Eccotemp L5 User manual

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
English L5
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
FOR YOUR RECORDS
Write the model and serial numbers here:
#_______________________________
#_______________________________
You can nd them on a label on the appliance
and/or packaging.
Staple sales slip or canceled check here.
Proof of the original purchase date is needed to
obtain service under the warranty.
READ THIS MANUAL
Inside you will nd many helpful hints on how to
use and maintain your water heater properly. A
little preventive care on your part can save you
time and money over the life of your water heater.
You’ll nd many answers to common problems in
the Troubleshooting Guide. If you review the chart
of Troubleshooting Tips rst you may not need to
call for service.
READ THE SAFETY INFORMATION
Your safety and the safety of others are very
important. There are many important safety
messages in this manual and on your water
heater. Always read and obey all safety messages.
This is the safety alert symbol. Recognize
this symbol as an indication of Important Safety
Information! This symbol alerts you
to potential hazards that can kill or hurt
you and others.
All safety messages will follow the safety alert
symbol and the words: “DANGER”, “WARNING”,
“CAUTION” or “NOTICE”.
These words mean:
DANGER - An imminently hazardous situation
that will result in death or serious injury.
WARNING - A potentially hazardous situation
that could result in death or serious injury
and/or damage to property.
CAUTION - A potentially hazardous situation
that may result in minor or moderate injury.
NOTICE: Attention is called to observe
a specied procedure or maintain a
specic condition.
Congratulations!
You’ve just purchased a new
Eccotemp L5 portable tankless
water heater. This will open a
world of enjoyment to going
tankless!
We highly suggest you take the
time to read through all of the
safety and installation procedures
in this manual, before attempting
to install your new water heater.
Should you have any questions,
please feel free to visit our
helpdesk located at
www.eccotemp.com for further
information.
General Safety ........................... 3-5
Features and Benets ............ 6-7
Care and Maintenance ......... 8-9
Getting Started ............................ 10
Use and Starting .................. 11-12
Troubleshooting Guide ...... 13-14
Product Comparison ............... 15
Warranty Information .............. 16

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
3
L5 English
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
IMPORTANT SAFETY INFORMATION READ ALL
INSTRUCTIONS BEFORE USING
Be sure to read and understand the entire Use and Care Manual before attempting to install or
operate this water heater. It may save you time and money. Pay particular attention to the Safety
Instructions. Failure to follow these warnings could result in serious bodily injury or death. Should
you have problems understanding the instructions in this manual, or have any questions, STOP,
and get help from a qualied service technician, or the local gas utility.
DANGER!
PROPERLY INSTALL WATER HEATER
Failure to properly install the water heater outdoors as outlined in the Installation
Instructions in this manual can result in unsafe operation of the water heater. To
avoid the risk of re, explosion, or asphyxiation from carbon monoxide, never
operate this water heater unless it is installed properly and has an adequate
air supply for proper operation. Be sure to inspect the ue terminal for proper
installation at initial start-up; and at least annually thereafter. Refer to the Care
and Cleaning section of this manual for more information regarding ue terminal
inspection.
WARNING!
Gasoline, as well as other ammable materials and liquids (adhesives, solvents,
paint thinners etc.), and the vapors they produce are extremely dangerous. DO NOT
handle, use or store gasoline or other ammable or combustible materials any where
near or in the vicinity of a water heater or any other appliance. Be sure to read and
follow the labels on the water heater, as well as the warnings printed in this manual.
Failure to do so can result in property damage, bodily injury or death.
Vapors from ammable
liquids will explode and catch re
causing death or severe burns.
Do not use or store ammable products
such as gasoline, solvents or adhesives
In the same room or area near the
water heater.
Keep ammable products :
1. Far away from heater
2. In approved containers
3. Tightly closed
4. Out of children‘s reach
Water heater has a main burner ame.
The main burner ame
1. Can come on at any time and
2. Will ignite ammable vapors.
Vapors:
1. Cannot be seen
2. Are heavier than air
3. Go a long way on the oor
4. Can be carried from other rooms to
the main burner ame by air currents.
Installation:
Do not Install water heater where ammable products will be stored or used
unless the main burner ame Is at least 18” above the oor. This will reduce, but
not eliminate, the risk of vapors being ignited by the main burner ame.
Read and follow water heater warnings and Instructions. If owners manual is
missing, contact the retailer or manufacturer.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
4
English L5
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
DANGER!
NATURAL GAS AND LIQUEFIED PETROLEUM MODELS
Both liquid propane and natural gas have an odorant added to aid in detecting
a gas leak. Some people may not physically be able to smell or recognize this
odorant. If you are unsure or unfamiliar with the smell of liquid propane or natural
gas, ask the gas supplier. Other conditions, such as “odorant fade”, which causes
the odorant to diminish in intensity, can also hide or camouage a gas leak. Always
check with commercial leak detector or soapy water.
• Gas detectors are recommended in liquid propane and natural gas applications
and their installation should be in accordance with the detector manufacturer’s
recommendations and/or local laws, rules, regulations or customs.
• Water heaters utilizing liquid propane gas are dierent from natural gas models.
A natural gas water heater will not function safely on liquid propane gas and
vice versa.
• No attempt should ever be made to convert the water heater from natural gas
to liquid propane gas. To avoid possible equipment damage, personal injury or
re, do not connect the water heater to a fuel type not in accordance with the
portable tankless water heater data plate; propane for propane portable tankless
water heaters and natural gas for natural gas portable tankless water heaters.
These portable tankless water heaters are not certied for any other fuel type.
• Liquid propane appliances should not be installed below grade (for example, in
a basement) if such installation is prohibited by federal, state and/or local laws,
rules, regulations or customs.
• Propane or liquid propane gas must be used with great caution. It is heavier
than air and will collect rst in lower areas making it hard to detect at nose
level.
• Before attempting to light the water heater, make sure to look and smell for
gas leaks. Use a soapy solution to check all gas ttings and connections.
Bubbling at a connection indicates a leak that must be corrected. When smelling
to detect a gas leak, be sure to sni near the oor also.
• It is recommended that more than one method, such as soapy solution, gas
detectors, etc., be used to detect leaks in gas applications.
Notice: If a gas leak is present or suspected:
• DO NOT attempt to nd the cause yourself.
• DO NOT try to light the water heater.
• DO NOT touch any electrical switch.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
5
L5 English
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
ADDITIONAL WARNINGS
1. Do not leave unattended.
2. The exhaust gas and top of the portable tankless
water heater is HOT! Do not place hands or any
foreign object near the top of the heater.
3. Do not use in high wind conditions.
4. If the smell of gas is detected, turn o the gas
valve at the tank immediately! Do not use ame for
leak detection.
5. Use only Liquid Propane.
6. Use only outdoors.
7. Do not over tighten the gas regulator
connection to the portable tankless water heater
with a wrench. This may cause a crack in the gas
regulator.
The Eccotemp L5 is a portable liquid propane red water heater capable of delivering 1 to 1.4
gallons of hot water almost anywhere. The portable tankless water heater has standard 1/2”
NPT pipe ttings and an adapter for using a standard garden hose for inlet water supply.
The L5 is not a toy. People around the world use similar portable tankless water heaters to
heat water for recreation use, safely, and reliably.
Gas is recommended to be supplied from a standard 20 pound propane cylinder (not
included) such as used with outdoor grills. A regulator with hose is included with the heater.
A shower nozzle with on/o switch and multiple spray patterns is included.
Ignition is automatic and powered by 2 “D” cell batteries (not included). Burners come on
when water ows, and o when the water is shut o. No pilot light!
There is an automatic 20 minute shuto timer as an additional safety feature. This timer is
reset each time operation stops or the shower head is turned o and then back on.
Ideal operating use with water pressure between 20-80 PSI.
The Purpose and Benets the L5

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
6
English L5
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
Functions and Features
• Water controlled automatic ignition: Water pressure between 20-80 PSI and 0.75-1.0 GPM
opens the ignition circuit for easy and convenient operation.
• Auto-cut-o protection: The auto-cut-o protection will shut the gas supply o immediately
in the event of ameout to reduce the risk of gas leakage.
• Removable drain valve to avoid water pipe and regulator damage caused by freezing water*.
• Anti-dry combustion protection: The portable tankless water heater will shut o the gas
supply in the event water stops owing through the portable tankless water heater.
*Read the maintenance section on draining the portable tankless water heater entirely to avoid
freeze related issues.
Fuel Type
Model
Activation Flow Rate
BTU/h
Related gas pressure
Ignition
Protections
Dimensions
Pipe ttings
LPG (Liquid propane gas)
L5
25 PSI
35,000
0.4 PSI
Electric Pulse, D cell Battery Powered
(No electrical connection required)
Auto-cut o water control, automatic ignition, anti-dry
combustion
protection, over-pressure overheating and ameout
protection
11.5” x 17.0” x 4.7”
1/2” NPT, incoming/outgoing water & gas
TECHNICAL SPECIFICATIONS - PORTABLE
Gas Setting
Highest
Lowest
TEMPERATURE INCREASE PER GPM
MODEL
L5
Portable
0.5 GPM
96 °
34 °
1.0 GPM
48 °
17 °
1.5 GPM
32 °
11 °
2.0 GPM
25 °
9 °
*Temperature increases listed are based on use of the water heater under optimal conditions.
Variable factors such as incorrect or imperfect installations and varying incoming water
temperatures may yield dierent results.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
7
L5 English
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
Construction and parts of the L5

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
8
English L5
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
Properly maintained, your water heater will provide years of dependable
trouble-free service. It is recommended that a periodic inspection of the
burner, water lter and top exhaust should be made by service personnel
qualied in gas appliance repair.
It is suggested that a routine preventive maintenance program be
established and followed by the user.
Inspect the area around the water heater to ensure a safe operating
environment. Keep water heater area clear and free from combustible
materials, gasoline, and other ammable vapors and liquids. Ensure the unit
has not been damaged. If damage or denting is present, contact a service
personnel to verify proper operation.
Check for any abnormal sounds during normal operation of the water heater.
All piping should be checked for gas and/or water leaks. Refer to page 4 of
this manual for instructions on leak testing.
The air intake and cold water supply lters should be cleaned monthly.
Refer to the “Housekeeping” section for
further information.
DO NOT operate the water heater if you feel something is wrong with the unit.
DO NOT allow children to operate or otherwise handle the unit.
DANGER: Before
disconnecting the
water supply, make
certain no one will
be exposed to the
danger of the hot
water released by
disconnecting. The
water may be hot
enough to create a
scald hazard. The
water should be
released into a
suitable drain to
prevent injury or
property damage.
DANGER: Hotter
water increases the
potential for hot
water scalds.
DANGER: Failure
to perform the
recommended
routine preventative
maintenance can
harm the proper
operation of this
water heater, which
can cause carbon
monoxide dangers,
excessive hot water
temperatures and
other potentially
hazardous conditions.
6 MONTH CLEANING ROUTINE
To prevent water scale, lime or rust deposit buildup and ensure
your Eccotemp tankless water heater is running as eciently as
possible it is highly recommended that you clean your Eccotemp
tankless water heater every 6 months. To do this we recommend
that you use our Eccotemp EZ-Flush System Descaler Kit. For more
information and to purchase please visit us at www.eccotemp.com
or call 1-866-356-1992.
Care and Maintenance

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
9
L5 English
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
Before performing any Housekeeping tasks to this water heater, be sure to turn the unit o and
disconnect the water supply.
Vacuum around the water heater for dust, dirt and lint on a regular basis. Clean the water heater and
front panel by using a damp soft cloth with a few drops of mild detergent and gently wiping the
surfaces of the unit. Wipe any remaining moisture with a dry soft cloth.
To ensure sucient ventilation and combustion air supply, proper clearances must be maintained. The
water lters should be cleaned on a monthly basis.
STORAGE
When not in use your portable tankless water heater should be stored away in a climate controlled
area. WARNING: Item should not be left or stored in freezing conditions. Internal damage can occur.
Upon completion of use prepare your water heater for storage.
1. Turn OFF water and gas supply and then disconnect from water heater.
2. Open the drain valve (ribbed cylindrical stem next to the water input valve) to ensure draining of water.
3. Remove the lter at the end of the water inlet pipe and clean. Return lter after cleaning. (see
Housekeeping section above for instructions)
4. Store water heater in a climate controlled area.
HOW TO CLEAN THE WATER FILTER:
1. Make sure the unit is OFF
2. Disconnect the water supply from the water heater.
3. Locate the lter at the end of the water inlet pipe and gently remove
with a screw driver.
4. Rinse the lter in a sink or with a hose to remove any debris.
5. Return the lter by gently inserting back into the end of the water inlet pipe.
6. Reconnect the water supply and turn ON the water heater.
Housekeeping

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
10
English L5
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
Getting Started
1. Check box for damage. Damages caused in shipment must be reported immediately.
2. Make sure you have all the parts:
Please note: included parts and accessories may vary depending on country and regulations.
All accessories come with a 30 day manufacturers warranty
3. If the vent shield is included in your model, attach the vent shield securely to the top of your
portable tankless water heater by sliding the shield into the designated slots.
4. If using a standard garden hose, attach the 1/2” NPT to garden hose adapter to the tting marked
‘Water Input”. Use Sealant tape or other approved sealing method on the threads for a secure, water
tight t. Check to make sure the screen inside the water inlet is in place and clean. Then attach your
water input/garden hose.
5. Install gas supply line and regulator to the portable tankless water heater by using 2 wrenches,
one on the compression tting already attached to the water heater and the other on the gas line.
DO NOT OVER TIGHTEN. OVER TIGHTING MAY CRACK THE GAS REGULATOR CAUSING A GAS LEAK!
Check for any gas leak before ignition! Make sure the gas connection is secured.
6. Attach the shower nozzle hose to the water output to the tting marked ‘Water Outlet.’ Do not
over tighten.
7. Install two D Cell batteries in the compartment on the bottom left of the heater. Check that
batteries are facing the correct direction.
8. Use the top tab on the portable tankless water heater to suspend from a mounted screw capable
of holding 30 pounds. Place at a comfortable height without putting stress on the gas hose. Do not
use suspended from the handle! Do not permanently mount this portable tankless water heater!
9. Attach gas regulator with hose to the LP tank. Use hand pressure only on the plastic connector.
LEAVE GAS TANK VALVE IN THE “OFF” POSITION.
Before going to the USE section:
Check around area for ammables, especially gasoline or other vapors which may ignite. The Exhaust and
top of the portable tankless water heater will get HOT! Make sure there are no foreign objects around the
portable tankless water heater or that have fallen into the top.
qty. 1 - Water heater qty. 1 - Shower Nozzle
and Hose
qty. 1 - 1/2” NPT to
garden hose adapter
qty. 1 - Gas hose
and regulator qty. 1 - Hardware pack
qty. 1 - Vent Shield

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
11
L5 English
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
WARNING!
GAS HOSE ADAPTER
THE L5, L7,& L10 PORTABLE TANKLESS WATER HEATERS HAVE 1/2” TO 3/8” ADAPTER ALREADY
ATTACHED TO THE GAS INLET ON THE WATER HEATER.
PLEASE ENSURE THE ADAPETER IS CORRECTLY INSTALLED WITH THREAD SEALANT. A
SPOOL OF SEALANT TAPE IS INCLUDED WITH THE WATER HEATER.
MULTIPLE WRAPS OF SEALANT TAPE MAY BE NECESSARY TO ASSURE COMPLETE SEAL.
ALWAYS CHECK FOR GAS LEAKS BEFORE USING HEATER.
Warning: This model is intended for recreational & portable use only. This
model CANNOT be permanently mounted or plumbed in any way.
1. Turn on incoming water supply. Ensure that you have adequate water
pressure between 20-80 PSI.
2. Turn your water output device to its “o” position.
3. Turn the gas valve on the cylinder all the way open.
4. IF THE SMELL OF GAS IS DETECTED, TURN OFF THE GAS VALVE
IMMEDIATELY!!
5. Set the water regulator knob on the face of the portable tankless water
heater to its highest setting.
6. Set the gas regulator knob on the face of the portable tankless water
heater to its minimum setting.
7. Turn on your water output device to the “on” position and adjust to the
desired water ow.
8. There will be a series of audible clicks and the burner will ignite. Should
the burner not ignite after 5 seconds, shut o and go to the “Trouble
Shooting” section.
9. Upon completion of use or storage, open the drain valve (ribbed
cylindrical stem next to the water input valve) to ensure draining of water.
10. Turn o your gas supply.
11. WARNING: If the outside temperature is around or below freezing (32
degrees F, 0 degrees C), ensure that the drain valve is opened and water
drained from the portable tankless water heater after each use to avoid
internal damage to the water regulator. You will also need to unhook the
outgoing water line to ensure that any water in the heat exchanger is
drained. Failure to properly drain your portable tankless water heater will
cause water damage which may or may not be reparable. Please check the
warranty information found on our website at www.eccotemp.com for
more information on freezing issues.
Use and Starting

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
12
English L5
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
The temperature of the outgoing water is dependent on the temperature of the incoming
water balanced with the amount of heat applied. Use extreme caution when setting the
outlet water temperature.
Adjustment
WARNING: THE PORTABLE TANKLESS
WATER HEATER IS CAPABLE OF PRODUCING
SCALDING WATER TEMPERATURES!
1. With the water regulator set to high, and the gas regulator set to low,
feel the outgoing water. This is the lowest setting available.
2. To initially raise the outgoing temperature, slowly turn the gas valve
towards maximum. Adjust slowly and check the temperature often. There
will be a slight delay between increasing the gas supply and the increase
in water temperature.
3. Should the outlet water temperature need to be higher, slowly reduce
the water ow regulator until desired temperature is reached.
(Warning: Do not alter or change this water heater’s original temperature sensor)

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
13
L5 English
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
Portable tankless water heater will not start – there are no audible clicks at startup:
a. The rst thing to check is to ensure that the incoming water on the “right” side of the portable
tankless water heater. If the incoming and outgoing are reversed, the portable tankless water
heater will not work. The incoming is on the far right and the outgoing is in the middle.
b. The “On/O” switch should be with the”-” sign pushed down.
c. Check to make sure you have fresh batteries and they are installed in the correct position.
d. Number one reason that the portable tankless water heater does not ignite is that there is not
enough water pressure. You need to make sure that you have a minimum of 20 PSI of sustained
water pressure.
ADJUSTMENT: Looking up at the bottom of the portable tankless water heater, you will see
2 oval holes in the case. The hole that is furthest on the right looks up at the water regulator
where you will see two Phillips head screws. Take the screw that is furthest on the right in about
a 1/4 or 1/2 turn. This will enable the portable tankless water heater to operate on a lower water
pressure by restricting ow.
There is a simple test that we can help you perform if you are unaware if you have enough water
pressure. Please visit the Eccotemp helpdesk at www.eccotemp.com/helpdesk or contact us via
email at suppor[email protected] for additional troubleshooting steps.
e. A wire has become disconnected inside the portable tankless water heater during shipping.
Make sure the gas is OFF and the switch is in the OFF position. The front cover is held by four
screws, two top, two bottom. The knobs pull o. All the wiring is done with push together
plastic connectors. They are all visible without further dismantling of the portable tankless
water heater. It should be obvious when a wire has become disconnected.
NOTE: Before attempting to remove the cover, call technical support at 866.356.1992
f. It is possible that some debris or epoxy might have entered the water regulator. Check to see
if the lter screen on the waler inlet is clear of debris. You can also reverse the hookup by taking
your water source and hooking it up to the water outlet side and back ushing the system.
Propane gas cylinders sometimes are contaminated with air, especially new tanks upon their
rst lling. Cycle the portable tankless water heater on and o by using the shower head switch
several times (5) to purge the air from the gas.
Should a portable tankless water heater fail to light or stay lit after 10 cycles, please visit the
eccotemp helpdesk at www.eccotemp.com/helpdesk or contact us via email at support@
eccotemp.com for additional troubleshooting steps.
Portable tankless water heater will not start – but there are audible clicks at startup:
a. The portable tankless water heater requires a minimum of about 2 GPM and a minimum of
about 25 PSI. Note: water pressure is at the lower end of operating parameters. You will need
a sustained water pressure of approximately 40-60 PSI for adequate use if you are using a
12/18/120 volt pump. See adjustment in previous section.
b. High Wind. For safety reasons the heater will not start in sustained wind, nd an alternate
location for the water heater.
c. Out of, or low on gas. Propane gas cylinders sometimes are contaminated with air, especially
new tanks upon their rst lling. Cycle the portable tankless water heater on and o by using
the shower head switch several times (5) to purge the air from the gas.
DO NOT RETURN TO STORE
Troubleshooting
Please visit our Helpdesk at www.eccotemp.com or contact us via email at
suppor[email protected] if you encounter a problem!

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
14
English L5
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
d. One of the ignition sensors is bent and/or too close to the burner. Look to ensure that the
ignition pins and the heat sensor are completely vertical and they do a 90 degree to the back
of the box. If they are not straight (i.e. a 45 degree angle) then you can straighten them with
pliers. Please call technical support at 866.356.1992 for assistance with this matter.
e. The thermocouple is either too high or too low to complete the circuit. Check to ensure
that the thermocouple is ush with the hole in the heat exchanger. Please call technical
support at 866.356.1992 for assistance with this matter.
f. The gas sensor wire might have come loose or is no longer connected. Please call technical
support at 866.356.1992 for assistance with this matter.
The water does not get hot enough:
a. You are operating the portable tankless water heater above 4,000 feet. While it has been
eld tested up to 5,500 feel, we only recommend using it below elevations of 4,000-5,500
feet.
b. Look into the viewer panes (3 teardrop shaped windows on the front cover) to see if there
is a blue ame. If the ame is yellow there could be a cracked gas regulator. Do Not Attempt
to use the portable tankless water heater and call Eccotemp directly at 866.356.1992.
c. Please refer to the eccotemp helpdesk for more troubleshooting solutions at www.
eccotemp.com/helpdesk.
Water is owing. but there is no hot water coming out:
a. Ensure that you have the incoming water supply and the outgoing water supply hooked
up properly. Your water supply should be attached to your incoming connection (located on
the far right) and the shower head should be attached to the outgoing water (located as the
center connection).
b. Ensure that you have adequate water pressure of at least 20 PSI, sustained.
c. Ensure that you have adequate gas in your propane bottle and that the LP regulator is
threaded all of the way on to the portable tankless water heater.
d. Fresh batteries are required for ignition spark. Make sure batteries are aligned in the
proper polarity(+/-) Flat negative of battery towards spring side of battery compartment.
e. Please refer to the eccotemp helpdesk for more troubleshooting solutions at www.
eccotemp.com/helpdesk.
If you are still having troubles or are on a modied water system, please call technical
support at 866.356.1992.
The portable tankless water heater does nothing:
a. Ensure that you have your water source hooked up to the water inlet side (far right
connection) and the shower handle is hooked up on the water outlet side (middle
connection).
b. Ensure that you have an adequate supply of propane.
c. Ensure that you have fresh batteries.
d. Please refer to the eccotemp helpdesk for more troubleshooting solutions at
www.eccotemp.com/helpdesk.
Troubleshooting Continued...

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
15
L5 English
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
L5
PORTABLE PRODUCT COMPARISONS
L7 L10
BTU
Flow Rate
Portable
Power Source
Gas Type
Venting
Water Pressure
Regulator & Hose
Temperature Control
Warranty
Product Dimensions
Package Dimensions
INSTALLATION OUTDOOR ONLY
37,500
Rated 1.5 GPM
Yes
2 “D” Cell Batteries
Liquid Propane Only
None Needed
20-80 PSI
Standard / Included
Manual 80°- 120°F
1 Year
12” x 4.5” x 20” - 11.2 lbs
12.4” x 7.7” x 21.9” - 13.8 lbs
L5 L7
OUTDOOR ONLY
L10
OUTDOOR ONLY
41,000
Rated 1.6 GPM
Yes
2 “D” Cell Batteries
Liquid Propane Only
None Needed
20-80 PSI
Standard / Included
Manual 50°- 125°F
2 Years
13.5” x 6.5” x 19.5” - 14.7 lbs
14” x 7.7” x 25.8” - 16 lbs
75,000
Rated 2.65 GPM
Yes
2 “D” Cell Batteries
Liquid Propane Only
None Needed
25-80 PSI
Standard / Included
Manual 80°- 140°F
1 Year
15” x 6.5” x 35” - 17.5 lbs
15.7” x 9.6” x 35.4” - 23.5 lbs
SPECIFICATIONS

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
16
English L5
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
Eccotemp Systems ,LLC
Limited Warranty Information
EccoTemp hereby warrants this product to be free of material defects in materials and workmanship when
installed and operated according to EccoTemp’s installation and operating instructions. This Limited Warranty
extends to the original purchaser and subsequent owners, but only while the product remains as the site of
the original installation. This Limited Warranty terminates if moved or reinstalled at a new location. There are
no warranties, express or implied made or given other than contained in this Limited Warranty. No agent,
employee or representative of EccoTemp has any authority to bind EccoTemp to any representation or warranty
concerning the Product not contained in this Limited Warranty.
Except as expressly set forth herein, THERE ARE NO REPRESENTATIONS OR WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING, WITHOUT LIMITATION, AS TO MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE WITH RESPECT TO ANY GOODS SOLD HEREUNDER. BUYER’S EXCLUSIVE REMEDY IS LIMITED TO
REPAIR OR REPLACEMENT OF THE GOODS SOLD, AT ECCOTEMP’S DISCRETION. ECCOTEMP SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Item Period of Coverage
Heat Exchanger 1 year
All other parts 1 year
Free Accessories (Showerhead,hose,regulator etc) 30 days
Coverages are void if the unit is used in a hot water circulation loop, in series with a circulation system or where
an on-demand recirculation system is not incorporated.
Owner is responsible for all other costs incidental to repair such as labor, shipping, delivery and permits. Proof
of purchase required. Products repaired will be covered under this Limited Warranty for the remainder of term
of the original purchase.
This Limited Warranty becomes null and void if any of the following are determined to be a contributing factor
to the failure of the product:
1. Abuse, misuse, alteration, neglect or misapplication;
2. Improper or inadequate maintenance;
3. Inadequate water quality;
4. Installation in a corrosive or otherwise destructive environment;
5. Freeze Damage;
6. Scale buildup;
7. Incorrect gas or water pressure;
8. Acts of force Majeure
This Product is not to be used as a pool or spa heater.
Shipping Related Costs:
Within the rst 30 days of purchase, Eccotemp will cover all ground shipping costs for warranty related issues,
excluding AK, HI, Canada, and any location outside of the continental US. After the rst 30 days of purchase,
Eccotemp will cover all shipping costs to the customer for warranty related issues, excluding AK, HI, Canada,
and any location outside of the continental US. After the rst 30 days of purchase, the customer is responsible
for all shipping to Eccotemp, regardless of reason or circumstance. The method for warranty related shipping
will be Ground equivalent with the provider of Eccotemp’s choosing.
AK, HI, Canada, and any location outside of the continental US, will be responsible for all shipping costs,
regardless of reason or circumstance.
All shipments of any type of product coming to Eccotemp for any reason must have an RGA for any repairs to
be made. Please contact Eccotemp to obtain an RGA number prior to shipping anything to Eccotemp. Failure to
do so could result in loss of product. Eccotemp will not be responsible for replacement due to loss or damage
if these steps are not properly followed.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL
IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
17
L5 English
Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
Phone: [phone] | Email: [email protected] | Address: 315 - A Industrial RD Summerville, SC 29483
