EAW MQ2364e User guide

EASTERN ACOUSTICWORKS
(1.95)
50.10
6.37
DIMENSIONS APPLY TO
BOTH SIDES
54.00
GRILL PARTIALLY SHOWN
FRONT
MQ2364e
L
C
13.00
12.16
50°
23.28
32.00
(8.12)
TOP
DIMENSIONS APPLY TO
TOP AND BOTTOM
25.61
5.00 A
11.91
A
C
L
48.93
5.00
INPUT
4.00
25.88
PRODUCTION
VIEW A-A BACK 2.54
27.00
L
C
NOTES:
1. SYMBOL INDICATES MOUNTING POINT,
3/8-16 THREADED HOLE (PI ANGLE).
2. SYMBOL INDICATES NON LOAD BEARING MOUNTING POINT,
3/8-16 THREADED HOLE (PI ANGLE).
3. SYMBOL INDICATES CENTER OF BALANCE.
4. WEIGHT APPROX. 217 LBS.
5. SHIPPING WEIGHT APPROX. 241 LBS.
13.15
