The EasySYNC ES-R-2001B-M and ES-R-2101B-M are used to convert RS-232 signals to RS-422/RS-
485 signals. The converters provide instant connectivity to RS-422/RS-485 communication devices
for factory automation equipment, multi-drop data collection devices, barcode readers, time clocks,
scales, data entry terminals, PC to PC long distance communications (up to 1.3KM) and serial
communication in harsh environments.
This manual covers the following products:
ES-R-2001B-M
ES-R-2101B-M
EasySYNC Ltd
ES-R-2x01B-M
RS-232 to RS-422/RS-485
Converters Manual
Document Reference No.: ES_000086
Version 1.0
Issue Date: 2011-08-24
