Eagle Peak HTM1500 User manual

EAGLE PEAK Greenhouse Heater incl. Digital Thermostat
INSTRUCTION MANUAL
Thank you for choosing Eagle Peak !

DO NOT DISCARD THIS MANUAL , PLEASE RETAIN THIS MANUAL FOR FUTURE USE
FOR YOUR SAFETY
DO NOT STORE
OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS
OR LIQUIDS
IN THE VICINITY OF THIS OR
ANY OTHER APPLIANCE
WARNING!
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
Made in China
1

INTENDED USE: This product is intended only for indoor household or office use.
It is NOT intended for industrial or commercial use. DO NOT USE OUTDOORS OR IN
AREAS EXPOSED TO THE ELEMENTS.
IMPORTANT
PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances,
basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to
persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles
when moving this heater. Keep combustible materials, such as fabric, furniture, pillows, bedding, papers, clothes and
curtains at least 3 feet (0.9 m) from the heater.
3. Extreme caution is necessary when any heater is used by or near children or pets and whenever the heater is left
operating unattended.
4. Always unplug this appliance when not in use.
5. Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has been dropped or
damaged in any manner.
6. Any repairs to this appliance should be carried out by a qualified service person.
7. Under no circumstances should this appliance be modified. Parts having to be removed for servicing must be
replaced prior to operating this appliance again.
8. Do not use outdoors or leave exposed to outside weather and elements.
9. Use your heater only in dry environments. This heater is not intended for use in bathrooms, laundry areas and
similar indoor locations. Never locate the heater where it may fall into a bathtub or other water container. Do not use
your heater outdoors. Do not use near sinks, swimming pools or other damp areas such as flooded basements,
garages, etc or anyplace where the heater could come in contact with water.
10. Do not use this heater in elevated locations, such as on shelves, raised platforms, etc.
11. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Arrange cord
away from traffic area and where it will not be tripped over.
12. To disconnect heater, first turn controls to off, then remove plug from outlet.
13. Connect to a properly grounded outlet only. GFCI outlets are recommended for greenhouse use.
14. This appliance, when installed, must be electrically grounded in accordance with local codes, with the current
CSA C22.0 Canadian Electrical codes or for USA installations, follow local codes or for USA installations, follow local
codes and the National Electric code ANSI/NFPA No. 70.
15. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electrical
shock or fire, or damage the heater.
16. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft surfaces, like a
bed, where openings may become blocked.
17. This appliance has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint or
flammable liquids are used or stored. This appliance should not be used as a drying rack for clothing, nor should
Christmas stockings or decorations be hung or near it.
18. Use this heater only as described in this manual. Any other use not recommended by the manufacturer may
cause fire, electric shock, or injury to persons.
19. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or relocatable power
strip.
20. Do not use this heater with missing, damaged, or broken legs.
21. SAVE THESE INSTRUCTIONS
2

ALWAYS OBSERVE THESE SAFETY PRECAUTIONS WHEN OPERATING YOUR
ELECTRIC HEATER
ALWAYS Read all instructions before operating.
ALWAYS Locate your electric heater away from furniture or loose hanging drapes.
ALWAYS Keep the rear grill away from walls or drapes so as not to block the air intake. (If applicable)
ALWAYS Unplug electric heater when not in use.
ALWAYS Use electric heater on a flat dry surface.
ALWAYS Use on 110-120 volt 60 Hz AC power supply.
ALWAYS Route the cord so it will not be walked on tripped over or pinched by furniture.
ALWAYS Keep electrical cords, drapes and other furnishings away from your electric heater.
ALWAYS Keep your electric heater clean and the filter free of dust. (If applicable)
ALWAYS Use indoors only.
NEVER Place drapes, clothing, fabric, towels, or any combustible material over electric heater to dry.
NEVER Use in the presence of explosive or flammable vapors such as gas or paint.
NEVER Plug another electrical appliance into the same circuit. Blown fuses, tripped circuits and fire
hazards may result.
NEVER Use water or liquids to clean your electric heater.
NEVER Let bare skin touch hot surfaces as this may cause burns.
NEVER Leave electric heater unattended. NEVER Leave electric heater when children or pets are
present.
NEVER Locate electric heater where it may fall into a bath tub or other water containers.
NEVER Operate electric heater with a damaged cord, plug or after the heater malfunctions, or has been
dropped or damaged in any manner.
NEVER Run cord under carpeting or cover with throw rugs or runners.
NEVER Insert or allow foreign objects to enter any ventilation or exhaust openings, as this may cause
an electrical shock, fire or damage.
3

SAVE THESE INSTRUCTIONS
IMPORTANT: Read all instructions and warnings carefully before
installation and use. Failure to follow these instructions may result
in a possible electric shock, injury to persons, fire hazard and will
void the warranty
OPERATING INSTRUCTIONS
Note: When using the heater for the first time, you may notice a slight emission of
smoke. This is normal and will stop after a short time. The heating element is made
of steel and was coated with a layer of protective oil during production.
1. Position the fan heater so that it stands on a firm level surface (When used as portable) and at a
safe distance from wet locations and flammable objects.
2. Connect the fan heater to the proper electrical power. See grounding
instructions.
3. Set the power settings knob to fan or heating position.
4. Set the thermostat dial to the maximum temperature.
5. Once the room reaches the desired temperature, turn the thermostat dial back until heating
element turns off. The heater will cycle automatically around this present temperature. To
increase temperature, turn the thermostat knob clockwise. To lower temperature, turn the
thermostat counterclockwise.
Setting Function
Unit is off
Fan Runs - No Heat
Fan Runs - Full Power Heat
4
Electrical outlet wiring must comply with local building codes and
other applicable regulations to reduce the risk of fire, electrical
shock and injury to persons.
Do not use this appliance if any part of it has been underwater.
And do not replace any part of the electrical system which has
been under water.
Power Settings Knob
Thermostat Dial Knob

Automatic Overheat Safety Control
·This heater is equipped with an internal heat limiting thermostat and overheats protection circuit.
When a potential overheat temperature is reached, the system will automatically shut the heater
off. Unplug heater allow to cool down for 10 minutes, and then restart.
Automatic Overheat Safety Control
·This heater is equipped with an internal heat limiting thermostat and overheats protection circuit.
When a potential overheat temperature is reached, the system will automatically shut the heater
off. Unplug heater allow to cool down for 10 minutes, and then restart.
Cleaning and Maintenance
Any electrical repairs or rewiring of this unit should be carried out by a licensed
electrician and accordance with national and local codes.
·Before cleaning the appliance, disconnect it from the power outlet and let it cool down.
·In order to protect the enclosure, don't s plash water onto the heater, and never use a solvent like
gasoline, isoamyl acetate, toluene, etc. to clean the heater. DO NOT open the heater or attempt to
clean the inside of this appliance.
Automatic Overheat Safety Control
·This heater is equipped with an internal heat limiting thermostat and overheats protection circuit.
When a potential overheat temperature is reached, the system will automatically shut the heater
off. Unplug heater allow to cool down for 10 minutes, and then restart.
CAUTION:
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO SERVICEABLE PARTS INSIDE
Grounding Instructions:
Make sure the heater is switched OFF before
plugging the heater into the outlet. Connect to
properly grounded outlets only.
Note: The power cord has a polarized plug (with
one blade wider than the other) that will only fit in
a polarized outlet one way. If it does not insert
easily try reversing the plug. If it still does not fit
contact your electrician to replace your outlet.
DO NOT defeat the safety purpose of the polarized plug.
5

Model
BTU’s per/Hour
Voltage
Watts
Amps
Water Resistance
Heating Area change to square
feet or cubic feet
HTM1500(ALL specifications +5% / -10% tolerance)
5120
120V
1500
15
IPX4 (Splash Resistant)
15
Model
Heating element does not
glow red
Do not feel heat or air flow
CAUSE SOLUTION
Stainless steel elements won’t
glow red to produce heat
No power to heater
Desired room temperature
reached
Auto-Reset has tripped
Heater has fan only setting
Heater is operating
correctly
Check power connection
to heater
Thermostat will shut off
heater once desired room
temperature is reached
Unplug heater allow to
cool down for 10 minutes,
then restart
Set to run on full power
for heating
SPECIFICATIONS
TROUBLE SHOOTING
6

EAGLE PEAK Digital Thermostat
OPTIMUM TEMPERATURE CHART
The ideal temperature is crucial to growing strong healthy plants.
Excessive heat or cool results in poor growth quality.
Optimum plant
temperatures
Alyssum
Aster
Calendula
Dahlia
Dianthis
Petunia
Marigold
Flowering plants
DAY Night
Temperature for transplant growth
Temperature for seed
germination
Plant type
Verbana family
Herb,shrubs,trees
21
21
21
21
21
21-27
21-27
℃
28
65
70
70
70
70
70-80
70-80
℉
65
16
24
16
24
16
16
24
℃
24
60
75
60
70
60
60
75
℉
75
10
18
10
18
10
10
18
℃
18
50
65
50
65
50
50
65
℉
65
7

The digital temperature control device that allows gardeners to select and maintain optimum
temperatures for faster germination, cutting propogation, and plant growth. It is compatible with
heat mats and greenhouse heaters with maximum power draw of 15A or 1500W.
SET UP THE THERMOSTAT
1. For heat mat use: insert the probe approximately 1"-1.5 " into the rooting area. For greenhouse
heater use use the suction cup mount to measure air temperature in the middle of the greenhouse.
2. Position the thermostat up and away from seedling trays and stray water. DO NOT SUBMERGE THE
THERMOSTAT.
3. Plug the heat mat or heater into the thermostat.
4. Plug the thermostat's power cord into the power source/electrical outlet. The POWER LED lights up.
5. Set the maximum desired temperature for the heat mat or greenhouse heater.
USE THE CONTROLLER
1. Press the SET button to display the current pre-set temperature. The thermostat's LED screen
shows the current temperature whenever the SET button is not activated.
2. Press and hold the SET button for three seconds to enter temperature selection mode. Press the ▲
(UP) or ▼(DOWN) button to adjust the temperature. The thermostat's LED screen shows the
numbers as you cycle through them. Press the SET button again to set the chosen temperature.
The HEATING light cycles on when the mat or heater is in the process of heating. When the LED is
not lit, the mat, or heater, is not providing heat. The light turns off automatically when the probe
reaches the preset temperature.
3. Press the ▼(DOWN) button to display the temperature in Celsius. Press the ▲(UP) button to
display the temperature in Fahrenheit.
TIPS
The Digital Heat Mat is designed to achieve the desired heat temperature within 5 hours. If it takes
longer than 5 hours, or if the mat runs for longer than 5 hours, desired temperaturesare not being
reached. To conserve power and increase the mat's effectiveness, move the mat to a more insulated
surface. You can also add a humidity dome to cover the seedling tray, whichaides in heat retention.
WARNING: DO NOT IMMERSE CONTROLLER IN WATER
If the probe's temperature reaches 108 degrees F, the automatic safety shut-off is activated. In the
event that you would like to use your thermostat to control air temperature, we have included a
suction cup so that the probe can be mounted outside the rooting area. Simply clip the suction cup
over the probe and apply to desired area. It may help to moisten the suction cup prior to sticking it to
the desired surface.
8
