Power Blower
Operator'sManual
MODEL PB-200
X753001510
03/04
X7531133400
WARNING DANGER
Read rules for safe operation and all instructions carefully. ECHO provides this
Operator’s Manual, which must be read and understood for proper and safe operation.

2
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job-
dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and
SAFETYmessages.
TABLE OF CONTENTS
Introduction ...............................................................2
- The Operator's Manual ...................................2
Manual Safety Symbols and Important Information ..3
Safety ........................................................................3
- Decals .............................................................3
- InternationalSymbols .....................................4
Safety Instructions ....................................................4
- Personal Condition and Safety Equipment......4
- ExtendedOperation/ExtremeConditions......... 5
- Equipment .......................................................5
- SafeOperation.................................................6
EmissionControl........................................................6
Description ................................................................7
- Contents..........................................................7
Specifications.............................................................8
Assembly ...................................................................8
- BlowerApplication .........................................8
Pre-Operation .............................................................9
- Fuel .................................................................9
Operation ................................................................. 10
- StartingCold Engine ..................................... 10
- StartingWarmEngine ................................... 11
- Stopping Engine............................................ 11
- OperatingBlower .......................................... 12
Maintenance ............................................................ 13
- SkillLevels .................................................... 13
- Maintenance Intervals .................................. 13
- AirFilter ........................................................ 14
- FuelFilter ...................................................... 14
- SparkPlug ..................................................... 15
- CoolingSystem ............................................. 15
- ExhaustSystem ............................................. 16
- Carburetor Adjustment ................................. 17
Troubleshooting ...................................................... 18
Storage..................................................................... 19
ServicingInformation............................................... 20
- Parts .............................................................. 20
- Service........................................................... 20
- ECHOConsumerProductSupport ................ 20
- Warranty Card............................................... 20
- Additional or Replacement Manuals............. 20
Specifications, descriptions and illustrative material in this
literature are as accurate as known at the time of publica-
tion, but are subject to change without notice. Illustrations
may include optional equipment and accessories, and may
not include all standard equipment.
THE OPERATOR’SMANUAL
Read and understand this manual before operation. Keep it in a safe
place for future reference. It contains specifications and information for
operation, starting, stopping, maintenance, storage and assembly
specific to this product.
Copyright©2004ByEcho,Incorporated
All Rights Reserved.

3
POWER BLOWER
OPERATOR'SMANUAL
IMPORTANT
The enclosed message provides
information necessary for the
protection of the unit.
NOTE
This enclosed message provides tips
for use, care and maintenance of the
unit.
Throughout this manual and on the product itself, you will find safety
alerts and helpful, informational messages preceded by symbols or key
words. The following is an explanation of those symbols and key
words and what they mean to you.
General Warning Decal (located on top of blower housing)
IMPORTANT
NOTE
P/N 89016006361
P/N 89016009461
65Category I
dB(A)
Measured at 50 ft. (15m) per ANSI B175.2
P/N X508000120
Sound Label (located on blower housing)
Hot Decal (near muffler)
MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION
This symbol accompanied by the words WARNING and
DANGER calls attention to an act or condition that can lead to
serious personal injury to operator and bystanders.
The circle with the slash symbol means whatever is shown
within the circle is prohibited.
SAFETY
DECALS
Locate these safety decals on your unit. Make sure the decals are
legible and that you understand and follow the instructions on them. If
a decal cannot be read, a new one can be ordered from your ECHO
dealer. SeePARTSORDERINGinstructionsforspecificinformation.

4
INTERNATIONALSYMBOLS
SYMBOL
Carburetor
Adjustment
-Idlespeed
Carburetor
Adjustment
-Highspeed
mixture
Emergency
Stop
Carburetor
adjustment
-Lowspeed
mixture
Ignition
ON/OFF Primer
Bulb
Choke Control
"Cold Start"
Position
(ChokeClosed)
Choke Control
"Run"
Position
(ChokeOpen)
DESCRIPTION SYMBOL DESCRIPTION
Hot
Surface
Read and under-
stand Operator's
Manual.
Weareyes,ears
andhead
protection
Fueland oil
mixture
Finger
Severing
Safety/Alert
Wear hand
protection.Use
twohanded.
DONOTsmoke
nearfuel.
DONOTallow
flamesorsparks
nearfuel.
Wear slip
resistantfoot
wear.
SYMBOL DESCRIPTION SYMBOL DESCRIPTION
SAFETYINSTRUCTIONS
PERSONAL CONDITION AND SAFETY EQUIPMENT
WARNING DANGER
Power Blower users risk injury to themselves and others if the power blower is used improperly and
or safety precautions are not followed. Proper clothing and safety gear must be worn when operating a blower.
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• if you are taking medication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Wear eye protection that meets ANSI Z87.1 or CE
requirements whenever you operate the unit.
Hand Protection
Wear no-slip, heavy-duty work gloves to improve your
grip on the blower handle. Gloves also reduce the
transmission of machine vibration to your hands.
Breathing Protection
Wear a facemask to protect against dust.
Hearing Protection
ECHOrecommendswearinghearingprotectionwhenever
unit is used.
Proper Clothing
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DONOTWEARSHORTS,
• DONOTWEARTIES,SCARVES,andJEWELRY.
Wear sturdy work shoes with nonskid soles:
• DONOTWEAROPENTOEDSHOES,
• DONOTOPERATEUNITBAREFOOTED.
Keep long hair away from engine and blower intake.
Retain hair with cap or net.
Hot Humid Weather
Heavy protective clothing can increase operator fatigue,
which may lead to heat stroke. Schedule heavy work for
early morning or late afternoon hours when temperatures
arecooler.

5
POWER BLOWER
OPERATOR'SMANUAL
EQUIPMENT
• Check unit for loose/missing nuts, bolts and screws. Tighten
and/or replace as needed.
• Inspect fuel lines, tank and area around carburetor for fuel leaks. DO
NOT operate unit if leaks are found.
• Do not use blower if any part is missing or damaged.
• Have repairs done only by an authorized ECHO Service dealer.
• Do not use any attachment, accessory or replacement part unless it is
recommended in this Operator's Manual.
EXTENDED OPERATION/EXTREME CONDITIONS
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon, which
affects the fingers of certain individuals, may be brought about by
exposure to vibration and cold. Exposure to vibration and cold may
cause tingling and burning sensations, followed by loss of color and
numbness in the fingers. The following precautions are strongly
recommended,because theminimum exposure,which mighttrigger the
ailment,isunknown.
• Keep your body warm, especially the head, neck, feet, ankles, hands,
and wrists.
• Maintain good blood circulation by performing vigorous arm
exercises during frequent work breaks, and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the unit or other hand-held power equipment is not
required.
• If you experience discomfort, redness, and swelling of the fingers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the fingers,
hands, arms, and shoulders may cause soreness, swelling, numbness,
weakness, and extreme pain in those areas. Certain repetitive hand
activities may put you at a high risk for developing a Repetitive Stress
Injury(RSI).AnextremeRSIconditionisCarpalTunnelSyndrome
(CTS), which could occur when your wrist swells and squeezes a vital
nerve that runs through the area. Some believe that prolonged expo-
sure to vibration may contribute to CTS. CTS can cause severe pain for
months or even years.
To reduce the risk of RSI/CTS, do the
following:
• Avoid using your wrist in a bent, ex-
tended, or twisted position. Instead try to
maintain a straight wrist position. Also,
when grasping, use your whole hand, not
just the thumb and index finger.
• Takeperiodicbreakstominimizerepeti-
tion and rest your hands.
• Reduce the speed and force with which
you do the repetitive movement.
• Do exercises to strengthen the hand and
armmuscles.
• Immediately stop using all power equip-
ment and consult a doctor if you feel
tingling, numbness, or pain in the fingers,
hands, wrists, or arms. The sooner RSI/
CTSisdiagnosed,the morelikelyperma-
nent nerve and muscle damage can be
prevented.

6
SAFE OPERATION
WARNING DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can cause
serious injury or death.
DetermineOperationArea
• Review area to be cleared. Look for potential hazards such as stones
or metal objects.
• Take wind conditions into account: avoid open doors and windows.
• Do not point blower at people or animals.
• Start unit on ground with throttle at idle. Check that blower pipe is
not blocked by the ground or by any objects.
ReadtheManuals
• Provide all users of this equipment with the Operator's Manual and
Safety Manual for instructions on Safe Operation.
KeepAFirmGrip
• Hold handle with fingers together encircling the handle.
CleartheWorkArea
• Spectators and fellow workers must be warned, and children and
animalsprevented fromcoming nearer than15 m (50ft.) whiletheunit
is in use.
KeepASolidStance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on
ladders.
• Do not perform Maintenance or Assembly procedures with engine
running.
NoiseControl
• Follow local noise regulations on sound
levels and hours of operations. Use only
during appropriate hours.
• Never use a higher speed setting then
necessary to perform a task. The higher
the engine speed the louder the blower
noise.
• Be a good neighbor.
AvoidHotSurfaces
• Duringoperation, the muffler orcatalytic
muffler and surrounding cover may
become extremely hot. Avoid contact
duringand immediatelyafteroperation.
Always keep exhaust area clear of
flammabledebris. Allow theengine and
mufflertocompletelycoolbeforeperform-
ing any maintenance activity.
EMISSION CONTROL
EPA Phase 2
The emission control system for these engines are EM (Engine Modifi-
cation).
AnEmission Control Label is located on the engine. (This is an
EXAMPLEONLY,informationonlabelvariesbyengineFAMILY).
PRODUCT EMISSION DURABILITY
The 300 hour emission durability compliance period is the time span selected by the manufacturer certifying the
engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures are
followed as listed in the Maintenance Section of this manual.
IMPORTANTENGINEINFORMATION
ENGINEFAMILY: 4EXHS.0214EG DISPLACEMENT: 21.2CC
EMISSION COMPLIANCE PERIOD: 300 HOURS
THIS ENGINE MEETS U.S. EPA PH 2 EMISSION REGULA-
TIONS FOR SMALL NONROAD ENGINES. REFER TO
OWNER'S MANUAL FOR MAINTENANCE SPECIFICATIONS
AND ADJUSTMENTS.

7
POWER BLOWER
OPERATOR'SMANUAL
DESCRIPTION
CONTENTS
1-Power Head
1-BlowerPipeAssembly
1 - Operator's Manual
1 - Warranty Registration Card
1- ECHO Emissionsand Warranty Statement
1- EchoPower Blend TM 2-strokeoil sample 1
2
3
4
5
6
7
8
10
1. STOP SWITCH - "SLIDE SWITCH" mounted on top of handle. Push forward to start and run. Slide back to stop.
2. THROTTLETRIGGER-Springloadedtoreturntoidlewhenreleased.Duringacceleration,presstriggergradually
for best operating technique.
3. SPARKPLUG-Providessparktoignitefuelmixture.
4. SPARKARRESTOR-CATALYTICMUFFLER/MUFFLER-Themufflerorcatalyticmufflercontrolsexhaustnoise
and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler. Keep
exhaustareaclearofflammabledebris.
5. RECOILSTARTERHANDLE-Pullrecoilhandleslowlyuntilrecoilstarterengages,thenquicklyandfirmly. When
engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.
6. FUELTANKCAP-Coversandsealsfueltank.
7. AIRCLEANER-Containsreplaceableairfilterelement.
8. THROTTLEPOSITIONLEVER-Pullbacktoincreaseenginespeed.Frictionwashersmaintainthrottlelever
setting.
9. PRIMERBULB-Pumpingprimer bulbbeforestartingenginedraws freshfuelfromthefuel tankprimingthe
carburetor for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump
bulb an additional 4 or 5 times.
10. CHOKE - Choke is located on the side of the air cleaner. Move choke lever to "COLD START" ( ) to close choke
for cold starting. Move choke lever to "RUN" ( ) position to open choke.
11. BLOWERPIPES-Twistlockdesign.
9
11

8
SPECIFICATIONS
MODEL -----------------------------------------------------PB-200HandHeld
Length-------------------------------------------------------330mm(13.0in.)(w/opipes)
Width-------------------------------------------------------- 215mm (8.5in.)
Height -------------------------------------------------------340mm(13.4in.)
Weight (dry) ------------------------------------------------3.8 kg(8.38lb.)
Engine Type ------------------------------------------------Air cooled, two-stroke, single cylinder gasoline engine
Displacement -----------------------------------------------21.2cc(1.39cu.in.)
Bore----------------------------------------------------------32.2mm(1.27in.)
Stroke-------------------------------------------------------- 26.0mm(1.10in.)
Carburetor --------------------------------------------------Zamaw/primerbulb
Ignition System --------------------------------------------Flywheel Magneto, capacitor discharge ignition type
SparkPlug --------------------------------------------------NGKBPM-8YGap0.65mm(0.026in.)
ExhaustSystem --------------------------------------------SparkArrestorMuffler
Fuel ----------------------------------------------------------Mixed(GasolineandTwo-strokeOil)
Fuel/OilRatio -----------------------------------------------50:1two-strokeair cooledengineoil
Gasoline -----------------------------------------------------89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
morethan10%ethyl alcoholor15%MTBE.
Oil ------------------------------------------------------------PowerBlendTM PremiumUniversal2-StrokeOil
FuelTankCapacity ----------------------------------------0.5lit.(16.9USfl.oz.)
RecoilStarterSystem --------------------------------------AutomaticRecoilStarterCentrifugalType
Wide Open Throttle Speed (RPM)-----------------------7,000-9,000
IdleSpeed(RPM) ------------------------------------------ 2,400-3,200
MaximumAirVolume --------------------------------------7.2m3/min.(254cu.ft./min.)
MaximumAirSpeedw/pipes(MPH) --------------------61.0m/sec (136mph)
SoundLevelat50ft.dB(A) scaleperANSIB175.2----65dB(A)
ASSEMBLY
WARNING DANGER
Never perform maintenance or assembly procedures with engine
running or serious personal injury may result.
BLOWER APPLICATION
Install Blower Pipes
1. Align grooves in straight pipe with pegs on blower housing and
slide pipe onto housing.
2. Turn straight pipe clockwise to lock into place.
3. Align grooves in fan head nozzle with pegs on straight pipe and
slide fan head nozzle onto straight pipe.
4. Turn fan head nozzle clockwise to lock into place.

9
POWER BLOWER
OPERATOR'SMANUAL
IMPORTANT
Spilled fuel is a leading cause of
hydrocarbon emissions. Some states
may require the use of automatic fuel
shut-off containers to reduce fuel
spillage.ContactyourECHOdealer
fororderinginformation.
After Refueling -
• Wipe any spilled fuel from the unit.
• Moveatleast3m(10ft.) fromrefueling
location before starting.
Afteruse -
• DO NOT store a unit with fuel in its tank.
Leaks can occur. Return unused fuel to
an approved fuel storage container.
Storage -
Fuel storage laws vary by locality. Contact
your local government for the laws affecting
your area. As a precaution, store fuel in an
approved, air tight container. Store in a well
ventilated, unoccupied building, away from
sparks and flames. Do not store fuel longer
than 30 days.
IMPORTANT
Storedfuel ages. Donot mix morefuel
than you expect to use in thirty (30)
days, ninety (90) days when a fuel
stabilizeris added.
Stored two-stroke fuel may separate.
ALWAYS shake fuel container thor-
oughly before each use.
PRE-OPERATION
FUEL
Fuel Requirements
Gasoline-Use89 Octane [R+M/2](mid gradeor higher)gasolineknown
to be good quality. Gasoline may contain up to 15% MTBE (methyl
tertiary-butylether).Gasoholcontainingmethyl(wood)alcohol is NOT
approved.
TwoStrokeOil-Atwo-strokeengineoilmeetingISO-L-EGD(ISO/CD
13738)and J.A.S.O. FC Standardsmustbe used. Echo brand premium
Power Blend TM Universal 2-Stroke Oil meets these standards. Engine
problems due to inadequate lubrication caused by failure to use an ISO-
L-EGDandJ.A.S.O.FCcertifiedoil,suchasEchopremiumPowerBlend
TM, will void the two-stroke engine warranty. (Emission related parts
only are covered for two years, regardless of two-stroke oil used, per
the statement listed in the Emission Defect Warranty Explanation.)
IMPORTANT
EchopremiumPowerBlendTM Universal2-StrokeOilmaybemixed
at 50:1 ratio for application in all Echo engines sold in the past
regardless of ratio specified in those manuals.
Mixing Instructions
1. Fill an approved fuel container with half of the required amount of
gasoline.
2. Add the proper amount of 2-stroke oil to gasoline.
3. Close container and shake to mix oil with gasoline.
4. Addremaininggasolineandremix.
5. Install fuel container cap and wipe any spilled fuel from container
and surrounding area.
Handling Fuel
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling or serious personal injury may result.
• Use an approved fuel container.
• DONOTsmokenearfuel.
• DONOT allowflames orsparks nearfuel.
• Fuel tanks/cans may be under pressure. Always loosen fuel
caps slowly allowing pressure to equalize.
• NEVERrefuelaunitwhentheengineisHOT!
• NEVERrefuel aunit withthe enginerunning.
• DONOTfillfueltanksindoors.ALWAYSfillfueltanks
outdoors over bare ground.
• Securely tighten fuel cap after refueling.
• Inspect for fuel leakage. If fuel leakage is found, do not start or
operate unit until leakage is repaired.
oitaR1:05-xiMliOotleuF
.S.UCIRTEM
SAGLIOSAGLIO
snollaG.zo.lFretiL.cc
1
2
5
6.2
2.5
31
4
8
02
08
061
004

10
OPERATION
• Provide all operators of this equipment with the Operator's Manual
and instructions for safe operation.
• Before starting the unit, equip yourself and any other person working
within the 15 m (50 ft.) Safety Zone with the required Protective
Equipment and clothing.
STARTING COLD ENGINE
1. Stop Switch
Move stop switch button (A) away from the STOP position.
2. Throttle Position
Move throttle position lever (B) midway between idle and full
throttle positions.
3. Choke
Move choke (C) to "Cold Start" ( ) Position.
4. Primer
Pumpprimer bulb (D) until fuel is visible andflows freely in the
clear fuel tank return line. Pump bulb an additional 4 or 5 times.
IMPORTANT
Recoil starter: Use short pulls - only 1/2-2/3 of rope for starting.
Do not allow the rope to snap back in. Always hold the unit
firmly.
5. Recoil Starter
Place the unit on a flat, clear area. Firmly grasp throttle grip with
left hand and rapidly pull recoil starter handle/rope (E) until engine
fires(5pullsmaximum).
6. Choke
After engine fires (or 5 pulls), move choke lever to “Run” ( )
position and pull starter handle/rope until engine starts and runs.
Allow unit to warm up at idle for several minutes.
NOTE
If engine does not start with choke in “Run” position after 5 pulls,
repeat instructions 2- 5.
7. After engine warm up, gradually depress throttle trigger to
increase engine RPM to operating speed.
A
B
C
D
E

11
POWER BLOWER
OPERATOR'SMANUAL
STARTING WARM ENGINE
The starting procedure is the same as Cold Start except DO NOT close
the choke.
1. Stop Switch
Move stop switch button (A) away from the STOP position.
2. Throttle Position
Move throttle position lever (B) midway between idle and full
throttle positions.
3. Recoil Starter
Place the unit on a flat clear area. Firmly grasp throttle grip with
left hand and rapidly pull recoil starter handle/rope (E) until engine
fires.
IMPORTANT
Recoil starter: Use short pulls - only 1/2-2/3 of rope for starting.
Do not allow the rope to snap back in. Always hold the unit
firmly.
NOTE
If engine does not start after 5 pulls, use Cold Start Procedure.
STOPPING ENGINE
1. Throttle Trigger/Throttle Position Lever
Release throttle trigger (F). Move throttle position lever (B)
forward to idle position and allow engine to return to idle before
shutting engine off.
2. Stop Switch
Move stop switch (A) to "Stop" position.
WARNING DANGER
If engine does not stop when stop switch is moved to STOP
position, close choke - COLD START position - to stall engine.
Have your ECHO dealer repair stop switch before using blower
again.
A
F
A
B
E
B

12
OPERATING BLOWER
WARNING DANGER
Always wear safety glasses, hearing protection and a face filter
mask or serious personal injury may result. .
Do not point the blower pipe in the direction of people or pets.
Read the Safety Section carefully.
IMPORTANT
To avoid engine damage due to over-revving, do not block
blowerpipe.
1. Use only during appropriate hours.
2. Allow the engine to warm up at a fast idle for a few minutes.
3. Control engine speed with throttle trigger (A), or for continuous
use, set engine speed with throttle position lever (B). Rotate
throttle position lever forward for lower speed; back for higher
speed.
4. Use lower speed to blow debris from hard surfaces.
5. Additional speed may be necessary to clean debris, snow, etc.
from lawns and flower beds.
B
NOTE
Never use a higher speed setting than necessary to perform a task.
Remember, the higher the engine speed, the louder the blower noise.
Minimize dust by using blower at lower speeds. Keep debris on
your property.
Be Smart - be a good neighbor.
A

13
POWER BLOWER
OPERATOR'SMANUAL
/TNENOPMOC
METSYS
ECNANETNIAM
ERUDECORP
D'QER
LLIKS
LEVEL
YLIAD
RO
EROFEB
ESU
YREVE
LEUFER
3
SHTNOM
09RO
SRUOH
6
SHTNOM
072RO
SRUOH
YLRAEY
serudecorPecnanetniaMrelaeDohcEdednemmoceR
troPtsuahxErednilyCnobraceD/naelC/tcepsnI 3C/I
serudecorPecnan
etniaMflesruoY-tI-oD
retliFriAecalpeR/naelC/tcepsnI 1C/I*R
ekohCnaelC/tcepsnI 2C/I
retliFleuFecalpeR/tcepsnI 1I*
R
skaeL,metsySleuFecalpeR/tcepsnI 1I*R/I
metsySgnilooCnaelC/tcepsnI 2C/I
rotserrAkrapSrelffuMecalpeR/tcepsnI 2*
R/I
epoRretratSlioceRnaelC/tcepsnI 1C/I*R/I
gulPkrapSnaelC/tcepsnI 2C/I*R
stloB/stuN/swercSecalpeR/nethgiT/tcep
snI 1*R/I
SEDOCRETTELERUDECORPECNANETNIAM NAELC=C,ECALPER=R,TCEPSNI=I:
-ETONTNATROPMI deriuqerfoycneuqerfehtenimretedlliwecneirepxeruoydnaesulaut
cA.mumixameranwohsslavretniemiT
.ecnanetniam
:SETONERUDECORPECNANETNIAM
*.noitcepsnignirudraewroegamadfognidnifehtnodesaberaecalperotsnoitadnemmocerllA
MAINTENANCE
Your ECHO blower is designed to provide many hours of trouble free service. Regular scheduled maintenance will help
your blower achieve that goal. If you are unsure or are not equipped with the necessary tools, you may want to take your
unit to an ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the
ECHO Dealer do it, each maintenance task has been graded. If task is not listed, see your ECHO Dealer for repairs.
SKILL LEVELS
Level1= Easy to do. Most required tools come with unit.
Level2= Moderate difficulty. Some specialized tools may be required.
Level3= Experiencerequired.Specializedtoolsarerequired.Echorecommends
that the unit be returned to your ECHO dealer for service.
ECHO offers REPOWERTM Maintenance Kits and Parts to make your maintenance job easier. Just below each task
heading are listed the various part numbers required for that task. See your ECHO dealer for these parts.
MAINTENANCE INTERVALS

14
AIR FILTER
Level1.
Tools required: 25-50mm(1-2in.)Cleaningbrush.
Parts required: 90008REPOWERTM AirandFilterKit
NOTE
Cleandaily.
1. Close choke (Cold Start Position). This prevents dirt from
entering the carburetor throat when the air filter is removed.
Brushaccumulated dirt from the air cleaner area.
2. Remove the air cleaner cover. Clean and inspect the element for
damage. If element is fuel soaked and very dirty, replace.
3. If element can be cleaned and reused, be certain it:
•still fits the cavity in the air cleaner cover.
•is installed with the original side out.
FUEL FILTER
Level1.
Tools required: 200-250mm(8-10in.)lengthofwirewithoneendbent
into a hook, Clean rag, funnel, and an approved fuel
container.
Parts required: 90008REPOWERTM AirandFilterKit
WARNING DANGER
FuelisVERYflammable.Useextremecarewhenmixing,storingor
handling.
1. Use a clean rag to remove loose dirt from around fuel cap and
emptyfuel tank.
2. Use the “fuel line hook” to pull the fuel line and filter from the
tank.
3. Removethe filter fromthe line and installthe new filter.

15
POWER BLOWER
OPERATOR'SMANUAL
SPARK PLUG
Level2.
Tools required: 3/4 in. Spark Plug deep socket, Feeler gauge
Parts Required: REPOWERTM Tune-UpKitP/N90074
1. Remove spark plug and check for fouling, worn and rounded
center electrode.
2. Clean the plug or replace with a new one. DO NOT sand blast to
clean.Remainingsandwilldamageengine.
3. Adjust spark plug gap by bending outer electrode.
4. Tightensparkplugto145-155kg/cm(125-135in.lb.).
COOLING SYSTEMS CLEANING
Level2.
Tools required: 25-50mm(1-2in.)Cleaningbrush,3mmHex
Wrench, Cross Head Screwdriver
Parts Required: None, if you are careful.
IMPORTANT
To maintain proper engine operating temperatures, cooling air must
pass freely through the cylinder fin area. This flow of air carries
combustion heat away from the engine.
Overheating and engine seizure can occur when:
• Air intakes are blocked, preventing cooling air from reaching the
cylinder.
• Dust and grass build up on the outside of the cylinder. This build up
insulates the engine and prevents the heat from leaving.
Removal of cooling passage blockages or cleaning of cooling fins is
considered “Normal Maintenance”. Any failure attributed to lack of
maintenance is not warranted.
Cleaning Grill
1. Brush accumulated debris from crankcase intake grill above the
fueltank.
INTAKE
GRILL
0.65 mm
(0.026 in.)

16
Cleaning Cylinder Fins
1. Remove spark plug lead and spark plug.
2. Removetwo upper 3 mm hex screws at recoil starter.
3. Remove engine cover (five screws), pull cover away from engine.
Loosely install spark plug to prevent dirt from entering cylinder.
Clean cylinder fins to allow cooling air to pass freely.
4. Remove spark plug and loosely reassemble engine cover with five
cross head and two hex head screws.
5. Tighten all screws securely.
6. Install spark plug and spark plug lead.
EXHAUST SYSTEM
Spark Arrestor Screen
Level2.
Tools required: CrossHeadScrewdriver,3mmHexWrench,25-50mm
(1-2in.)Cleaningbrush
Parts Required: Spark arrestor screen, Gasket
IMPORTANT
Carbon deposits in muffler will cause a drop in engine output and
overheating. Spark arrestor screen must be checked periodically.
1. Remove spark lead and spark plug.
2. Removetwo upper 3 mm hex screws at recoil starter.
3. Remove five engine cover screws and remove cover from engine.
Clean cylinder fins with brush to allow cooling air to pass freely.
4. Remove spark arrestor cover (A, B), gasket (C) and spark arrestor
screen(D) from muffler. Replace screen if plugged with carbon
deposits.
5. Install spark arrestor screen, gaskets, and cover.
6. Loosely reassemble engine cover with five cross head and two hex
head screws.
7. Tighten all screws securely.
8. Install spark plug and spark plug lead.
DCB
A

17
POWER BLOWER
OPERATOR'SMANUAL
Cylinder Exhaust Port
Level3.
IMPORTANT
The cylinder exhaust port must be inspected and cleaned of excess
carbon every 3 months or 90 hours of operation in order to maintain
this engine within the emissions durability period. ECHO strongly
recommends that you return your unit to your ECHO dealer for this
importantmaintenance service.
CARBURETORADJUSTMENT
Engine Break-In
New engines must be operated a minimum duration of two tanks of fuel
break-in before carburetor adjustments can be made. During the break-in
period your engine performance will increase and exhaust emissions will
stabilize. Idle speed can be adjusted as required.
High Altitude Adjustment
High altitude adjustment is not required for proper operation of this
engine.
Level2.
Tools required: Screwdriver,tachometer(EchoP/N99051130017)
Parts required: None.
NOTE
Every unit is run at the factory and the carburetor is set in compli-
ance with emission regulations. This carburetor does not have
acceleration and high speed adjustment needles.
1. Before adjusting the carburetor, clean or replace the air filter and
spark arrestor screen and blower pipes are installed.
2. Start engine and run for several minutes to reach operating
temperature.
3. Stop engine. Turn red HI speed needle (A) CCW (counter
clockwise) to stop.
4. Idle Speed Adjustment with tachometer.
•Start engine and turn “idle” speed adjustment screw (B) to idle
RPM found on page 8 in the "Specifications" section of this
manual.
5. Accelerate to full throttle for 2-3 seconds to clear excess fuel from
engine then return to idle. Accelerate to full throttle to check for
smooth transition from idle to full throttle. If engine stops or stalls
after full warm up return the unit to your authorized ECHO dealer
forrepair.
6. Check HI speed RPM at W.O.T. (Wide Open Throttle). HI speed
RPM should be set to specifications found on page 8 "Specifica-
tions" of this manual.
7. Check idle speed and reset if necessary.
A
B

18
WARNING DANGER
Fuel vapors are extremely flammable and may cause fire and/or explosion. Never test for ignition spark by ground-
ing spark plug against cylinder, otherwise serious personal injury may result.
TROUBLESHOOTING
TRAHCGNITOOHSELBUORT
melborPkcehCsutatSesuaCydemeR
-sknarcenignE
/drahstrats
t'nseod
trats
roterubractaleuFroterubractaleufoNdeggolcreniartsleuF
deggolcenilleu
F
roterubraC
ecalperronaelC
ecalperronaelC
relaedohcEruoyeeS
rednilyctaleuFrednilyctaleufoNroterubraCrelaedoh
cEruoyeeS
leufhtiwtewrelffuMhcirooterutxiMleuFekohcnepO
retlifriaecalper/naelC
roterubractsujdA
relaedohcEr
uoyeeS
dnetakrapS
eriwgulpfo
krapsoNffohctiwspotS
melborplacirtcelE
hctiwskcolretnI
NOothctiwsnruT
relaedohcE
ruoyeeS
relaedohcEruoyeeS
gulptakrapSkrapsoNtcerrocnipagkrapS
nobrachtiwderevoC
leufhtiwdeluoF
evitcefedgulP
).ni620.0(mm56.ottsujdA
ecalperronaelC
ecalperronaelC
gulpecalpeR
,snurenignE
roseidtub
tonseod
etarelecca
yl
reporp
retlifriAytridretlifriAraewlamroNecalperronaelC
retlifleuFytridretlifleuFseudiser/stnanimatnoCni
leuf
ec
alpeR
tnevleuFdeggulptnevleuFleufniseudiser/stnanimatnoCecalperronaelC
gulPkrapSnrow/ytridgulPraewlamroNecalp
errotsujdadnanaelC
roterubraCtnemtsujdareporpmInoitarbiVtsujdA
metsySgnilooCmetsysgnilooC
deggulp/ytrid
ninoi
tarepodednetxE
snoitacolytsud/ytrid
naelC
neercSrotserrAkrapSneercsrotserrakrapS
deggulp
raewlamroNecalpeR
se
odenignE
knarcton
A/NA/NmelborpenignelanretnIrelaedohcEruoyeeS
,snurenignE
t'nseodrewolb
sirokrow
nevenu/kaew
e
piprewolBdeggolcepiPsirbedfopu-dliuBgolcnU
esoolepiPnoitarbiVnethgiT
degamadepiPesusiM/raeWecalpeR

19
POWER BLOWER
OPERATOR'SMANUAL
STORAGE
WARNING DANGER
During operation the muffler or catalytic muffler and surrounding cover becomes hot. Always keep exhaust area
clear of flammable debris during transportation or when storing, otherwise serious property damage or personal
injurymayresult.
Long Term Storage (Over 30 Days)
Do not store your unit for a prolonged period of time (30 days or longer) without performing protective storage mainte-
nance which includes the following:
1. Store unit in a dry, dust free place, out of the reach of children.
WARNING DANGER
Do not store where fuel fumes may accumulate or reach an open flame or spark.
2. Place the stop switch s in the "STOP" position.
3. Remove accumulation of grease, oil, dirt and debris
fromexteriorofunit.
4. Perform all periodic lubrication and services that are
required.
5. Tighten all screws and nuts.
6. Drainthe fueltank completelyand pullthe recoil
starter handle several times to remove fuel from the
carburetor.
7. Remove the spark plug and pour 7cc (1/4 oz.) of
fresh, clean ECHO 2-stroke engine oil into the
cylinder through the spark plug hole.
A. Place a clean cloth over the spark plug hole.
B. Pull the recoil starter handle 2-3 times to
distribute the oil inside the engine.
C. Observe the piston location through the spark
plug hole. Pull the recoil handle slowly until the
piston reaches the top of its travel and leave it
there.
8. Install the spark plug (do not connect ignition
cable).
9. Removeblowerpipe assemblyfromunit.

DEALER?
Call
1-800-432-ECHO
or
www.echo-usa.com
CONSUMER PRODUCT
SUPPORT
1-800-673-1558
8:30 - 4:30 Mon - Fri C.S.T.
SERVICINGINFORMATION
PARTS
GenuineECHOPartsandECHOREPOWER™PartsandAssembliesfor
yourECHO productsare availableonly froman AuthorizedECHO
Dealer. When you do need to buy parts always have the Model
Number and Serial Number of the unit with you. You can find these
numbers on the engine housing. For future reference, write them in the
space provided below.
Model No. _____________ SN. ____________
SERVICE
Service of this product during the warranty period must be performed
by an Authorized ECHO Service Dealer. For the name and address of
the Authorized ECHO Service Dealer nearest you, ask your retailer or
call:1-800-432-ECHO(3246). Dealerinformationisalsoavailableonour
Web Site. When presenting your unit for Warranty service/repairs,
proof of purchase is required.
ECHO CONSUMER PRODUCT SUPPORT
If you require assistance or have questions concerning the application,
operation or maintenance of this product you may call the ECHO
ConsumerProductSupportDepartmentat1-800-673-1558from8:30am
to4:30 pm(Central Standard Time)Monday through Friday.Before
calling, please know the model and serial number of your unit to help
your Consumer Product Support Representative.
WARRANTYREGISTRATION
You may register your Echo equipment using the warranty registration
card or register on-line at www.echo-usa.com. Registering provides a
direct link between you and ECHO if we find it necessary to contact
you.
ECHO, INCORPORATED
400OAKWOODROAD
LAKEZURICH,IL 60047-1564
www.echo-usa.com
ADDITIONAL OR REPLACEMENT MANUALS
SafetyManuals in English/Spanishor English/Frenchare available,freeofcharge,fromyourECHO dealeror at
www.echo-usa.com.
Operator’sandPartsManualsareavailableby:
• Downloadingfreefromwww.echo-usa.com
• Purchasingfrom yourEcho Dealer.
• Manuals are available by sending a written request stating the model number and serial number of your Echo unit,
part number of the manual, your name and address, and mail to the address below.
SafetyVideos are available from your Echo dealer.A$5.00 shipping charge will be required for eachvideo.
08001001/08999999
