EasyPro Pond Monsta User manual

The Pond Masters Guide to
Complete Cleaning System

The Pond Masters Guide to
Complete
Cleaning
System
Congratulations on buying a Pond Monsta cleaning system.
Manufactured to the highest quality with leading market
technology to create a clean and healthy pond for your sh.
~ IMPORTANT ~
Please attach proof of purchase to
this manual and le in a safe place.
2

Table of Contents
Getting to know your Pond Monsta ................................... 4-5
Parts and Description.......................................................... 4-5
Getting to know your Monsta Collector............................. 6-7
Parts and Description.......................................................... 6-7
Technical Specication...........................................................7
Installation......................................................................... 8-9
Electrical Installation .......................................................... 8-9
Radio Frequency Receiver ......................................................9
How to use Pond Monsta ............................................... 10-13
Minimum Start Depth...........................................................10
Handle Activation and Battery Installation ............................11
Clearing Blockages ...............................................................12
Monsta Collector Recycling Water Options ..........................12
Cleaning Collected Waste.....................................................13
Storage .................................................................................13
Maintenance ........................................................................14
Removing and Fitting Impeller..............................................14
Troubleshooting....................................................................15
Faults and Problems Procedure.............................................15
Consumer Contact Details....................................................15
Warranty ................................................................ Back Cover
3

44
Getting to know your
POND MONSTA
EasyPro Part #PMV35

5
Getting to know your
POND MONSTA
1.............................................................................Handle
2............................................ Extendable pole, top section
3...........................................................................Pole cap
4........................................... Extendable pole base section
5.............................................Locking nut, hose/cable clip
6................................................................Hose/cable clip
7............................................................ Fixed pole section
8...................Optional 1.2m (3.91') extension pole section
9.......................................................................Hose guide
10.................................................................. Carry handle
11...................................................... Electrical cord guide
12..................................... 10m (32.8') electric power cord
13................................................................Motor housing
14........................................................................Air outlet
15.................................................Air outlet cleaning spike
16................................................... Clear impeller housing
17.............................................Impeller cover clip spacers
18........................................................Impeller cover clips
19............................................ Impeller cover clips screws
20.................................. Stainless steel clip spacer retainer
22......................................................... Outlet clear elbow
23......................................................Outlet clear hose tail
24.......................................................... Outlet locking nut
25.......................................Optional hose clip xing point
26........................................ 6m (19.6') 11/2" hose supplied
27................................................................. Impeller shaft
30........................................... Pond impeller, 70mm (23/4")
31............................................................. Impeller washer
32............................................................Impeller lock nut
33................................................................Impeller cover
34................................ Monsta head clip, spacer & screws
35...................................Monsta head clip, spacer retainer
36........................................................... Monsta head clip
37................................................... Monsta head back clip
38.......................................... 10cm (4") power brush head
39......................... 20cm (8") optional wheeled brush head
41.................................................... Power connector plug
42.............................Red power on standby indicator light
43...................................... Green power on indicator light
44................................................Radio frequency receiver
45....................................................3m (9.8') rubber cable
46................................................................Three pin plug
47....................................... Remote control handle battery

6
Getting to know your
POND MONSTA COLLECTOR

7
Getting to know your
POND MONSTA COLLECTOR
1..............................................................Filter net handles
2................................................Collector water tight body
3........................... Monsta waste inlet locator, support clip
4....................................................................... Filter mesh
5...................................................... Top left collector pole
6...............................................Bottom right collector pole
7.................................................Bottom left collector pole
8.................................................... Top right collector pole
9......................................................................... Hose reel
10.................................................................. Center screw
11................................................................ Center washer
12........................................................Center back washer
13......................................................................Center nut
14............................................................ Hose reel screws
15.......................................................... Hose reel washers
16................................................................Hose reel nuts
17.............................................................Collector outlets
18..................................................... Rubber outlet washer
19.............................................................Outlet back nuts
Technical Specications & Performance
Voltage ......................................................................115V
Hertz.........................................................................60Hz
Watts........................................................................... 350
Safety rating...........................................................IPX8 CE
Cable tted...................................10m + 3m (32.8' + 9.8')
Remote control handle battery..... GA 23A Alkaline Battery
Maximum submerged depth .............................. 5m (16.4')
Maximum ow impeller ................ 5400 It/hr (1188 gal/hr)
Maximum lift impeller ...................................... 2.9m (9.5')

8
Installing your
POND MONSTA
Electrical Installation
All electrical work must be performed by a qualied techni-
cian. Always follow the National Electrical Code (NEC) or
the Canadian Electrical Code as well as all local, state and
provincial codes. Code questions should be directed to
your local electrical inspector. Failure to follow electrical
codes and OSHA safety standards may result in personal injury or equip-
ment damage. Failure to follow manufacturer’s installation instructions may
result in electrical shock,
re hazard, personal injury
or death, damaged equip-
ment, provide unsatisfac-
tory performance and
may void manufacturer’s
warranty.
Always connect to a
Ground Fault Circuit
(GFCI).
Always disconnect
the electricity sup-
ply before han-
dling, maintaining,
repairing or in-
stalling any pond
equipment.

9
Installing your
POND MONSTA
For permanent installations to the main supply, it is necessary to conform
to the regulations of your electric company and electrical ordinances for
your area. This would include the use of metal or plastic conduit to protect
the cable.
Attention has been drawn to the fact that special rules may exist concern-
ing the permanent installation of your Monsta (i.e. local building codes and
regulations).
Pond Monsta must not be used in swimming pools or areas where people
are in contact with the water.
Always disconnect the main electrical supply while the equipment is being
installed, repaired or maintained. Contact a qualied electrician to install
and wire this product to the main supply.
Warning - The Monsta pump has a thermal shut off that temporarily
switches off the pump in case of over heating and the pump may auto-
matically restart.
Never run the Monsta out of the water for prolonged periods as this may
cause irreparable damage.
Radio Frequency Receiver
1. No Lights - Main plug is not switched on or plug fuse/GFI/breaker
has activated.
2. Red Light - Receiver is on standby, power is received, handle lever
not compressed.
3. Green Light - Power on, Monsta motor receiving power, handle
lever compressed.

MIN: 30cm (11.81")
MAX: 5m (16.4')
10
How to use your
POND MONSTA
MINIMUM START DEPTH
Water level MUST sub-
merge the air outlet before
starting the Monsta.
Minimum water depth -
30cm (11.81")
Maximum water depth -
5m (16.4')

11
How to use your
POND MONSTA
Ensure that the remote control handle battery is installed (see diagram below).
Note - Remove large objects over 32mm (11/4") in size with a net to prevent exces-
sive blocking of Pond Monsta during operation. It is normal for Pond Monsta to
block and require clearing occasionally. Pond Monsta has been designed so that
this requires a minimum of time and effort (see “clearing blockages” on page 12).
1. Plug in GFI (not supplied).
2. Plug in tted three prong RF receiver plug.
3. Plug in RF receiver connector plug.
4. Connect hose to outlet hose tail rmly, a hose clip may be used to secure (not
supplied).
5. Choose Collector recycling option/position for Collector outlet returns (see
page 12).
6. Place hose in Collector locator.
7. Connect hose and cable to hose cable clips. Adjust so that the hose is level
with the water surface when the Monsta is fully submerged.
8. Adjust pole by twisting and locking to a comfortable height.
9. Switch on main electrical supply, standby light will show red on the RF re-
ceiver.
10. Submerge Pond Monsta fully until air stops releasing from air outlet (the Mon-
sta will not pump effectively until all air is released).
11. Compress safety button and squeeze lever to activate pumping on, release to
turn off.
12. Waste will now start to ow into the Collector, it is recommended that the
higher shelf areas are cleaned rst. Always move the Pond Monsta in a slow
back and forth motion to prevent disturbing the sediment and waste.
13. Secondly, clean the base of the pond, again use a slow back and forth mo-
tion using the clear hose as a visual guide to indicate which areas have been
cleared.
14. When the Collector basket is full or over owing, turn off the Pond Monsta by
releasing the handle and remove the collected debris to waste or compost.
RREELLEEAASSEEOOFFFF
ON

12
How to use your
POND MONSTA
Clearing Blockages
Monsta Collector Recycling Water Options
With the use of the Pond Monsta Collector you can either recycle your
pond water back into the pond, directly into your plant beds as pond water
is an excellent feed source your plants can use to grow tall and healthy or
the waste water can go into a drain.
Pond Monsta is completely safe to healthy adult pond sh.
Always turn the Pond Monsta
off at the main circuit before
opening impeller cover.

13
How to use your
POND MONSTA
Cord Storage
Wind cord
between hose
guide &
adjustable
hose/cable

14
Maintenance of your
POND MONSTA

15
Troubleshooting your
POND MONSTA
Poor Flow from the Pond Monsta
• Follow clearing blockages procedure on page 12. Check the hose attachment,
the motor housing and the brush head inlet for blockages like large clumps of
blanket weed, large stones, sticks or any other large pond debris.
• If the impeller has been changed, check to see that it has been correctly tted
(see page 14).
• Ensure the outlet hose is not kinked or crushed.
• Only use smooth bore hose as hose with ridges on the inside wall will greatly
restrict ow.
• Check all air is released from air outlet.
No Power to the Motor
• The LED is glowing red on the RF receiver but there is no action when activat-
ing the handle lever - check the batteries are correctly tted in the remote
control handle and the handle does not have any water inside the casing. If
there is water present, place inside a warm area to let the water evaporate. If
the Pond Monsta has been used for prolonged periods the battery will need
replacing.
• The LED on the receiver are not glowing when plugged into the main circuit -
check your plug in the GFI, your fuse box or breaker box. Check fuse in three
prong plug, if needed replace and test again.
• The LED is glowing red on the receiver and turning green when the trigger on
the handle is compressed but still no action from the motor - this may indicate
that the motor has overheated, the motor will reset when cooled after fteen
minutes.
Handle Activation Control
• Occasional loss of squeeze on, release off control is normal. Ensure line of
sight between handle and receiver, adjust hands and body position - this will
improve receiver signal reception.
Faults - Problems Procedure
Before returning your Pond Monsta to your dealer or contacting our customer
advice department, please try the following steps. This will solve most problems
quickly and easily.
1. Ensure electrical procedure has been followed fully. Check fuse and any cable
connectors or switch boxes.
NOTE - If the pump has overheated the thermal overload will temporarily
switch off pump.
2. Follow “clearing blockages” on page 12 and “troubleshooting” guide above.
3. Return pump to point of purchase for inspection and advice (you will need
proof of purchase). If there is a warranty issue please call EasyPro Pond Prod-
ucts for an RA number and shipping address at 800-448-3873.
Consumer Contact Details
EasyPro Pond Products
4385 East 110th, Grant, MI 49327
231-834-7720 • 800-448-3873
[email protected] • www.easypropondproducts.com

POND MONSTA wARRANTy
This product is warranted against defects in material and workmanship for two
years from the date of purchase, under normal usage. The guarantee DOES NOT
APPLY in case of improper use, negligence, lack of maintenance or accidental dam-
age to either the Pond Monsta or the Pond Monsta Collector. If the Pond Monsta or
the Pond Monsta Collector fails due to manufacturing fault within this period it will
be either repaired or replaced free of charge. Liability is limited to replacement of
the faulty product only, no other costs will be reimbursed.
The warranty is not transferable and does not affect your statutory rights. This war-
ranty does not confer any rights other than those expressly set out above. Excludes
consumable parts (batteries, lter mesh, impellers and hose). If any parts are
needed, spares are available from your dealer. Please see getting to know your Pond
Monsta on pages four through six for spare part descriptions. Pond Monsta can be
returned with an RA number for warranty issues. Please call EasyPro Pond Products
for an RA number and shipping address at 800-448-3873.
www.EasyProPondProducts.com
800-448-3873
