EasyAwn Standard Awning Maintenance manual

Copyright 2015, EasyAwn, LLC Page 1 EA-INST-C060403
EasyAwn™Installation, Care and Maintenance Manual
“Quality, Since 1946”
EasyAwn
EasyAwn, LLC
Toll Free: 877-EasyAwn
http://www.EasyAwn.com
READ AND SAVE THESE INSTRUCTIONS!
EasyAwn™Standard Awning Installation
Congratulations – You have made an excellent decision in choosing an EasyAwn Do-it-
Yourself awning. EasyAwn uses innovative designs and quality materials to make your awning
easy to install and ensure a long life.
Please take a minute and become familiar with this entire document BEFORE beginning your
installation. This will ensure a quick, trouble-free installation
Basic Tools Needed for Installation
Tape Measure & Pencil Level (recommended)
Drill Screwdriver
Drill Bits (Depends on Surface) Ladder
Adjustable Wrench
General Comments
•Wash your hands before installation and be sure they are clean when handling the
fabric.
•Always be careful with the fabric during installation. Drills, screwdrivers and other items
can puncture the fabric. This and other customer installation damage is not covered by
the warranty.
•A second person to assist in holding the awning up and the fabric back when installing
your awning is recommended
•Take your time when planning to install your new awning. Although simple to install,
take your time to ensure a proper installation.
IMPORTANT
!
If you need replacement parts or hardware for
installation, please do not return your awning
to the store or dealer. We will promptly
provide these to you at no charge.
Call 877-EasyAwn or 877-327-9296

Copyright 2015, EasyAwn, LLC Page 2 EA-INST-C060403
Planning and Layout of the Installation Location
The first step in installing your EasyAwn™is to determine where you will mount the awning. It should
be installed level and centered over the window or door. If the door or window opens outward, the
awning must be high enough to provide clearance when the door or window is in the open
position. Note: In some cities and counties there are building codes that specify how awnings can be
mounted.
Determine where you will be mounting the awning and refer to the figure below for typical locations of
studs and headers. The framing members outlined in Gray will provide an appropriate anchoring point
for the fasteners.
On masonry walls drill and insert anchors for the mounting screws. For other surfaces, locate the studs
for anchoring the supplied screws.
•If the locations of the predrilled holes do not match your stud locations, drill new ¼” holes in the
back bar of the frame to match your stud locations.
•If you have planking or another thick surface over the framing, you may need to use longer
screws than those supplied to ensure a secure fastening.
Dimensions and List of Parts
15” 21”
30”
Width
See the list of parts in the figure below. Become familiar with each part before you begin.

Copyright 2015, EasyAwn, LLC Page 3 EA-INST-C060403
Item
Description
1
Rafter
6
Clamps
2
Return Arm
7
Front Bar
3
Center Brace – 8’ – 12” Only
8
Front Bar Center – 8’ -12’ Only
4
Back Bar
9
Center Return Arm – 8 ’- 12’ Only
5
Back Bar Center – 8’ – 12” Only
(item 9 is shown below)
Assembly and Mounting of your new EasyAwn Awning
There are 2 options for installing your new Easyawn Awning.
Installation Option 1
Assemble the awning on the ground and then attach the awning to the home.
Installation Option 2
Assemble the awning on the home as shown in the following steps.
Assemble the two back bar pipes (three on the 8’). Insert the grooved post into the mating tube.
Connect and secure with the set screw.
Position the back bar to the correct height above the window or door. Mark the center of the window or
door to make sure the awning is centered. For 8’,10’ and 12’ awnings there is a return are that need to
be mounted at least 3 inches below the back bar to keep the front bar level.

Copyright 2015, EasyAwn, LLC Page 4 EA-INST-C060403
Ensure the back bar is level and fasten the clamps tightly to the wall.
Review the completed EasyAwn™assembly as shown below.
2
1
4
7
6
5
3
Item
Description
Item
Description
1
Back Bar
5
Pocket
2
Cover
6
Return Arm
3
Valance
7
Rafter
4
Front Bar
8
Center Return Arm (not shown)
Slide the rope sewn into the back edge of the cover into the back bar on the wall. You may need to use
a screwdriver to slightly open the channel at each section if the fabric catches on the edges.
Assemble the front bar and slide it into the front pocket of the cover.
NOTE: On the 8’, 10’ and 12’ Wide EasyAwn Classic Awnings
there is a center return arm as shown. Make sure the
threaded rafter holder is above and the tab with he hole in it is
below the front bar

Copyright 2015, EasyAwn, LLC Page 5 EA-INST-C060403
Hold the front bar out from the wall so the rafter is level to the ground to loosen the fabric. Install a
rafter connecting the back bar to the front bar. Raising the front bar to the same height as or above the
back bar may be required. A second person to hold the front bar out and level may be needed on
larger awnings.
Loosely fasten a nut at each end of the back bar to hold the rafter in place.
•DO NOT TIGHTEN THE NUTS ON THE ENDS OF THE FRONT AND BACK BAR UNTIL THE
INSTALLATION IS COMPLETED.
Repeat the above step for the rafter on the opposite end of the awning.
Slide the return arm into the pocket on the side panel of the awning. Make sure the tab for mounting
the return are to the wall is facing to the inside of the awning. Loosely fasten a nut at each end of the
front bar to hold the rafter and return arm in place.
Level the return arms and fasten the end of the return arms to the wall. Pull the return arms down
firmly to further tension the fabric before fastening. The last step is to tighten the frame bolts.
Install Center Brace – 8’ -12’ EasyAwn Only: Slide the open end of the center brace over the stub on
the center section of the front bar. Insert the pin on the opposite end into the hole in the center section
of the back bar. Place as much tension on the fabric as possible and secure the center rafter with the
fastener.
Install Center Return Arm – 8’ -12’ EasyAwn Only: Attached the end of the center rafter to the font
bar and the bracket to the rear of the return arm as shown below. You can mount the bracket
anywhere from a few inches below the back bar to 12’ below the front bar but if possible it should be
mounted level with the other return arms. Adjust the nut so the center of the front bar is level from side
to side.
Congratulations - Your EasyAwn™installation is now complete! If you would like a waterproof
seal at the wall, use a non-adhesive caulk to seal the aluminum channel to the wall. This is not
recommended if you will be removing the awning each season.

Copyright 2015, EasyAwn, LLC Page 6 EA-INST-C060403
Care and Maintenance
Keep your EasyAwn™looking great by hosing off the Sunbrella™fabric on a monthly basis. This will
help prevent dirt from embedding in the fabric and reduce the need for thorough cleanings. In most
environments, a thorough cleaning will be needed every two to three years with the EasyAwn™fabric
on the awning frame or removed for cleaning in your washing machine.
When cleaning your EasyAwn™on the frame, follow these simple steps:
•Brush off loose dirt.
•Hose down.
•Prepare a cleaning mixture of water and mild, natural soap (no detergents).
•Use a soft bristle brush to clean.
•Allow soap to soak in.
•Rinse thoroughly.
•Air dry.
If you are removing the cover and using a washing machine, these steps should be followed:
•Use only natural soaps. No detergent.
•Wash and rinse in cold water.
•Air dry. Never put EasyAwn™fabrics in your dryer.
After a thorough cleaning, EasyAwn™fabrics should be treated to re-establish water repellency. Your
EasyAwn™fabric is treated with fluorocarbon-based water repellency chemicals during manufacturing,
and it is recommended that a retreatment with ScotchGard® or similar product is done following
cleanings.
General Care Tips
•Keep trees and shrubs trimmed back from all canvas awnings
•Do not use harsh chemicals or bleaches for cleaning.
•Insect repellents and other chemicals can damage the fabric
•Do not hang from the awning, it will damage the fabric and the frame
•Remove awnings for painting
•Snow accumulation can stretch or tear the fabric
•Remove awnings during snow conditions
•Do not let water pool on the fabric.
Limited Warranty
If you are installing your EasyAwn™on a commercial building or in another area restricted by building and zoning regulations,
contact your local building officials prior to installing your EasyAwn™to ensure you will comply with local regulations. Many
homeowners associations also require approval prior to making any exterior home improvement and should be consulted prior
to installation. If you need engineered drawings for the building permit please request them from us as we are happy to
provide these to verified customers. Our standard engineered drawings are valid in most permit applications but you may
need additional engineering for permitting as required by your local building codes which is not included in this purchase.
EasyAwn, LLC is committed to customer satisfaction and we offer a money back guarantee if you are not completely satisfied
with your EasyAwn™. This is limited to awnings returned within 30 days of shipment and must not be damaged. Happy
customers are the best salespeople we have and we are very thankful for the thousands of customer advocates that we
have. If your not an advocate, or at least a really happy customer we need to know.
EasyAwn, LLC warrants this product against defects in materials and workmanship on a prorated basis for a period of seven
years from the date of original purchase. EasyAwn, LLC agrees to either repair the product or replace it, at the sole discretion
of EasyAwn, LLC. This warranty does not include any costs associated with the physical installation, removal or return of this
product.

Copyright 2015, EasyAwn, LLC Page 7 EA-INST-C060403
Only the original purchaser of this product is extended this warranty. No warranty work will be provided under this warranty
without the purchaser’s receipt or other proof of the date of purchase.
EasyAwn, LLC’s warranty covers product failure due to defects in material or workmanship only. It does not cover corrosion or
discoloration, or product failure due to misuses, abuse, faulty installation, alteration, lack of reasonable care, or any other
failure not related to defects in materials or workmanship.
There are no other warranties except those stated above.
EasyAwn, LLC shall not be liable for incidental, special or consequential damage resulting from the use of the
product or arising out of any breach of this warranty. All implied warranties, if any, including implied warranties of
merchantability and fitness for a particular purpose, are limited in duration to the length of this express warranty.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an
implied warranty lasts, so the above exclusions or limitations may not apply to you. No other warranty, written or verbal, will
be honored for this product. This warranty gives you specific legal rights and you may also have other rights, which vary from
state to state.
EasyAwn, LLC is not responsible for damage of merchandise in transit. Repaired or replaced products shall be subject to the
terms of this warranty and are inspected prior to return shipment. Damages that are incurred during transit should be reported
at once to the carrier and a claim should be filed with them.
For assistance with this product or to obtain warranty services, call EasyAwn, LLC’s Customer Service Department 8:00 – 5:00
Eastern Standard Time toll free at 877-EasyAwn. Please have the product’s model number and date of purchase when you
call to avoid delays.
We appreciate your purchase of this EasyAwn™. We have made every effort to supply a high quality product that
insures trouble free service for many years. Please contact us if you have any questions, concerns or if we can be of
help in any way.
EasyAwn, LLC
Toll Free: 877-EasyAwn
www.EasyAwn.com
Email: [e-mail]
