Dynatron Solaris 700 Series User manual

DYNATRON SOLARIS®
700 SERIES
SERVICE MANUAL

Dynatron Solaris® 700 Series
ii
CAUTION: Federal law restricts these devices for sale by or on the order of a physician,
chiropractor, physical therapist, or dentist licensed by the law of the state in which said
person practices to use or order the use of the devices.
Risk of burns and fire - Do not use near conductive materials such as metal bed parts, inner
spring mattresses and the like.
DANGER - Explosion Hazard: Do not use in the presence of flammable anesthetics.
IMPORTANT: Before treating a patient with any Dynatron Solaris®Device, see the
“Contraindications, Warnings, and Precautions” in this manual.
INDICATIONS FOR USE
ELECTROTHERAPY:
• Electrical muscle stimulation therapy (Russian, Biphasic, High Volt) for:
1. relaxation of muscle spasm;
2. prevention or retardation of disuse atrophy;
3. increasing local blood circulation;
4. muscle re-education;
5. immediate post surgical stimulation of calf muscles to prevent venous thrombosis
6. maintaining or increasing range of motion.
• Transcutaneous electrical nerve stimulation and Interferential Current Therapy (Interferential,
Premodulated, High Volt, Microcurrent) for:
Symptomatic relief of chronic intractable and/or management of post-traumatic or post-surgical pain.
DIRECT CURRENT THERAPY:
Direct Current is indicated for relaxation of muscle spasms.
ULTRASOUND THERAPY:
Ultrasound therapy is intended to generate deep heat within body tissues for the treatment of selected medical
conditions such as relief of pain, muscle spasms, and joint contractures, but not for the treatment of
malignancies.
LIGHT THERAPY:
Light therapy provides topical heating for temporary increase in blood circulation, temporary relief of minor
muscle and joint aches, pain and stiffness, relaxation of muscles, and treatment of muscle spasms and minor
pain and stiffness associated with arthritis.
PATENT PENDING
REV. 02-07_14
INVENTORY MKT299
Authorized European
Representative:
Emergo Group, Inc.
Molenstraat 15
2513 BH The Hague
The Netherlands
Tel: [phone]
Fax: [phone]
0344
Dynatron Solaris®Operator’s Manual
Revised February 2007
© Copyright 2003
Dynatronics Corporation
7030 Park Centre Drive
Salt Lake City, UT 84121
[phone]
[phone]
www.dynatronics.com
ALL RIGHTS RESERVED
The Solaris D890 laser product is designated as class 1M during all procedures of Operation and
Maintenance.
AVOID INADVERTENT EXPOSURE TO POTENTIALLY HAZARDOUS LIGHT

Dynatron Solaris® 700 Series
iii
Table of Contents
SECTION I
INTRODUCTION
Introduction to the Dynatron Solaris®700 Series................................................................................... 2
Summary of Features by Device ............................................................................................................ 2
Simplified Setup ..................................................................................................................................... 3
Before You Treat a Patient ..................................................................................................................... 3
Installation and Features............................................................................................................................ 4
Unpacking .............................................................................................................................................. 4
Standard Components............................................................................................................................. 4
Soundheads............................................................................................................................................. 5
Optional Accessories.............................................................................................................................. 5
Dynatron Solaris®Physical Features...................................................................................................... 6
General Selections................................................................................................................................ 12
Conductance ......................................................................................................................................... 17
Output Connectors and Jacks ............................................................................................................... 19
Power Switch / Battery......................................................................................................................... 21
Booster Box / Booster Box Jacks ......................................................................................................... 21
Instructions for Using Toggle Keys ..................................................................................................... 22
Channel Output Indicator Lights.......................................................................................................... 23
Current Limit........................................................................................................................................ 24
Current Limit Warning......................................................................................................................... 24
Lead Wires / Electrodes........................................................................................................................ 25
Lead Wires ........................................................................................................................................... 25
Test Leads............................................................................................................................................. 25
“LEAD” Warning - No Patient Current ............................................................................................... 26
Carbon Electrodes ................................................................................................................................ 27
Self-Adhesive Electrodes ..................................................................................................................... 28
Quick Reference of Special Key Presses ................................................................................................. 29
SECTION II
OPERATION AND TREATMENT INSTRUCTIONS
Electrotherapy Information ..................................................................................................................... 32
and Usage Cautions................................................................................................................................... 32

Dynatron Solaris® 700 Series
iv
Interferential / Premodulated Instructions .............................................................................................35
Basic Interferential / Premod Setup ......................................................................................................35
Detailed Interferential / Premodulated Setup........................................................................................35
Interferential and Premodulated Modality Information ........................................................................40
Interferential (Quadpolar) Therapy.......................................................................................................40
Premodulated (Bipolar) Therapy ..........................................................................................................40
Target ....................................................................................................................................................41
Why Is Target Better?...........................................................................................................................41
Target Sweep ........................................................................................................................................41
Interferential Electrode Placement........................................................................................................42
Interferential / Premodulated Default Settings......................................................................................42
Interferential Default Settings...............................................................................................................42
Premodulated Default Settings..............................................................................................................43
Biphasic / Russian Instructions ................................................................................................................44
Basic Biphasic / Russian Setup.............................................................................................................44
Detailed Biphasic / Russian Setup ........................................................................................................45
Biphasic / Russian Modality Information .............................................................................................49
Russian Stimulation ..............................................................................................................................49
Biphasic Stimulation.............................................................................................................................49
Biphasic / Russian Parameters ..............................................................................................................49
Biphasic / Russian Default Settings ......................................................................................................51
High Volt Instructions...............................................................................................................................52
Set Up High Volt Treatment with Electrodes .......................................................................................52
Set Up High Volt Probe Treatment.......................................................................................................53
Basic High Volt Setup ..........................................................................................................................53
High Volt Treatment Time....................................................................................................................54
Detailed High Volt Setup......................................................................................................................54
High Volt Modality Information...........................................................................................................59
High Volt Waveform ............................................................................................................................59
High Volt Settings.................................................................................................................................59
High Volt Default Settings....................................................................................................................60
High Volt Waveform Specifications.....................................................................................................60
Microcurrent Instructions ........................................................................................................................61
How To Use The MultiStim Probe For Microcurrent Treatments........................................................61
Basic Microcurrent Setup .....................................................................................................................62
Microcurrent Treatment Time...............................................................................................................63
Detailed Microcurrent Setup.................................................................................................................63
Microcurrent Modality Information......................................................................................................66

Dynatron Solaris® 700 Series
v
Microcurrent Waveforms ..................................................................................................................... 66
Microcurrent Guidelines....................................................................................................................... 66
Microcurrent Default Settings .............................................................................................................. 67
Direct Current Instructions ..................................................................................................................... 68
Direct Current Setup............................................................................................................................. 68
Detailed Direct Current Setup .............................................................................................................. 68
Direct Current Modality Information ................................................................................................... 70
Direct Current Probes Therapy............................................................................................................. 70
Direct Current Waveforms ................................................................................................................... 70
Direct Current Cautions........................................................................................................................ 70
Direct Current Default Specifications .................................................................................................. 71
Direct Current Default Settings ............................................................................................................ 71
Infrared Light Therapy Operating Instructions.................................................................................... 72
Infrared Light Therapy Treatment Setup.............................................................................................. 73
Detailed Treatment Setup ..................................................................................................................... 73
Infrared Light Therapy Treatment Notes.............................................................................................. 77
Infrared Light Therapy Modality Information .....................................................................................78
Infrared Light Therapy Basic Vocabulary............................................................................................ 78
Solaris Light Therapy Probes & Dynatron Xp Pad Specifications ...................................................... 78
Infrared Light Therapy Probe Overlays ............................................................................................... 81
Infrared Light Therapy Probe/Pad Default Settings............................................................................. 81
Ultrasound Instructions............................................................................................................................ 82
Soundhead Warming ............................................................................................................................ 83
Turn Soundhead Warming Off / On..................................................................................................... 83
Coupling ............................................................................................................................................... 83
Patient Coupling Display...................................................................................................................... 83
Ultrasound Coupling Bar Graph........................................................................................................... 84
Head Temperature Hot Display............................................................................................................ 84
Display Watts or W/cm2....................................................................................................................... 85
Basic Ultrasound Setup ........................................................................................................................ 86
Basic Ultrasound Setup ........................................................................................................................ 86
Detailed Ultrasound Setup.................................................................................................................... 86
Ultrasound Modality Information......................................................................................................... 89
Selecting the Appropriate Soundhead .................................................................................................. 89
Penetration of Ultrasound Waves......................................................................................................... 90
Types of Delivery................................................................................................................................. 90
Treatment Time .................................................................................................................................... 91
Treatment Intensity............................................................................................................................... 91

Dynatron Solaris® 700 Series
vi
Frequency of Treatment........................................................................................................................91
Usage Cautions – Combination Treatments..........................................................................................92
Potential for Burns or Periosteal Pain...................................................................................................92
Soundhead Optimization (D701, D708, D709) ....................................................................................92
Adding or Replacing Soundheads.........................................................................................................92
Ultrasound Calibration Procedures .......................................................................................................94
Problem Solving ...................................................................................................................................96
Soundhead Temperature Too Hot.........................................................................................................96
Cooling the Soundhead.........................................................................................................................97
Whirlpool Treatments ...........................................................................................................................97
Soundhead Temperature Too Cold .......................................................................................................97
No Soundhead.......................................................................................................................................97
Other Error Messages in the Display ....................................................................................................98
Ultrasound Specifications (Dynatron Solaris 701, 708, and 709 only) ................................................98
Ultrasound Default Settings..................................................................................................................98
Ultrasound Regulation and Technical Information...............................................................................99
Beam Profiles......................................................................................................................................100
Combination Therapy Instructions .......................................................................................................103
Comboplus™.......................................................................................................................................103
Stim Through the Soundhead..............................................................................................................104
Combination Therapy Setup ...............................................................................................................104
Modify Treatment ...............................................................................................................................107
Combination Default Settings.............................................................................................................107
Simultaneous Treatments .......................................................................................................................108
Set Up A Second Treatment................................................................................................................108
Modify Simultaneous Treatments.......................................................................................................109
Stop One Treatment ............................................................................................................................109
SECTION III
CONTRAINDICATIONS, WARNINGS, AND PRECAUTIONS
Contraindications, Warnings, & Precautions for Interferential, Premodulated, Russian,
Biphasic, High Voltage Pulsed Stimulation, and Direct Current Treatments ...................................112
Contraindications ................................................................................................................................112
Warnings.............................................................................................................................................112
Precautions..........................................................................................................................................113
Treatment Setup Warnings .................................................................................................................113
Adverse Effects...................................................................................................................................114
Use Only Dynatronics Accessories.....................................................................................................114

Dynatron Solaris® 700 Series
vii
Contraindications, Warnings, & Precautions for Microcurrent ........................................................ 115
Contraindications................................................................................................................................ 115
Warnings ............................................................................................................................................ 115
Precautions ......................................................................................................................................... 115
Adverse Reactions.............................................................................................................................. 116
Contraindications, Warnings, & Precautions for Ultrasound Treatment......................................... 117
Contraindications................................................................................................................................ 117
Precautions ......................................................................................................................................... 118
Warnings ............................................................................................................................................ 118
Contraindications, Warnings, & Precautions for Solaris Light Therapy Treatments ..................... 119
Contraindications................................................................................................................................ 119
Precautions and Warnings .................................................................................................................. 119
Laser Safety (D890 Probe) ................................................................................................................. 120
SECTION IV
TECHNICAL INFORMATION
Setting Defaults ....................................................................................................................................... 124
Save New Defaults ............................................................................................................................. 124
Restore Factory Defaults .................................................................................................................... 124
Battery Operation ................................................................................................................................... 126
Battery Requirements ......................................................................................................................... 126
Battery Life......................................................................................................................................... 127
General Specifications ............................................................................................................................ 128
Dynatron Solaris Specifications ......................................................................................................... 128
Environmental Conditions.................................................................................................................. 128
Safety Features of the Dynatron Solaris............................................................................................. 128
Care and Cleaning Instructions .......................................................................................................... 128
Suggested Maintenance Schedule ...................................................................................................... 129
Routine Ultrasound Calibration Inspections for Solaris..................................................................... 130
Software Updates ............................................................................................................................... 130
Returning a Unit for Repair................................................................................................................ 131
Definition of Symbols and Labeling .................................................................................................. 132
Equipment Classification.................................................................................................................... 133
Disposal of Equipment and Accessories ............................................................................................ 133
Dynatronics Electrodes and Lead Wires ............................................................................................ 134
Additional Technical Information Available (for Technicians Only) ................................................ 135

Dynatron Solaris® 700 Series
viii
SECTION V
SCHEMATICS AND QC CHECK LISTS
Quality Check Sheet ................................................................................................................................138
Ultrasound Quality Check Sheet.........................................................................................................140
Schematic Drawings ...........................................................................................................................141
Index… .....................................................................................................................................................159
Limited Warranty ...................................................................................................................................162

Dynatron Solaris® 700 Series
Introduction
1
SECTION I
INTRODUCTION

Dynatron Solaris® 700 Series
2
Introduction to the
Dynatron Solaris® 700 Series
The Dynatron Solaris 700 Series offers the practitioner a wide range of treatment options.
These devices provide Interferential and Premodulated therapy; High Voltage pulsed
stimulation; Russian and Biphasic therapies; Microcurrent and Direct Current treatments; and
Infrared Light Probe applications. The Solaris 700 Series devices may, with the use of the
Dynatron®Booster Box, operate the Dynatron®Xp™, a powerful 8”X10” Infrared Light Pad.
In addition, the Solaris 701, 708, and 709 include Ultrasound and the Dynatronics
Comboplus™feature providing almost unlimited combinations of treatment options.
The 700 Series devices include the standard advantages of Dynatronics engineering, such as
customizable treatments, electrode conductance meters and the popularTarget feature. In
addition all units offer the option of battery operation, making the devices truly portable. The
manufacturer’s warranty for these devices is two years (see full warranty details at the back
of this manual).
This manual provides operator information and instructions for five Solaris models: the 701,
705, 706, 708, and 709. The section that discusses Ultrasound and Comboplus treatments
applies only to the Dynatron 701, 708 and 709 models. All other sections of this manual
apply to all Dynatron Solaris devices.
Summary of Features by Device
Feature 701 709 708 706 705
Electrotherapy
IFC X X X X
Premod X X X X
Biphasic X X X X
Russian X X X X
High Volt X X X X
Microcurrent X X X X
Direct Current X X X X
Combo Electrotherapy/Ultrasound X X
Light Therapy X X X X X
Ultrasound X X X
Special Features
Electrotherapy Channels 4 2 4 2
High Volt Channel 1 1 1 1
Stim Probe Channel X X X X
Infrared/Laser Light Therapy Port X X X X X
Conductance Meter X X X X
*Booster Box / Light Pad Capability X X X X X
*Note: The Dynatron Solaris Booster Box must be used in conjunction with the Dynatron Xp Light pad on all
Solaris 700 Series devices. Software upgrades are required on all devices manufactured prior to September 2005.

Dynatron Solaris® 700 Series
Introduction
3
Simplified Setup
The unique design of the Solaris front panel means treatment setup has never been easier. A
few simple key presses are all you need to fully set up a treatment. The careful grouping of
available options for each modality ensures that you can easily see and select from the
appropriate options for that modality.
Each modality offers default settings which are automatically preset when the modality is
selected—saving time in the treatment setup. You can change these defaults to match your
own most common treatment setups reducing setup time to a matter of seconds.
Before You Treat a Patient
Before administering a treatment to a patient with the Solaris devices, you should familiarize
yourself with all the operating instructions for the modality used, as well as the
contraindications, warnings, and precautions for that modality.
You should also read the general information about each of the modalities provided in this
manual. In addition to this information, consult other published sources for additional
application and safety instructions regarding use of each type of therapy.

Dynatron Solaris® 700 Series
Installation & Features
4
Installation and Features
Unpacking
When you receive the unit, immediately unpack it and all accessories and check for possible
damage, obvious or concealed. In case of damage, immediately notify the freight carrier and
take any steps necessary to file a claim for the damage sustained. Do not destroy or discard
the shipping carton. The carton should be reused if the device must be shipped for any
reason. The carton is specially designed to protect the unit from shipping damage. Improper
packaging of the unit during transport can result in damage and invalidate the warranty.
Complete the warranty registration form located at the back of this manual and return
it to Dynatronics within 30 days of purchase. This is essential to insure you are not
billed for services that are covered by the warranty policy. Warranty registration
should include serial numbers for both the device and soundheads.
Connect the AC power cord, which is equipped with a hospital grade, UL listed plug, to a
properly grounded 110/120V 60 Hz AC outlet (the device will automatically switch to
220/240V 50 Hz when connected to a power source with that voltage). The power cord must
also be firmly plugged into the device itself. When the cord is properly connected, it can not
be easily pulled out. Do not place the cord or the device in a place where the cord could be
tripped over or accidentally pulled out of its socket during a treatment.
If Infrared Light Therapy probes or pads are being used in conjunction with a Solaris
device and/or Booster Box, they should be plugged into the Solaris console and/or
Booster Box prior to powering-on the device(s).
Read the operating instructions in this manual before proceeding with a treatment.
Standard Components
The following accessories are included with the Solaris units:
Qty Part No. Description
One of the following devices:
1 D701 Solaris 701
1 D705 Solaris 705
1 D706 Solaris 706
1 D708 Solaris 708
1 D709 Solaris 709
1 7B0241 Power Cord (black)
1 9G0011 Operator's Manual
1 7B0268 Protocol Reference Manual for Electrotherapy & Ultrasound
(Guffey, 2003)
1 7B0217 Dynagel Ultrasound Gel 100 ml sample - Solaris 701, 708 and
709 only

Dynatron Solaris® 700 Series
Installation & Features
5
Note: The following are not applicable to the D701.
Qty Part No. Description
2 7B0232 120” double leads (2 red) - Solaris 706 and 709 only
2 7B0233 120” double leads (2 black) - Solaris 706 and 709 only
1 7B0230 72” double lead (1 red) - Solaris 705 and 708 only
17B0231 72” double lead (1 black) - Solaris 705 and 708 only
1 7B0234 COMBOplus lead wires –Solaris 708 and 709 only
1 7B0265 Ultra Polys™Self-adhesive electrodes 2” x 4” w/pin connector
(pkg. of 4)
1 8E0017A MultiStim Point Tip Attachment
1 7B0250 MultiStim probe (requires one or more applicators)
1 8E0018 High Volt applicator 5/8” round
1 8E0019 High Volt applicator 2”x1-1/2”
2 7B0063 3” round carbon electrodes (2 red)
2 7B0065 3” round carbon electrodes (2 black)
4 7B0210 Sponge fabric for use with 3” carbon electrodes
1 7B0193 Sponge Pocket 1 1/2” x 2”
1 7B0192 Sponge Pocket 5/8”
2 DW248 2.5” x 48” straps (pkg. of 2) Solaris 706 and 709 only
1 DW248 2.5” x 48” straps (pkg. of 2) Solaris 705 and 708 only
1 7B0191 5” x 8” dispersive electrode for High Volt (gray)
1 7B0201 Sponge Fabric for use with 5”x 8” dispersive electrodes
1 8D0027 Microcurrent Ground Probe
1 7B0079 Banana-to-Pin Adapter (black)
Soundheads
The Solaris devices may be purchased with one or more applicator soundheads in the
following sizes:
Part No. Size Frequencies
9GSH02 2 cm2Operates at 1, 2, and 3 MHz
9GSH05 5 cm2Operates at 1, 2, and 3 MHz
9GSH10 10 cm2Operates at 1, 2, and 3 MHz
Optional Accessories
The following optional and replacement accessories may be purchased from Dynatronics or
from your Dynatronics dealer:
Part No. Description
D880 Dynatron 880 Cluster Probe
D890 Dynatron 890 Light Therapy Probe
D405 Dynatron 405 Infrared Cluster Probe
D881 Dynatron 880Plus Infrared Cluster Probe
9G0104 Protective Eyewear (D405)
Xp Dynatron Xp Infrared Light Pad (Booster Box required)
XpB Dynatron Solaris Booster Box
7B0271 Light Therapy Applications Manual (Enwemeka & Pöntinen)
7B0272 Hard Side Carrying Case for Solaris Units
7B0273 Soft Side Carrying Case
7B0208 2” diameter carbon electrodes (red)
7B0209 2” diameter carbon electrodes (gray)
7B0063 3” diameter carbon electrodes (red)

Dynatron Solaris® 700 Series
Installation & Features
6
Part No. Description
7B0065 3” diameter carbon electrodes (gray)
7B0059 3” x 5” carbon electrodes (red)
7B0061 3” x 5” carbon electrodes (gray)
7B0067 1.5” x 2.0” carbon electrodes (red)
7B0069 1.5” x 2.0” carbon electrodes (gray)
7B0260 2” x 4” Ultra Polys™adhesive electrodes (with snap or pin
connector)
7B0261 2” x 2” Ultra Polys™square adhesive electrodes
(with snap or pin connector)
7B0077 Bifurcated extension lead wire for High Volt use
7B0082 Pin-to-Banana adapter (black)
7B0079 Banana-to-Pin Adapter (black)
7B0001 Snap adapter
5LTRGEL Ultrasound Coupling Gel (5 liter container)
9G0079 Light Probe Covers (Disposable / 25 per package)
8A0061 Remote Stop Cable Assembly (Applicable only to customized,
special order units).
Dynatron Solaris®Physical Features
Before operating the Dynatron Solaris devices, acquaint yourself with the control panel by
reviewing the illustrations and descriptions on the following pages. The numbered features in
the diagrams correspond to the numbered descriptions. Before administering treatment to a
patient, read the sections later in this manual that provide specific instructions for performing
treatments, discussions of each modality, definitions of the available options, along with
contraindications, warnings, and precautions for all modalities. Note that some options use
“toggle” keys for making selections. More specific instructions for using toggle keys are
provided later in this section.

Dynatron Solaris® 700 Series
Installation & Features
7
Solaris 701
1
2
3
4
5910 11
27
16
18
26
8
17
Dynatron Solaris 701 Control Panel

Dynatron Solaris® 700 Series
Installation & Features
8
Solaris 705
RATE/DUTY
SERIES
S LARIS
705
Dynatron
5
4
7
6
14
13
12
26
15
29
28
24
25
23
22
21
19
20
3
2
1
27
11
10
9
8
CH1 CH2 HV
CH 1
CH 1
CH 2
CH 2
Dynatron Solaris 705 Control Panel

Dynatron Solaris® 700 Series
Installation & Features
9
Solaris 706
RATE/DUTY
SERIES
S LARIS
5
4
7
6
14
13
12
26
15
28 29
24
25
23
22
21
19
20
3
2
1
27
11
10
9
8
CH1 CH2 CH3 CH4 HV
706
Dynatron
CH 1
CH 1
CH 2
CH 2
Dynatron Solaris 706 Control Panel

Dynatron Solaris® 700 Series
Installation & Features
10
RATE/DUTY
SERIES
S LARIS
5
4
7
6
14
13
12
26
17
16
18
15
29
28
24
25
23
22
21
19
20
3
2
1
27
11
10
9
8
CH1 CH2 HV
708
Dynatron
CH 1
CH 1
CH 2
CH 2
Solaris 708
Dynatron Solaris 708 Control Panel

Dynatron Solaris® 700 Series
Installation & Features
11
RATE/DUTY
SERIES
S LARIS
28
29
OUTPUT
5
4
7
6
14
13
12
26
17
16
18
15
24
25
23
22
21
19
20
3
2
1
27
11
10
9
8
CH1 CH2 CH3 CH4 HV
709
Dynatron
CH 1
CH 1
CH 2
CH 2
Solaris 709
Dynatron Solaris 709 Control Panel

Dynatron Solaris® 700 Series
Installation & Features
12
General Selections
1. START: Press this key to start the treatment timer and treatment proceeds as set up. For
probe treatments, the START key only activates the probe in preparation for the
treatment. The treatment begins after the 1/0 (ON/OFF) key on the probe handle is
pressed.
2. STOP: Pressing this key during a treatment IMMEDIATELY stops the output and sets
the treatment time to zero for all modalities. To stop just one treatment only, press and
hold the FUNCTION key while you press the STOP key, or simply reduce that channel’s
treatment time to zero. For Light Probe treatments, press the 1/0 (ON/OFF) key located
on the probe handle. On custom devices equipped with the remote stop feature,
treatments may also be stopped by pressing the button on the REMOTE STOP cable,
terminating all treatments.
3. PAUSE/FUNCTION:This key is used in combination with other key presses for
accessing unique features including: Select polarity (High Volt, Microcurrent and Direct
Current), audio volume control (Microcurrent), and to stop one treatment. Specific
instructions for using this key are provided later in this manual.
Ultrasound: For Dynatron Solaris 701, 708 and 709 only: This key is also used to
PAUSE an Ultrasound treatment. For the Solaris 708 and 709, first press the CHANNEL
TOGGLE (CH) to select SOUND. For the D701, press the SOUND key. With
Ultrasound as the focus, press PAUSE/FUNCTION; the Ultrasound output is stopped, the
treatment time is paused, and the light on the PAUSE key is lighted. When this key is
pressed again, the Ultrasound treatment countdown resumes and the light on the PAUSE
key is off.
Combination Treatment: During a COMBO treatment, only the Ultrasound output and the
treatment timer are stopped when you press PAUSE; the stim output continues.
Infrared Light Therapy Probe/Pad: Pressing the PAUSE/FUNCTION key will not pause a
Solaris Light Therapy Probe treatment that is in progress. A Light Therapy Probe
Treatment is paused by pressing the “1/0” key on the Light Probe handle. However,
pressing the PAUSE/FUNCTION key will pause a pad treatment.
Please note: Following the completion of either a Pad or Probe treatment when using
the Dynatron Booster Box, the practitioner must press the PAUSE/FUNCTION-STOP
keys to exit the current focus (pad or probe) and switch to the opposite Light Therapy
mode (pad or probe). For example: If the Booster Box is operational, and an
Infrared Probe treatment has just timed out, the practitioner must press
PAUSE/FUNCTION-STOP before using the CH toggle key to switch to an Infrared
Light Pad treatment. PAUSE/FUNCTION-STOP would also have to be pressed
following the Pad treatment to return back to a Probe treatment mode.
4. TIME ARROW KEYS:These UP/DOWN arrow keys are used to increase/decrease the
treatment time or other parameters that are displayed in the TIME display.
5. TIME DISPLAY:This display is used to show the treatment time for one treatment at a
time; the display shows treatment time for the selected channel (the selected channel is
indicated by the GREEN LED—all other channels in use at the time will have YELLOW
LEDs). The TIME display can also show the pulse rate and duration for Russian and
Biphasic treatments as well as the frequencies for Interferential, Premodulated, and
Microcurrent treatments, pulse duration for Direct Current treatments, and the pulse rate
for High Volt. The treatment parameters for any treatment in progress may be displayed
