dynarex DynaRest Airfloat 300 User manual

WARNING
• Do not use this product or any available optional
equipment without first completely reading
and understanding this instruction manual.
• Do not use the product for any purpose not indicated in
this manual.
• Only qualified personnel trained in the treatment and
prevention of bedsores should operate this device.
• Dynarex declines all liability for any consequences
resulting from incorrect use of this product and from
unauthorized alteration of the product.
• The manufacturer reserves the right to change the
information contained in this document without prior notice.
• Do not allow children to play with or operate the pump
or mattress.
• Never operate this product if it has a damaged cord or
plug, if it is not working properly, if it has been dropped
or damaged, or dropped into water. Return the product
to a service center for examination or repair.
• Keep the unit and cord away from heated surfaces
and liquids.
• Never block the air openings of the product or place it
on a soft surface, such as a bed or couch, where the air
openings may be blocked. Keep the air openings free of
lint, hair and the like.
• Never drop or insert any object into any opening or hose.
• Do not use outdoors.
• Connect this product to a properly grounded outlet only.
INTENDED USE
The DynaRest™Airfloat 300 Air Mattress with Pump is
intended to reduce the incidence of pressure ulcers while
optimizing patient comfort.
PRODUCT FUNCTIONS
Pump
The functions of the pump are described below. Please refer
to the figures of the pump.
(1) Power Switch
• Turn ON/OFF the power, the pump will
start/stop operation.
(2) Pressure Adjust Knob adjustable by patient’s weight
• Turn the Pressure Adjust Knob to set a comfortable
pressure level by using the weight scale as a guide.
(3) Normal Pressure Indicator
• A visible indicator (green) tells the pressure has
reached a preset level.
(4) Low Pressure Indicator
• A visible indicator (amber) warns the pressure is below
a preset level.
(5) Alarm Reset
• The audible/visible alarm turns on when the pressure
is low.
• To mute the audible alarm, press the reset button.
The visible alarm indicator will flash.
• Re-press the reset button to reactivate the alarm.
• The air pressure issue must be corrected in order for
the visible alarm to shut off. Once corrected the
audible/visible alarm function will automatically reset.
Note! In static mode, the mattress provides a
firm surface that makes it easier for the patient
to transfer or reposition. The static mode helps
prevent the patient from bottoming out when in
a sitting position.
(6) Static Control
• Press the Static button to set it in static mode, and the
Static indicator will come on. The static mode will be
started within approximately 6 minutes. Press the Static
button again to switch back to alternating mode.
(7) Air Pressure Valve
• The air pressure valve is located on the left side
of the pump.
• Connect the air tubes securely into the air pressure
valve of the pump.
DynaRest™Airfloat 300
Air Mattress with Pump
564
1
2
7
3
Mattress
(1) Pillow
(2) Cover
(3) Fixing belt
(4) Low air loss holes
(5) Male quick connector
(6) Protective cap of connector
(7) Air tubing
(8) CPR valve
USER MANUAL
Reorder No. 10442
Pump
(1) Power switch
(2) Pressure adjust knob
(3) Normal Pressure Indicator (green)
(4) Low Pressure Indicator (amber)
(5) Alarm Reset
(6) Static Control
(7) Air Pressure Valve

Pump
Power supply: 120V/60Hz,1A
Air output: 8 liter/min.
Pressure range: 30 mmHg – 60 mmHg
Cycle time: 10 min. alternating cycle
Static Mode
Alarm Reset Mode
With normal / low pressure light
Size: 11″(L) × 8″(W) × 4″(H)
Weight: 4.8 lb.
Size: 80″(L) × 35″ (W) × 8″ (H)
Top cover: Quilted cover with zipper
Air cells: Nylon / PVC
Base: Nylon / PVC
20 air cells
CPR valve for emergency procedures
Pillow function
Quick connectors
Mattress
OPERATING INSTRUCTIONS
• Place pump on a horizontal surface or hang it by the hooks
on the back of the unit.
• Open mattress on the bed. Air tubes must be at foot end
of bed.
• Connect air tubes securely into the air pressure valve of
the pump. Ensure that the tubes are airtight and not
kinked or twisted. Allow space for the bed rails to
drop freely.
• Plug unit into an outlet. Turn on the pump power. The
indicator of the power switch will come on. The pump starts
to pump air into the mattress.
• The Low Pressure indicator (amber) will come on while the
mattress is inflating.
• For first inflation, we recommend that you press the Static
button to quickly inflate the mattress.
• When the pressure reaches the preset level within
approximately 30 minutes, the Normal Pressure indicator
will come on, and the Low Pressure indicator will turn off.
• Turn the Pressure Adjust Knob to set a comfortable
pressure level from soft to firm.
TECHNICAL SPECIFICATIONS
ENVIRONMENT REQUIREMENTS
• Operation Temperature: 50°F~95°F (10°C~35°C).
• Storage Temperature: 5°F~122°F (-15°C~50°C).
• Operation Humidity: 20%~80% non-condensing.
• Storage Humidity: 10%~90% non-condensing.
CONTROL UNIT & MATTRESS MAINTENANCE
In this section, we describe the procedures to clean and
decontaminate the control unit and mattress. It is important
to follow these procedures before using the system again.
The cleaning task is required at least once a week to
maintain personal hygiene.
• Can be cleaned by wiping with disinfectant solution.
• Do not immerse the control unit in liquids.
• Do not heat or steam in autoclave.
• The mattress and cover should be aerated to fully dry.
WARRANTY
Your Dynarex DynaRest™ Airfloat 300 is warrantied to be
free of defects in materials and workmanship for One (1)
year on Pump and for Ninety (90) days on the Air Mattress,
from original date of purchase, for use by the original
consumer purchaser. This item was built to exacting
standards and carefully inspected prior to shipment. This
Warranty is an expression of our confidence in the materials
and workmanship of our products and our assurance to the
consumer of dependable service.
The Warranty shall not apply under the following conditions:
problems arising from normal wear; problems arising from
failure to adhere to the product instructions; problems
arising from misuse, negligence, accident or improper
operation, maintenance or storage; problems arising from
modifications or unauthorized repairs, parts or attachments;
products where the serial number has been removed or
defaced; Problems with non-durable components, such as
rubber accessories, casters, and grips, which are subject to
normal wear and need periodic replacement Dynarex shall
not be liable for any consequential or incidental damages
whatsoever. Dynarex shall repair or replace defective
products at its option. The foregoing warranty is exclusive
and in lieu of other express warranties, if any, including the
implied warranties of merchantability and fitness of a
particular purpose. The remedy for any violation of the
implied warranty shall be limited to repair or replacement
of the defective product pursuant to the terms
contained herein.
SYMBOL GLOSSARY
For an explanation of symbols
used in Dynarex packaging, visit
dynarex.com/symbols.php
Manufactured for: Dynarex Corporation
10 Glenshaw Street • Orangeburg, NY 10962
USA • www.dynarex.com
Made in China R180518
