Page 3 Door Closer – Model DCT2024 Rev.1
Copyright © 2008 Eurospec Failure to install this product as per these instructions &
dimensions shown on template will negate guarantee
Installation – Fig 61 Application – Angle of opening 180°
Fig 61 – Transom Mounting Application (Door closer fitted on frame on push side of door)
Fig. 4
Fig. 6
Fig. 1
FAST SLOW
No.2
No.1
No.1 Closing Speed
No.2 Latching Speed
Fig. 2
Fig. 3
TransomMountingApplication
USETHESEFITTINGHOLES
FORPOWERSIZES3&4USETHESEFITTINGHOLES
FORPOWERSIZE2
SIZES2&4SIZE3
Fig. 5
Adjust if
required
Illustrations show clockwise closing door
1. Ensure that the door & surrounding frame are in good
condition & the door closes freely.
2. Use Fig.1 easi-fit template and select correct hand of door.
Stick template to top corner of door and frame, ensuring
closer is mounted on frame and shoe is mounted on door.
(See Figs. 1 & 2)
3. Determine the power size of door closer required. Drill pilot
holes in door & frame according to template. Remove slide
plate and fix door closer body with screws supplied, ensuring
correct fitting holes are used (See Figs. 2 & 3)
4. Carefully detach link arm from adjuster arm & securely
fix adjuster arm shoe to door ensuring the shoe is
rotated in the correct position to suit power size
required. (See Fig. 4)
5. Place link arm onto closer spindle at right angles
to door, fit securing screw, move link arm and
re-connect to adjuster arm. (See Figs. 4 & 5)
Note: To adjust arm to suit depth of frame, loosen
nut, adjust arm & re-tighten nut.
6. Fit spindle cover cap to upperside of closer. (See Fig. 5)
7. Check for correct closing & latching speeds. Adjust if
necessary. (See Fig. 6)
8. Stick easi-exit logo onto indent of slide plate and refit to
door closer. (See Fig.6)
Note: Not suitable for power size 4 when fitting in Fig 61 application
