Dyson DC30 User manual

OPERATING MANUAL
WASH FILTER
Wash your filter with cold water
regularly or as required.
ASSEMBLY
clik
2
1
3
clik
REGISTER
YOUR 2 YEAR
GUARANTEE
TODAY
FULLY
CHARGED

Note your serial number for future reference
Your Dyson handheld vacuum will be covered for parts
and labour for 2 years from the date of purchase, subject
to the terms of the guarantee.
If you have a query about your Dyson handheld vacuum,
call the Dyson Customer Care Helpline quoting the serial
number and details of where/when you bought the Dyson
handheld vacuum. The serial number can be found on
the rating plate which is behind the filter.
Most queries can be solved over the phone by one of our
trained Dyson Customer Care Helpline staff.
Visit our website to register your full parts and labour
guarantee online (Australia only).
www.dyson.com.au/register
IMPORTANT SAFETY PRECAUTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
When using an electrical appliance, basic precautions should always be followed, including the following:
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
Use only as described in this Dyson Operating Manual. Use only Dyson recommended attachments.1.
Do not use outdoors, on wet surfaces or near a naked flame.2.
Do not use to pick up flammable or combustible liquids, such as petrol or use in areas where they may be present.3.
Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.4.
Do not use without the clear bin and the filter in place.5.
Children should be supervised to ensure they do not play with the Dyson handheld vacuum.6.
Do not use with damaged cable or plug. If the Dyson handheld vacuum is not working as it should, has been7.
dropped, damaged, left outdoors or dropped into water, contact the Dyson Customer Care Helpline.
This Dyson handheld vacuum is not intended for use by persons (including children) with reduced physical, sensory8.
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning the use of the Dyson handheld vacuum by a person responsible for their safety.
Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair and9.
anything that may reduce air flow.
Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.10.
Use extra care when cleaning on stairs.11.
Use only the charger supplied with the product to recharge.12.
Do not charge the unit outdoors, in a bathroom or where it may be wet.13.
Do not handle charger, including the charger plug and the charger terminals with wet hands.14.
Do not unplug the charger by pulling on the cable. To unplug, grasp the plug, not the cable.15.
Do not incinerate the Dyson handheld vacuum even if it is severely damaged. The batteries may explode in a fire.16.
Do not use with an extension cable.17.
Unplug the charger from the supply before maintenance.18.
SAVE THESE INSTRUCTIONS
THIS HANDHELD VACUUM IS INTENDED FOR DOMESTIC HOUSEHOLD AND CAR USE ONLY.
REGISTER
BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
REGISTER
BY PHONE
Call our dedicated Helpline.
REGISTER
ONLINE
Visit our website to register your
full parts and labour guarantee
online (Australia only).
www.dyson.com.au/register
3 EASY WAYS TO REGISTER YOUR 2 YEAR GUARANTEE
Do not use near
naked flame.
Do not store near
heat source.
Do not pick up water
or liquids.
Do not pick up
burning objects.
23
This illustration is for example purposes only.
AU 1800 239 766
NZ 0800 397 667
SG 7000 435 7546
ID 021 707 39766

clik
clik
3
1
See page 8
Do not use under 3˚C
12
12
2
clik
Charging
Fully charged
Not charging,
battery
Not charging,
low temp
45
Looking for blockages Power Charging
Emptying the clear bin
Tools
IMPORTANT!
WASH FILTER
Wash your filter with cold water
regularly or as required.

12
IMPORTANT!
WASH FILTER
Wash your filter with cold water regularly or as required.
67

89
2 YEAR GUARANTEE - TERMS AND CONDITIONS
To help us ensure you receive prompt and efficient service, please register as a
Dyson owner. There are three ways to do this:
Online (Australia only) at [e-mail]•
By calling the Dyson Customer Care Helpline.•
By completing and returning the enclosed form to us by mail.•
This will confirm ownership of your Dyson handheld vacuum in the event of an
insurance loss and enable us to contact you if necessary.
DYSON CUSTOMER CARE
If you have a query about your Dyson handheld vacuum call the Dyson
Customer Care Helpline and quote your serial number or contact us via the
Dyson website. The serial number can be found on the main body of the
handheld vacuum behind the filter.
Most queries can be solved over the phone by one of our Dyson Customer Care
Helpline staff.
If your Dyson handheld vacuum needs a service, call the Dyson Customer Care
Helpline so we can discuss the available options.
DYSON CUSTOMER CARE DETAILS
Any queries – just call the Dyson Customer Care Helpline
AU: 1800 239 766 (Mon-Fri 8:00am to 6:00pm EST,
Sat-Sun 8:30am to 4.00pm EST) www.dyson.com.au
NZ: 0800 397 667 (Mon-Fri 8:30am to 5:00pm) www.dyson.co.nz
ID: 021 707 39766 www.dyson.com
SG: 7000 435 7546 w ww.dyson.com.sg
SUMMARY OF COVER
Terms and conditions of the Dyson 2 year guarantee.
The guarantee becomes ef fective from the date of purchase.•
All work will be carried out by Dyson Appliances (Aust) Pty Ltd, Avery Robinson•
Ltd (New Zealand).
Any parts replaced will become the property of Dyson Appliances (Aust) Pty Ltd.•
The repair or replacement of your Dyson handheld vacuum under guarantee will•
not extend the period of guarantee.
The guarantee provides benefits which are additional to and do not affect your•
statutory rights as a consumer.
You must provide proof of purchase before any work can be carried out on•
your Dyson handheld vacuum. Without this proof, any work carried out will be
chargeable. Please keep your receipt.
WHAT IS COVERED
The repair or replacement of your Dyson handheld vacuum if your vacuum•
cleaner is found to be defective due to faulty materials, workmanship or
function within 2 years of purchase (if any part is no longer available or out of
manufacture, Dyson will replace it with a functional replacement part).
WHAT IS NOT COVERED
Dyson shall not be liable for costs of repair or replacement of a product incurred
as a result of:
Normal wear and tear.•
Industrial use of the Dyson handheld vacuum such as vacuuming gyprock dust•
or builders dust may void your guarantee.
Accidental damage, faults caused by negligent use or care, neglect, careless•
operation or handling of the Dyson handheld vacuum which is not in
accordance with this Dyson Operating Manual.
Blockages – please refer to the Dyson Operating Manual for details on how to•
unblock your Dyson handheld vacuum.
Use of the Dyson handheld vacuum for anything other than normal domestic•
purposes.
Use of parts not assembled or installed in accordance with the instructions•
of Dyson.
Use of parts and accessories other than those produced or recommended•
by Dyson.
External sources such as transit damage or weather.•
Repairs or alterations carried out by parties other than Dyson or its authorised•
agents.
If you are in any doubt as to what is covered by your guarantee, please call the•
Dyson Customer Care Helpline on:
Australia 1800 239 766
New Zealand 0800 397 667
Indonesia 021 707 39766
Singapore 7000 435 7546
ABOUT YOUR PRIVACY
Dyson may use this information for future marketing and research purposes
(including sending commercial electronic messages) and may disclose it to third
parties for the purposes of providing the services you have requested or to our
business partners or professional advisers. If you wish to access your personal
information or see our full privacy policy, please contact us at
[e-mail]
CONFORMITY INFORMATION
A sample of this product has been tested and found to be in conformity with the
following European Directive: 2006/95/EC Low voltage Directive, 93/68/EEC
CE Marking Directive, 2004/108/EC EMC Directive, and the following Austraila
and New Zealand Directive: AS/NZS60335.2.2 2002.
PRODUCT INFORMATION
Net weight: 1.23kg
This product is protected by the following intellectual property rights:
PATENTS/APPLICATIONS
CA 2544609; JP 2007-508934; US 2007-0079579; AU 2004294771;
AU 2002226556; CA 2,439,250; EP 1370172; JP 4002185; US 6991666;
AU 2002225207; EP 1361814; JP 3860541; US 7018439; AU 2001240894;
EP 1268076; JP 2003-528704; US 6,835,222; AU 2002-225232; EP 1361815;
JP 3940082; US 6,974,488; EP 1748848; JP 2007-534377;
US 2007-0175189; WO 2005/110608; WO 2008/009884; WO 2008/009891;
WO 2008/015377; WO 2008/015378; WO 2008/009886;
WO 2008/009888; WO 2008/009883; GB 2440515; GB 2440514;
GB 2440126; GB 2440109; GB 2440107.
DESIGNS/DESIGN APPLICATIONS:
GB 3025398; GB 3025399; GB 3025400; GB 3025401; GB 3025402;
GB 3025403; GB 3025404; EU 651849.
Equivalent patents, registered designs and applications exist in other countries.
USING THE DYSON HANDHELD VACUUM
CAUTION:
Dirt and debris may be released from the Dyson handheld vacuum if it is turned•
upside down. Ensure the Dyson handheld vacuum remains upright in use and
storage.
Do not operate the Dyson handheld vacuum while checking for blockages.•
PLEASE NOTE:
Do not carry out any maintenance or repair work other than that shown in this•
Dyson Operating Manual or advised by the Dyson Customer Care Helpline.
This Dyson handheld vacuum is designed for domestic indoor and car use only.•
Do not use it while the car is in motion or while driving.
Do not press down on the nozzle with excessive force when using the Dyson•
handheld vacuum as this may cause damage.
If the motor overheats, the Dyson handheld vacuum will cut out automatically.•
Leave it to cool for at least an hour and check for blockages before restarting.
Fine dirt such as flour or plaster dust should only be vacuumed in very small•
amounts.
Consult your flooring manufacturer’s recommended instructions before•
vacuuming and caring for your flooring, rugs and carpet.
TROUBLESHOOTING – DYSON HANDHELD VACUUM
Charged.
Less than one minute of charge remaining/fully discharged.
Less than 3°C – do not use.
Filter missing/filter fitted incorrectly.
EMPTYING THE CLEAR BIN
CAUTION:
Switch off the Dyson handheld vacuum and disconnect from charger before•
emptying the clear bin.
Empty as soon as the dirt reaches the level of the• MAX mark – do not over fill.
To release the dirt, push the button at the side of the clear bin as shown.•
PLEASE NOTE:
Do not use the Dyson handheld vacuum without the clear bin in place.•
CLEANING THE CLEAR BIN
CAUTION:
Ensure the clear bin is completely dry before replacing.•
PLEASE NOTE:
To remove the clear bin, push the release button on the underside of the Dyson•
handheld vacuum as shown.
Use only cold water to clean the clear bin. Do not use detergents, polishes or•
air fresheners.
Do not put the clear bin in a dishwasher.•
WASHING THE FILTER
CAUTION:
Switch ‘OFF’ and disconnect from charger before removing the filter.•
Ensure filter is completely dry before refitting to the Dyson handheld vacuum.•
PLEASE NOTE:
This Dyson handheld vacuum has one filter, located as shown. It is important to•
check your filter and wash with cold water regularly or as required, to maintain
performance. Please leave to dry completely for 12 hours.
The filter may require more frequent washing if vacuuming fine dust.•
Do not use detergents to clean the filter.•
Do not put the filter in the dishwasher, washing machine, tumble dryer, oven,•
microwave or near an open flame.
LOOKING FOR BLOCKAGES
CAUTION:
Switch off the Dyson handheld vacuum and disconnect from charger before•
looking for blockages.
Beware of sharp objects when clearing blockages.•
Refit all parts of the Dyson handheld vacuum securely before using.•
PLEASE NOTE:
Clearing blockages is not covered by the Dyson handheld vacuum’s guarantee.•
If any part of the Dyson handheld vacuum becomes blocked, it may overheat
and then automatically shut off.
Unplug the Dyson handheld vacuum and leave to cool down. Clear blockage•
before restarting.
CHARGING AND STORING THE DYSON
HANDHELD VACUUM
The Dyson handheld vacuum will turn off if the battery temperature is below
3°C. This is designed to protect the motor and batter y of your product. Do
not charge the Dyson handheld vacuum and then move it to an area with a
temperature below 3˚C for storage purposes.
TROUBLESHOOTING – CHARGER
Charging.
Fully charged.
Not charging – battery.
Not charging – low temp.
BATTERY SAFETY INSTRUCTIONS
Use only Dyson batteries and charging unit for the Dyson handheld vacuum.
The battery is a sealed unit and under normal circumstances poses no safety
concerns. In the unlikely event that liquid leaks from the battery do not touch
the liquid and observe the following precautions:
Skin contact – can cause irritation. Wash with soap and water.
Inhalation – can cause respiratory irritation. Expose to fresh air and seek
medical advice.
Eye contact – can cause irritation. Immediately flush eyes thoroughly with
water for at least 15 minutes. Seek medical at tention.
Disposal – wear gloves to handle the bat tery and dispose of immediately
following local ordinances or regulations.
CAUTION:
The battery used in this device may present a risk of fire or chemical burn if
mistreated. Do not disassemble, short contacts, heat above 140° F (60° C), or
incinerate. Replace battery with a Dyson battery only, use of any other battery
may present a risk of fire or explosion. Dispose of used battery promptly. Keep
away from children. Do not disassemble and do not dispose of in fire.
The battery must be removed from the Dyson handheld vacuum before it is•
scrapped.
The battery is to be disposed of safely.•
The Dyson handheld vacuum must be disconnected from the supply mains when•
removing the battery.
The symbol on the product or on its packaging indicates that this product
should not be treated as household waste. Instead it should be handed over
to the applicable collection point for the recycling of electrical and electronic
equipment – this may be your local civic amenity site product. By ensuring
this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and for human health, which could other wise
be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact the Dyson Customer
Care Helpline, your local authority civic amenity site product.

www.dyson.com
Dyson Customer Care
If you have a ques tion about your Dyson handheld vacuum,
call the Dyson Customer Care Helpline with your serial number
and details of where and when you bought the Dyson handheld
vacuum, or contact us via the Dyson website. The serial number
can be found on the main body of the Dyson handheld vacuum
behind the filter.
JN.3 0565 PN.17811-05-01 29.05.09
AU Dyson Customer Care
[e-mail]
1800 239 766
Dyson Appliances (Aust) Pty Ltd.,
PO Box 2835,
Taren Point, NSW 2229,
Australia
www.dyson.com.au
NZ Dyson Customer Care
[e-mail]
0800 397 667
Avery Robinson Ltd.,
Unit F, 151D Marua Road,
Ellerslie, Auckland 1051,
New Zealand
www.dyson.co.nz
IMPORTANT!
WASH FILTER
QUESTIONNAIRE
1 This handheld cleaner is…
My first handheld cleaner
A replacement handheld cleaner
An additional handheld cleaner
2 Which brand of cleaner are you replacing or adding to?
Dyson Electrolux
Hoover LG
Miele Panasonic
Samsung Nilfisk
Vax Kambrook
Volta Wertheim
Other, please specify
3 Why did you choose to buy a Dyson handheld cleaner?
(Please rank in order, 1-5. 1 being the most important).
Dyson reputation
Good for pet hair pick-up
Performs consistently well
No loss of suction
Previous experience of Dyson
Features
HEPA filtration
Price/special offer
Wanted a bagless handheld
Compact and easy to store
Store staff recommendation
Picks up more dust than others
Latest model/technology
Reliability/quality
Friend/family recommendation
Other
4 Where did you first hear about the Dyson model you bought?
From friends and family
Saw it on the internet
From a TV/magazine advert
Saw it in a store catalogue
Saw it in a store
Recommended by salesperson
5 Do you own a Dyson handheld?
Yes No
6 What is your average household income?
Less than $45,000
Between $45,000 – $74,000
Between $75,000 – $100,000
Over $100,000
7 Do you have any household pets?
Dog Cat
None Other
8 Does anyone in your household suffer from any of the following?
Asthma Allergies
None
9 To which age group do you belong?
16 – 24 25 – 34
35 – 44 45 – 54
55 – 64 65+
10 Would you recommend a Dyson handheld cleaner to your family
and friends?
Yes No
11 Do you have children?
Pre-school Aged 5-17 years
Aged +17 years Children no longer at home
Pregnant No children
12 Which best describes your house?
(Tick one from each column).
Own house Up to 2 beds
Rented house 3-4 beds
Own apartment/villa More than 4 beds
Rented apartment/villa
Live with parents
Share accommodation
Please take a few moments to answer our questions.
They will help us develop new products for the future.
THANK YOU FOR YOUR TIME
Wash your filter with cold water regularly or as required.
Register for a filter wash reminder by email (Australia only);
[e-mail]

3 EASY WAYS TO REGISTER YOUR 2 YEAR GUARANTEE
REGISTER
BY MAIL
Complete and return
the form to Dyson in
the envelope supplied.
REGISTER
BY PHONE
Call our dedicated Helpline.
REGISTER
ONLINE
Visit our website to register your
full parts and labour guarantee
online (Australia only).
www.dyson.com.au/register
GUARANTEE FORM
By mail Yes No
By phone Yes No
Did you purchase an extended warranty?
If yes, for what additional period?
Yes
1 year
No
2 years 3 years
Title Surname
First name
Telephone Mobile
e-mail
Postcode Country of purchase Australia New Zealand
Address
Date of purchase / / Store of purchase
Serial number
Privacy Act
Dyson may use this information for future marketing and research purposes (including sending commercial electronic messages) and may
disclose it to third parties for the purposes of providing the services you have requested or to our business partners or professional advisers.
If you wish to access your personal information or see our full privacy policy, please contact us at [e-mail]
If you do not wish to receive marketing information by these methods from Dyson please tick this box.
By email Yes No
By text message Yes No
As a Dyson owner, you can hear about Dyson inventions and ideas before anyone else. If it’s okay to contact you, please let us know how we may
do this.
AU 1800 239 766
NZ 0800 397 667
SG 7000 435 7546
ID 021 707 39766
