Easi-Exit DCS2024 User manual

Page 1 Door Closer – Model DCS2024/25 Rev.1
Copyright © 2008 Eurospec Failure to install this product as per these instructions &
dimensions shown on template will negate guarantee
Installation Instructions
Overhead Door Closer – Model DCS2024/25
IMPORTANT INFORMATION
Selecting the correct door closer to suit door size
This product is non handed and can be fitted on both left handed and right handed doors.
*Minimum size for use on fire doors
Important notes:
Minimum size 3 MUST be used on fire doors
Hold open arms must NOT be used on fire doors
Maintenance
PLEASE LEAVE THESE INSTRUCTIONS WITH THE END USER
Tel: [phone]
Fax: [phone]
Web: www.eurospec.co.uk
Check that the door closer closes the door correctly and adjust as necessary. Ensure fixing screws are tight and periodically
apply light oil or grease to arm knuckle joint
21 - CPD - AD0198
21 - CPD - AD0199
Eurospec
Architectural Hardware Ltd
Stancliffe Street, Mill HIll
Blackburn, BB2 2QR
Power Size Max. Width of Door Max. Mass of Door
2 850mm 40Kg
3*950mm 60Kg
4 1100mm 80Kg
5 1250mm 100Kg
6 1400mm 120Kg

Page 2 Door Closer – Model DCS2024/25 Rev.1
Copyright © 2008 Eurospec Failure to install this product as per these instructions &
dimensions shown on template will negate guarantee
Installation – Fig 1 Application – Angle of opening 180°
Illustrations show anti-clockwise closing door
1. Ensure that the door & surrounding frame are in good
condition & the door closes freely.
2. Select the correct hand of Fig. 1 easi-fit template
and with the door in the closed position, stick template to
top corner of door and frame. (See Figs. 1 & 2)
3. Determine the power size required and using the supplied
allen key, adjust door closer strength as per chart on
template. Drill pilot holes in door and frame according to
template. Remove slide plate and fix door closer body with
screws supplied ensuring power adjusting valve faces away
from hinge side of door. (See Figs. 2 & 3)
4. Carefully detach link arm from adjuster arm & securely fix
adjuster arm shoe to frame ensuring the shoe is rotated
in the correct position as shown on the template. (See Fig. 4)
Note: Rotate shoe 180°for power size 2
5. Place link arm onto closer spindle at right angles
to door, fit securing screw, move link arm and re-
connect to adjuster arm. (See Figs. 4 & 5)
Note: To adjust arm to suit depth of frame, loosen
nut, adjust arm & re-tighten nut.
6. Fit spindle cover cap to underside of closer. (See Fig. 5)
7. Check for correct closing & latching speeds and
adjust if necessary. Adjust backcheck as required. (See
Fig.6)
8. Stick easi-exit logo onto indent of slide plate and refit to
door closer. (See Fig. 6)
Fig 1 – Standard Application (Door closer fitted on pull face of door)
Fig. 2
Fig. 3
Fig. 4
Fig. 6 Fig. 5
Adjust power strength of door closer here
Fig. 1
StandardApplication
Adjust if
required
FAST SLOW
No.1 Closing Speed
No.2 Latching Speed
No.2
No.1
_+
backcheck
Delayed Action
SIZES3,4&5SIZE2
Note: For delayed action model DCS2025BCDA, adjust valve as required

Page 3 Door Closer – Model DCS2024/25 Rev.1
Copyright © 2008 Eurospec Failure to install this product as per these instructions &
dimensions shown on template will negate guarantee
Installation – Fig 61 Application – Angle of opening 180°
Fig 61 – Transom Mounting Application (Door closer fitted on frame on push side of door)
Fig. 4
Fig. 6 Fig. 5
Fig. 1
Fig. 2
Fig. 3
TransomMountingApplication
Adjust power strength of door closer here
SIZES3,4&5SIZE2
Adjust if
required
90
No.2
No.1
FAST SLOW
No.1 Closing Speed
No.2 Latching Speed
_+
backcheck
Delayed Action
Illustrations show clockwise closing door
1. Ensure that the door & surrounding frame are in good
condition & the door closes freely.
2. Use Fig. 1 easi-fit template and select correct hand of door,
stick template to top corner of door and frame, ensuring
closer is mounted on frame and shoe is mounted on door.
(See Figs. 1 & 2)
3. Determine the power size required and using the supplied
allen key, adjust door closer strength as per chart on
template. Drill pilot holes in door and frame according to
template. Remove slide plate and fix door closer body with
screws supplied, ensuring power adjusting valve faces away
from hinge side of door. (See Figs. 2 & 3)
4. Carefully detach link arm from adjuster arm & securely fix
adjuster arm shoe to door ensuring the shoe is rotated
in the correct position as shown on the template. (See Fig. 4)
Note: Rotate shoe 180°for power size 2
5. Place link arm onto closer spindle at right angles
to door, fit securing screw, move link arm and re-
connect to adjuster arm. (See Figs. 4 & 5)
Note: To adjust arm to suit depth of frame, loosen
nut, adjust arm & re-tighten nut.
6. Fit spindle cover cap to upperside of closer. (See Fig. 5)
7. Check for correct closing & latching speeds and adjust if
necessary. Adjust backcheck as required. (See Fig.6)
8. Stick easi-exit logo onto indent of slide plate and refit to
door closer. (See Fig. 6)
Note: For delayed action model DCS2025BCDA, adjust valve as required.

Page 4 Door Closer – Model DCS2024/25 Rev.1
Copyright © 2008 Eurospec Failure to install this product as per these instructions &
dimensions shown on template will negate guarantee
Installation – Fig 66 Application – Angle of opening 180°
Fig 66 – Parallel Arm Application (Door closer fitted on push face of door)
Fig. 4
Fig. 6 Fig. 5
Fig. 1
Fig. 3
Fig. 2
ParallelArmApplication
NO.1
NO.2
FAST SLOW
No.1 Closing Speed No.2 Latching Speed
_+
backcheck
Delayed Action Adjust if
required
Adjust power strength of door closer here
CLOCKWISECLOSINGANTI-CLOCKWISECLOSING
Illustrations show clockwise closing door
1. Ensure that the door & surrounding frame are in
good condition & the door closes freely.
2. Select the correct hand of Fig 66 easi-fit template
and stick body of template to top corner of door.
Fold and stick top of template to underside of
frame. (See Figs. 1 & 2)
3. Determine the power size required and using the supplied
allen key, adjust door closer strength as per chart on
template. Drill pilot holes in door and frame according to
template. Remove slide plate and fix door closer body
with screws supplied, ensuring power adjusting valve
faces the hinge side of door. (See Figs. 2 & 3)
4. Carefully detach link arm from adjuster arm & securely fix
adjuster arm shoe to fig.66 bracket ensuring the shoe is
rotated in the correct position. (See Fig. 4)
5. Place link arm onto closer spindle parallel
to door, fit securing screw, move link arm and
re-connect to adjuster arm. (See Figs. 4 & 5)
Note: Adjust arm length as required: Loosen
nut, adjust arm & re-tighten nut.
6. Fit spindle cover cap to underside of closer. (See Fig. 5)
7. Check for correct closing & latching speeds. Adjust if
necessary. (See Fig. 6)
8. Stick easi-exit logo onto indent of slide plate and refit to
door closer. (See Fig.6)
Note: For delayed action model DCS2025BCDA, adjust valve as required.
