Ecco EW3000 User manual

Installation and Operation Instructions
REMOTE SPOTLIGHT
ECCO’s EW3000 Series Remote Spotlights are multifunc-
tional, motorized searchlights featuring a 12-24 VDC op-
eration. Both spotlights can be installed wirelessly and are
protected by a polycarbonate lens and the housings are
available in black or white.
The EW3000/3001 offers 360-degree rotation and a 90
degree tilt range, while the EW3010/3011 offers full,
continuous rotation, a 135-degree tilt range and features
an optional hardwired in-dash joystick controller. The
EW3010/3011 spotlight also has a home setting that
automatically returns the light to its original position upon
powering off the device.
Page 1 of 4
Specications:
Input Voltage: 12-24V
Current Draw: 1.7 Amps (peak)
Power: 23.2 Watts (max)
IMPORTANT! Read all instructions before installing and using. Installer: This manual must be
delivered to the end user.
Do not install and/or operate this safety product unless you have read and understand the safety
information contained in this manual.
1. Proper installation combined with operator training in the installation, use, care and maintenance of vehicle equipment accessories is
essential to ensure the safety of you and those you are trying to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including re.
4. Proper placement and installation are vital to the performance of this worklamp. Install this product so that output
performance of the system is maximized and the controls are placed within convenient reach of the operator so that s/he can
operate the system without losing eye contact with the work area.
5. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use, the
vehicle operator should ensure the projection of the beam is not blocked by vehicle components (i.e., open trunks
or compartment doors), people, vehicles, or other obstructions.
6. The manufacturer assumes no liability for any loss resulting from the use of this device.
WARNING!
Failure to install or use this product according to manufacturer’s recommendations may result in property
damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect! Check wattage
before installing light to avoid possible equipment damage.
!

Installation & Mounting:
Caution! When drilling into any vehicle surface, make sure that the area is free from any electrical wires, fuel lines,
vehicle upholstery, etc. that could be damaged.
!
Permanent Mounting:
1. Select a level surface for installation.
2. Drill mounting holes using the base as a template and attach with included hardware.
Page 2 of 4
Carefully remove the unit from its packaging. Examine the unit for transit damage. If damage is found, return the product to your local dealer for
warranty replacement. Do not use damaged or broken parts.
Important! Disable power before wiring the spotlight.
Wiring:
EW300X
Notes:
1. Larger wires and tight connections will provide longer service life for components. For high current wires, it is recommended that
terminal blocks or soldered connections be used with shrink tubing to protect the connections. Do not use insulation displacement
connectors (e.g.,3M Scotchlock type connectors).
2. Route wiring using grommets and sealant when passing through compartment walls. Minimize the number of splices to reduce
voltage drop. High ambient temperatures (e.g., under-hood) will signicantly reduce the current carrying capacity of wires, fuses and
circuit breakers. All wiring should conform to the minimum wire size and other recommendations of the manufacterer and be
protected from moving parts and hot surfaces. Looms, grommets, cable ties and similar installation hardware should be used to
anchor and protect all wiring.
3. Fuses or circuit breakers should be located as close to the power takeoff points as possible and properly sized to protect the wiring
and devices.
4. Particular attention should be paid to the location and method of making electrical connections and splices to protect these points from
corrosion and loss of conductivity.
5. Ground termination should be only made to substantial chassis components, preferably directly to the vehicle battery.
6. Circuit breakers are very sensitive to high temperatures and will “false trip” when mounted in hot environments or operated close to
their capacity.
The wiring for this conguration is as shown in the gure below. All wiring should be a minimum of 18AWG. The positive line must have a 5 amp
fuse, as shown. Routing the ground wire directly back to negative battery terminal is recommended. Pack dielectric grease, such as Dow Corning 4,
around each electric connection exposed to moisture or the ambient environment.
EW301X
GROUND 5 AMP FUSE
BLACK WIRE
RED WIRE

Remote Control Operation:
To program the wireless remote:
1. Power off the spotlight. Ensure there is no transmitter operating within 10 feet.
2. Power on the spotlight, then press the ▲ and down ▼ buttons on the remote at the same time. To program a second remote, press the
up ▲ and down ▼ buttons on the second remote within ve seconds.
3. The spotlight will ash when the remote has been successfully programmed.
Joystick Control Operation:
Page 3 of 4
ON/OFF TOGGLE
SWITCH
SPEED
TOGGLE
SWITCH
LIGHT BEAM
DIRECTION
SWITCH
LIGHT BEAM
DIRECTION OPERATION
EW300X: STROBE ON/OFF
EW301X: SPEED FAST/SLOW
ON/OFF
BUTTON

920-9914-00 Rev. C Page 4 of 4
Manufacturer Limited Warranty and Limitation of Liability:
Manufacturer warrants that on the date of purchase, this product will conform to Manufacturer’s specications for this product (which are avail-
able from the Manufacturer upon request). This Limited Warranty extends for Thirty-Six (36) months from the date of purchase.
DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICA-
TIONS, FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAINTAINED IN ACCORDANCE WITH THE MAIN-
TENANCE PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND OPERATING INSTRUCTIONS VOIDS THIS LIMITED WARRANTY.
Exclusion of Other Warranties:
MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESSED OR IMPLIED. THE IMPLIED WARRANTIES FOR MERCHANTABILITY, QUALITY
OR FITNESS FOR A PARTICULAR PURPOSE, OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE ARE HEREBY EXCLUD-
ED AND SHALL NOT APPLY TO THE PRODUCT AND ARE HEREBY DISCLAIMED, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW.
ORAL STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT DO NOT CONSTITUTE WARRANTIES.
Remedies and Limitation of Liability:
MANUFACTURER’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDY IN CONTRACT, TORT (INCLUDING NEGLIGENCE), OR UNDER ANY
OTHER THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE, AT MANUFACTURER’S DISCRETION, THE
REPLACEMENT OR REPAIR OF THE PRODUCT, OR THE REFUND OF THE PURCHASE PRICE PAID BY BUYER FOR NON-CONFORMING PROD-
UCT. IN NO EVENT SHALL MANUFACTURER’S LIABILITY ARISING OUT OF THIS LIMITED WARRANTY OR ANY OTHER CLAIM RELATED TO THE
MANUFACTURER’S PRODUCTS EXCEED THE AMOUNT PAID FOR THE PRODUCT BY BUYER AT THE TIME OF THE ORIGINAL PURCHASE. IN NO
EVENT SHALL MANUFACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR, PROPERTY DAMAGE, OR
OTHER SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF CONTRACT, IMPROPER INSTAL-
LATION, NEGLIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRESENTATIVE HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER OBLIGATION OR LIABILITY WITH RESPECT TO THE PRODUCT
OR ITS SALE, OPERATION AND USE, AND MANUFACTURER NEITHER ASSUMES NOR AUTHORIZES THE ASSUMPTION OF ANY OTHER OBLIGA-
TION OR LIABILITY IN CONNECTION WITH SUCH PRODUCT.
This Limited Warranty denes specic legal rights. You may have other legal rights which vary from jurisdiction to jurisdiction. Some jurisdictions
do not allow the exclusion or limitation of incidental or consequential damages.
833 West Diamond St
Boise, Idaho 83705
Customer Service
USA 800-635-5900
UK [phone]
AUS [phone]
www.eccoesg.com
Replacement Parts and Accessories:
Description Part No.
Replacement Remote (For use with EW3000/01/10/11 ER3010
Flood Diffuser (For use with EW3010/11) EZ3010F
Colored Lens (For use with EW3010/11) EZ3010X*
In-Dash Joystick Controller (For use with EW3010/11) EZ3011
5 Meter Joystick Cable (For use with EZ3011) EZ3012
5 Meter Joystick Cable Extension (For use with EZ3011) EZ3013
Magnet Mount Kit, Black (For use with EW3000) EZ3014
Magnet Mount Kit, White (For use with EW3001) EZ3015
Magnet Mount Kit, White (For use with EW3011) EZ3016
Magnet Mount Kit, Black (For use with EW3010) EZ3017
Where X* indicates color: A=Amber, R=Red and G-Green
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
