E-Lins H900 Series User manual

H900 Quick Start
E-Lins Technology Co.,Limited
Tel: [phone] E-mail: sale[email protected] www.e-lins.com www.szelins.com
Before Installation and Configuration
1. H900 router has different version. Study your router version before installation.
2. For GSM/GPRS/EDGE/HSDPA/HSUPA/HSPA/HSPA+/4G LTE+5G(SA) or 5G(NSA) version, please get a
SIM card with data business.
3. For CDMA2000 EVDO/CDMA1x version, please get a UIM card with data business or inform us before
order if the network uses non-ruim (nam-flashing).
4. Make sure the sim card or uim card is with enough data business and balance.
5. Make sure the signal is good enough where you test or install the router. Weak signal will make the router
no work. If you find your signal strength is not good, please contact us for high gain antenna.
6. Different countries and carriers use different network band and frequency. E-Lins packs units with free
world-wide-use antenna. It can work, but the data speed or signal may not be good at your sites. Please buy
dedicated high gain antenna from your local suppliers or contact E-Lins to OEM/ODM the antenna.
Notes: This quick start is for GSM/GPRS/EDGE/HSDPA/HSUPA/HSPA+/TD-SCDMA/4G LTE/5G network only.
For EVDO network or CDMA network, please refer to manual or contact us freely.
Step 1) Confirm the sim card if can work with other 2G/3G/4G/5G router or modem. If the sim card can not work, the
router will not work correctly.
Step 2) Connect the H900 Router LAN port to a PC via RJ45 cable. Make the PC automatically to get the IP,
Submask, DNS.
The PC will be get a IP of 192.168.1.xxx.
Step 3) At PC web browser, please type: http://192.168.1.1
Username: admin Password: admin
Step 4) System –Setup Wizard
4.1) General

H900 Quick Start
E-Lins Technology Co.,Limited
Tel: [phone] E-mail: sale[email protected] www.e-lins.com www.szelins.com
a) Set the Web Login password;
b) Sync with system time with clicking “Sync with browser”, or select the “Timezon”;
c) Click “Save & Apply”button for next step;
4.2) Mobile

H900 Quick Start
E-Lins Technology Co.,Limited
Tel: [phone] E-mail: sale[email protected] www.e-lins.com www.szelins.com

H900 Quick Start
E-Lins Technology Co.,Limited
Tel: [phone] E-mail: sale[email protected] www.e-lins.com www.szelins.com
Item
Description
Enable
Check it
Mobile connection
“DHCP mode”or “PPP mode”. Normally system will automatically select
PIN code
If the SIM card uses PIN code, please put here. Wrong PIN code makes router no work.
If the SIM card doesn’t use PIN code, please keep blank here.
Dialing number
Fill in the right parameters. Get this parameter from the Sim Card Provider or Carrier. With
experience, most of time, 2G/3G/4G use *99#, and CDMA/EVDO use #777.
APN
Fill in the right parameters. Get this parameter from the Sim Card Provider or Carrier;
Authentication
method
Fill in the right parameters. Get this parameter from the Sim Card Provider or Carrier;
None
No more settings
CHAP
Need set “Username”and “Password”
PAP
Need set “Username”and “Password”
Dual APN support
Most of SIM cards or Carriers/Operators just use one APN, but some use two APNs. Check
this feature to use.
Second APN: configure it referring to “APN”;
Second Authentication method: configure it referring to “Authentication method”;
Dual sim support
sim2: configure it referring to “sim1”; 2 sim cards can choose different operators, 1 sim card
works, and the other is a backup

H900 Quick Start
E-Lins Technology Co.,Limited
Tel: [phone] E-mail: sale[email protected] www.e-lins.com www.szelins.com
Sim Switch
Manually select sim1 or sim2 as Master SIM, or follow Switch Rules to select Master SIM
Network Type
Select the network you want to use. Normally keep default settings
Demand
Normally keep default settings. For some models, there is no this option.
MTU
Normally keep default settings
Click “Save & Apply”button for next step;
4.3) LAN
Set the router LAN IP parameters. Click “Save & Apply”button for next step;
4.4) WiFi

H900 Quick Start
E-Lins Technology Co.,Limited
Tel: [phone] E-mail: sale[email protected] www.e-lins.com www.szelins.com
Notes: for security, it is highly recommend to set “Encryption”for the WiFi Radio.
Step 5) once the router is online, it gets a WAN IP Address and Status Page will show similar info, also the “Cell
LED”will light on. And “Cell Signal LED”flash if there is enough signal.
Level
Signal Strength Value
Cell Signal LED Flashing Speed
1
1-4
Flash per 2 seconds
2
5-17
Flash per 1 second
3
18-31
Flash per 0.5 second
5.1) Status –Overview

H900 Quick Start
E-Lins Technology Co.,Limited
Tel: [phone] E-mail: sale[email protected] www.e-lins.com www.szelins.com
Step 6) In order to keep the router working stably, it’s highly recommended to activate the “ICMP Check”feature.

H900 Quick Start
E-Lins Technology Co.,Limited
Tel: [phone] E-mail: sale[email protected] www.e-lins.com www.szelins.com
Notes:
1) For router working with best stability, we highly suggest activate and use this feature. With this feature, the
Router will automatically detect its working status and fix the problem.
2) You can fill in Host1 only, also you can fill in Host1 and Host2 together.
Below list the ICMP checking principle diagram.
