Too Bright/Image Too Dark
Adjust brightness and contrast by OSD.
Irregular Image
Check the signal connection between the computer
and LCD monitor.

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #19 of 26
Select “Auto Adjust” button.
Distorted Image
Reset the LCD monitor. (Select “Recall” function by
using OSD)
Image Is Not Centered / Size Is Not
Appropriate
Use OSD Image Menu to adjust H. Position and V.
Position.
Check image size setting.
Select Auto Adjust.
Uneven Color / Color Too Dark / Dark
Area Distorted / White Color Is Not White
Use OSD Color Temperature Menu to adjust color
setting.
No Sound
Check the audio signal cable connection between the
computer and LCD monitor.
Try pressing the “+MUTE” button to disable the volume
Mute function.
* Some models do not have speakers (sound)
The Display Is Dark / Bright Or Saturated
Verify video input levels are appropriate; 0.7VPP for Analog
inputs or 5 VPP for TTL input video signal.
The Display Blinks
Check the signal connection between the computer
and LCD monitor.
Image Blinks On And Off
The timing is special and not programmed in the MCU.
Contact the Sales department at Dynamic Displays, Inc.
800-793-6862.
Hook On Top Of The Image
The LCD monitor needs the Universal Video Input Box.
Contact the Sales Department at Dynamic Displays, Inc.
Dim Image
1. Adjust the brightness and contrast with OSD.
2. The timing is special and not programmed in
the MCU. Contact the Sales Department at
Dynamic Displays.
3. Flat Panel may have come unplugged from
inverter.
4. Lamp in Flat Panel may have failed.
* Contact Dynamic Displays, Inc. and return unit for
repair if suggestion 1 or 2 does NOT fix the Dim
Image.
Lines Missing Or Not Displaying On Top Or
Bottom Of The Image
The timing is special and not programmed In the MCU.

Dynamic Displays, Inc. User Manual Doc: 0048070
1625 Westgate Road 17C3 A/D Series Rev 2
Eau Claire, WI 54073 Glee 17C3 Page #20 of 26
Contact the Sales department at Dynamic Displays, Inc.
800-793-6862.
Characters Missing On Left Or Right Of
The timing is special and not programmed In the MCU.
Contact the Sales department at Dynamic Displays, Inc.
800-793-6862.
CLEANING INSTRUCTIONS
•When cleaning, unplug the AC adapter from the LCD display and outlet for safety.
•Lightly wipe dirt from the cabinet and LCD panel surface with a clean lint-free cloth soaked in a neutral cleaning
solution. This removes dust and other particles that can scratch the screen
•Treat the LCD panel with care. Do not rub the LCD panel surface with a rough item or hit it on the surface.
Also, do not strongly press the LCD panel surface. This can lead to unevenness in the screen and also
failure of the product.
•Cleaners recommended for the LCD panel are isopropyl alcohol (without abrasive), non-ammonic glass
cleaner, and watered-down neutral cleaning solution. Do not use organic solvent such as acetone and
toluene.
•Do not use thinner, benzine, alcohol or such on the plastic cabinet. These can damage the cabinet, alter its
quality and cause the paint to peel off.
•Do not apply insecticides and other volatile items to the cabinet. Also do not leave rubber and vinyl products or
such in contact with it for long hours. This can cause the surface quality to alter and the paint to peel off.
