Sync Control for Eaton 9395P and 93PM
User’s and Installation Guide

Sync Control for Eaton 9395P and 93PM 2
User’s and Installation Guide
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions that you should follow during installation and
maintenance of the UPS and batteries. Please read all instructions before operating the
equipment and save this manual for future reference.
WARNING
This is a product for commercial and industrial application in the second environment.
Installation restrictions or additional measures may be needed to prevent disturbances.
©2015 Eaton Corporation
All Rights Reserved
The contents of this manual are the copyright of the publisher
and may not be reproduced (even extracts) unless permission granted.
Every care has been taken to ensure the accuracy of
the information contained in this manual, but no liability
can be accepted for any errors or omission. The right
to make design modifications is reserved.

Sync Control for Eaton 9395P and 93PM 3
User’s and Installation Guide
Sync Control for Eaton 9395P and 93PM UPS
User’s and Installation Guide
P-164000495
Contents
1
Introduction.........................................................................................................................4
1.1 Conventions Used in This Manual .................................................................................................. 5
1.2 Safety Warnings................................................................................................................................. 6
1.3 For More Information ........................................................................................................................ 7
1.4 Getting Help......................................................................................................................................... 7
2
Installation Plan and Unpacking........................................................................................8
2.1 Creating an Installation Plan............................................................................................................ 8
2.2 Preparing the Site .............................................................................................................................. 8
2.2.1. Environmental and Installation Considerations ........................................................................... 8
2.2.2. Eaton Sync Control Wiring Preparation....................................................................................... 10
2.3 Inspecting and Unpacking the Eaton Sync Control................................................................... 10
3
Eaton Sync Control Installation .......................................................................................11
3.1 Installation and Wiring with an Eaton 9395P UPS ..................................................................... 11
3.2 Installation and Wiring with an Eaton 93PM UPS ..................................................................... 18
4
Eaton Sync Control Operating Instructions ....................................................................26
4.1 Startup for UPS Systems Equipped with an Eaton Sync Control............................................ 26
4.2 Understanding Eaton Sync Control Operation ........................................................................... 26
4.3 Operation ........................................................................................................................................... 28
4.4 Customer Monitoring....................................................................................................................... 30
4.5 Maintenance Operations................................................................................................................ 31
5
Recycling the used Eaton Sync Control..........................................................................32
6
Warranty............................................................................................................................33
7
Technical Data..................................................................................................................34

Sync Control for Eaton 9395P and 93PM 4
User’s and Installation Guide
1Introduction
The Eaton® Sync Control maintains the critical load outputs of two separate Eaton UPS systems
in synchronization. Use of the Eaton Sync Control provides the uninterrupted transfer of the load
from one load bus to another by means of downstream, dual-source, static transfer switches.
Without the load sync option, the two system output (critical load) buses could become out of
phase with each other. This condition occurs if suitable bypass sources are not available or if the
bypass sources feeding each system are not in sync with each other. Examples of this condition
are two systems supplied by separate diesel generator sets, or the bypass sources for the two
systems are lost.
The Eaton Sync Control can provide customer remote monitoring of sync control operation and
alarms. See paragraph 4.4 for detailed information.
Figure 1-1 shows the front view and Figure 1-2 shows the interior view of the Eaton Sync
Control.
Figure 1-1 Eaton Sync Control

Sync Control for Eaton 9395P and 93PM 5
User’s and Installation Guide
Figure 1-2 Eaton Sync Control with Door Open
1.1 Conventions Used in This Manual
This manual uses these type conventions:
•Bold type highlights important concepts in discussions, key terms in procedures, and menu
options, or represents a command or option that you type or enter at a prompt.
•Italic type highlights notes and new terms where they are defined.
•Screen type represents information that appears in the screen or LCD.
In this manual, the term UPS refers only to the UPS cabinet and its internal elements. The term
UPS system refers to the entire power protection system – the UPS cabinet, the battery cabinet,
and options or accessories installed.
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECRICAL SHOCK – Indicates that a risk of electric shock is present and the
associated warning should be observed.
CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for
additional information, such as important operating and maintenance instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries in the
trash. This product contains sealed, lead-acid batteries and must be disposed of
properly. For more information, contact your local recycling/reuse or hazardous waste
center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local recycling/reuse
or hazardous waste center.

Sync Control for Eaton 9395P and 93PM 6
User’s and Installation Guide
1.2 Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions that you should follow during installation and
maintenance of the UPS and batteries. Please read all instructions before operating the
equipment and save this manual for future reference.
The UPS cabinet is designed for industrial or computer room applications, and contains safety
shields behind the doors. However, these units comprise a sophisticated power system and
should be handled with appropriate care.
DANGER
This equipment contains LETHAL VOLTAGES. All repairs and service should be performed
by AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS
inside the Eaton Sync Control.
WARNING
•To reduce the risk of fire or electric shock, install this equipment in a temperature and
humidity controlled, indoor environment, free of conductive contaminants. Ambient
temperature must not exceed 40°C (104°F). Do not operate near water or excessive
humidity (95% maximum). The system is not intended for outdoor use.
•
Ensure all power is disconnected before performing installation or service.
CAUTION
•
Keep the equipment doors closed to protect personnel from dangerous voltages
inside the unit.
•Do not install or operate the equipment close to gas or electric heat sources.
•The operating environment should be maintained within the parameters stated in
this manual.
•Keep surroundings uncluttered, clean, and free from excess moisture.
•Observe all DANGER, CAUTION, and WARNING notices affixed to the inside and
outside of the equipment.

Sync Control for Eaton 9395P and 93PM 7
User’s and Installation Guide
1.3 For More Information
Refer to the applicable Eaton 9395P User’s and Installation Guide or Eaton 93PM UPS 30-200 kW
Users and Installation Guide for the following additional information:
•UPS cabinet, optional components, and accessory installation instructions, including site
preparation, planning for installation, and wiring and safety information. Detailed illustrations
of cabinets and optional accessories with dimensional and connection point drawings are
provided.
•UPS operation, including UPS cabinet controls, functions of the UPS, standard features and
optional accessories, procedures for starting and stopping the UPS, and information about
maintenance and responding to system events.
•Communication capabilities of the UPS system.
Visit http://powerquality.eaton.com or contact your Eaton service representative for information
on how to obtain copies of these manuals.
1.4 Getting Help
If help is needed with any of the following:
•Scheduling initial startup
•Regional locations and telephone numbers
•A question about any of the information in this manual
•A question this manual does not answer
Please call your local service representative. Contact information of the closest Eaton service
location can be found through www.eaton.eu.

Sync Control for Eaton 9395P and 93PM 8
User’s and Installation Guide
2Installation Plan and Unpacking
The Eaton Sync Control is shipped as a separate item and can be mounted on any surface that
can safely bear its weight. See paragraph 2.2 for weight, dimensions, and wiring preparation.
2.1 Creating an Installation Plan
Before installing the UPS system, read and understand how this manual applies to the system
being installed. Use the procedures and illustrations in the following chapters to create a logical
plan for installing the system.
NOTE
Startup and operational checks must be performed by an authorized Eaton Customer
Service Engineer, or the warranty terms specified on page 33 become void. This service is
offered as part of the sales contract for the UPS. Contact service in advance (usually a
two week notice is required) to reserve a preferred startup date.
2.2 Preparing the Site
For the Eaton Sync Control to operate at peak efficiency, the installation site must meet the
environmental parameters outlined in the applicable Eaton 9395P or Eaton 93PM User’s and
Installation Guide that are listed in paragraph 1.3 on page 7.
2.2.1. Environmental and Installation Considerations
The life of the Eaton Sync Control is adversely affected if the system is not installed in a
temperature and humidity controlled indoor area free of conductive contaminants.
Failure to follow guidelines may void your warranty.
Attach the Eaton Sync Control to the wall with appropriate fasteners and washers. The Eaton
Sync Control includes 4 x 8mm mounting holes as shown in Figure 2-1. As wall materials vary,
fasteners for fixing to the wall are not included.
The equipment operating environment must meet the weight requirements shown in Table 2-1
and the size requirements shown in Figure 2-1 and Figure 2-2. Dimensions are in millimeters
(inches).
Table 2-1 Equipment Weight
Eaton Sync Control
Shipping
Installed
Weight [kg] (lbs)
33,4 (73,6)
30,1 (66,4)

Sync Control for Eaton 9395P and 93PM 9
User’s and Installation Guide
Figure 2-1 Eaton Sync Control dimensions, front view – Dimensions are in millimetres [inches]
Figure 2-2 Eaton Sync Control dimensions, top – Dimensions are in millimetres

Sync Control for Eaton 9395P and 93PM 10
User’s and Installation Guide
2.2.2. Eaton Sync Control Wiring Preparation
Read and understand the following notes while planning and performing the installation:
•Refer to national and local electrical codes for acceptable external wiring practices.
•Material and labour for external wiring requirements are to be provided by designated
personnel.
•For external wiring, use 70°C copper wire with a minimum insulation rating of 400V. If wire
is run in an ambient temperature greater than 30°C, higher temperature wire and/or larger
size wire may be necessary. See the applicable wiring information in Chapter 3.1 for the
Eaton 9395P and in Chapter 3.2 for the Eaton 93PM UPS.
•Use wiring with a minimum insulation rating of 400V for interconnections between the Eaton
Sync Control, the UPS, and the customer remote monitoring system.
•Sync Control dry contacts are rated at 5–30 VDC/250 VAC at 2A per contact (maximum load).
•When installing external wiring between the Eaton Sync Control and the UPS, run cables
separate from any power cables to minimize risk for inducted noise to the control signals.
•The Eaton Sync Control can be installed up to a maximum of 150 m (500 ft) from the Eaton
9395P or 93PM UPS system.
CAUTION
When connecting the bypass and load voltage from another model UPS to a Eaton 9395P
or 93PM UPS using the Eaton Sync Control accessory, connect all three phases from the
other UPS to the Sync Control connection point. DO NOT connect the other model UPS
Neutral to the Sync Control connection point when connecting to a Eaton 9395P or 93PM
UPS.
2.3 Inspecting and Unpacking the Eaton Sync Control
The unit arrives covered with protective packaging material.
1. Carefully inspect the outer packaging for evidence of damage during transit.
CAUTION
Do not install a damaged cabinet. Report any damage to the carrier and contact your
Eaton service representative immediately.
2. Remove the protective cardboard covering from the Eaton Sync Control by cutting where
indicated using a knife blade no longer than 25 mm (1”).
3. Remove the plastic bag and foam packing material, and discard or recycle them in a
responsible manner.

Sync Control for Eaton 9395P and 93PM 11
User’s and Installation Guide
3Eaton Sync Control Installation
WARNING
•
Only qualified service personnel (such as a licensed electrician) shall perform the
electrical installation. Risk of electrical shock.
•Shut down all sources of power to the Eaton UPS system before connecting the
control wiring to the Eaton Sync Control enclosure and UPS. Hazardous voltages
exist inside the UPS and in the Eaton Sync Control enclosure. Check all terminal
conductors with a known serviceable voltmeter before connecting the wiring.
When the Eaton Sync Control has been moved to its installed location, unpacked, and inspected,
it is ready for installation and wiring.
Use the applicable procedure from the following list to install the Eaton Sync Control to the UPS:
•� With an Eaton 9395P UPS, proceed to paragraph 3.1.
•� With an Eaton 93PM UPS, proceed to paragraph 3.2.
3.1 Installation and Wiring with an Eaton 9395P UPS
To install and wire:
1. Install the Eaton Sync Control panel to the selected mounting location.
See Figure 2-1 on page 9 for mounting hole dimensions and Figure 2-2 on page 9 for cable
entrance locations.
2. Unfasten the front door latches and swing the door open.
3. Complete all control wiring interconnections using Table 3-1 on page 12 or Table 3-2 on page
13 for wiring requirements.
Figure 3-1 on page 14 shows the Eaton Sync Control TB1 terminal block and ground terminal
locations. Figure 3-2 on page 15 shows the TB1 terminal block wiring detail.
Figure 3-4 on page 16 shows the typical locations of the UPS TB2, TB3, and TB6 terminal
blocks. Figure 3-3 on page 16 shows the TB6 detail.
Refer to the applicable Eaton 9395P UPS Installation and Operation Manual listed in
paragraph 1.3 on page 7 for UPS cabinet terminal locations and assignments, termination
requirements, cable landing locations, and terminal access instructions.
4. Verify the jumper is installed between Eaton Sync Control terminal TB1-72 and TB1-73 (see
Figure 3-2 on page 15).
5. If applicable, complete all customer remote monitoring system wiring interconnections using
Table 3-3 on page 14 for wiring requirements.
Figure 3-2 on page 15 shows the TB1 terminal block wiring detail.
6. When all wiring is complete, close the door and secure the latches.

Sync Control for Eaton 9395P and 93PM 12
User’s and Installation Guide
CAUTION
When connecting the bypass and load voltage from another model UPS to the Eaton
9395P UPS using the Eaton Sync Control accessory, connect all three phases from the
other UPS to the Sync Control connection point. DO NOT connect the other model UPS
Neutral to the Sync Control connection point when connecting to a Eaton 9395P UPS.
Table 3-1 Eaton 9395P UPS System Control Wiring Interconnections for Single UPS
Function
From UPS
System A
To Sync
Control
Wire Size
[mm
2
]
Voltage Note
Bypass Voltage A TB6-1 TB1-78 1,5 400Vac
Bypass Voltage B TB6-2 TB1-79 1,5 400Vac
Bypass Voltage C TB6-3 TB1-80 1,5 400Vac
Output Voltage A TB6-5 TB1-81 1,5 400Vac
Output Voltage B TB6-6 TB1-82 1,5 400Vac
Output Voltage C TB6-7 TB1-83 1,5 400Vac
Bypass Voltage A Return TB6-8 TB1-84 1,5 400Vac
Bypass Voltage B Return TB6-9 TB1-85 1,5 400Vac
Bypass Voltage C Return TB6-10 TB1-86 1,5 400Vac
Building Alarm 1(See Note)
TB3-1 TB1-54 1,5 24Vdc
Twisted pair
Building Alarm 1 Return TB3-2 TB1-55 1,5 24Vdc
On Bypass (N.O.) TB2-5 TB1-52 1,5 24Vdc Twisted pair
On Bypass Common TB2-6 TB1-51 1,5 24Vdc
Function
From UPS
System B
To Sync
Control
Wire Size
[mm
2
]
Voltage Note
Bypass Voltage A TB6-1 TB1-87 1,5 400Vac
Bypass Voltage B TB6-2 TB1-88 1,5 400Vac
Bypass Voltage C TB6-3 TB1-89 1,5 400Vac
Output Voltage A TB6-5 TB1-90 1,5 400Vac
Output Voltage B TB6-6 TB1-91 1,5 400Vac
Output Voltage C TB6-7 TB1-92 1,5 400Vac
Bypass Voltage A Return TB6-8 TB1-93 1,5 400Vac
Bypass Voltage B Return TB6-9 TB1-94 1,5 400Vac
Bypass Voltage C Return TB6-10 TB1-95 1,5 400Vac
Building Alarm 1 (1 TB3-1 TB1-56 1,5 24Vdc
Twisted pair
Building Alarm 1 Return TB3-2 TB1-57 1,5 24Vdc
On Bypass (N.O.) TB2-5 TB1-53 1,5 24Vdc
Twisted pair
On Bypass Common TB2-6 TB1-51 1,5 24Vdc
NOTE:
If Building Alarm 1 is being used for another purpose, any unused building alarm on the
UPS TB3 terminal board can be used for the Sync Control. Refer to the applicable Eaton
9395P UPS User’s and Installation Guide listed in paragraph 1.3 on page 7 for the UPS
TB3 terminal assignments.

Sync Control for Eaton 9395P and 93PM 13
User’s and Installation Guide
Table 3-2 Eaton 9395P UPS System Control Wiring Interconnections for Parallel Systems (Distributed
Bypass)
Function
From UPS
System A
To Sync
Control
Wire Size
[mm
2
]
Voltage Note
Bypass Voltage A
System A (1
Bypass Phase A
TB1-78 1,5 400Vac
Bypass Voltage B
System A (1
Bypass Phase B
TB1-79 1,5 400Vac
Bypass Voltage C
System A (1
Bypass Phase C
TB1-80 1,5 400Vac
Output Voltage A
System A (2
Output Phase A
TB1-81 1,5 400Vac
Output Voltage B
System A (2
Output Phase B
TB1-82 1,5 400Vac
Output Voltage C
System A (2
Output Phase C
TB1-83 1,5 400Vac
Bypass Voltage A Return TB6-8(3 TB1-84 1,5 400Vac
Bypass Voltage B Return TB6-9(3 TB1-85 1,5 400Vac
Bypass Voltage C Return TB6-10(3 TB1-86 1,5 400Vac
Building Alarm 1 (4 TB3-1(3 TB1-54 1,5 24Vdc
Twisted pair
Building Alarm 1 Return TB3-2(3 TB1-55 1,5 24Vdc
On Bypass (N.O.) TB2-5(3 TB1-52 1,5 24Vdc
Twisted pair
On Bypass Common TB2-6(3 TB1-51 1,5 24Vdc
Function
From UPS
System B
To Sync
Control
Wire Size
[mm
2
]
Voltage Note
Bypass Voltage A
System B (1
Bypass Phase A
TB1-87 1,5 400Vac
Bypass Voltage B
System B (1
Bypass Phase B
TB1-88 1,5 400Vac
Bypass Voltage C
System B (1
Bypass Phase C
TB1-89 1,5 400Vac
Output Voltage A
System B (2
Output Phase A
TB1-90 1,5 400Vac
Output Voltage B
System B (2
Output Phase B
TB1-91 1,5 400Vac
Output Voltage C
System B (2
Output Phase C
TB1-92 1,5 400Vac
Bypass Voltage A Return TB6-8(3 TB1-93 1,5 400Vac
Bypass Voltage B Return TB6-9(3 TB1-94 1,5 400Vac
Bypass Voltage C Return TB6-10(3 TB1-95 1,5 400Vac
Building Alarm 1 (4 TB3-1(3 TB1-56 1,5 24Vdc
Twisted pair
Building Alarm 1 Return TB3-2(3 TB1-57 1,5 24Vdc
On Bypass (N.O.) TB2-5(3 TB1-53 1,5 24Vdc
Twisted pair
On Bypass Common TB2-6(3 TB1-51 1,5 24Vdc
NOTES:
1. Voltage taken from UPS System input switchgear through N.O. aux contacts of UPS
input (bypass) feeders.
2. Voltage taken from UPS System output switchgear, system common output.
3. Connection point in each UPS of a parallel system. Signals can be daisy-chained from
one UPS to next.
4. If Building Alarm 1 is being used for another purpose, any unused building alarm on
the UPS TB3 terminal board can be used for the Sync Control. Refer to the applicable
Eaton 9395P UPS User’s and Installation Guide listed in paragraph 1.3 on page 7 for

Sync Control for Eaton 9395P and 93PM 14
User’s and Installation Guide
the UPS TB3 terminal assignments.
Table 3-3 Customer Remote Monitoring System Wiring Interconnections
Function
From Sync
Control
Wire Size
[mm2] Note
UPS System A – Active Master Source TB1-63 1,5 Twisted pair
Common Return TB1-62 1,5
UPS System B – Active Master Source TB1-64 1,5 Twisted pair
Common Return TB1-62 1,5
UPS System-A – Synchronized to Load B TB1-65 1,5 Twisted pair
Common Return TB1-62 1,5
UPS System-B – Synchronized to Load A TB1-66 1,5 Twisted pair
Common Return TB1-62 1,5
Load Sync Enabled TB1-68 1,5 Twisted pair
Common Return TB1-67 1,5
Figure 3-1 Eaton Sync Control Typical Control Wiring Termination Locations
TB1
Ground Terminal

Sync Control for Eaton 9395P and 93PM 15
User’s and Installation Guide
Figure 3-2 Eaton Sync Control TB1 Terminal Block Detail for 9395P
NOTE:
If Building Alarm 1 is being used for another purpose, any unused building alarm on the
UPS TB3 terminal board can be used for the Sync Control. Refer to the applicable Eaton
9395P UPS User’s and Installation Guide listed in paragraph 1.3 on page 7 for the UPS
TB3 terminal assignments.
On Bypass Common
UPS System-A─On Bypass NO
UPS System-B─On Bypass NO
UPS System-B─Reference Voltage Phase B
UPS System-B─Reference Voltage Phase A
UPS System-B─Reference Voltage Phase C
UPS System-A─Building Alarm 1 (See Note)
UPS System-B─Building Alarm 1 (See Note)
UPS System-A─Sync Control Alarm NO
UPS System-A─Sync Control Alarmt Return
UPS System-B─Sync Control Alarm NO
UPS System-B─Sync Control Alarm Return
Common Return
UPS System-A─Active Master Source
UPS System-B─Active Master Source
UPS System-A─Synchronized to Load B
UPS System-B─Synchronized to Load A
Common Return
Load Sync Enabled
Jumper wire
UPS System-A─Building Alarm 1 Return
UPS System-B─Building Alarm 1 Return
UPS System-B─Output Voltage Phase B
UPS System-B─Output Voltage Phase A
UPS System-B─Output Voltage Phase C
UPS System-B─Bypass Voltage Phase B
UPS System-B─Bypass Voltage Phase A
UPS System-B─Bypass Voltage Phase C
UPS System-A─Reference Voltage Phase B
UPS System-A─Reference Voltage Phase A
UPS System-A─Reference Voltage Phase C
UPS System-A─Output Voltage Phase B
UPS System-A─Output Voltage Phase A
UPS System-A─Output Voltage Phase C
UPS System-A─Bypass Voltage Phase B
UPS System-A─Bypass Voltage Phase A
UPS System-A─Bypass Voltage Phase C
UPS System-A─Bypass Available (Option)
UPS System-B─Bypass Available (Option)

Sync Control for Eaton 9395P and 93PM 16
User’s and Installation Guide
Figure 3-3 Eaton 9395P UPS TB6 Terminal Block Detail
Figure 3-4 Eaton 9395P UPS (500–600 kVA) Interface Locations for Eaton Sync Control

Sync Control for Eaton 9395P and 93PM 17
User’s and Installation Guide
NOTES:
•
The bypass phase A, B and C voltage from the system input switchgear is connected to the Eaton Sync Control.
•
All signal wires must be protected by appropriate fuses. The fuse rating shall be 5A slow blow.
•
The output voltage phase A, B and C are connected to the Eaton Sync Control from the system output switchgear.
•
The circuit diagram above shows the interconnecting signal wiring between UPSs in the Eaton 93PM Parallel UPS system.
•
Contact your local Eaton representative for further information before planning the installation.
Figure 3-5 Eaton Sync Control Wiring Diagram with a Parallel 9395P UPS System

Sync Control for Eaton 9395P and 93PM 18
User’s and Installation Guide
3.2 Installation and Wiring with an Eaton 93PM UPS
To install and wire:
7. Install the Eaton Sync Control panel to the selected mounting location.
See Figure 2-1 on page 9 for mounting hole dimensions and Figure 2-2 on page 9 for cable
entrance locations.
8. Unfasten the front door latches and swing the door open.
9. Complete all control wiring interconnections using Table 3-4 on page 19 or Table 3-5 on page
20 for wiring requirements.Figure 3-6 on page 21 shows the Eaton Sync Control TB1
terminal block and ground terminal locations. Figure 3-7 on page 22 shows the TB1 terminal
block wiring detail.
Figure 3-8 on page 23 shows the sync control interface of the 93PM. Figure 3-9 on page 23
shows the typical locations of the UPS Inputs, Outputs and X11 terminal blocks. Figure 3-10
on page 24 shows the X11 detail.
Refer to the applicable Eaton 93PM UPS Installation and Operation Manual for UPS cabinet
terminal locations and assignments, termination requirements, cable landing locations, and
terminal access instructions.
10. Verify the jumper is installed between Eaton Sync Control terminal TB1-72 and TB1-73 (see
Figure 3-7 on page 22).
11. If applicable, complete all customer remote monitoring system wiring interconnections using
Table 3-6 on page 21 for wiring requirements.
Figure 3-7 on page 22 shows the TB1 terminal block wiring detail.
12. When all wiring is complete, close the door and secure the latches.

Sync Control for Eaton 9395P and 93PM 19
User’s and Installation Guide
CAUTION
When connecting the bypass and load voltage from another model UPS to the Eaton
93PM UPS using the Eaton Sync Control accessory, connect all three phases from the
other UPS to the Sync Control connection point.
Table 3-4 Eaton 93PM UPS System Control Wiring Interconnections for Single UPS
Function
From UPS
System A
To Sync
Control
Wire Size
[mm2] Voltage Note
Bypass Voltage A X11-1 TB1-78 1,5 400Vac
Bypass Voltage B X11-2 TB1-79 1,5 400Vac
Bypass Voltage C X11-3 TB1-80 1,5 400Vac
Output Voltage A X11-4 TB1-81 1,5 400Vac
Output Voltage B X11-5 TB1-82 1,5 400Vac
Output Voltage C X11-6 TB1-83 1,5 400Vac
Bypass Voltage A Return X11-8 TB1-84 1,5 400Vac
Bypass Voltage B Return X11-9 TB1-85 1,5 400Vac
Bypass Voltage C Return X11-10 TB1-86 1,5 400Vac
Building Alarm 1(See Note) Input1 pin10 TB1-54 1,5 24Vdc
Twisted pair
Building Alarm 1 Return Input1 pin9 TB1-55 1,5 24Vdc
On Bypass (N.O.) Output pin2 TB1-52 1,5 24Vdc
Twisted pair
On Bypass Common Output pin3 TB1-51 1,5 24Vdc
Function
From UPS
System B
To Sync
Control
Wire Size
[mm
2
]
Voltage Note
Bypass Voltage A X11-1 TB1-87 1,5 400Vac
Bypass Voltage B X11-2 TB1-88 1,5 400Vac
Bypass Voltage C X11-3 TB1-89 1,5 400Vac
Output Voltage A X11-4 TB1-90 1,5 400Vac
Output Voltage B X11-5 TB1-91 1,5 400Vac
Output Voltage C X11-6 TB1-92 1,5 400Vac
Bypass Voltage A Return X11-8 TB1-93 1,5 400Vac
Bypass Voltage B Return X11-9 TB1-94 1,5 400Vac
Bypass Voltage C Return X11-10 TB1-95 1,5 400Vac
Building Alarm 1 (1 Input1 pin10 TB1-56 1,5 24Vdc
Twisted pair
Building Alarm 1 Return Input1 pin9 TB1-57 1,5 24Vdc
On Bypass (N.O.) Output pin2 TB1-53 1,5 24Vdc
Twisted pair
On Bypass Common Output pin3 TB1-51 1,5 24Vdc
NOTE:
If Building Alarm 1 is being used for another purpose, any unused building alarm on the
UPS Signal inputs can be used for the Sync Control. Refer to the applicable Eaton 93PM
UPS User’s and Installation Guide for the UPS Signal Inputs.

Sync Control for Eaton 9395P and 93PM 20
User’s and Installation Guide
Table 3-5 Eaton 93PM UPS System Control Wiring Interconnections for Parallel Systems (Distributed
Bypass)
Function
From UPS
System A
To Sync
Control
Wire Size
[mm
2
]
Voltage Note
Bypass Voltage A
System A (1
Bypass Phase A
TB1-78 1,5 400Vac
Bypass Voltage B
System A (1
Bypass Phase B
TB1-79 1,5 400Vac
Bypass Voltage C
System A (1
Bypass Phase C
TB1-80 1,5 400Vac
Output Voltage A
System A (2
Output Phase A
TB1-81 1,5 400Vac
Output Voltage B
System A (2
Output Phase B
TB1-82 1,5 400Vac
Output Voltage C
System A (2
Output Phase C
TB1-83 1,5 400Vac
Bypass Voltage A Return X11-8(3 TB1-84 1,5 400Vac
Bypass Voltage B Return X11-9(3 TB1-85 1,5 400Vac
Bypass Voltage C Return X11-10(3 TB1-86 1,5 400Vac
Building Alarm 1 (4 Input1 pin10(3 TB1-54 1,5 24Vdc
Twisted pair
Building Alarm 1 Return Input1 pin9(3 TB1-55 1,5 24Vdc
On Bypass (N.O.) Output pin2(3 TB1-52 1,5 24Vdc
Twisted pair
On Bypass Common Output pin3(3 TB1-51 1,5 24Vdc
Function
From UPS
System B
To Sync
Control
Wire Size
[mm
2
]
Voltage Note
Bypass Voltage A
System B (1
Bypass Phase A
TB1-87 1,5 400Vac
Bypass Voltage B
System B (1
Bypass Phase B
TB1-88 1,5 400Vac
Bypass Voltage C
System B (1
Bypass Phase C
TB1-89 1,5 400Vac
Output Voltage A
System B (2
Output Phase A
TB1-90 1,5 400Vac
Output Voltage B
System B (2
Output Phase B
TB1-91 1,5 400Vac
Output Voltage C
System B (2
Output Phase C
TB1-92 1,5 400Vac
Bypass Voltage A Return X11-8(3 TB1-93 1,5 400Vac
Bypass Voltage B Return X11-9(3 TB1-94 1,5 400Vac
Bypass Voltage C Return X11-10(3 TB1-95 1,5 400Vac
Building Alarm 1 (4 Input1 pin10(3 TB1-56 1,5 24Vdc
Twisted pair
Building Alarm 1 Return Input1 pin9(3 TB1-57 1,5 24Vdc
On Bypass (N.O.) Output pin2(3 TB1-53 1,5 24Vdc
Twisted pair
On Bypass Common Output pin3(3 TB1-51 1,5 24Vdc
NOTES:
1. Voltage taken from UPS System input switchgear through N.O. aux contacts of UPS
input (bypass) feeders.
2. Voltage taken from UPS System output switchgear, system common output.
3. Connection point in each UPS of a parallel system. Signals can be daisy-chained from
one UPS to next.
4. If Building Alarm 1 is being used for another purpose, any unused building alarm on
the UPS Signal Inputs can be used for the Sync Control. Refer to the applicable Eaton
93PM UPS User’s and Installation Guide for the UPS Signal Inputs.
