Tynetec ZXT315 User manual

DocNo.FM0665issueD Page1
Adventxt(2013)
WardenCallSystem

______________________________________________________________________________________________________________
UserGuide
ZXT315MANAGER’SDISPLAYPANEL



Tynetecoperatesapolicyofcontinualproductimprovementand
reservestherighttomodifythespecificationofitsproducts.

Ifanyvariationtothedetailsinthisdocumentaresuspectedplease
contactTynetec’sTechnicalSupporton01670352371.
Tynetec,abusinessunitofLegrandElectricLtd
Unit10CowleyRoad,BlythRiversideBusinessPark,Blyth
Northumberland,NE245TF.Tel:01670352371Fax:01670362807
Email:[email protected]Web:www.tynetec.co.uk

DocNo.FM0665issueD Page2
INDEX
SectionTopicPage

1WelcomeScreen3
2SystemScreen 4
3EventLog 5
4InactivityStatus6
4.1IntercomPrivacyStatus 7
4.2I’mOKStatus8
4.3HandsetPrivacyStatus9
5SchemeManagerLogOn10
5.1AddaRadioDevice11
5.2RemoveaRadioDevice 12
5.3ChangePassword13
6EngineerLogOn14
6.1ChangeFlatLabels 15
6.2ChangeTelephoneNumbers 16
6.3ChangeSiteName17
6.4ClosetheApplication17
6.5CalibratetheTouchscreen18
7MemoryCardManagement18
7.1ArchivingMemoryCardData18
7.2FormattingtheMemoryCard19
8Specification20



DocNo.FM0665issueD Page3
1.WELCOMESCREEN
Afewsecondsafterpower‐uptheWelcomescreenwillbedisplayed;


















PanelStatus:OnlinewillbedisplayedwhenconnectionismadetotheAdventxtsystem

TheTimeandDateissetfromtheAdventxtsystem

Thebuildingnamee.g.HOLLYCOURTcanbesetupintheEngineersutility

TouchthebuttontoselecttheEngineersutility‐seesection6

TouchthebuttontoselecttheSchemeManagersutility‐seesection5

Touchthetabsalongthetopofthescreentoselect;

System–displaysthecurrentsystemstatus‐seesection2

EventLog–displaysthehistoryofeventsforachosendate‐seesection3

Inactivity1to30–displaystheactivitystatusofallflats‐seesection4

IntercomPrivacy1to30–displaystheprivacystatusofallwardencallintercoms‐seesection4.1

I’mOK1to30–displaystheI’mOKstatusofallflats‐seesection4.2

HandsetPrivacy1to30–displaystheprivacystatusofalldoorentrytelephones‐seesection4.3





Anyoneofthese4tabsmaybeshown(dependingonwhichwasviewedlast)andthe
numberrange(e.g.1to30)willcorrespondwiththenumberofflatsinyourscheme




EngineerLogOn
SchemeManagerLogOn

DocNo.FM0665issueD Page4
2.SYSTEMSCREEN
TouchtheSystemtabandthescreenwilldisplay;

















TheSystemStatus:windowwilldisplaythecurrentoperatingmodeas;Onsite,LocalOffsiteor
RemoteOffsite,ifthere’sanyFaultsonthesystemandifthere’saCallinProgress

TheCurrentAlarmwindowwilldisplaytheCallinProgressinlargereddigitse.g.0006

Ifthecallisfromazonedpendant,theresidentsflatandzonewillbedisplayede.g.0006Z02

3buttonsareusedtoselecttheoperatingmode;thecurrentmodewillbegreene.g.

Touchthe  or   buttonstochangetheoperatingmode

YouwillbepromptedforaPasswordtochangetheoperatingmode;

Enterthepassword(default1234)thentouch(tochangethepasswordseesection5)

TheSystemEventslistwillshowthelast100events,usethesliderbartoscrollup/downthelist

SetthecheckboxtopreventTelecaresensoractivityfillinguptheSystemEventslist

ClearthecheckboxtoallowTelecaresensoractivityintheSystemEventslist

Touchthe  buttontocleartheSystemEventslist




YoucannotchangetheoperatingmodeifthereisaCallinProgress
ClearingtheSystemEventlistdoesnotcleartheEventLog


On Site
Local Offsite Remote Offsite
Clear Events
Log On

DocNo.FM0665issueD Page5
3.EVENTLOG
TouchtheEventLogtabandthescreenwilldisplay;


















TouchthebuttonontheFrom:dateboxandacalendarwindowwillopen

Selectayear,monthanddayfromthecalendarwindowthentouchthebutton

Alleventsforthechosendaywillbelisted

Usethesliderbartoscrollup/downthelist




Eventsarelistedintimeorder‐thefirsteventofthedayisatthetopofthelist


















Show Events


DocNo.FM0665issueD Page6
4.INACTIVITYSTATUS
TouchtheInactivitytabandthescreenwilldisplay;

















Thisshowstheflatswheretheresidentsare“upandabout”eachday
Upto3activitymonitoringperiodscanbesettorepeateachday

Aredspot=NOACTIVITY

Agreenspot=ACTIVITY




RefertotheAdventxtuserguideforinstructionsonhowtosetupactivitymonitoring






















DocNo.FM0665issueD Page7
4.1INTERCOMPRIVACYSTATUS

Touchthebuttonandthescreenwilldisplay;


















ThisshowswhichflatshaveprivacymodeselectedontheAdventxtintercom

Aredspot=PRIVACYON

Agreenspot=NORMAL(privacyoff)




Whenintercomprivacyisontheresidentcanhearyoubutyoucannothearthem





















Intercom Privacy

DocNo.FM0665issueD Page8
4.2I’MOKSTATUS
Touchthebuttonandthescreenwilldisplay;


















Thisshowswhichflatshaveresponded“I’mOK”eachday

Aredspot=NORESPONSE(notOK)

Agreenspot=I’MOK




RefertotheAdventxtuserguideforinstructionsonhowtosetuptheI’mOKfeature





















I’m OK

DocNo.FM0665issueD Page9
4.3HANDSETPRIVACYSTATUS

Touchthebuttonandthescreenwilldisplay;













Thisshowswhichflatshaveprivacymodeselectedonthedoorentrytelephonehandsets

Aredspot=PRIVACYON

Agreenspot=NORMAL(privacyoff)





Ifaflathas2doorentryhandsetsbothmustbeinprivacytoshowonscreenasprivacymode
Whenhandsetprivacyisontheresidentwillnotgetcallsfromvisitorsattheentrancedoor





















Handset Privacy

DocNo.FM0665issueD Page10
5.SCHEMEMANAGERLOGON
FromtheWelcomescreentouchthebuttonandthescreenwilldisplay;
















Enterthepassword(default1234)thentouchandthescreenwilldisplay;


















Seesection5.1toaddaRadioDevice

Seesection5.2toremoveaRadioDevice

Seesection5.3toChangePassword






SchemeManagerLogOn
Log On
