EarthQuake HoLeeS-12 Reference manual

Congratulations and thank you for trusting in us uses a voice coil that is built with an aluminum bobbin and
and acquiring thenew HoLeeS Competition subwoofer, military-grade flat surface wire. The voice coil is over 3” in
anotherincrediblesubwooferfromthemindandsoulofMr. winding height and diameter which makes it one of the
JosephSahyoun(PresidentofEarthquakeSound).“Ireally most respected drivers for producing high excursion, not
worked very hard on this driver for several years now, and only does it move a lot when you press on it, it has the
wanted to perfect every aspect of the driver before it was electrical force necessary to move it the distance of the
released.” actual voice coil. During movement, this driver pulls less
“Thissubisconstructedfromthefinestpartsonthe current from your amp than any other speaker on the
planet;andImeanit.”Whenitcomestothesurround,much market.Since it is designedandoptimizedtohaveahigher
attention to detail is required to accommodate the huge impedanceduringworkingperiods(reactiveimpedance),it
amount ofexcursion andpressure thatwill beapplied.The never goes into compression and to do so it would have to
surround uses Polyether Draw, the strongest and longest move double what is out there. The “PSP” terminal (patent
lasting material available. When the driver is in a long pending) allows the users to have their speaker in 2-ohm,
excursion situation, you will not start to see any dual 4-ohm or 8-ohm.As you can see this terminal and the
deformations or dimples unless the speaker is being rest of the speaker are the first of their kind and we are
pushed to it’s absolute max peak. Unlike many extremelyproudtobethebrainsbehindthem.
subwoofers, HoLeeS’s surround will not deteriorate after a Earthquake Sound is a reputable manufacturer of
few years of hard-core pounding; the surround has a high-end home and mobile audio products for nearly 20
working life span of 10 years plus. This wide surround will years. You will notice that the engineers and other parties
easily outlast any other and its many qualities make it the involvedwiththeproductionofthesefinesubscoveredalot
widest,longestlastingandmostreliablesurround,period. of ground making sure that every user is satisfied and
The driver is constructed with a unique triangular educated as much as possible. If there is anything that you
bridgetype design.The voicecoilpusheson theflatpiston, do not understand or need help with or if you have
notthe cone.Thecone isused forassemblypurposes only. comments please feel free to contact us at [phone]
HoLeeS’s cone is connected to the flat diaphragm and its or email to Thank you once
lattice structure in the middle, creating the triangular againforyoursupportandweappreciateyoubusiness.
system that removes cone distortion caused by wobbles,
found in typical speaker designs. Earthquake's HoLeeS
[email protected].
Recommended Power For One Subwoofer
Blue(Minimum):
If you are powering your sub in this
range,itwilloperatecomfortablywith
zero strain or fatigue. Power ranges
this low will not damage your
speaker, but it wont capture the
Subzerofullcapabilities.
Yellow(Optimized):
This zone represents the best
compromise between long-term
reliability, high-output and low-
distortion. If you are operating your
subwoofer in this range you are
taking advantage of the best low
distortion and sound quality that the
Subzero is capable of delivering
betweentherecommendedpower.
Red(Maximum):
In this zone low-distortion and sound
quality become compromised. A
small amount of SPL can be gained
in this zone, but only a couple of dB.
Remember that the more you travel
out of the recommended power
range the greater the chances of
failure and warranty rejection. Be
wise and use extreme caution and
carewithyourspeakers.
Black(DON’T):
Inthiszonethechancesoffailureare
almost inevitable. When exposed to
excessive heat and/ or mechanical
stress the driver will loose sound
quality, SPL and could seriously
damagethedriveroryouvehicle.
SUBWOOFERS OPERATED IN
THIS ZONE WILL NOT BE
COVEREDBYWARRANTY.
Legend Minimum Optimized Maximum Don’t
1000W 1500W 3000W 6000W 12000W 24000W
HoLeeS-15
HoLeeS-12
HoLeeS-10
800-576-7944 www.earthquakesound.com•
Introduction to HoLeeS-12
Sound That Will Move You.

HoLeeS
Earthquake’s Super Wide Edge
Surround allows the driver to utilize all of
working parts and maximize piston area
tothe full potentialeventually resultingin
more SPL and overall better sound
quality.
1) - Wide Polyether Surround
This invention includes all of the moving
parts of the speakers. These parts which
include the V.C., cone, dust-cap,
surround, bridge and spiders are
connectedtoeachotherandreinforcedat
the joints. This design helps eliminate
wobbles and offsets usually caused by,
non-linear spiders, V.C.s and other
factoryoffsetparts.
2) - Triangular Lattice
The HoLeeS spider is centered and
pressed between two specially designed
rings that keep the spider linear at all
timesandimprovesuspensionlife.
3) - Spider Ring
The “PSP” terminal may be one of the
most unique features on the HoLeeS.
Thisterminalisstylishandisextremely
easy to use. When directions are
followed any level of installer can
quickly have their amplifier hooked up
quickly.ThePSPterminalallowsusers
to easily wire their speaker according
totheiramplifiersspecs.
4) - PSP Terminal (Patent Pending)
TheHoleeS'sareallaboutimprovingthemovingpartsdesignofaspeaker.Currentspeaker
designs suffer from several compromising parts that play a major role in producing a high
level of distortions. Ahuge trend that many designers follow is to increase the excursion of
the driver for a couple of added dB. This may be a good temporary band-aid, but they still
lack compatible parts for the type of excursion that is being dealt with. If you increase the
excursion you need strong, reliable and better engineered parts to do the job. If this is not
done (which it usually isn’t), then the speaker will be weak and will have a high level of
deformation, non-linearity and distortion. The HoleeS's design blocks these bad but
common traits from passing on and supports better over all bass reproduction and sound
quality.
4
Fuse Inserts
8-Gauge Speaker Terminals
Hex tightening
screws
1
2
3
NEW TECHNOLOGIES
HoLeeS
800-576-7944 www.earthquakesound.com•
Sound That Will Move You.

Driver Specifications
Application / Box Design SPL Burping
Outer volume: 3.259
Inner volume: 2.5 cubic feet / Tuned @ 68Hz
Port surface: 43.5sq. inch
Port length: 8” (203.2mm)
Port length may vary depending on frequency
Wall thickness: 1” (25.4mm)
Front baffle: 2” (50.8mm)
cubic feet
Ported Enclosure
For more enclosure designs and or
technical support please feel free to
contactus.
22” (558.8mm)
16” (406.4mm)
16”
(406.4mm)
14.5” (368.29mm)
8”
(203.2mm)
3” (76.19mm)
8Ft.
7Ft.
5Ft.
6Ft.
4Ft.
Tune @ 65Hz
Sensitivity/ L
Tune @ 65Hz
Tune @ 65Hz
Tune @ 65Hz
Tune @ 65Hz
Cut out hole ( )11 1/2" 292mm
Mounting depth:
11 7/8”
(301.625mm)
HoLeeS-12
To prevent serious damage or injury
call Earthquake Tech-support
before powering up the HoLeeS
subwoofer. If the subwoofer is not
wired correctly and a malfunction
occurs, the damage may void the
warranty. So please help us help
you, and give us a call toll free.
Tech-Support: 800•576•7944
Net Weight: 99.6 lbs
Revc: 2.000ohm
Levc: 5.946mH
Fo: 26.395Hz
Sd: 53.000msqM
BL: 22.250TM
Qms: 4.915
Qes: 0.293
Qts: 0.277
No: 0.201%
SPLo: 85.0dB
Vas: 1.17CuFt
Cms: 83.043uM/N
Mms: 437.8253g
Mmd: 430.809g
Max Power: 10,000 Watts
IMPORTANT
800-576-7944 www.earthquakesound.com•
Sound That Will Move You.

Wiring Configurations
Please Read
Instructions
Thoroughly
VC #1
1
- --
S
2
1
2
+ +
1-CHANNEL
1-OHM LOAD
(voice coils in parallel)
(No Fuses)
DO NOT
USE
MONO 1-OHM
8-GAUGE 8-GAUGE
VC #1
1
- --
S
2
1
2
+ +
1-CHANNEL
1-OHM LOAD
(voice coils in parallel)
(No Fuses)
DO NOT
USE
MONO 1-OHM
8-GAUGE 8-GAUGE
AMPLIFIER
1 Ohm
Parallel
1/2 Ohm
1 Ohm
AMPLIFIER
Series
2 Ohm
AMPLIFIER
Normal
1 Ohm 1 Ohm
1 Ohm 1 Ohm
The HoLee-S subwoofer comes equipped with 2 voice coils (dual 1 ohm), it can be used in .5 or 2
ohm configurations. The terminal comes equipped with fused jumpers, please note that center
terminals are not operational.
S
AMPLIFIER TERMINAL
