e-Flame USA FS2210C User manual

ELECTRIC FIREPLACE STOVE
MODEL FS2210C
OWNERS MANUAL
Only use this heater as described in this manual. Any other use is not
recommended by the manufacturer, and may cause fire, electric shock, or
other personal injury.
WARNING! Read and understand this entire owner’s manual, including all
safety information, before plugging in or using this product. Failure to do
so could result in fire, electric shock, serious personal injury, or death.
WARNING! INDOOR use only! NEVER use this heater outdoors!
SAVE THESE INSTRUCTIONS!
CAUTION! Keep this owner’s manual for future reference. If you sell or give
this product away, make sure this manual accompanies this product.
NO VENTING REQUIRED
Power: 110 ~ 120V AC; 60 Hz
Maximum Heat: 1500 WATTS
IMPORTANT SAFETY INFORMATION!

2
WARNING
l ALWAYS keep electric cords, home furnishings, drapes, clothing, papers, or
other combustibles at least 3 feet (0.9m) away from the front of this heater,
and away from the bottom, sides, and rear of this heater.
l DO NOT place the heater near a bed because objects such as pillows or blankets
can fall off the bed and be ignited by the heater.
l DO NOT COVER this heater or block the air vents at all. Doing so could cause a
fire.
l AVOID fire or electric shock! NEVER insert or allow any foreign objects to enter
the ventilation or exhaust openings of this heater.
l Prevent Fire! Keep all flammable liquids, like gasoline or paint, away from this
heater. This heater produces arcing sparks that could ignite flammable liquids.
l DO NOT cover this heater in any manner. Doing so could block the air flow and
cause the unit to overheat, or could ignite the material covering the heater.
l NEVER run the power cord under carpet, rugs, runners, or any other covering.
Doing so could cause the cord or materials covering the cord to overheat.
l AVOID FIRE! Regularly inspect all air vents to make sure they are free from dust,
lint, or other blockage. Unplug the unit and clean with a vacuum ONLY. DO NOT
rinse or get wet.
WARNING
l For residential use only! NOT for commercial use! NEVER use this fireplace
for other than its intended purpose.
l Use extreme caution if using this heater near children, or where children may be
present.
l NEVER leave this heater unattended. ALWAYS unplug this heater when not in
use.
l This heater is hot when in use. AVOID INJURY! DO NOT TOUCH hot surfaces,
or attempt to move this heater while it is hot.
l ALWAYS turn this heater off before unplugging it from the outlet.
l AVOID INJURY! Keep the cord from crossing traffic areas to avoid tripping.
l NEVER modify this fireplace. Doing so could result in personal injury or property
damage. Modification of this fireplace completely voids all warranties.
l Discontinue use if this fireplace malfunctions or is dropped or damaged in any
manner.
WARNING

3
l Risk of electric shock! DO NOT OPEN! No user-serviceable parts inside!
l ALWAYS disconnect this unit from the power supply before performing any
assembly or cleaning, or before relocating the electric fireplace.
l ALWAYS store this heater in a dry location. NEVER use the fireplace if it has
become wet.
l NEVER use this heater in bathrooms, laundry rooms, or any other location
where the heater could fall into a bathtub or pool, become damp or come in
contact with water.
l NEVER operate this heater if the power cord or plug has become damaged, or if
the grounding pin is damaged or missing.
l Place the heater near a wall outlet so an extension cord is not needed. If an
extension cord is needed, the gauge of the cord must be at least 14AWG, and
the rating must be at least 1875 Watts. NEVER use a smaller gauge cord with
a lower rating. Doing so may result in fire or electric shock.
l ONLY use this heater on a 110~120 Volt 15 Amp grounded circuit. NEVER
overload the circuit. If this heater trips the circuit breaker, unplug all other
appliances on the same circuit before the next use. Avoid plugging other
appliances into the same circuit as this heater.
l NEVER plug this heater into an outlet that is old, cracked, or has any loose wires
or connections. Plugging this heater into a faulty outlet could result in electric
arcing within the outlet and cause the outlet to overheat or catch fire.
l ALWAYS check your heater cord and plug connections with each use!
i) MAKE SURE the plug fits tight in the outlet! Faulty wall outlet connections or
loose plugs can cause the outlet to overheat.
ii) Heaters draw more current than small appliances. Overheating may occur
even if it has not occurred with the use of other appliances.
iii) During use check frequently to see if the plug outlet or faceplate is HOT!
iv) If the outlet or faceplate is HOT, discontinue use immediately and have a
qualified electrician inspect and/or replace the faulty outlets.
l The cord supplied with the heater
has a plug with two blades (live
and neutral) and one round pin
(ground). If a 3-slot receptacle is
not available, an adapter MUST
be used. The adapter MUST be
properly grounded to the outlet
box (see figure at right).
PREPARATION

4
l Remove all parts and hardware from the carton and place them on a clean, soft,
and dry surface.
Make sure all parts are dry, and the power cord and plug are not damaged.
See IMPORTANT SAFETY INFORMATION on pages 2 and 3.
l Compare the contents with the parts list to make sure nothing is missing.
l Dispose of all packaging materials properly.
l Please recycle whenever possible.
TOOLS NEEDED FOR ASSEMBLY
l Phillips (“+”) screwdriver (not included)
PARTS AND HARDWARE
Item
Description
Qty
A
Stove
1
B
Legs
4
C
Screws
8
C

5
ASSEMBLY
ALWAYS make sure the unit is unplugged before beginning assembly!
NEVER move or clean the heater, or change the bulbs, while it is plugged in.
1) Carefully turn the STOVE (A) upside down and lay it on a clean soft surface.
2) Insert the TAB of one LEG (B) into the SLOT in the corner of the stove frame.
3) Thread two SCREWS (C) through the holes in the leg and into the stove frame.
Partially tighten the screws with a Phillips screwdriver.
4) Repeat Steps 2 and 3 for the other three legs.
5) Check the alignment and tighten all 8 screws securely with the screwdriver. DO
NOT over-tighten the screws.
ALWAYS attach the feet before using! NEVER plug in or operate this unit if
the feet are not securely attached!
TAB
B

6
OPERATION
NOTICE
When the heat function is used for the first time, a slight odor may be
present. This is normal and should not occur again unless the heater is
not used for an extended period of time.

7
CARE AND MAINTENANCE
TEMPERATURE LIMITING CONTROL
This heater is equipped with a Temperature Limiting Control. Should the heater reach
an unsafe temperature (212°F / 100°C), the heater will automatically turn OFF. To reset:
1. Unplug the power cord from the outlet.
2. Turn the ON/OFF switch on the CONTROL PANEL to OFF.
3. Wait 5 minutes.
4. Inspect the fireplace to make sure no vents are blocked, or clogged with dust or
lint. If they are, use a vacuum to clean the vent areas.
5. With the POWER switch OFF, plug the power cord back into the outlet.
6. If the problem continues, have your outlet and wiring inspected by a professional.
CLEANING
ALWAYS turn the heater OFF and unplug the power cord from the outlet
before cleaning, changing the light bulbs, or moving this stove. Failure to do
so could result in electric shock, fire, or personal injury.
NEVER immerse in water or spray with water. Doing so could result in
electric shock, fire, or personal injury.
Metal:
l Buff using a soft cloth, slightly dampened with a citrus oil-based product.
l DO NOT use brass polish or household cleaners as these will damage the metal.
Glass:
• Use glass cleaner and dry thoroughly with a paper towel or lint-free cloth.
• NEVER use abrasive cleansers or any cleaner that could scratch the surface.
Plastic:
• Wipe with a slightly damp cloth and a mild solution of dish soap and warm water.
Vents:
• Use a vacuum or duster to remove dust and dirt from the heater and vent areas.
MAINTENANCE
Risk of electric shock! DO NOT OPEN the main panels! No user-
serviceable parts inside!
Storage:
• Store heater in a clean dry place when not in use.
Electrical and Moving Parts:
• The fan and motors are lubricated at the factory and will not require lubrication
for the life of the stove.
• Except for the light bulbs, all electrical parts and components are integrated into
the heater and are not serviceable by the consumer.
Light Bulb Inspection and Replacement:
The flame effect is created by two 40-Watt light bulbs with an E-12 (small) socket base.
Use only this same type of bulb as a replacement. If the flame effect does not work, the
bulbs may have come loose or been damaged during shipping.

8
Light bulbs become very hot during use. Allow at least 10 minutes for
the bulbs to cool before touching.
To inspect or replace the bulbs, first unplug the power cord from the outlet. Locate the
access panel on the back of the stove. Remove the screws and the panel. Check the
bulbs to be sure they are finger tight and in working order. Replace any damaged or
faulty bulbs. Reattach the access panel. Do not operate this heater without the access
panel in place. Do not remove the back cover. There are no serviceable parts inside.
LIMITED WARRANTY
This warrants to the original purchaser that this product is free from defects in material and workmanship
as of the date of purchase and that it will, under normal use and proper care, remain so for 30 days from
the date of purchase. Missing or initially defective parts will be replaced free of charge during the period
of this limited warranty. The original dated sales receipt is required for all warranty claims. This warranty
does not cover damage which has occurred during transport from the point of purchase to the consumer’s
home. This warranty does not cover glass, light bulbs, remote controls, or batteries.
This product is for residential use only. Any and all commercial use of this product voids all
warranties, and frees the manufacturer from all liability. Read and understand all assembly and operating
instructions, and all safety information and warnings, before use. The following will void this warranty:
Damage caused from tampering with, modifying, or altering the fireplace insert in any manner; Damage
due to incorrect assembly, improper care, misuse, or abuse; Damage from being used with the wrong
power source; Water damage; Damage caused from this insert being used outdoors; Damage caused
from this insert being used for excessive periods of time; Damage caused by the insert being used in a
commercial application; Damage from use as a primary heat source; Other misuse or abuse not
specifically listed herein. This product is not intended to be used as a primary heat source.
Dura Global Sourcing Inc.(hereafter, DURA), its directors, officers, or agents, will not be liable to the
purchaser or any third party, whether in contract, in tort, or on any other basis, for any indirect, special,
punitive, exemplary, consequential, or incidental loss, cost, or damage arising out of or in connection with
the sale, maintenance, use, or inability to use this product, even if DURA, or its directors, officers, or
agents have been advised of the possibility of such losses, costs or damages, or if such losses, costs, or
damages are foreseeable. In no event will DURA, or its officers, directors, or agents be liable for any
direct losses, costs, or damages that exceed the purchase price of the product. Some states do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion
may not apply to the purchaser. This limited warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
Thank you for purchasing this product! If you have questions about the assembly or
operation of this product, are missing parts, or have defective parts, please e-mail us at
[email protected]
