Easylife EL5868 User manual

Solar PIR Security Light
INSTRUCTION MANUAL
Model No. EL5868
Please read carefully before use and keep for future reference
Imported and distributed by Easylife Group Ltd, London NW1 0JP
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
IN5868-1 © 2014 Easylife Group Ltd Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
PANTONE 072 C
PANTONE 123 C
DISPOSAL
• Pleaserespecttheenvironment!
• Disposeofthepackagingaccordingtothelocalrecyclingregulations.
• Disposeoftheapplianceattheendofitslifespanaccordingtoenvironmentalconsiderations.
DECLARATION OF CONFORMITY
Easylife Group Ltd
11-13King’sTerrace
London
NW1 0JP
Declaresthatthefollowingproduct
EL5868SolarPIRSecurityLight
IsinconformitywiththeprovisionsofthefollowingECdirectives:
EMCDirective2004/108/EC
Thefollowingstandardsareapplied:
EN55015:2006+A1:2007+A2:2009
EN61547:2009
WARNING
Thisproductisintendedfordomesticuseonly.
TECHNICAL SPECIFICATION
Measures:
WELCOME
VISITORS
AND DETER
INTRUDERS
Paperweight60gsm

PANTONE 072 C
PANTONE 123 C
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
Dear Customer
ThankyouforpurchasingtheSolarPIRSecurityLight.
IMPORTANT SAFETY INSTRUCTIONS
• Donotinstallclosetowhereotherpeopleorpassingvehiclescouldtamperorobstructthesecurity
light.Keepchildrenandinfantsawayfromtheproduct.
• Donotinstallclosetoanythingammable.
• Installthesecuritylightonasolidandverticalbase.
• Thesolarpanelshouldfacetowardsthesuninorderforittore-charge.Cleanthepanel
beforecharging.
• Donotstaredirectlyatthelightforalongtimewhileitison.
• Donotinstallitclosetootherproductsthatsendradiowaves.
• Topreventitfromfalling,installthebaseunitcorrectlywithanexpansionscrew.
• Thesecuritylightcannotpreventcrimesbyitself.It’suseisonlyintendedasadeterrentandshouldbe
usedinconjunctionwithotherhomesecuritysystems.
• Makesurethesolarpaneljackisfullyinsertedintothesocketofthelightheadxture.
CHARGING THE BATTERY
• Youcanchargethebatteryusingsolarpanel.
• Positiontheswitchto“AUTO”or“OFF”whenyouinstallthesolarpanel.
• Thesolarpanelshouldfacetowardsthesun.Ifthesolarpanelisdirtyitwillhinderandpreventthe
batteryfromchargingefciently.
PART LIST
 Part Description Part Description
 1 Lamp 8 ON/OFF/AUTOSwitch
 2 SolarPanel(5mwire) 9 BatteryHousingoutlet
 3 Expansionscrew 10 SolarPanelMountingBracket
 4 60PCSLED 11 LUXAdjustingKnob
 5 BatteryHousing 12 SENSAdjustingKnob
 6 MotionDetectorHead 13 TIMEAdjustingKnob
 7 “U”shapedMountingPlate 14 NI-HMbattery(notshown)
PARTS
INSTALLATION
• Thesecuritylightshouldbesetupinalocationwhereyourequireadditionallightinginordertodetect
personsorobjectsthatmoveatnightorinthedark.
• Decidewhereyouwanttoplacethelamp(1)andsolarpanel(2).TheLightisequippedwith5metres
ofconnectingwiresotheLamp(1)andSolarpanel(2)canbeinstalledupto5metresapart.
• TheSolarpanel(2)mustbesetinalocationthatreceivesfull,directsunlightwithaminimumof8
hoursaday.Soweadviseputtingitonawallorroof.
• Mountthelamp(1)2to3metresabovegroundonasolidsurfacecapableofsupportingthelamp(1)
andsecureenoughsothatitwillnotmovewhenexposedtovibrationorwind.Theunitmustbehigh
enoughtoallowforthemotiondetectionandlightdistribution.
• Usingthemountingplateasatemplatemarkwherelampistobeinstalled.Secureinplacethe
mountingplatewiththemountingscrews(3)provided.
• Installthesolarpanel(2)inthesamewaythatyouinstalledthelamp(1).
• Carefullyroutethepowercordofthesolarpanel(2)tothelamp(1)andplugitintothebattery
housingoutlet(9).
• Adjustthemotiondetectorhead(6)belowthelightbymovingitleftorrightsothatitfacesthearea
wheremovementwilloccur.Moveitupordownbyusingthescrewlocatedontheneckofmotion
detectorhead(6).
Paperweight60gsm

PANTONE 072 C
PANTONE 123 C
Customer service: 0871 855 6100
For more innovative products from Easylife please visit:
www.easylifegroup.com
OPERATION
• Beforethesecuritylightcanoperatetoitsfullcapacity,thesolarpanelneedstobeindirectsunlight
for3daystofullychargethebattery.Turntheswitchtothe“OFF”position.Aftercharging,turnthe
switchto“AUTO”or“ON”position.
• Turntheswitchtothe“AUTO”position,thelightwillturnonautomaticallyatnightwhenmotionis
detectedbythemotiondetectorhead(6).
• Turntheswitchtothe“ON”position,thelightcanthenbeusedasastandardlight.
PERSONALISE YOUR SECURITY LIGHT
Youcanchoose3waystousealtertheswitchunderthebatteryhousingofthelamp(1).
 OFFMiddleposition-whenyoudonotneedlight.
 AUTOLeftposition-lightturnsonautomatically(suitablefortheentranceofgarages,porches,
eavesetc.)
 ONRightposition-lightcanbeusedasastandardlight(suitableforcamping,shingetc)
HOW TO USE THE CONTROL KNOBS
• Thesecuritylighthas3differentcontrolknobswhichcontrolthelight’sduration,sensitivitytolightand
sensitivity to motion.
LUX (Light level)
• TheLUXadjustingknob(11)tellsthesensorthelevelofdarknessthatmustbereachedbeforethe
lightturnson.
• Ifsettothemaximumlevel,thelightwillgooninmostsituationsrangingfromdarktodaylight.
• Ifsettotheminimumsettingthesensorwillonlytriggerthelighttoturnonatduskorwhenitis
dark.Thisistheidealpositionforgeneraleveningandnightoperation.Ifthesecuritylightisnotin
operationatnightduetointerferencefromastreetlightorotherinterference,turntheLUXknob
towards.
Paperweight60gsm
TIME
• TheTIMEadjustingknob(13)setsthedurationoftimethatthelightshouldstaylitaftermotionisno
longerdetectedintheeldofvision.
• TheTIMEisadjustablefrom8secondsto2minutes.Adjustingtheknobclockwisewillmakeitstay
onlonger.
SENS (Sensitivity) (12)
• Minimumposition(idealforhotsummerconditionsorwhennuisancetrippingisaproblem).
• Midposition(normalsetting).
• Maximumposition(idealforcold,winterconditionsortomaximizerange).
Note: Themotiondetectorheadismostsensitivetomovementacrossthedetectionzone,ratherthan
movementtowardorawayfromthemotiondetectorhead(6).
  Ifthelightisover-activatedbysmallanimalsorrapidchangesinheat.
  Ifthelightismiss-operatedinhotsummerconditions,thesensitivitycanbereducedbyturningthe
knobcounterclockwisetowardstheminimumsetting.
MAINTENANCE
• Whenstoringyoursecuritylightindoorsformorethan2or3days,turntheswitchto“OFF”.Storethe
lightinadrylocationfreeofdustanddebris.Makecertainthatthelightisoutofreachofchildren.
• Thelightmustbefullychargedfor5daysandswitchedtothe“OFF”positionbeforestoring.Storing
thelightforprolongedperiodsmaydamagethelightordecreaseperformance.
• Keepthesolarpanelawayfromdirtanddebris.Adirtysolarpanelwillpreventthebatteriesfrom
charging.Cleanregularlywithadampcloth.
• Keepthesolarpanelfreeofdirt,dustandgrime.Dustcoveringthesolarpanelwillblockoutsunlight
causingadecreaseorhinderingtheefciencyofrechargingthebatteries.
BATTERY REPLACEMENT
• Thebatterypackislocatedinthebatteryhousing(5).
• Turntheswitch(8)tothe“OFF’position.Removethefourscrewsfromthebatteryhousing(5).
• Separatethebatterypackconnector.Removeoldbatterypack.Replaceonlywithanidentical
rechargeablebatterypack(14).
• Replacethecoverofthebatteryhousing(5).Secureitwiththefourscrews.
