Eagle power 315P Guide

IMPORTANT! READ THIS MANUAL PRIOR TO USE.
MODELS:
315P
415P
429P
415S
415ST
415PLT
429ST
OPERATIONS AND PARTS MANUAL
WET/DRY VACUUMS
POLYETHYLENE, POLYPROPYLENE & STEEL

TABLE OF CONTENTS
Page No.
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . .1-3
Vacuum and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Daily Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Periodic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Servicing the Filter and Vac Motor . . . . . . . . . . . . . . . . . .6-7
Vacuum Parts Diagram . . . . . . . . . . . . . . . . . . . . . . . . . .8-13
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precaution must
always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
This machine is for commercial use.
WARNING
DANGER: Failure to read and observe all DANGER statements could result in severe bodily injury or
death. Read and observe all DANGER statements found in your Owner’s Manual and on
your machine.
WARNING: Failure to read and observe all WARNING statements could result in injury to you or to
other personnel; property damage could occur as well. Read and observe all WARNING
statements found in your Owner’s Manual and on your machine.
CAUTION: Failure to read and observe all CAUTION statements could result in damage to the
machine or to other property. Read and observe all CAUTION statements found in your
Owner’s Manual and on your machine.
DANGER: Failure to read the Owner’s Manual prior to operating or attempting any service or
maintenance procedure to your machine could result in injury to you or to other personnel;
damage to the machine or to other property could occur as well. You must have training in
the operation of this machine before using it. If you or your operator(s) cannot read
English, have this manual explained fully before attempting to operate this machine.
DANGER: Operating a machine that is not completely or fully assembled could result in injury or
property damage. Do not operate this machine until it is completely assembled. Inspect
the machine carefully before operation. Use only as described in this manual. Use only
the manufacturer’s recommended attachments.
DANGER: Machines can cause an explosion when operated near flammable materials and vapors.
Do not use this machine with or near fuels, grain dust, solvents, thinners, or other
flammable materials.
DANGER: Do not pick up flammable fluids, dust or vapors.
DANGER: Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
DANGER: This machine is not suitable for picking up health endangering dust.
DANGER: Using a machine with a damaged power cord could result in an electrocution. Do not use
the machine if the power cord is damaged. Do not use the electrical cord to move the
machine. Keep cord away from heated surfaces. Do not unplug by pulling on the cord;
grasp the plug, not the cord. Turn off all controls before unplugging. Do not close a door
on cord or pull around sharp edges or corners.
!
!
!
!
!
!
!
!
!
!
1

DANGER: Electrocution could occur if maintenance and repairs are performed on a unit that is not
properly disconnected from the power source. Disconnect the power supply before
attempting any maintenance or service.
WARNING: Operating a machine without observing all labels, decals, etc., could result in injury or
damage. Read all machine labels before attempting to operate the machine. Make sure
all of the labels are attached or fastened to the machine. Get replacement labels and
decals from the manufacturer’s distributor.
WARNING: Electrical components can “short-out” if exposed to water or moisture. Keep the electrical
components of the machine dry. Always store the machine in a dry area.
WARNING: Use of this machine to move other objects or to climb on could result in injury to the
operator or damage to the machine. Do not use this machine as a step or furniture. Do
not allow to be used as a toy. Close attention is necessary when used by or near children.
WARNING: Moving parts of this machine can cause injury and/or damage. Keep hands, feet, loose
clothing, hair, fingers, and all parts of the body away from openings and moving parts.
WARNING: Electrocution could occur if you handle the plug or appliance with wet hands. Do not
handle plug or appliance with wet hands.
WARNING: The machine employs a removable float for wet pick-up operation to reduce risk of
electric shock. Always install float before any wet pick-up operation.
WARNING: Rotating fan blades inside the cover. Before opening cover, switch off machine. Wait until
the fan/brush stops completely or dust and debris may be ejected.
WARNING: If the machine is not working properly, has been dropped, damaged, left outdoors, or
dropped into water, return it to an Authorized service center.
WARNING: Damage could occur to machine if openings are blocked. Do not put any object into
openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything
that may reduce air flow.
WARNING: Injury could occur to the operator or the machine if used without the dust bag and/or
filters. Do not use the machine without the dust bag and/or filters in place.
WARNING: Injury to the operator and/or damage to the machine could occur when cleaning on stairs,
unless extra caution is used. Use extra caution when cleaning on stairs.
WARNING: To reduce the risk of electrical shock, always use a 3-wire electrical system connected to
the electrical ground. Whenever possible connect the machine to an outlet protected by a
ground fault interrupter (GFCI). See “Grounding Instructions.”
SAVE THESE INSTRUCTIONS
!
!
!
!
!
!
!
!
!
!
!
!
2
!

120 Volt Machine Instructions For Connection
To The Power Supply And The Electrical Ground
This machine must be connected to the electrical
ground to protect the operator from electric shock.
The machine has an approved power cord with three
conductors and a plug with three terminals. Connect
the plug to a receptacle that has three holes and is
connected to the electrical ground. The green (or
green and yellow) conductor in the cord is the
ground wire. Never connect this wire to any terminal
other than the ground terminal.
This machine uses a 120 volt AC 60 cycle electrical
circuit. Make sure you have the correct frequency
and voltage before connecting the power cord to an
outlet. The machine has a plug as shown in Figure 1.
If a receptacle connected to the electrical ground as
shown in Figure 1 is not available, have one installed
by an electrical contractor. Do not use an adapter.
WARNING: To reduce the risk of electric shock,
protect the machine from rain. Keep
the machine in a dry area.
WARNING: To reduce the risk of electric shock,
always use a 3-wire electrical system
connected to the electrical ground.
Whenever possible connect the
machine to an outlet protected by a
ground fault interrupter (GFCI).
WARNING: Do not cut, remove or break the ground
pin. If the outlet does not fit the plug,
consult your electrical contractor.
WARNING: Have worn, cut or damaged cords and
plugs replaced by an authorized
service person.
OUTLET
MUST BE
CONNECTED TO
THE ELECTRICAL
GROUND
PLATE
SCREW
GROUND PIN
GFCI Outlet
!
!
!
!
3

VACUUM AND ACCESSORIES
4
A Motor Block
B On/Off Switch
C Float: Keeps liquid out of Motor Block
D Polyester Filter: Remove for use with liquids
E Hooks: Secure Motor Block to Tank
F Suction Inlet
G Tank
H 1-pc. Hose End, Bent PVC
I Hose, 10-ft. x 1-1/2" Flexible
J 1-pc PVC Wand (2)
K Adapter
M Dust Brush
N Crevice Tool
O Floor Brush, 16"
P Squeegee, 16"
ATTENTION: The Polyester Filter must be cleaned after each
use to maintain efficient suction.
IMPORTANT INSTRUCTIONS
• Before use, the equipment must be correctly assembled with
all its components.
•Check that electrical outlet is correct for use with the plug on
the machine.
• Before connecting, check that the specified motor voltage
corresponds to the main voltage available.
• Never use the equipment near inflammable, explosive or toxic
substances: sparks from the motor could cause dangerous
reactions.
• Always unplug the machine from electrical outlet when leaving
machine unattended or before attempting any repair.
• Service and repair should be done by qualified personnel only.
Use only original manufacturer’s replacement parts.
S72672
Complete Standard Tool Kit
includes H, I, J, K, M, N, O and P.
H
(S76389)
I
(S70008)
J
(S76387)
K
(S76388)
P
(S76385)
O
(S76384)
N
(S70003)
M
(S76295)

5
This machine is a commercial vacuum designed for wet and
dry pick-up. The dual vac motors can be run together or
separately as the job requires.
Dry soil can be vacuumed directly into the tank. To empty the
tank of dry soil, remove the top and dump into trash
receptacle.
For wet pick-up, remove polyester filter. The machine is
equipped with a float shut-off. As the tank is filled to capacity,
a float rises and seals the vac intake, causing loss of vacuum.
Switch off the vacuum when this happens and bring the
machine to a floor drain.
Use the convenient drain hose at the back of the vacuum to
empty the tank.
With both wet and dry applications be sure to frequently clean
the filter. This is especially true when the vacuum is being
used with strippers and wax.
OPERATION
DAILY MAINTENANCE
Dual Vacuum
Single Vacuum
DUAL SWITCHES
Caution: Strippers and some detergents produce foam
which will damage the vac motors. The vac shut-off may
not be sensitive to all foams. Be sure to check that the
tank is not filling with foam. Use a defoaming agent to
avoid pulling foam through vac motor. Should vac motor
become wet, remove source of overflow and immediately
run vac motor open to dry.
At the end of each working day:
1. After each use, rinse tank with fresh water.
Periodically inspect the recovery tank and
decontaminate if necessary, using a Hospital Grade
Virucide or a 1:10 bleach to water solution. Waste
water should be disposed of properly.
2. Remove head assembly and allow tank to dry.
3. Remove filters for cleaning or to allow to dry.
4. Inspect hoses for wear. Frayed or cracked hoses
should be replaced to avoid vacuum loss.
5. Inspect power cord for wear. This cable will lay on wet
surfaces. To prevent electrical shock replace cords with
frayed or cracked insulation immediately.
3
2
1
LN
ELECTRIC DRAWING
1 – terminal block
2 – switch
3 – motor

6
(Every six to twelve months):
1. Check filter for wear, replace dirt saturated filters that
do not respond to normal cleaning.
2. Inspect gasket seals and replace those which have
begun to leak.
3. Examine carbon motor brushes and commutator.
PERIODIC MAINTENANCE
The filter is accessed by lifting the head assembly off the tank.
Polyester filter is easily removed by simply lifting the filter basket out of the tank.
Cartridge filters – Remove the filter retainer by turning the black knob 90 degrees counter-clockwise.
Cartridge filter will then slide off of float assembly.
NOTE:
Be sure to frequently clean the filter.
Allow filter to dry after being used for wet pick-up.
Filters used for wet pick-up including stripper must be thoroughly cleaned before being allowed to dry.
Worn filters can affect vacuum performance. Replace the filter when it becomes worn out and normal cleaning
will not restore vac performance.
SERVICING THE FILTER
MOTOR REPLACEMENT
1. Disconnect power cord from power source.
2. To access the vac motor, remove the screws that attach the main cover to the head assembly and set
the cover to one side.
3. Disconnect the motor’s 2 red lead wires from the main switch.
4. Disconnect green/yellow wire by removing screw from motor core.
5. Remove the four motor mounting screws.
6. Remove motor plate and set aside.
7. Take out the motor and remove the upper and lower gaskets.
8. Inspect gaskets. If they shown any wear or tear in the material, replace.
9. Install gaskets onto new motor. Make sure gaskets are properly seated.
10. Install the new motor. Make sure foam mufflers are positioned properly.
11. Attach motor plate to motor.
12. Connect green/yellow wire to motor core.
13. Connect motor’s 2 red lead wires to main switch.
14. Re-assemble vac cover.
15. Test for proper operation.
SERVICING THE VAC MOTOR
Replace both carbon
brushes when either is
less than 3/8" long. (PN S8TOEG845)

7
CARBON BRUSH REPLACEMENT
1. Disconnect power cord from power source.
2. To access the vac motor, remove the
screws that attach the main cover to the
head assembly and set the cover to one
side.
3. Remove the motor cover by removing two
screws. See Figure 1
4. Remove the wire terminal from carbon
brush housing. See Figure 2
5. Remove the carbon brush assembly by
removing the 2 screws that attach it to the
vac motor. See Figure 3
6. Inspect armature commutator. If it is
extremely pitted, grooved or not concentric
then the motor will need to be replaced or
sent to a qualified service center.
7. Slide the yellow brush housing from plastic
holder. See Figure 4
8. Reverse steps 7 through 4 to install new
brush and housing (part number
S8TOEG845)
9. Repeat steps 4 through 8 for the other
carbon brush.
10. Reverse steps 3 and 2 for re-assembly.
11. Test for proper operation
SERVICING THE VAC MOTOR
Fig. 1
Fig. 2
Fig. 3
Fig. 4

315 VACUUM MOTOR ASSEMBLY
No. Part Num. Description Qty.
1. S80326 Switch, ON/OFF 1
2. S81006 Screw, 5 x 20 5
3. S81006 Screw, 5 x 20 2
4. S80140 Terminal Block 1
5. S81006 Screw, 5 x 20 4
6. S82992 Handle, Lift 1
7. S81152 1
8. S80138 Strain Relief, Black 1
9. S81122 Cord 1
10. S81006 Screw, 5 x 20 2
11. S80139 Clamp, Cord 1
12. S83937 Filter
13. S81146 Cover, Dome 1
14. S83969 Gasket, Motor Exhaust 1
15. S81006 Screw, 5 x 20 4
16. S81005 Screw, 5 x 14 2
17. S83900 Filter 1
18. S83608AU Motor Support 1
19. S83901 Motor Gasket 1
20. S81024 Washer, M4 1
21. S81064 Screw, M4 x 8 1
22. S81120S Motor, 1000W, 120V/60Hz 1
23. S83901 Motor Gasket 1
24. S83866 Disk, Noise Reduction 1
25. S80120 Base, Black, with Gasket 1
315 FILTER GROUP
No. Part Num. Description Qty.
1. S83706 Bushing, Ø8 4
2. S83724 Screw, 5 x 25 4
3. S82823 Body, Float 1
4. S83138 Filter, Strainer 1
5. S82676 Float 1
6. S80123 Ring, Filter 1
7. S82860 Filter Bag 1
8. S82859 Support, Filter Bag 1
315 TANK ASSEMBLY
No. Part Num. Description Qty.
S82221 Complete Tank 1
1. S82028 Tank 1
2. S81302 Rivet, 5 x 19 4
3. S81847 Clamp 2
4. S81026 Screw, 5 x 30 4
5. S82846 Gasket 1
6. S82585 Retainer 1
7. S82608 Spring 1
8. S82593 Deflector 1
9. S82594 Push Button 1
10. S82583 Hose Adapter 1
11. S82008 Caster 4
12. S82680 Screw, M4 x 15 16
8

415 VACUUM MOTOR ASSEMBLY
No. Part Num. Description Qty.
1. S81006 Screw, 5 x 20 6
2. S81150 Cover, Dome 1
3. S82992 Handle 1
4. S81006 Screw, 5 x 20 2
5. S80139 Clamp, Cord 1
6. S80138 Strain Relief 1
7. S81122 Power Cord, Single Motor 1
T82102005 Power Cord, Dual Motor
8. S81006 Screw, 5 x 20 2
9. S81005 Screw, 5 x 14 2
10. S80508 Terminal Block 1
11. S83383 Cap 2
12. S81050 Screw, 5 x 35 7
13. S81130 Cover, Single Motor 1
S81135 Cover, Dual Motor
14. S80326 Switch, On/Off 1
15. S81026 Screw, 5 x 30 1
16. S81006 Screw, 5 x 20 4
17. S81006 Screw, 5 x 20 8
18. S80464AU Motor Base 1
19. S83969 Gasket 3
20. S83901 Gasket 1
21. S81024 Washer, M4 1
22. S81064 Screw, M4 x 8 1
23. S81120S Motor, 1000W, 120V/60Hz 1
24. S83901 Gasket 1
25. S83901 Gasket 2
26. S83451 Plug 2
27. S83454 Filter 3
28. S83456 Filter 3
29. S83519 Cap 2
30. S80488 Base with Gasket 1
415 FILTER GROUP
No. Part Num. Description Qty.
1. S83706 Bushing 4
2. S83724 Screw, 5x25 4
3. S82823 Body, Filter Support 1
4. S83117 Strainer 1
5. S82676 Float 1
6. S80473 Filter Ring 1
7. S82845 Filter Bag 1
8. S82833 Support, Filter 1
9. S82852 Filter – OPTIONAL 1
10. S82855 Filter Retainer – OPTIONAL 1
9

10
415P TANK ASSEMBLY
No. Part Num. Description Qty.
S82615 Complete Tank 2
1. S82558 Handle 1
2. S82637 Tank 1
3. S81026 Screw, 5x30 4
4. S82584 Retainer, Tank 1
5. S82846 Gasket 1
6. S82593 Deflector 1
7. S82652A Adapter, Hose 1
8. S81300 Rivet, 5 x 24.5 4
9. S81847 Clamp, Tank 2
10. S81050 Screw, 5 x 35 8
11. S83883 Plastic Washer 8
12. S81072 Support, Handle 2
13. S81860 Support, Handle 2
14. S81302 Rivet, 5 x 19 2
15. S82559 Caster 2
16. S82680 Screw, 4 x 15 8
17. S82556 Support, Axle 2
No. Part Num. Description Qty.
18. S80904 Wheel, Ø200 2
19. S82557 Cap, End 2
20. S83835 Cap, Axle 2
21. S82607 Spacer, Wheel 2
22. S81006 Screw, 5 x 20 8
23. S82555 Axle 1
24. S80834 Nut, Flange 1
25. S80256 Gasket 1
26. S82763 Elbow 1
27. S83308 Clamp 1
28. S82765 Drain Tube 1
29. S83156 Screw, 5 x 20 1
30. S82788 Clip Tube 1
31. S82812 Strap, Plug 1
32. S82764 Plug, Hose 1
33. S86250 Handgrip 2
34. S82594 Push Button, Two-Piece, Red 1

415ST TANK ASSEMBLY
No. Part Num. Description Qty.
1. S82993 Handle 2
2. S81847 Clamp, Tank 2
3. S81302 Rivet, 5 x 19 4
4. S83629 Screw, 5 x 25 4
5. S83883 Washer 4
6. S83253 Tank – Steel 1
7. S81026 Screw, 5 x 30 4
8. S82586 Adapter, Tank 1
9. S82846 Gasket 1
10. S82593 Deflector 1
11. S82583 Adapter, Hose 1
12. S82594 Button 1
No. Part Num. Description Qty.
13. S82608 Spring 1
14. S82993 Handle 1
15. S82974 Washer 2
16. S83629 Screw, 5 x 25 2
17. S83156 Screw, 5 x 25 4
18. S83883 Washer 4
19. S82968 Hook, Tank 1
20. S82970 Swivel 2
21. S82969 Knob, Release 2
415ST CART
11
No. Part Num. Description Qty.
1. S83250 Cart 1
2. S80976 Plug 2
3. S82557 Cap, End 2
4. S80904 Wheel 2
5. S83835 Cap 2
6. S81012 Washer 2
7. S80478 Nut 2
8. S80479 Wheel, Front 2
9. S81979 Screw, 5 x 25 4
10. S83450 Clip Pad 4
11. S86250 Hand Grip 2

415S TANK ASSEMBLY
No. Part Num. Description Qty.
1. S82993 Handle 2
2. S81847 Clamp, Tank 2
3. S81302 Rivet, 5 x 19 4
4. S83629 Screw, 5 x 25 4
5. S83883 Washer 4
6. S80476 Tank 1
7. S81026 Screw, 5 x 30 4
8. S82586 Adapter, Tank 1
9. S82846 Gasket 1
10. S82593 Deflector
11. S82583 Adapter, Hose 1
12. S82594 Button 1
13. S82608 Spring 1
415S CART
12
No. Part Num. Description Qty.
1. S80918 Handle, Cart 1
2. S80917 Support, Handle 2
3. S80913 T-tube 2
4. S81301 Rivet, 5 x 11 2
5. S80902 Block 1
6. S80914 Hand Wheel, M8 x 60 1
7. S81402 Spring 1
8. S81403 Plate, Threaded 1
9. S81301 Rivet, 5 x 11 2
10. S80901 Base, Cart 1
11. S80915 Screw, 12 x 140 2
12. S81028 Washer, M12 2
13. S80904 Wheel 2
14. S81401 Bushing 2
15. S82052 Spacer 2
16. S81301 Rivet, 5 x 11 2
17. S80479 Wheel 2
18. S81012 Washer 6
19. S80478 Nut, M10 2
20. S86250 Hand Grip 2

415PLT TANK ASSEMBLY
No. Part Num. Description Qty.
1. S81847 Clamp, Tank 2
2. S81300 Rivet, 5 x 24.5 4
3. S83773 Tank 1
4. S81026 Screw, 5 x 30 4
5. S82586 Adapter, Tank 1
6. S82846 Gasket 1
7. S82593 Deflector, Tank 1
8. S82583 Adapter, Hose 1
9. S82594 Button, Hose 1
10. S82608 Spring 1
11. S83771 Bumper 1
12. S82993 Handle 1
No. Part Num. Description Qty.
13. S83883 Washer, Plastic 2
14. S81026 Screw, 5 x 30 2
15. S81026 Screw, 5 x 30 4
16. S83883 Washer, Plastic 4
17. S82172 Hook, Tank 1
415PLT CART
13
No. Part Num. Description Qty.
1. S82053 Spring 2
2. S82607 Spacer 2
3. S82173 Lock, Plastic 2
4. S81979 Screw, 5 x 25 4
5. S83725 Clamp 2
6. S83751 Shaft 1
7. S83694 Handle 1
8. S83835 Cap, Axle 2
9. S82557 Cap, End 2
10. S80904 Wheel 2
11. S82607 Spacer 2
12. S82980 Spacer 2
13. S83752 Axle 1
14. S81026 Screw, 5 x 30 8
15. S82967 Support, Axle 2
16. S81050 Screw, 5 x 35 2
17. S82974 Washer 6
18. S82627 Screw, 5 x 40 12
19. S81006 Screw, 5 x 20 8
20. S82559 Caster 2
21. S83797 Base, Cart 1

ACCESSORIES
S70042 Front Mounted Squeegee, for all 415 models
S72741 Paper Bag
S82860 Filter Bag, Standard for 315 model
S82845 Filter Bag, Standard for 415 model
S82852* Filter Cartridge, Paper, Optional for 415
S76061* Filter Cartridge, Washable Paper, Optional for 415
S82995* Filter Cartridge, HEPA Equivalent, Optional for 415
S82881* Filter Cartridge, HEPA Equivalent, Optional for 315
S82855 Cartridge Filter Retainer, for all models
*also order S82855 Retainer with Filter
RECOMMENDED
SPARE PARTS
S8TOEG845 . . . . . . . Motor Brush
S80326 . . . . . . . . . . . Switch, On/Off
S82860 . . . . . . . . . . . Polyester Filter, 315
S82845 . . . . . . . . . . . Polyester Filter, 415
S83117 . . . . . . . . . . . Strainer
14
S70042 FRONT-MOUNTED SQUEEGEE
No. Part Num. Description Qty.
1. S82164 Handwheel, M8 x 45 1
2. S82187 Small Block, Fixed 1
3. S82163 Handwheel, M6 x 25 1
4. S83115 Plate, Adjustment 1
5. S82189 Driver Pivot 1
6. S81033 Nut, M8 2
7. S81732 Adjustment Knob 2
8. S86137 Spring, Ø40 2
9. S82245 Rear Squeegee 1
10. S86138 Wheel, AIF, Ø40 2
11. S81034 Washer, Plain, M8 1
No. Part Num. Description Qty.
12. S82177 Body, Wet Fix Tool 1
13. S82198 Spacer 2
14. S82196 Front Squeegee 1
15. S82197 Bracket, Squeegee 2
16. S81856 Screw, M4 x16 16
17. S80010 Hose, Wet Fix Tool 1
18. S82297 Mounting Bracket 1
19. S81035 Nut, M5 4
20. S81036 Washer, M5 4
21. S81755 Screw, M5 x 16 4
22. S81006 Screw, M5 x 20 4

Please be sure to record this information. This information will be necessary for future warranty rclaims.
Warranty Policy
Limited Warranty
Eagle Power Products (EPP) warrants new cleaning equipment against defects in material and
workmanship under normal use and service to the original purchaser as detailed below.
10 Years
Subject to the conditions stated below, EPP warrants polyethylene tanks and housings to be
free from defects in materials and workmanship for a period of ten years.
3 Years
Subject to the conditions stated below, EPP warrants all automatic scrubber components to
be free from defects in materials and workmanship for a 3-year period. Parts replaced or
repaired are warranted for the remainder of the original warranty period.
1 Year
Subject to the conditions stated below, EPP warrants all other cleaning equipment
components to be free from defects in materials and workmanship for a 1-year period. Parts
replaced or repaired are warranted for the remainder of the original warranty period.
Batteries are prorated for one year.
EPP will furnish and charge for replacement parts, including transportation, to the original
owner through an EPP authorized service center. If the part is returned within 30 days and is
found defective, the owner will be credited for the cost of the replacement part including
shipping and handling.
Labor charges are covered for one year from the date of purchase if provided by an authorized
EPP service center. Travel is covered for 90 days for battery operated equipment only.
Wear items exempt from warranty include belts, carbon brushes, power cords, wheels, pad
drivers, clutch plates, brushes, pads, handle grips, filters, screens, throttle cables, and squeegees.
This warranty shall not apply to failures caused by misuse or abuse, improper
maintenance as stated in the operation manuals, use of unauthorized repair parts, repairs
by other than an EPP authorized service center, and damage in transit.
EPP disclaims and denies any liability for any direct, indirect, special incidental or consequential
damage which may be suffered as a result of sale, delivery, servicing, use, loss of any product,
downtime, labor, freight, or other charges not expressly included herein.
Date Purchased:
Model Number:
Serial Number:
2002 Eagle Power Products All rights reserved. T9022- Rev A-5/02
Eagle Power Products Sales and Service Provided by:
1174 Northland Drive Mendota Heights, MN 55120
651.686.5399 Fax [phone]
www.eaglepower.com
