AC6 Stacking Plate Instructions
These instructions are to provide a detailed step by step procedure for using the AC6
Stacking Plates.
Inventory your kit
Part # Part Name Quantity Reference
2071927-9999 PLATE LOCKING ASSY 1 A
2071924 M5X20 FLH SKT SS BLK - Use w/Reference A 3 per assembly B
2071924 M5X20 FLH SKT SS BLK 4 per plate B
2071918-9999 Slide Plate 2 C
2071929-9999 MOUNT PLATE ASSY AC6 1 D
2071920 SCREW M20X40 HHCS SS BLK OX 1 E
2071922 WASHER CURVED LOCK M20X34mm 1 F
2071923 WASHER FLAT M20 X 60mm OD SS BLK OX 1 G
0022095 SCREW M6 X 55 SHCS BLK 4 per assembly H
105059 WASHER SPLIT-LOCK M6 SS BLK 4 per assembly I
2071921 WASHER FLAT M6 X18mm OD SS BLK OX 4 per assembly J
D
C
A
B E H
IF
G J

Tel [phone] | www.eaw.com 2
AC6 Stacking Plate Instructions
• M3 Allen Wrench
• M4 Allen Wrench
• 30mm Wrench
Required Tools & Supplies
Prepare AC6 for Stacking
1. Attach Locking Plate (A) to the top of the rst AC6 (If using with subwoofer mount
plate, follow instructions in step 2 to attach slide plate to bottom of rst AC6)
• Remove 3x M5x12mm screws from top of AC6 (Figure 1).
• Position Locking Plate over open holes, then use screws (B) to secure plate to
the cabinet (Figure 2)
Figure 3 - Remove screws Figure 4 - Install Slide Plate
2. Attach slide plate (C) to bottom of next AC6
• Remove 4x M5x12mm screws from bottom of AC6 (Figure 3).
• Position Slide Plate over open holes, then use screws (B) to secure plate to the
cabinet (Figure 4)
Figure 1 - Remove screws Figure 2 - Install Locking Plate

Tel [phone] | www.eaw.com 3
AC6 Stacking Plate Instructions
Prepare Subwoofer Mount Plate for Stacking (if applicable)
3. Attach Mount Plate (D) to the top of SBX218/SBX118/RSX18F (Figure 5)
• Remove M6x35mm screws from subwoofer pole mount.
• Place Mount Plate on top of subwoofer, aligning hole Awith pole cup.
• Lock into place with M6 screws (H), lock washer (I) and at washer (J)
• Secure mount with M20 Screw (E), lock washer (F) and at washer (G)
Figure 5 - Attach Mount Plate Figure 6 -Mount Plate installed
Congure AC6 Column on Subwoofer Mount Plate
4. Attach rst AC6 to Subwoofer with mount plate
• Using two people, lift AC6 and line up bottom slide plate with subwoofer
mount plate
• Slide into place (Figure 7). An audible clicking sound may be heard if pins are
not in up position.
• On rear of mount plate, rotate both pin knobs clockwise to lock into position.
Figure 7 - Slide rst AC6 to
mount plate
Figure 8 -AC6 Installed on mount
plate

Tel [phone] | www.eaw.com 4
AC6 Stacking Plate Instructions
Connect two AC6 Column loudspeakers with stacking plates
5. Attach two AC6 columns (Procedure is the same whether using Subwoofer
Mounting Plate or not)
• Ensure rst AC6 (bottom position) is standing at on a surface or locked into
place with the subwoofer mounting plate.
• If connecting a second AC6 on a subwoofer stack, using two steady ladders
and two people, lift second AC6 and line up slide plate with the rst AC6
locking plate.
• If connecting the second AC6 to rst AC6 without utilizing the subwoofer
mount plate, a ladder may not be needed. Still using two people, position
second AC6 slide plate to line up with rst AC6 locking plate.
• Slowly slide into plate until an audible click is heard. (Figure 9)
• On rear of rst AC6 locking plate, rotate both screw knobs clockwise to lock
into position.
• When using subwoofer mounting plate, only two AC6's are supported.
Figure 9 - Attach AC6 columns
