SPECIFICATIONS MM80
FEATURES
• Multi-enclosure, dual-channel extended range
multimedia system
• 2x JF80 full range satellites plus 2x SB150
subwoofers
• Per JF80: 2x 6.5-in LF/1-in exit HF on Wave Guide
Plate™
• Per SB120: 15-in LF/internal passive crossover/filter
network
• Switchable powering: full range passive or bi-amp
(passive MF/HF)
• For portable use or permanent installation
DESCRIPTION
A 2-channel 3-way extended range system combining 2x JF80
2-way full range systems and 2x SB150ixR subwoofers. Each
JF80 includes 2x 6.5-in woofer (vented), a 1-in exit/1.75-in
voice coil compression driver on a Wave Guide Plate™ and a
passive LF/HF crossover. Each SB150ixR includes a 15-in
woofer in a vented enclosure and a passive sub/fullrange
crossover. Powering is switchable: passive (3-way crossover)
or bi-amplified (active sub/full range with passive LF/HF
crossover).
APPLICATIONS
The MM80 delivers extended range output at surprisingly high
levels with flat response. Simple to set up and power with
each subwoofer housing an internal passive crossover/filter
network. Switch allows choice of passive or biamp powering.
Despite the small size, an MM80 can fill medium sized ven-
ues with high definition, extended range sound. Six year
warranty.
Applications include:
Band PA MultiMedia
Ballroom Events Boardrooms
PHYSICAL
Subwoofer
Subsystem 1x 15-in, vented (per SB150)
LF Subsystem 2x 6.5-in, vented (per JF80)
HF Subsystem 1x 1-in exit/1.75 voice coil
compression driver on WGP
Waveguide (per JF80)
Configuration 2 channel, 3-way, extended range,
4 enclosures
Powering Switchable: extended range
(passive sub/LF/HF crossover) or
bi-amplified (passive LF/HF
crossover)
Controls (switches, knobs) Powering mode switch (per sub)
Biamplified Crossover 100 Hz
Cabinet Type (shape) Trapezoidal (JF80)
Rectangular (SB150)
Enclosure Materials Baltic birch plywood
Finish Black catalyzed polyurethane
Connectors Per SB150ixR: 3x Neutrik NL4
Speakon (1 input, 1 loop-through,
1 output to JF80)
Per JF80: 2x Neutrik NL4 Speakon
Suspension Hardware JF80: (6) 1/4”-20 threaded points
(1 each top and bottom, 4 on back
for Omnimount Series 100), (2)
5/16”-18 threaded points for
external stand mount adapter.
Grille Vinyl coated perforated steel
Mounting Bracket JF80 980002 wallmount bracket
Shown as one channel of an MM80 package.
PERFORMANCE
(data reflect per channel, passive crossover mode performance)
Frequency Response (1 Watt @ 1m)
±3 db 43 Hz to 19 kHz
-10 dB 32 Hz
Axial Sensitivity (dB SPL, 1 Watt @ 1m)
Extended Range 94
Impedance (Ohms)
Extended Range 8
Power Handling, AES Standard (Watts)
Extended Range 500
Calculated Maximum Output (dB SPL @ 1m)
Extended Range Peak 127.0
Extended Range Long Term 121.0
Special
Biamped Performance See JF80 and SB150 Datasheets
Nominal Coverage Angle, -6 dB Points (degrees)
Horizontal 100
Vertical 80
Recommended High-Pass Frequency
24 dB/Octave 25 Hz
