Echo Smartpen User manual

SMARTPEN HARDWARE
Processor ARM 9
Screen 96 x18 OLED display
Camera High speed infrared camera (>70 images/sec)
Storage 2GB NAND
(over 200 hours recording time)1
Battery Rechargeable lithium (non-removable)
Record Smartpen embedded microphone -
mono recording
Playback Embedded speaker
Standard 3.5 mm audio jack
PC Connectivity Micro USB cable (charging & data transfer)
Size & Weight Length: 158 mm (6.22 in.)
Width: 19.7 mm (0.78 in.) at top
11.5 mm (0.45 in.) at tip
Weight: 36 grams (1.3 oz.) no cap
BUNDLED SMARTPEN SOFTWARE
Paper Replay Record and replay synchronized
ink and audio
Paper Replay Password Prevent access to your recorded
audio
Notes Ink capture (without audio)
Quick Record Quick-access audio recording
Printed Calc Scientific calculator
Quick Calc Simple calculator that can be
used on any Livescribe dot paper
Other Utilities Multi-language support, Time,
Date, Storage, and Battery
LIVESCRIBE™DESKTOP SOFTWARE
• Search, view and replay notes
• Export your notes and audio file
• Open and play back pencasts shared with you
• Print your own notebooks on qualified printers2
• Available as free software download
MAC SYSTEM REQUIREMENTS
• Mac OS®X version 10.8 or later
• 300 MB of available disk space
• An available USB 2.0 port
• An internet connection
WINDOWS®SYSTEM REQUIREMENTS
• Windows 7, Windows 8, or later
• 300 MB of available disk space
• An available USB 2.0 port
• An internet connection
1Actual available memory will be less. Recording time varies by audio quality setting. 2Must be Adobe PostScript compatible, 600dpi, color laser printer. 0114 - Rev. B - USACAN
AUDIO JACKPOWER BUTTONREPLACEABLE
INK TIP
BUILT-IN SPEAKER OLED DISPLAY MICRO USB CONNECTOR
ANTI-ROLL DESIGN MICROPHONE
