E-Z Trench Groundsaw EZ-9100 User manual

Owners Manual
E-Z Trench Manufacturing Co., Inc.
2315 S. Hwy. 701 • Loris, S.C. 29569
[phone]
Fax [phone]
www.eztrench.com
EZ-9100
1.
A WORD TO E-Z TRENCH OWNERS . . .
THIS MANUAL HAS BEEN PREPARED TO ACQUAINT YOU WITH THE
ASSEMBLY, OPERATION AND MAINTENANCE OF YOUR E-Z TRENCH
TRENCHING MACHINE, AND TO PROVIDE SAFETY INFORMATION.
WE URGE YOU TO READ IT CAREFULLY AND FOLLOW THE RECOM-
MENDATIONS CONTAINED TO HELP ASSURE THE MOST TROUBLE-
FREE OPERATION.
WE WOULD LIKE TO TAKE THIS OPPORTUNITYTO THANK YOU FOR
CHOOSING E-Z TRENCH, AND TO ASSURE YOU OF OUR
CONTINUING INTEREST IN YOUR NEEDS.
INDEX
4.-1. A WORD TO E-Z TRENCH OWNERS & SAFETY PRECAUTIONS
4.-2. OPERATING INSTRUCTIONS.
4.-3. MAINTENANCE SCHEDULE
4.-5. PARTS DRAWING / PARTS LIST
4.-6. TERMS AND WARRANTY
4.-7. WARRANTY REGISTRATION
4.-8. TROUBLE SHOOTING & BOLT SIZES.
WARNINGS! & SAFETY PRECAUTIONS
1. ALWAYS WEAR EYE PROTECTION.
2. STAY CLEAR FROM CUTTING BLADES.
3. KEEP HANDS AND FEET CLEAR OF PULLEYS AND BELTS
WHEN ENGINE IS RUNNING.
4. LOCATE ALL UNDERGROUND POWER LINES, GAS LINES,
AND WATER LINES BEFORE TRENCHING.
5. ENGINE R.P.M. SHOULD RUN AT 3600 R.P.M.

2.
EZ9100 OPERATING INSTRUCTIONS
1. FILL CRANKCASE AND CLUTCH WITH OIL BEFORE STARTING.
FOLLOW INSTRUCTIONS OF ENGINE MANUFACTURER.
2. START ENGINE.
3. SQUEEZE THROTTLE LEVER ON HANDLE BAR TO
START BLADE.
4. SLOWLY LOWER THE BLADE BY TURNING DEPTH ADJUSTMENT
CRANK (8012) CLOCKWISE UNTIL DESIRED DEPTH IS REACHED.
5. PULL THE MACHINE BACKWARD. BEGIN TRENCHING SLOWLY
UNTIL FAMILIAR WITH THE MACHINE AND SOIL CONDITIONS.
6. IF THE BLADE STOPS TURNING WHILE TRENCHING, THE
CLUTCH IS SLIPPING DUE TO TRENCHING TOO FAST
OR SUDDEN IMPACT WITH AN OBJECT. STOP TRENCHING
AND REMOVE OBJECT FROM PATH OR SLOW DOWN.
THEN CONTINUE TRENCHING.
AFTER MACHINE HAS RUN APPROXIMATELY ONE HOUR:
RE-ADJUST CHAIN IN GEAR BOX BY SLIDING GEAR BOX DOWN.
THIS IS DONE BY LOOSENING THE THREE BOLTS BEHIND THE
PULLEY (EZ40) AND SLIDING THE GEAR BOX AWAY FROM THE
HANDLE BAR, THEN RETIGHTENING THE BOLTS.
3.
1. DO NOT OVERTIGHTEN NUT ON BACKSIDE OF LARGE
PULLEY (EZ40). IT ONLY NEEDS TO BE SNUG.
2. KEEP CASTLE NUT ON TOP OF JACK SNUG.
3. TO REPLACE BITS:
A. INSERT 2 STRAIGHT BITS DIRECTLY ACROSS FROM
EACH OTHER.
B. NEXT, INSERT THE LEFT AND RIGHT BITS BY PLACING
THEM IN THE SLOT THAT BENDS IN THE SAME DIRECTION
AS THE BIT. (REMEMBER THAT THE CARBIDE SHOULD
FACE LEFT WHEN YOU ARE FACING THE MACHINE FROM
THE BLADE SIDE.)
4. NOTE: PROPER BELT TENSION, 1/8” OR WHEN A DIME
WILL FIT SNUGLY BETWEEN COIL SPRING.
EZ9100 GROUNDSAWTM
MAINTENANCE SCHEDULE
Perform at every indicated month
or operating hour interval,
whichever comes first.
Check blade and bits* 
Check engine oil & air filter 
Lubricate pivot points after washing 
Snug castle nut on top of jack 
Tighten any loose bolts 
Change engine oil** 
Tighten chain in gearbox (pg 2) 
Check air pressure of tires 
Clean air filter or replace 
Change clutch oil*** 
*Replace carbide bits before carbide tips are completely worn.
See tips below on proper bit installation.
**Break in engine with petroleum based oil, then switch to E-Z TrenchTM specially
formulated synthetic.
***Use only E-Z TrenchTM synthetic for high wear resistence and reduced heat.
Every
Use
First
month
or
20 Hrs.
Every
3months
or
50 Hrs.
Every
6months
or
100 Hrs.
➧
DIME
MAINTENANCE TIPS

4. 5.
843-756-6444
Model EZ9100

6.
TERMS AND CONDITIONS OF SALE
USE:
E-Z TRENCHER IS DESIGNED TO TRENCH IN SOIL ONLY. ANY
OTHER USE IS AT THE RISK OF THE OWNER.
PRICES:
Prices are subject to change without notice and will be invoiced at prices
in effect on date of order.
CHANGES:
E-Z TRENCH MANUFACTURING, Inc. reserves the right to discontinue
items, change specification, design, or prices at any time, without notice
and without incurring any obligation whatsoever.
FREIGHT POLICY:
All orders are F.O.B., Loris, South Carolina, USA. Title to goods and risk
of loss passed in Loris, South Carolina.
DAMAGED OR LOST SHIPMENTS:
All shipments must be carefully inspected. In case of damaged or loss,
accept the shipment, but have carrier note damages or loss on delivery
receipt. If it is concealed damage, call carrier for inspection. Make claim
for damage with carrier.
LIMITED WARRANTY:
The E-Z Trencher is warranted against defects in workmanship or mate-
rials for a period of one year. Blades, bits, belts, clutches and bearings,
which are normal wear items, are not warranted. This warranty covers
replacement of parts only, no consequential damages are covered. In the
event of a warranty claim contact E-Z Trench Manufacturing Company, Inc.
This warranty does not include products which have been subject to
improper use, or application, or misuse, neglect or accident; nor does it
attend to products which have been repaired or altered by other than E-Z
Trench Manufacturing Company, Inc.All warranty repairs are F.O.B., Loris,
S.C, U.S.A. E-Z Trench Manufacturing Company, Inc. will not be responsi-
ble for any transportation charges.
THERE IS NO OTHER EXPRESS WARRANTY. TO THE EXTENT
PERMITTED BY LAW ALL IMPLIED WARRANTIES INCLUDED THOSE
OF MERCHANTABILITYAND FITNESS FOR APARTICULAR PURPOSE
ARE EXCLUDED. LIABILITY FOR CONSEQUENTIAL DAMAGES
UNDER ANY AND ALL WARRANTIES ARE EXCLUDED TO THE
EXTENT THATEXCLUSION IS PERMITTED BY LAW. Some states do
not allow limitation on how long an implied warranty lasts, and some
PARTS# DESCRIPTON
8012 DEPTH ADJUSTMENT CRANK
8013 DEPTH LINKAGE ROD
8013A JACK LINKAGE BUSHING
8014 DEPTH CONTROL SCREW
8014A CASTLE NUT
8014B BRASS BUSHING
8014C JACK SHIM
8015 LINKAGE PIN
8016 1/4 X 2 X 5” WASHER PLATE
8048 COMPLETE JACK
8048A JACK BOTTOM
8048B JACK TOP
8160 HANDLE
9002 HOOD
9003 PNEUMATIC WHEEL
9004 PUSH CAP
9017 BLADE GUARD
9018 BELT GUARD
9027 INSIDE HALF GEAR BOX
9029 SPACER BUSHING
9030 11 TOOTH SPROCKET
9033 CHAIN
9038 HOOD BRACE
9045 BEARING (INSIDE GEARBOX HALF)
9022V4 1” BEARING
9028V4 OUTSIDE HALF GEARBOX
9031V4 29 TOOTH SPROCKET
9032V4 1” SHIM
9034V4 1” NUT
9035V4 HD BLADE ASMBLY W/OUT BITS
9036A ROLL PINS
9036L LEFT HEAVY DUTY CARBIDE BIT
9036R RIGHT HEAVY DUTY CARBIDE BIT
9036ST STRAIGHT HEAVY DUTY CARBIDE BIT
9039 FRONT AXLE
9039A FRONT AXLE SPACER
9049V4 BLADE W/BITS (1” ARBOR)
9100 FRAME
9100A DEBRIS DEFLECTOR
9100B GREASE FITTING
9142 ENGINE PULLEY
9142A CRANKSHAFT EXTENSION
9142B CRANKSHAFT SPACER
9142C CRANKSHAFT KEY
EZ1 ENGINE THROTTLE
EZ10 BELT TENSION SPRING
EZ11 TENSIONER EYE BOLT
EZ16 HANDLE GRIPS
EZ2 THROTTLE CABLE
EZ22 3/4” BEARING
EZ380 3/4” NUT
EZ40 LARGE PULLEY
EZ43 IDLER ASSEMBLY
EZ6835 BELTS
EZ70 V-IDLER PULLEY
EZ90 HALF MOON KEY

8.
TROUBLE SHOOTING
PROBLEM SOLUTION
IRREGULAR OR 1. CHECK FOR PULLEY MISALIGNMENT.
EXCESSIVE BELT WEAR 2. USE OF OTHER THAN FACTORY
POWER-RATED BELTS.
3. RATE OF DIG IS TOO FAST FOR
SOIL CONDITION.
EXCESSIVE VIBRATION 1. LOOSE, BENT, OR BROKEN
BLADE OR BIT.
2. LOOSE ENGINE MOUNT BOLTS.
3. ENGINE R.P.M. SHOULD BE
3600 R.P.M.
HOUSING CLOGGING 1. SOIL IS TOO WET.
WITH DIRT 2. FOREIGN OBJECT IN HOUSING.
BENT OR BROKEN 1. STRIKING HARD OBJECTS, SUCH
DIGGING BLADE AS BRICKS, LARGE ROCKS, AND
STEEL OBJECTS.
BOLT SIZES FOR EZ9100 GROUNDSAWTM
PART # QTY.SIZE ATTACHES PART...
516134 2 5⁄16 x 13⁄48160 to frame
14234 1 1⁄4x 23⁄48048A
382 1 3⁄8x 2 8048B to 8013
38214 1 3⁄8x 21⁄48048A to 9101
516134 4 5⁄16 x 13⁄4engine bolts
38134 1 3⁄8x 13⁄4EZ43
38112 1 3⁄8x 11⁄2EZ70 to EZ43
51612C 2 5⁄16 x 1⁄29018
51634 6 5⁄16 x 3⁄49002
51634 1 5⁄16 x 3⁄49038 to frame
5161 3 5⁄16 x 1 9017 to frame & 9038
1458 12 1⁄4x 5⁄89027 and 9028V4
3858G8 3 3⁄8x 5⁄8transfer case to carriage
14114 1 1⁄4x 11⁄48012 to 8014
14516ss 2 1⁄4x 5⁄16 set screws for large pulley
51638ss 2 5⁄16 x 3⁄8set screws for engine pulley
7.
states do not allow the exclusion or limitation or incidental or consequential
damages, so the above limitation and exclusion may not apply to you. This
warranty gives you specific legal rights and you may also have other rights
which may vary from state to state.
E-Z Trench Manufacturing Company, Inc. does not warrant the engine but
the purchaser must look to the engine manufacturer for the warranty of the
engine.
NORMAL WEAR:
Warranty will not cover repair where normal use has exhausted the life of a
part. Trenchers, like all mechanical devices, need periodic parts replace-
ment and service to perform well. It should be remembered that the service
life of any trencher is dependent on the care it receives and the conditions
under which it has to operate. Trenchers operate in harsh conditions, which
can cause what appears to be premature wear. Such wear, when caused
by rocks or other abrasive material, is not covered by warranty.
E-Z TRENCH WARRANTY DOES NOT COVER THE FOLLOWING:
1. Bent or broken parts; Such damage is normally the result of abuse,
such as striking a solid object with the cutting blade.
2. Broken parts, which results from excessive vibration caused by loose
engine mounting, loose cutting blades, unbalanced blades, improperly
attaching equipment to trencher, overspeeding or abuse in operation.
3. Misuse, neglect, improper operation, damage or abuse.
4. Alteration or removal of name plates or serial numbers.
5. Modification or change of this product outside the factory.
STANDARD TERMS:
1. C.O.D./F.O.B., Loris, SC, USA
2. Cash, money order, certified check, or wire transfer with order.
3. 30 day with approved credit.
All sales are final with no right to return, price protection or implied con-
signment. No person, including agent, representative, or employee of E-Z
TRENCH MANUFACTURING, Inc. is authorized to assume for E-Z
TRENCH MANUFACTURING, Inc. any obligation or liability concerning
terms or conditions of sale other than that expressly stated herein.
EFFECTIVE MARCH 1, 1985
