Easi-Exit DCF2003 User manual

Page 1 Door Closer – Model DCF2003 Rev.1
Copyright © 2008 Eurospec Failure to install this product as per these instructions &
dimensions shown on template will negate guarantee
Installation Instructions
Overhead Door Closer – Model DCF2003
IMPORTANT INFORMATION
Selecting the correct door closer to suit door size
This product is non handed and can be fitted on both left handed and right handed doors.
*Minimum size for use on fire doors
Important notes:
Minimum size 3 MUST be used on fire doors
Hold open arms must NOT be used on fire doors
Maintenance
PLEASE LEAVE THESE INSTRUCTIONS WITH THE END USER
Tel: [phone]
Fax: [phone]
Web: www.eurospec.co.uk
Eurospec
Architectural Hardware Ltd
Stancliffe Street, Mill HIll
Blackburn, BB2 2QR
Check that the door closer closes the door correctly and adjust as necessary. Ensure fixing screws are tight and periodically
apply light oil or grease to arm knuckle joint
Power Size Max. Width of Door Max. Mass of Door
2 850mm 40Kg
3*950mm 60Kg
4 1100mm 80Kg
5 1250mm 100Kg
6 1400mm 120Kg

Page 2 Door Closer – Model DCF2003 Rev.1
Copyright © 2008 Eurospec Failure to install this product as per these instructions &
dimensions shown on template will negate guarantee
Installation – Fig 1 Application – Angle of opening 180°
Illustrations show anti-clockwise closing door
1. Ensure that the door & surrounding frame are in
good condition & the door closes freely.
2. Select the correct hand of Fig. 1 easi-fit template
and with the door in the closed position, stick
template to top corner of door and frame. (See
Figs. 1 & 2)
3. Drill pilot holes in door and frame according to
easi-fit template & securely fix door closer
body with screws supplied. Ensure adjusting
screws face hinge side of door. (See Figs. 2 & 3)
4. Carefully detach link arm from adjuster arm &
securely fix adjuster arm shoe to frame ensuring
the shoe is rotated in the correct position as
shown on the template. (See Fig. 4)
5. Place link arm onto closer spindle at right angles
to door, fit securing screw, move link arm and
re-connect to adjuster arm. (See Figs. 4 & 5)
Note: To adjust arm to suit depth of frame, loosen
nut, adjust arm & re-tighten nut.
6. Fit spindle cover cap to underside of closer. (See Fig. 5)
7. Check for correct closing & latching speeds and
adjust if necessary. (See Fig.6)
StandardApplication
Fig 1 – Standard Application (Door closer fitted on pull face of door)
FAST SLOW
No.1 Closing Speed
No.2 Latching Speed No.2
No.1
Fig. 2
Fig. 3
Fig. 4
Adjust if
required
90
Fig. 6 Fig. 5
ADJUSTING SCREW
Fig. 1

Page 3 Door Closer – Model DCF2003 Rev.1
Copyright © 2008 Eurospec Failure to install this product as per these instructions &
dimensions shown on template will negate guarantee
Installation – Fig 66 Application – Angle of opening 180°
Illustrations show clockwise closing door
1. Ensure that the door & surrounding frame are in
good condition & the door closes freely.
2. Select the correct hand of Fig 66 easi-fit template
and stick body of template to top corner of door. Fold
and stick top of template to underside of frame.
(See Figs. 1 & 2)
3. Drill pilot holes in door and frame according to
template & securely fix door closer body and Fig 66
bracket with screws supplied. Ensure adjusting screws
face away from hinge side of door. (See Figs. 2 & 3).
4. Carefully detach link arm from adjuster arm &
securely fix adjuster arm shoe to fig.66 bracket ensuring
the shoe is rotated in the correct position as
shown on the template. (See Fig. 4)
5. Place link arm onto closer spindle parallel
to door, fit securing screw, move link arm and
re-connect to adjuster arm. (See Figs. 4 & 5)
Note: Adjust arm length as required: Loosen
nut, adjust arm & re-tighten nut.
6. Fit spindle cover cap to underside of closer. (See Fig. 5)
7. Check for correct closing & latching speeds and
adjust if necessary. (See Fig.6)
Fig 66 – Parallel Arm Application (Door closer fitted on push face of door)
Fig. 4
Fig. 6 Fig. 5
Fig. 1
ParallelArmApplication
Fig. 3
Adjust if required
Fig. 2
No.1 Closing Speed
No.2 Latching Speed
No.2
No.1
SLOWFAST
CLOCKWISE CLOSING ANTI-CLOCKWISE CLOSING
