Comfort Glow EF6033R Assembly instructions

Part List
A)Top Panel 1 pc
B)Middle Panel 1 pc
C) Left&Right Back Panels 2pcs
D)Left&Right Panels 2pcs
E)Left&Right Small Panels 2pcs
F)Upper Left&Right Small Panels 2pcs
G)Middle Left&Right Small Panels 2pcs
H)Lower Left&Right Small Panels 2pcs
I)Middle Small Front Panels 2pcs
J)Left&Right Small Front Panels 2pcs
K)Base Panel 1pc
L)Screws 12pcs
M)Connectors 8sets
N)Wood Connectors 20pcs
O)KD Screws 6pcs
P)Mounting Heater(6*10) 2pcs
Q)Mounting Brackets 2pcs
R)Six-angles wrench 1pcs
T)Wood Nail 16pcs
U)Locking Nut and Screws 4sets

Step 1. Attached 8pcs Connectors (M) to The panels(,F) as show in Fig A
A
Step 2,Attached 16 wood connectors (S ) to the Left&Right Panels and Left&Right Small Panels (D.E) as
show in Fig B

B
Step 3.Attached 20 pcs wood connectors to the Middle Panel, Left&Right Panels and Left&Right Small
Panels (B.D.E) as show in Fig C
Step 4,Attached Left&Right Small panels(E) to the Base Panel (K ) using 4 Screws(P) by Six-angles
wrench(R),Attached the Middle Panel (B) to the Left&Right Small panels(E) using 4 Screws(P) by Six-angles
wrench(R).See Fig E.D,F,G
C

D
E

F
G
Step 5 Put the Left&Right Back Panels (C) to the Left&Right Small Panels(E).See Fig H

H
Step 6.Attached the Left&Right Panels(D) to the Base Panel(K) using 4 Screws(P) by Six-angles wrench(R) as
shown in Fig I.J

I

J
Step 7,Put the Middle Left&Right Small Panels(G) and Lower Left&Right Small Panels(H) in place as show on
Fig K

K
Step 8,Put the Upper Left&Right Small Panels(F) into the Body, Insert 8Locking Nuts(N) into each of
these holes keeping the screw head (+) facing out to enable tightening with screwdriver. See Fig
L,M

L
M
Step 9,Attached the Top Panel(A) to the Upper Left&Right Small Panels(F) by 4 Set Locking Nuts and

Screws(U) as show on Fig N,O
N
O
Step 10.Connect the Left&Right Small Front Panels(J) to the Left&Right samll Panels(E) by 4
KD Screws(O) as shown on Fig P

P
Step 11.Connect the Middle Small Front Panel(I) to the Middle Panel(B) by 2 KD Screws as shown on Fig
Q
Q

Step 12.Put the insert in place and install the insert to the mantle with 2 Mounting heaters(Q) and 2
Mounting Brackets(R) See Fig.R.S.T
R
S

Step 13. Tighten all KD Screws
.
ON/OFF 750W 1500W
