Echelon CONNECT SPORT User manual

1
INSTRUCTION MANUAL
CONNECT SPORT

3
Hello,
I am Lou Lentine, President of Echelon, and I would like to welcome you to the Echelon community. You’ve
made a great decision for yourself and your family. The Echelon Experience is an innovative combination
of fitness products integrated with our state-of-the-art Echelon Fit®App. This brand-new, fitness lifestyle
connects your family, friends, the Echelon community, and Echelon instructors together to help you with
your fitness goals. With thousands of live and on-demand classes, no matter your schedule or experience,
there is always a new and exciting class for you to join.
We embrace your decision to join our Echelon family in the pursuit of living a healthier lifestyle. We are
committed to continue engineering cutting edge, world-class fitness products to improve quality of life
through workout experiences that make an active lifestyle more accessible and sustainable.
Thank you again for choosing Echelon and I look forward to seeing you in the next live class!
Best personal regards,
Lou Lentine
CEO, Echelon Fitness Multimedia, LLC

4
4
3
1
10
7
11 12 13
8
5
9
6
9
14
15
15
17
16 18
21
19
22
20
24 25
4
4
2
23
INCLUDES
1. Handlebar height
adjustment lever
2. Handlebar post frame
3. Resistance knob/brake lever
4. Crank arms
5. Seat height adjustment lever
6. Front bracket
7. Rear bracket
8. Wheel chock (not visible)
9. Handlebars
10. Front foot
11. Rear foot
12. Handlebar post
13. Seat
14. Water bottle holder
15. Pedals
16. Seat post
17. Seat slide adjustment knob
18. Power adapter
19. Handlebar bottom bracket
20. Water bottle holder screws (x2)
21. Handlebar post screw
22. Foot bolts (x4)
23. Hex key with Phillips
screwdriver head
24. Double-sided wrench
25. Wrench
PARTS LIST

5
5
ACCOUNT CREATION
If this product was purchased on the echelonfit.com website, you should have received
an activation email.
Go to echelonfit.com and follow the on-screen instructions to choose a plan and setup your
account. This info will be needed to login to your account on the Echelon Fit® App.
All account info and plans are managed at member.echelonfit.com and use the same login. After creating your
account login on member.echelonfit.com, write down your login info. This will be the same login for the App.
1. Choose "sign up now"
2. Select Purchase location
3. Choose your plan
Monthly / 1 Year / 2 Year
Select purchase location and follow the
on-screen instructions.
4. Set up payment method
5. ENTER PERSONAL ACCOUNT INFO Once assembly is complete, you will be required to
sign into your account, choose a class, and connect
your bike.
If this product was purchased on the echelonfit.com
website, you should have received an activation email.
Click the link in the activation email and follow the
on-screen instructions. Enter your information to verify
payment information. You will not be charged until
the next month.
ACCOUNT ACTIVATION
6. View YOUR ACCOUNT
Where you can edit your billing info, add family
members, manage subscriptions, and (if on your
mobile device) download the app and sign in.
QUICK START GUIDE

6
6
DOWNLOAD THE ECHELON FIT®APP
Ensure latest version of the Echelon Fit App
is installed from the Google®Play Store or the
App Store.
OPERATIONAL INSTRUCTIONS
Connect to the Echelon Fit App to access tutorials
and operation instructions.
QUICK START GUIDE

7
7
SAFETY INFO AND WARNINGS
SPECS
Adaptor Model: XH0900-0500WA
Input: 100-240V~ 50/60Hz 0.2A
Bike: Input: 9V 0.5A
QDID: 60912
FCC ID: 2AMDBBLE002
CAN ICES3 BNMB3B HVIN: 1.0
IC: 22882BLE002
DIMENSIONS: 106.7 X 52 X 114.3CM
Use only with Power Adaptor Ninghai Yingjiao Electrical Co. Ltd, Model XH0900-0500WA
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this device.
FEDERAL COMMUNICATIONS COMMISSION FCC STATEMENT
15.21
YOU ARE CAUTIONED THAT CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR
COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
15.105B
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS B DIGITAL DEVICE,
PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE IN A RESIDENTIAL INSTALLATION. THIS EQUIPMENT GENERATES, USES AND CAN RADIATE
RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTIONS, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. HOWEVER, THERE IS NO GUARANTEE THAT INTERFERENCE
WILL NOT OCCUR IN A PARTICULAR INSTALLATION. IF THIS EQUIPMENT DOES CAUSE HARMFUL INTERFERENCE TO RADIO
OR TELEVISION RECEPTION, WHICH CAN BE DETERMINED BY TURNING THE EQUIPMENT OFF AND ON, THE USER IS
ENCOURAGED TO TRY TO CORRECT THE INTERFERENCE BY ONE OR MORE OF THE FOLLOWING MEASURES:
 REORIENT OR RELOCATE THE RECEIVING ANTENNA.
 INCREASE THE SEPARATION BETWEEN THE EQUIPMENT AND RECEIVER.
 CONNECT THE EQUIPMENT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM THAT TO WHICH
THE RECEIVER IS CONNECTED.
 CONSULT THE DEALER OR AN EXPERIENCED RADIOTV TECHNICIAN FOR HELP.

8
8
FCC RF RADIATION EXPOSURE STATEMENT:
1. THIS TRANSMITTER MUST NOT BE COLOCATED OR OPERATING IN CONJUNCTION WITH ANY OTHER ANTENNA
OR TRANSMITTER.
2. THIS EQUIPMENT COMPLIES WITH RF RADIATION EXPOSURE LIMITS SET FORTH FOR AN UNCONTROLLED
ENVIRONMENT. THIS EQUIPMENT SHOULD BE INSTALLED AND OPERATED WITH A MINIMUM DISTANCE OF 20 CM
BETWEEN THE RADIATOR AND YOUR BODY.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS:
1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND
2. THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
INNOVATION, SCIENCE AND ECONOMIC DEVELOPMENT CANADA ISED
INNOVATION, SCIENCE ET DÉVELOPPEMENT ÉCONOMIQUE CANADA ISED
THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES003
CET APPAREIL NUMÉRIQUE DE CLASSE B EST CONFORME À LA NORME NMB003.
CANADIAN NOTICE
THIS DEVICE COMPLIES WITH ISED LICENSEEXEMPT RSS STANDARDS. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS:
1. THIS DEVICE MAY NOT CAUSE INTERFERENCE, AND
2. THIS DEVICE MUST ACCEPT ANY INTERFERENCE, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION OF THE DEVICE.
AVIS CANADIEN
LE PRÉSENT APPAREIL EST CONFORME AUX CNR D’ISED APPLICABLES AUX APPAREILS RADIO EXEMPTS DE LICENCE.
L’EXPLOITATION EST AUTORISÉE AUX DEUX CONDITIONS SUIVANTES:
1. L’APPAREIL NE DOIT PAS PRODUIRE DE BROUILLAGE, ET
2. L’UTILISATEUR DE L’APPAREIL DOIT ACCEPTER TOUT BROUILLAGE RADIOÉLECTRIQUE SUBI, MÊME SI LE BROUILLAGE
EST SUSCEPTIBLE D’EN COMPROMETTRE LE FONCTIONNEMENT.
SAFETY INFO AND WARNINGS

9
9
CAUTION: EXPOSURE TO RADIO FREQUENCY RADIATION.
1. TO COMPLY WITH THE CANADIAN RF EXPOSURE COMPLIANCE REQUIREMENTS, THIS DEVICE AND ITS ANTENNA MUST NOT
BE COLOCATED OR OPERATING IN CONJUNCTION WITH ANY OTHER ANTENNA OR TRANSMITTER.
2. TO COMPLY WITH RSS 102 RF EXPOSURE COMPLIANCE REQUIREMENTS, A SEPARATION DISTANCE OF AT LEAST 20 CM MUST
BE MAINTAINED BETWEEN THE ANTENNA OF THIS DEVICE AND ALL PERSONS.
ATTENTION: EXPOSITION AU RAYONNEMENT RADIOFRÉQUENCE.
1. POUR SE CONFORMER AUX EXIGENCES DE CONFORMITÉ RF CANADIENNE L’EXPOSITION, CET APPAREIL ET SONANTENNE
NE DOIVENT PAS ÊTRE COLOCALISÉS OU FONCTIONNANT EN CONJONCTION AVEC UNE AUTRE ANTENNE OU
TRANSMETTEUR.
2. POUR SE CONFORMER AUX EXIGENCES DE CONFORMITÉ CNR 102 RF EXPOSITION, UNE DISTANCE DE SÉPARATION D’AU
MOINS 20 CM DOIT ÊTRE MAINTENUE ENTRE L’ANTENNE DE CET APPAREIL ET TOUTES LES PERSONNES
NOTE: CARE SHOULD BE TAKEN IN MOUNTING AND DISMOUNTING THE STATIONARY EXERCISE BIKE. BEFORE
MOUNTING OR DISMOUNTING MOVE THE PEDAL ON THE MOUNTING OR DISMOUNTING SIDE TO ITS LOWEST
POSITION AND BRING THE MACHINE TO A COMPLETE STOP.
THE MANUFACTURER RECOMMENDS TO PLACE THE ECHELON®CONNECT SPORT BIKE IN A SPACE WHERE YOU
HAVE TWO FEET OF CLEARANCE ON ALL SIDES OF THE BIKE FOR SAFE MOUNTING AND DISMOUNTING OF THE
EXERCISE BIKE. THE MINIMUM DIMENSIONS ARE: 0.5 M 19.7 IN. ON AT LEAST ONE SIDE, AND 0.5 M 19.7 IN.
EITHER BEHIND OR IN FRONT OF THE EXERCISE BIKE.
WHILE CLEANING YOUR ECHELON®CONNECT SPORT BIKE, PLEASE USE A SOFT RAG WITH MILD DETERGENT
OR WATER TO WIPE DOWN THE MACHINE. DO NOT USE CORROSIVE CHEMICAL LIQUIDS WHICH MAY DAMAGE
THE COVER.
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including
the following:
Read all instructions before using THE ECHELON®CONNECT.
SAFETY INFO AND WARNINGS

10
10
SAFETY INFO AND WARNINGS
DANGER -
To reduce the risk of electric shock:
1. Always unplug this appliance from the electrical outlet immediately after
using and before cleaning.
WARNING - To reduce the risk of burns, fire, electric shock, or injury
to persons:
1. An appliance should never be left unattended when plugged in. Unplug from outlet when not
in use, and before putting on or taking off parts.
2. Do not operate under blanket or pillow. Excessive heating can occur and cause fire, electric
shock, or injury to persons.
3. This appliance is not intended for use by persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Keep children
under the age of 13 away from this machine.
4. Use this appliance only for its intended use as described in this manual. Do not use attachments
not recommended by the manufacturer.
5. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged, or dropped into water. Return the appliance to a service center for
examination and repair.
6. Do not carry this appliance by supply cord or use cord as a handle.
7. Keep the cord away from heated surfaces.

11
11
8. Never operate the appliance with the air openings blocked. Keep the air openings
free of lint, hair, and the like.
9. Never drop or insert any object into any opening.
10.Do not use outdoors.
11. Do not operate where aerosol (spray) products are being used or where oxygen
is being administered.
12. To disconnect, turn all controls to the off position, then remove plug from outlet.
BEFORE starting any fitness or strength program, consult with your physician or health
official. This will ensure that you engage in the proper strength or fitness program for your
age and physical condition.
Before using the Echelon®Connect Sport, answer these questions:
• Have you been sick recently?
• Have you had prolonged dizziness recently?
• Have you been out of breath for no reason recently?
• Have you had chest pain recently?
• Do you currently have any injuries preventing you from exercise?
• Are you pregnant?
• Do you have any conditions or reasons you should NOT exercise?
• Are you over 35 years old and physically inactive?
• Have you been told by a doctor that you should NOT exercise?
IF YOU ANSWER “YES” TO ANY OF THE ABOVE QUESTIONS, YOU SHOULD SEEK FURTHER
ADVICE FROM YOUR DOCTOR PRIOR TO USING THE ECHELON®CONNECT.
Read the user manual fully and follow all instructions. This ensures your safety.
SAFETY INFO AND WARNINGS

12
12
WARNINGS
• ALWAYS use the Echelon®Connect Sport on solid, level ground and in a well lit and ventilated area.
• ALWAYS check that the seat and handlebars are securely fastened before use.
• NEVER allow children to play on or around the bike. This helps protect them from injury from moving parts.
• ALWAYS set the bike up properly for your specific body type. The Echelon®Connect offers up/down and
fore/aft adjustments that are clearly marked to ensure a quick and easy customization for each workout.
• ALWAYS check the bike before use.
• NEVER use the bike if it is not properly/completely assembled or is damaged in any way.
• NEVER exceed the weight limit for this bike. The weight limit for this bike is 300 pounds.
Do not use the Echelon®Connect Sport if your body weight is in excess of 300 pounds.
• NEVER use Echelon®Connect Sport when sick or fatigued.
• ALWAYS wear proper attire and footwear that fully covers your feet. Long hair should be tied back or tucked
away. Ensure that shoelaces are tucked into your shoes.
• ALWAYS warm up/stretch before starting exercise.
• ALWAYS be cautious when getting on and off the Echelon®Connect Sport.
• ALWAYS wait until the pedals have come to a complete stop before taking your feet off of the pedals or
dismounting. Do not stand or climb on the handlebars.
• ALWAYS keep hands away from moving parts and ensure that hands are never placed where there is no
rubber handlebar grip.
• NEVER overexert yourself or work to exhaustion. If you feel faint, dizzy, short of breath, or if you have chest
or other pains, STOP IMMEDIATELY! Consult your physician before using the Echelon®Connect Sport again.
SAFETY INFO AND WARNINGS

13
13
SAFETY INFO AND WARNINGS
• NEVER use the Echelon®Connect Sport in a standing position at high revolutions per minute (RPM)
(see OPERATION section, Fig. 2).
• ALWAYS keep your pelvis positioned over the center line of the Echelon®Connect Sport.
• NEVER adjust the resistance of the flywheel or the position of the handlebars while in a standing position
(see OPERATION section, Fig. 2).
• NEVER use accessory attachments that have not been recommended by the manufacturer. Using such
attachments may cause injury or damage to the bike and will affect the warranty of the bike.
• ALWAYS ensure that the Echelon®Connect Sport is wiped down after each use to keep it sanitary.
• Cleaning and user maintenance shall not be made by children without supervision.
If any problems arise affecting the performance of the Echelon®Connect, contact the manufacturer
immediately. Always ensure that parts which undergo wear are checked regularly.
IF WARNING LABELS ON YOUR CONNECT SPORT BECOME DAMAGED, CONTACT ECHELON CUSTOMER
SERVICE ([e-mail]) TO REQUEST REPLACEMENT LABELS.
THIS SAFETY INFORMATION AND USER MANUAL DOES NOT REPLACE THE NEED TO BE ALERT AND
TO USE COMMON SENSE WHEN USING THE ECHELON®CONNECT SPORT!

14
14
Lay the Connect Sport on its side
and remove wheel chock bolts with
hex key and set to the side.
Place the front foot with wheels
facing forward under the
front bracket.
Place the rear foot under the rear
bracket.
Using your wrench or fingers, pull
wheel chock out and set aside.
Insert foot bolts into front foot and
tighten down with hex key.
Insert foot bolts into rear foot and
tighten down with hex key.
REMOVAL OF FRAME

15
15
Connect the coiled wire from the
bike to the wire at coming out of the
handlebar post.
Place seat onto seat post and secure
with included wrench.
Unscrew handlebar height
adjustment lever, but do not remove.
Pull lever out and fully insert
handlebar post into frame. Release
lever and post is secure.
Place water bottle holder over the
two screw holes near the Sport logo
and secure with two water bottle
holder screws.
Place the handlebars on the
handlebar post and the handlebar
bottom bracket (shown above) and
screw in the handlebar post screw
with hex key.
Remove nut from left pedal by
turning clockwise.
ASSEMBLY

16
16
ASSEMBLY
Finger tighten nut counterclockwise
back onto pedal bolt.
Hold pedal with double sided
wrench and use single sided wrench
to tighten nut counterclockwise.
Remove nut from right pedal by
turning counterclockwise.
Screw right pedal onto crank arm
clockwise.
Screw left pedal onto crank arm
counterclockwise.
Use double sided wrench to ensure
pedal is firmly seated against crank
arm.
The threads are reversed on LEFT pedal and nut.

17
17
ASSEMBLY
Plug power adapter into port located
on the rear foot bracket, then plug
into wall outlet.
Use double sided wrench to ensure
pedal is firmly seated against crank
arm.
Hold pedal with double sided
wrench and use single sided wrench
to tighten nut clockwise.
Finger tighten nut clockwise back
onto pedal bolt.
The assembly of your Echelon®
Connect Sport bike is now
complete!

18
18
Turn seat slide adjustment lever
counterclockwise to loosen. Move seat
along track to desired location. Turn
seat slide adjustment lever clockwise
to tighten and secure in place.
Turn seat height adjustment lever counterclockwise until
you are able to pull the lever halfway out. Pull and hold the
seat height adjustment lever and raise the seat to desired
position. Ensure lever engages one of the adjustment holes.
Turn seat height adjustment lever clockwise until secure.
TROUBLE CONNECTING?
If your bike does not connect using the process above, navigate to the Settings app on the tablet
and select Apps (on older versions of Android you will select ’Application’ and then ‘Application
manager’). At the top right select the icon (on older versions, select ‘MORE’) and then select ‘Show
system’ or ‘Show system apps’. Select ‘Bluetooth Share’, then ‘Storage’, and then either ‘Clear Data’
or ‘Clear Cache,’ depending which button is highlighted. Restart the Echelon Fit®App and attempt
connection again. If you have any issues after completing this process, please contact us at
echelonfit.com
SEAT ADJUSTMENT

19
19
HANDLEBAR / leveling ADJUSTMENT
Turn handlebar adjustment lever
counterclockwise until you are
able to pull the lever halfway
out. Pull and hold the handlebar
adjustment lever and raise or
lower the handlebars to desired
position. Ensure lever engages
one of the adjustment holes.
Turn handlebar adjustment lever
clockwise until secure.
To level the Connect Sport, adjust
the pads on the front and rear feet
until stable.

20
20
OPERATION
FIG. 1 FIG. 2
There are two different positions (shown below) you will see during
classes on the Echelon Fit®app. Fig. 1 demonstrates a relaxed upper
body while in seated position. Fig. 2 demonstrates proper hand
placement and weight distribution while in an upright position.
