HIS HIS-ML19 H Series User manual

19" PANEL MOUNT INDUSTRIAL MONITOR
USER MANUAL
Model No. HIS-ML19- _ _ _ H
REVISION H

2 ML19H User Manual, 99154B, November 2022
Table of Contents
Safety and Regulatory Information��������������������������������������������������������������������������������3
FCC Notice �����������������������������������������������������������������������������������������������������������������������������3
Hazardous Locations ��������������������������������������������������������������������������������������������������������������4
Waste Electrical and Electronic Equipment Directive (WEEE) ����������������������������������������������� 4
Mechanical Drawings������������������������������������������������������������������������������������������������������5
Front and Side Views��������������������������������������������������������������������������������������������������������������5
Bottom View����������������������������������������������������������������������������������������������������������������������������5
Rear View �������������������������������������������������������������������������������������������������������������������������������6
Installation Instructions��������������������������������������������������������������������������������������������������7
Step 1: Prepare for Installation ���������������������������������������������������������������������������������������������� 7
Step 2: Bench-test Conguration������������������������������������������������������������������������������������������� 8
Connect Video and Power Cables ����������������������������������������������������������������������������������������������������� 8
Connect and Set Up Touch Screen�������������������������������������������������������������������������������������������������� 10
Step 3: Install into Panel ������������������������������������������������������������������������������������������������������ 12
Video Settings����������������������������������������������������������������������������������������������������������������14
Setting the Timing Mode ������������������������������������������������������������������������������������������������������� 14
Control Panel Buttons����������������������������������������������������������������������������������������������������������� 15
OSD and Power Lock Settings ��������������������������������������������������������������������������������������������� 16
On-Screen Display (OSD) Menus����������������������������������������������������������������������������������������� 17
Auto Image Adjust Menu ������������������������������������������������������������������������������������������������������������������ 18
Contrast / Brightness Menu�������������������������������������������������������������������������������������������������������������� 18
Input Select Menu ���������������������������������������������������������������������������������������������������������������������������� 18
Color Adjust Menu���������������������������������������������������������������������������������������������������������������������������� 19
Information Menu ����������������������������������������������������������������������������������������������������������������������������� 20
Manual Image Adjust Menu�������������������������������������������������������������������������������������������������������������� 20
Setup Menu�������������������������������������������������������������������������������������������������������������������������������������� 22
Memory Recall Menu ����������������������������������������������������������������������������������������������������������������������� 22
Cleaning Instructions����������������������������������������������������������������������������������������������������23
Troubleshooting ������������������������������������������������������������������������������������������������������������24
Video Troubleshooting ����������������������������������������������������������������������������������������������������������24
Touch Screen Troubleshooting ��������������������������������������������������������������������������������������������� 26
Specications ����������������������������������������������������������������������������������������������������������������27
Display ����������������������������������������������������������������������������������������������������������������������������������27
Physical ��������������������������������������������������������������������������������������������������������������������������������27
Video�������������������������������������������������������������������������������������������������������������������������������������28
Functional �����������������������������������������������������������������������������������������������������������������������������28
Electrical �������������������������������������������������������������������������������������������������������������������������������29
Environmental����������������������������������������������������������������������������������������������������������������������� 29
Compliances and Certications �������������������������������������������������������������������������������������������� 30
Warranty Statement�������������������������������������������������������������������������������������������������������31

Safety and Regulatory Information
ML19H User Manual, 99154B, November 2022 3
To prevent re or shock hazard, do not expose live components to rain or moisture.
Dangerously high voltages are present inside the unit� Do not disassemble the
unit. Refer servicing to qualied personnel only. Operator could be exposed to
dangerously high voltage if AC power is not connected properly� Verify all wiring is
properly connected�
This equipment is not intended for use in critical applications where its failure
to operate would create immediate life threatening circumstances� Applications
including, but not limited to, nuclear reactor control, aerospace navigation systems
and life support systems are not appropriate for this product�
This product is intended to be mounted in a suitable cabinet or other enclosure�
The NEMA 4, 4X, or 12 ratings are applicable only when properly installed in a like
rated enclosure�
To be covered by UL 62368-1, the socket-outlet shall be installed near the equipment
and shall be easily accessible�
DC Supplied Units only: The HIS-ML19 subject unit is to be powered by a Listed
Power Supply suitable for the application with outputs at SELV/LPS or Class 2 levels
rated 9.6-36.6VDC, 2.5 A max. The equipment is not intended to connect directly to
a DC Mains source�
FCC Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications� Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense. Any changes or modications not
expressly approved by the grantee of this device could void the user’s authority to operate
the device�
Safety and Regulatory Information
WARNING!
!

Safety and Regulatory Information
4 ML19H User Manual, 99154B, November 2022
Waste Electrical and Electronic Equipment Directive (WEEE)
The following information is only for EU-member states:
The mark shown to the right indicates compliance with the Waste Electrical and
Electronic Equipment Directive 2002/96/EC (WEEE)�
The mark indicates the requirement NOT to dispose of the equipment as unsorted
municipal waste, but use the return and collection systems according to local law. Users
should contact their supplier and check the terms and conditions of the purchase contract�
When purchased directly from Hope Industrial Systems, you may contact technical support
for disposal arrangements.
Hazardous Locations
This equipment is suitable for use in Class I, Division 2, Groups A, B, C, and D; Class II,
Division 2, Groups F and G; Class III; or non-hazardous locations only�
Device is open-type and is to be installed in an enclosure suitable for the environment that
is only accessible with the use of a tool�
FR: Cet équipement peut être utilisé dans la Classe I, Division 2, Groupes A, B, C et
D: Classe II, Division 2, Groupes F et G; et Classe III, endroits hasardeux ou endroits
non-hasardeux seulement� Cet appareil doit être installé dans un enclos adapté à un
environnement accessible uniquement avec l’aide d’un outil.
WARNING – EXPLOSION HAZARD – Do not disconnect equipment unless power has
been removed or the area is known to be non-hazardous�
WARNING – EXPLOSION HAZARD – Substitution of any components may impair
suitability for Class I, II & III, Division 2 Locations�
Any steps marked with this symbol are required to ensure compliance with Class I,
II, III, Division 2 Hazardous Location requirements�
HAZ
LOC

Mechanical Drawings
ML19H User Manual, 99154B, November 2022 5
Mechanical Drawings
Front and Side Views
Bottom View
329.3 mm
(12.97")
7.1 mm
(0.28")
398.8 mm
(15.70")
482.6 mm
(19.00")
376 mm
(14.8")
301 mm
(11.9")
60.9 mm
(2.40")
409.8 mm
(16.14")
482.6 mm
(19.00")
7.1 mm
(0.28")
(Design to maximum depth
of 69.0 mm to ensure future
compatibility with later revisions
and replacement units.)

Mechanical Drawings
6 ML19H User Manual, 99154B, November 2022
Rear View
100 mm VESA
Mounting Pattern
(M4 screws provided,
16 mm maximum
depth of screw)

Installation Instructions
ML19H User Manual, 99154B, November 2022 7
Installation Instructions
Step 1: Prepare for Installation
IMPORTANT!
Perform the following steps BEFORE installation of the monitor into the panel.
1� Ensure that sucient power is available.
2� Ensure that sucient space is available to allow for proper air ow into and out of the
unit�
3� Ensure that the air temperature around the unit (top and bottom) will not exceed the
rated specications of the unit.
fThe maximum rated temperature for the HIS-ML19 is 50°C (122°F).
fRemember that heat rises – the temperature at the top of the
cabinet will be much hotter than at the bottom if air inside the
enclosure is not actively circulating. Even in a sealed enclosure,
use of a circulation fan can greatly reduce temperature�
fAlso, remember that even though this product is designed to
operate at 50°C, the life span of any electronic device is shortened
when it is consistently operated at high temperatures. Therefore,
it is wise to take steps to keep the temperature of the ambient air
around the unit as low as possible�
4� Ensure that the ambient humidity of the air around the unit does not exceed the
specications of the unit.
fT h e m a x i m u m r a t e d h u m i d i t y f o r t h e H I S - M L 1 9 i s 9 0 %
non-condensing�
!

Installation Instructions
8 ML19H User Manual, 99154B, November 2022
Step 2: Bench-test Conguration
Make sure everything works before installing into the production environment.
TIP!
If using a KVM extender, please refer to the installation instructions included
with the KVM extender module. It is particularly important to bench-test the full
conguration prior to nal installation. This will help to identify and troubleshoot
any system issues while conguration changes may still be easily made.
Connect Video and Power Cables
All monitors are shipped with a standard VGA video cable� AC-powered displays are also
shipped with a power/mains cable� The cable ports are located on the rear of the monitor�
DVI VIDEO
USB
(for Touch Screen option)
SERIAL
(RS-232)
POWER INPUT
VGA VIDEO
Video Connection
The HIS-ML19 supports digital signals (DVI, HDMI, DisplayPort) through its DVI-D port and
analog signals (VGA, RGB) through its VGA port. RGB (BNC, RCA), HDMI, and DisplayPort
video sources require additional adapters�
After selecting the appropriate interface, connect one end of your video cable to the input port
on the rear of the monitor� Secure the screw locks to ensure adequate strain relief� Connect the
other end to the appropriate port on your host computer or other video source�
HAZ
LOC
NOTE: If this step is not performed, the product will not comply with Class I,
II, III, Division 2 Hazardous Location requirements.

Installation Instructions
ML19H User Manual, 99154B, November 2022 9
TIP!
To avoid incompatibility issues, use only certied video adapters available from
Hope Industrial Systems. Many 3rd-party signal adapters are known to cause
signaling issues�
Power Connection
The HIS-ML19 is available with either AC or DC power input.
AC power input models accept 100 to 240 VAC, 1.5/0.75 A, 60/50 Hz. Loosen the retaining clip
for the power cable on the rear of the monitor� Connect the AC power cable to the power input
port on the monitor then retighten the retaining clip. Connect the other end into a nearby outlet.
HAZ
LOC
NOTE: If the retaining clip screw is not tightened, the product will not
comply with Class I, II, III, Division 2 Hazardous Location requirements.
DC power input models accept 9�6 to 36�6 VDC, 2�5 to 0�65 A, Class 2 or SELV/LPS�
1� With main power disconnected, hook up incoming
power wires to the DC input terminal blocks
according to the label markings. Securely tighten
terminal block screws�
2� Plug the connector into the unit and secure by
tightening the two side screws.
HAZ
LOC
NOTE: If steps 1 and 2 are not performed,
the product will not comply with Class I, II, III,
Division 2 Hazardous Location requirements.

Installation Instructions
10 ML19H User Manual, 99154B, November 2022
Connect and Set Up Touch Screen
Applies to touch screen monitors only� If you ordered a touch screen monitor, a USB cable is
supplied for the touch screen interface� To use the touch screen Serial (RS-232) interface, a
serial cable may be ordered separately� Instructions below apply to Windows systems�
Contact Hope Industrial Systems if you require a CD-ROM with documentation and touch screen
drivers. For a full list of downloadable drivers, please check the following address:
https://www�HopeIndustrial�com/support/drivers/
IMPORTANT!
If you will be using a USB connection, install the touch screen driver rst, and then
connect the USB cable. If you will be using a Serial connection, connect the Serial
cable rst, and then install the touch screen driver�
All touch screen models include both USB and Serial (RS-232) ports for touch screen operation,
but only one of these should be connected to the computer� When both ports are available on the
computer, USB is preferred�
Installing the Driver: USB Connections
1� Do not plug the USB connection into the computer until the driver installation is
complete� If the USB connection has already been made, disconnect at this point�
2� Download the appropriate driver for your operating system from the address listed
above� Click to "Run" the software when prompted�
3� Follow the on screen prompts to complete the driver installation�
4� Once the driver has been successfully installed, the USB connection can be made by
inserting the connector through the monitor's integrated cable retention bracket and
into the USB port� Connect the other end to the USB port on the host computer�
5� Proceed with Calibration (below)�
Note: detailed and up-to-date USB driver installation instructions can be found at the
following address:
https://www.hopeindustrial.com/blog/calibrating-a-touch-screen/
Table of contents
Other HIS Industrial Monitor manuals
Popular Industrial Monitor manuals by other brands

Austin Hughes
Austin Hughes RP-F821 user manual

WAGO
WAGO WAGO-PERSPECTO 762 Series Operating and assembly instructions

Advantech
Advantech IDS-3319 Series user manual

Acnodes
Acnodes APH 8064 user manual

Acnodes
Acnodes APW 5400 user manual

Dynamic Displays
Dynamic Displays QES1500 Progressive Series user manual

AXIOMTEK
AXIOMTEK Dk3g4PANEL 6153-O/P user manual

ESA
ESA XM7W7 installation manual

Siemens
Siemens SIMATIC Industrial Flat Panel IFP2200 Product information

Siemens
Siemens INOX PRO SIMATIC IFP1900 Compact operating instructions

Advantech
Advantech IDK-1115WP-45FHA1 user manual

Eaton
Eaton XV-152 Series operating instructions
