EAW SM12R 2D Guide

.59
6.96
15.89
R 17.93
HANDLE
DIMENSIONS APPLY TO
BOTH SIDES
RIGHT SIDE
GRILLE PARTIALLY SHOWN
26.04
FRONT
NOTES:
1. SYMBOL INDICATES CENTER OF BALANCE.
2. WEIGHT APPROX. 60 LBS.
3. SHIPPING WEIGHT APPROX. 68 LBS.
INPUT
3.00
.73
4.00
4.00
PRODUCTION
SM12R
EASTERN ACOUSTIC WORKS
4.75
12.75
.59
8.61
13.50
BACK
