Dynaudio Xeo User manual

Owner’s Manual Xeo
English

2Dynaudio
All Apple products are trademarks of Apple Inc.
All Sony products are trademarks of Sony Electronics Inc.
All Sonos products are trademarks of Sonos Inc.
Logitech Squeezebox is a trademark of Logitech Inc.
An update to this manual may be necessary due to product improvements and new functions.
The latest version of this manual can be found on the Dynaudio website at www.dynaudio.com/xeo

3
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer‘s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A po-
larized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufac-
turer, or sold with the apparatus. When a cart is used use caution when moving
the cart/apparatus combination to avoid injury from tip-over.
13. Unplug th is apparatus during lightning storms or when unused for long periods
of time.

4Dynaudio
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
15. WARNING: To reduce the risk of re or electric shock, this apparatus should not
be exposed to rain or moisture and objects lled with liquids, such as vases,
should not be placed on this apparatus.
16. To completely disconnect this eq uipment from the mains, d isconnect the pow-
er supply cord plug from the receptacle.
17. The mains plug of the power supply cord shall remain readily operable.
WARNING
RISK OF ELECTRIC SHOCK! DO NOT OPEN!
To reduce the risk of electric shock, do not remove the back panel and do not expose the
apparatus to rain or moisture. No user serviceable parts inside. Refer servicing to qualied
personnel. Never open the loudspeaker housing.

5
Safety information 7
Xeo loudspeakers 7
Power supply unit for Xeo Hub, Extender, and Link 7
Scope of delivery 8
Xeo loudspeakers (Xeo 4 or Xeo 6) 8
Xeo Hub 9
Xeo Extender 10
Xeo Link 10
Unpacking 11
Packaging material 11
Disposal 11
The Xeo system 12
Components 12
Combination examples 13
Remote control 14
Control elements 14
Xeo Hub 14
Display elements 15
Inputs 15
Other connections and control elements 16
Connection 16
Xeo loudspeakers 18
Connections and control elements 18
Division into audio zones 19
Cloth cover 20
Setting up 20
Connecting and adjusting 20
Switching on/standby mode 21
Selecting a Hub or input/autoplay function 21
Fixing the volume 21
Interface display 22
Xeo Extender 24
Connections and control elements 24
Connecting and establishing a link 25
Xeo Link 26
Connections and control elements 26
Connecting and establishing a link 27
Malfunctions 28
Technical data 29
Reminding 30
IC NOTICE 31
MPE Reminding 31
Table of Contents

6Dynaudio
Thank you
for choosing Dynaudio Xeo.
Xeo combines the latest wireless technology with impressive sound quality and makes listening to
music truly comfortable and easy.
The next few pages contain important information on connecting the system and its operation to
ensure perfect function and the best-possible sound quality.
We hope you have a great time listening to your favorite music,
Dynaudio

7
Safety information
Xeo loudspeakers
WARNING
Dangerous electrical voltage
If the loudspeakers are connected to the mains voltage, a dangerous electrical voltage is
present inside the speakers.
►Never open the loudspeaker housing.
►Do not operate defective loudspeakers and disconnect defective loudspeakers from the mains
voltage. Please contact your Dynaudio Xeo distributor if you have any problems. Distributor
addresses can be found in the Internet at www.dynaudio.com.
►Use the supplied power cable to connect the loudspeakers to the mains voltage. Make sure that
the power supply cable is not damaged; exchange it for a new one if it has been damaged.
Power supply unit for Xeo Hub, Extender, and Link
WARNING
Dangerous electrical voltage
When plugged in, a dangerous electrical voltage is present inside the housing of the supplied
Xeo power supply unit for Hub, Extender, and Link.
►Only use the delivered Xeo power supply unit.
►Never open the housing of the power supply unit.
►Make sure that the housing is not damaged. Exchange the power supply unit for a new one if it
has been damaged.

8Dynaudio
Scope of delivery
Xeo loudspeakers (Xeo 4 or Xeo 6)
2 Xeo loudspeakers (Xeo 4 or Xeo 6)
2 Xeo loudspeaker cloth covers
1 Xeo remote control
2 Xeo loudspeaker power cables (country-specic version)
1 Xeo rst time setup manual (quick guide for installation, not shown)



9
Xeo Hub
1 Xeo Hub
1 Xeo power supply unit with micro USB cable (country-specic version)
1 stereo analog cable (jack 3.5 mm – 3.5 mm)
1 stereo analog cable (RCA – RCA)
1 optical digital cable (Toslink – Toslink)
1 USB cable (USB – mini USB)
1 Xeo rst time setup manual (quick guide for installation, not shown)

 




10 Dynaudio
Xeo Extender
1 Xeo Extender
1 Xeo power supply unit with micro USB cable (country-specic version)
1 Xeo rst time setup manual (quick guide for installation, not shown)
Xeo Link
1 Xeo Link
1 Xeo power supply unit with micro USB cable (country-specic version)
1 stereo analog cable (RCA – RCA)
1 optical digital cable (Toslink – Toslink)
1 Xeo rst time setup manual (quick guide for installation, not shown)




 

11
Unpacking
After unpacking, make sure the system is complete and check the device and all accessories for
transport damage. Transport damage may be expected if the packaging is already severely harmed.
Do not attempt to commission a damaged device. If the contents are incomplete or damaged, please
contact your Dynaudio Xeo distributor. Distributor addresses can be found in the Internet at www.
dynaudio.com.
Packaging material
The packaging has been designed so that it may be reused if it was not damaged during transport.
Keep the packaging and use the original packaging for all further transport.
Disposal
Disposal of used electrical and electronic equipment (applicable in European countries with
separate collection systems for this equipment)
This symbol on the product or its packaging indicates that the product may not be treated as
household waste. Instead it must be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health. The recycling of
materials helps to conserve natural resources. For more detailed information on recycling this product,
please contact your local authority, community waste disposal ofce, or the shop where you purchased
the product.

12 Dynaudio
The Xeo system
Xeo consists of several high-quality components that are optimally matched. When combined, they
can fulll the most demanding requirements for a wireless multi-room and multi-source system.
NOTE: This manual describes all of the available Xeo components. It is possible that only a few of the
descriptions are relevant to you, depending on your system conguration.
Components
Xeo Hub The Xeo Hub is the control center for the Xeo system. Signal sources such as
tuners, receivers, CD players, TVs, streaming clients, network players, MP3
players, or computers are connected to it. Signals are sent via radio from the
Hub to the loudspeakers (or Xeo Link) where they are then played back.
Xeo Extender The Xeo Extender extends the reception range of the Xeo Hub. As a result,
Xeo loudspeakers or other Xeo components can be operated further away
from the Hub.
Xeo Link The Xeo Link receives wireless signals from a Xeo Hub and outputs analog
and digital signals from its connections. As a result, you can also connect
active subwoofers, active loudspeakers, or other components to the Xeo
system. Xeo Link can also be connected with a 1st generation Xeo Hub
(transmitter).
Xeo remote
control
The Xeo remote control can be used to turn the loudspeakers on and off,
change the volume, and select a Hub and its connected signal sources.
Xeo
loudspeakers
The active Xeo 4 and Xeo 6 loudspeakers receive the wireless signals from
the Hub and play them back in optimal sound quality. They have an integrated
amplier and can be controlled with the Xeo remote control. A display
indicates the operational state of the system and lets you switch it on/off or
change the volume without using the remote control.

13
Combination examples
Below you will nd several examples of Xeo component combinations. The high level of exibility in
the Xeo system enables even more variants. Ask your Dynaudio distributor to nd the perfect solution
for your needs.
Standard:
Hub + loudspeaker
Hub
For a larger range:
Hub + Extender + loudspeaker
Hub Extender
For additional active components:
Hub + loudspeaker + Link
This example would also be possible with only a
Hub, Link, and active component. Hub
Link
NOTE: The Extender and Link may also be combined.

14 Dynaudio
Connection and operation
This section describes the connections and control elements for the Xeo components. Please contact
your Dynaudio Xeo distributor if you have any problems with connection and start-up. Distributor
addresses can be found in the Internet at www.dynaudio.com.
Remote control
The Xeo remote control can be used to turn the loudspeakers on and off, change the volume, and
select a Hub and its connected signal sources. If the loudspeakers are being operated in stereo mode
(right/left), commands will always apply to both of the loudspeakers.
Control elements
MUTE Mute the loudspeaker
Briey pressing this button will mute or
unmute the selected loudspeaker.
Fixing the volume
Pressing this button for longer than 2 seconds will set a
high volume for the loudspeaker (see page 21).
ON/OFF Loudspeaker on/off
= on
= switch to standby
Reset
= Pressing this button for longer than 5 seconds will
reset the loudspeaker to the factory settings.
VOLUME Changing the volume
= louder, = quieter
INPUT
1/2/3/4
Selecting the signal source
Selects one of the signal sources Line In, Optical In, Coax In or USB In from the active Hub.
HUB
A/B/C
Selecting the Hub
Selects one of the three possible Hubs A, B, or C.
Xeo Hub
The Xeo Hub is the control center for the Xeo system. Signal sources such as tuners, receivers, CD
players, TVs, network players, MP3 players, or computers are connected to it. Signals are sent via
radio from the Xeo Hub to the loudspeakers where they are then played back.

15
Display elements
LED Connection status
LED illuminated in
blue:
Connection established (to a loudspeaker, Extender, or
Link).
LED ashes: The Hub is searching for a connection.
LED illuminated in red: The Hub could not establish a connection.
Inputs
1 Aux in Input for cable with stereo jack (3.5 mm stereo)
Connect devices here that have an output for the stereo jack.
Line in Input for cable with RCA plug
Connect devices here that have an output for the RCA plug.
NOTE: If a device is connected in parallel at Aux in, only that device will be played
back.
2 Optical In Input for optical digital cable (Toslink)
Connect devices here that have an optical digital output.
3 Coax In Input for electrical digital cable (coax)
Connect devices here that have an electrical digital output.
4 USB in Input for USB cable
Connect your computer’s USB output here. The Hub will then work as a sound
card.

16 Dynaudio
Other connections and control elements
Ethernet Network connection
Intended for future functions.
Id Transmission channel
If you assign an ID, you can select the desired Hub from several Hubs using the
remote control.
In addition, each ID has its own transmission channel: A = 2.4 GHz, B = 5.2 GHz,
C = 5.8 GHz. If the transmission quality is poor or there is a disruption caused by
other radio systems, changing to a different channel may produce an improvement.
Power Connection for power supply unit
Connect the delivered Xeo power supply unit here.
Do not use a different power supply unit!
Connection
►Connect the Hub to the mains voltage using the POWER connection and the Xeo power supply
unit. Do not use a different power supply unit!
Note: If you connect the Xeo Hub via a USB cable to a computer (that is switched on), you do not
need an additional mains connection.
►Connect your signal source to the appropriate input on the Hub.
Below you will nd a selection of signal sources and options for connecting to the Xeo Hub.
Your signal source Signal source
output
Xeo Hub
input
Cable
(source – Hub)
Notes
Notebook, MAC™, PC USB* 4: USB in USB – mini USB * The Hub works as a
sound card.
Optical 2: Optical In Toslink – Toslink
Line out 1: Line in RCA – RCA
Headphones 1: Aux in Jack 3.5 mm – 3.5 mm
Smartphone, other portable devices Headphones 1: Aux in Jack 3.5 mm – 3.5 mm –

17
Your signal source Signal source
output
Xeo Hub
input
Cable
(source – Hub)
Notes
Astell&Kern Headphones 1: Aux in Jack 3.5 mm – 3.5 mm –
Optical 2: Optical In Toslink – Toslink
PonoPlayer Jack 1: Aux in Jack 3.5 mm – 3.5 mm –
Docking station, network client, Sonos,
Logitech, Squeezebox, ...
Line out 1: Line in RCA – RCA * If available
Optical* 2: Optical In Toslink – Toslink
Apple AirPort Express Optical 2: Optical In Mini Toslink – Toslink –
Apple TV Optical 2: Optical In Toslink – Toslink –
Hard disk, network player,
CD player
Line out 1: Line in RCA – RCA * If available
Optical* 2: Optical In Toslink – Toslink
Electrical* 3: Coax In Coax – coax –
Analog radio, digital radio Line out 1: Line in RCA – RCA * If available
Optical* 2: Optical In Toslink – Toslink
Analog record player Line out* 1: Line in RCA – RCA * On phono preamplier
TV Headphones 1: Aux in Jack 3.5 mm – 3.5 mm Select a variant.
Line out 1: Line in RCA – RCA
Optical* 2: Optical In Toslink – Toslink * If available
Stereo preamplier Pre-out, main out 1: Line in RCA – RCA –
Stereo power amplier Tape out 1: Line in RCA – RCA * Disconnect bridge
Pre-out, main out* 1: Line in RCA – RCA
Second pre-out 1: Line in RCA – RCA
Subwoofer Analog output 1: Line in RCA – RCA –
AV receiver, AV processor Optical 2: Optical In Toslink – Toslink –
Pre-out, main out 1: Line in RCA – RCA

18 Dynaudio
Xeo loudspeakers
The active Xeo 4 and Xeo 6 loudspeakers have an integrated amplier and can be controlled with
the Xeo remote control. The loudspeakers can be switched between stereo and mono mode using a
switch on the rear.
Connections and control elements
Speaker
position
Sound adjustment (depending on the position of the loudspeakers)
• Neutral = with free-standing placement
• Wall = if placed near a wall
• Corner = if placed in a corner
Loudspeaker placement
• Left = left loudspeaker for stereo mode
• Mono = if only using one loudspeaker
• Right = right speaker for stereo mode
Speaker ID/
zone
Selection of audio zones
Loudspeakers assigned to different zones can be controlled separately via the
remote control. The zones are identied as Red, Green, and Blue.
Power Power switch
• I= The loudspeaker is on. The loudspeaker can be activated and deactivated via
the remote control. If the loudspeaker is activated and there is no signal, it will
switch to standby mode.
• O= The loudspeaker is completely off.
Mains socket
To connect the loudspeaker to the mains voltage.

19
Division into audio zones
The Xeo loudspeakers (as well as Xeo Link) can be assigned to an audio zone using the Zone
selector switch. All components assigned to a zone can be operated together via the remote control.
Red
Green
Blue
Speaker Id
Red
Green
Blue
Zone
Speaker Id
Red
Green
Blue
Zone
Speaker Id
Red
Green
Blue
Zone

20 Dynaudio
Cloth cover
The cloth cover has been designed so it does not inuence the sound dispersion of the loudspeaker.
The cloth cover is attached to the housing with magnets and may be removed if needed.
Setting up
CAUTION
Spikes with pointed ends
Xeo 6 oor-standing speakers are delivered with spikes for permanent installation on the
oor. The pointed ends of the spikes may result in injuries and damage delicate oors.
►Pay attention that you do not injure yourself with the spikes.
► We recommend inserting the spikes in aluminum feet if you have delicate oors, such as parquet
or laminate.
►Position the loudspeaker in the desired location.
– Do not expose the loudspeakers to direct sunlight, heat, or moisture.
– Do not place the loudspeakers near devices with strong electromagnetic radiation or devices
that could be destroyed or damaged by magnetic elds.
Connecting and adjusting
1. Use the power cable to connect the loudspeaker to the mains voltage and switch it on using the
power switch on the rear.
2. In stereo mode:
– Select Left operating mode for the left loudspeaker.
– Select Right operating mode for the right loudspeaker.
In mono: Select Mono operating mode.
3. Select the Red, Green, or Blue zone. In stereo, select the same zone for the right and left
loudspeakers. Loudspeakers with different zone settings can be controlled separately via the
remote control.
