Echo BEAR CAT PW2014E User manual

operator’smanual
ELECTRIC
PRESSURE
WASHER
PW2014E
WARNING: This product can expose you to
chemicals including lead, which is known to the
State of California to cause cancer and birth
defects or other reproductive harm. For more
information, go to www.P65Warnings.ca.gov.
Wash hands after handling.

2
TAbLE of ConTEnTS
Introduction
4 Using the Operator’s Manual
Product Identification
5 Pressure Washer
Safety
6 Safety Rules
Electric Washer Components
9 Component Chart
Specifications
10 Specifications of the unit
Assembly
11 Preparation
12 Assembly
Operation
16 How to Start your Pressure Washer
17 Use of detergent

3
TAbLE of ConTEnTS
Maintenance
19 Cleaning & Storage
20 GFCI plug
21 Pump saver
Troubleshooting
22 Troubleshooting Chart
Replacement parts
23 List of replacement parts
Warranty
24 Warranty coverage
25 Warranty process

4
Using the Operator’s Manual
The operator’s manual is an important part of your electric pressure
washer and should be read thoroughly before initial use, and referred to
often to make sure adequate safety and service concerns are being ad-
dressed.
Reading the operator’s manual thoroughly will help avoid any personal
injury or damage to your machine. The information in this manual will offer
you the most effective tools for cleaning as well as the safest. By know-
ing how best to operate this machine you will be better positioned to
show others who may also operate the unit.
This manual contains information for the electric pressure washer, and
is placed in order starting from the safety requirements to the operating
functions of your machine. You can refer back to the manual at any time
to help troubleshoot any specific operating functions, so store it with the
machine at all times.
Attention: Read through the complete
manual prior to the initial use of your
electric pressure washer.
InTRodUCTIon

5
PRodUCT IdEnTIfICATIon
Record Identification Numbers
Pressure Washer
If you need to contact an Authorized Dealer or Customer Service
for information on servicing, always provide the product model and
identification numbers.
You will need to locate the model and serial number for the machine and
record the information in the places provided below.
Date of Purchase:
Dealer Name:
Dealer Phone:
Product Identification Numbers
Model Number:
Serial Number:

6
SAfETy
This manual contains information that relates to PROTECTING PERSONAL
SAFETY and PREVENTING EQUIPMENT PROBLEMS. It is very important to read
this manual carefully and understand it thoroughly before using the product. The
symbols listed below are used to indicate this information.
DANGER indicates a potential hazard that will result in serious injury or loss
of life.
WARNING indicates a hazard that could result in serious injury or loss of life.
CAUTION indicates a potential hazard that may result in moderate injury or
damage to equipment.
NOTE is used to inform the reader of something the operator needs to know
about the tool.
WARNING
To reduce the risk of injury, the user must read and understand the instructions
before using this product.
1. Warning – When using this product basic, precautions should always be
followed, including the following:
2. Read all the instructions before using the product.
3. Know how to stop the product and bleed pressures quickly. Be thoroughly
familiar with the controls.
4. Keep operating area clear of persons.
5. Do not overreach or stand on unstable support. Keep good footing and
balance at all times.
6. Follow the maintenance instructions as specified in the manual.
7. To avoid personal injury and/or damage to property and to maximize your
power washing experience, carefully follow all of the safety tips, instructions,
warnings and safeguards and become familiar with all of the controls.
Save these Instructions
Safety Rules
This is the safety alert symbol. It is
used to alert you to potential personal
injury hazards. Obey all safety
messages that follow this symbol to
avoid possible injury or death.

7
SAfETy
8. This power washer conforms to CSA and other safety and consumer
standards. DO NOT modify or rebuild any part of your power washer.
9. DO NOT use your power washer when you are under the influence of alcohol
or drugs. Use this power tool carefully and only when you are alert.
10. Watch your balance and footing while using your power washer. Surfaces
become slippery when wet and are extra slippery when using a detergent or
cleaner.
11. NEVER operate the power washer in bare feet, sandals, or open-toed shoes.
12. When using the power washer near children, make sure they are closely
supervised by an adult to avoid injury. NEVER let a child use the power
washer.
13. Keep fingers, hands, feet and any part of your body clear of the stream of high
pressure water. The powerful spray can cause blindness or injuries. It can
break a window if you are too close when you pull the trigger on the
spray gun.
14. ALWAYS wear eye protection to prevent injury to eyes when operating the
power washer.
15. To avoid mishaps or injury, ALWAYS use the trigger safety lock when not
using the power washer even if the spraying stops for a moment.
16. The power washer is equipped with a Ground Fault Circuit Interrupter (GFCI)
which greatly reduces the chance of electric shock while the unit is in use.
If replacement of the plug or cord is needed, use only identical replacement
parts.
17. Point the spray gun in a safe direction when using the power washer.
18. NEVER spray directly at a person, animal, electrical device or the unit itself.
19. When first using the spray gun, hold the spray gun and lance with two hands
when pulling the trigger (one hand to pull the trigger and the other to stabilize
the gun assembly) until you get used to the “kickback” from the spray gun.
20. When you press the power switch to turn off the power washer, water
pressure may remain in the system. To discharge the pressure, point the spray
gun in a safe direction and pull the trigger.
21. NEVER spray flammable liquids.
22. NEVER use the power washer in areas that contain combustible dust, liquids
or vapors.
23. Avoid contact of the pressure hose with sharp objects and examine the hose
regularly. Replace if damaged. Due to the high pressure involved, it cannot be
repaired if cut or damaged.

8
SAfETy
24. Only use detergent specifically formulated for power washers and follow
instructions on the detergent’s label. Dish or laundry soap is too thick and will
clog the nozzle of your detergent bottle.
25. Protect eyes, lungs, and skin from exposure to detergent.
IMPORTANT: Store the power washer indoors to prevent the water in the unit
from expanding under freezing conditions. When the water freezes and expands,
your power washer will be damaged and become inoperable. Or, if storing
outdoors, it is recommended you use pump saver (not included) to protect
pumps.
26. NEVER use hot water with your power washer. It will overheat and damage
the high pressure pump.
27. NEVER leave the power washer unattended while it is powered “ON”.
28. ALWAYS turn the water supply “ON ” before turning the power washer
power to “ON”. Running the pump dry will cause damage to the internal
components.
29. NEVER use a water supply to your power washer that exceeds 150 PSI
maximum.
30. NEVER disconnect the high pressure hose from the power washer while the
system is pressurized.
31. NEVER permanently engage the trigger mechanisms on the spray gun.
32. NEVER operate the power washer unless all components are properly and
securely connected.
33. NEVER allow the power washer pump to run for more than one minute after
you have turned off the water supply. This can cause the motor and pump to
overheat and fail.
34. NEVER use lances or other parts that are not compatible for this specific
ECHO Bear Cat unit.
35. NEVER use an extension power cord since it defeats the effectiveness of the
GFCI and increases the chance of electrocuting the operator.
36. NEVER spray any electrical outlet with your power washer.
37. Inspect the power cord before using. DO NOT use it if it is damaged.

9
ELECTRIC
WASHER ComPonEnTS
Part Description Quantity
APower Washer Unit 1
BHigh Pressure Hose 1
CNozzle Cleaning Wire 1
DRotary Nozzle 1
EQuick Connect Nozzles 3
FZinc Steel Lance 1
GSpray Gun 1
HSpray Gun Trigger Lock Button 1
INozzle Tray 1
JSpray Gun Holster 1
KO-Ring Kit 1
LNozzle Holder (does not include nozzles) 1
AA Screws 2
0°– Red
25° – Green
Soap – Black
L
O-Rings
AA
GH
C
F
D
M
A
I
B
K
J
E
E
F G
H
I
J
K
L
A
B
C
D

10
SPECIfICATIonS
Specifications
Model PW2014E
Rated PSI (lbs/sq.) 2000
Max GPM (gal/per min) 1.4
Cold Water Yes
Volts 120
Amps 14
Weight (lb) 30.2

11
PREPARATIon
Before beginning assembly of product, make sure all parts are present.
Compare parts with package contents list and hardware contents list.
If any part is missing or damaged, DO NOT attempt to assemble the
product.
Estimated Assembly Time: 5 minutes
Tools Required for Assembly (not included): Phillips screwdriver and
5/16" (8 mm) hex key.

12
ASSEmbLy
Power Unit Assembly
Slide the spray gun holster (K) onto
left side, when facing the unit of
power washer unit (A).
Note: When placing the gun with
the lance attached, the nozzle will
rest in this tray.
Slip tab into slot and screw the
nozzle tray (J) on bottom left, when
facing the unit, of power washer
unit (A). Secure with screw (AA).
Note: DO NOT use a power screw-
driver. When the screw is completely
tight, give a small final clockwise
twist of the screwdriver.
DO NOT overtighten.
Hardware Used:
1
K
A
Screw 1X
AA
AA
Screw
Qty. 2
2
A
J
AA

13
ASSEmbLy
Slip tab of stabilizer foot (E) into
slot on bottom right, when facing
the unit, of power washer unit (A).
Secure with screw (AA).
Hardware Used:
High Pressure Hose Assembly
Connect the other end of high
pressure hose (B) to spray gun (H)
by screwing collar over gun inlet.
Hand tighten (turning clockwise)
until tight. Hose is now securely
attached to the spray gun.
Note: High pressure hose (B) is
fitted to the hose reel and ready to
use. It only needs to be attached to
the spray gun (H).
To release the hose (B) from spray
gun (H), turn black collar counter-
clockwise. Remove gun.
7
ASSEMBLY INSTRUCTIONS
3
E
AA
A
4
B
H
High Pressure Hose Assembly
Connect the other end of high pressure hose (B) to
spray gun (H) by screwing collar over gun inlet. Hand
tighten (turning clockwise) until tight. Hose is now
securely attached to the spray gun.
Note: High pressure hose (B) is tted to the hose reel
and ready to use. It only needs to be attached to the
spray gun (H).
Slip tab of stabilizer foot (E) into slot on bottom
righ, when facing the unit, of power washer unit (A).
Secure with screw (AA).
5
B
H
To release the hose (B) from spray gun (H), turn black
collar counterclockwise. Remove gun.
Screw x 1
AA
AA
Screw
Qty. 2
Hardware Used:
7
ASSEMBLY INSTRUCTIONS
3
E
AA
A
4
B
H
High Pressure Hose Assembly
Connect the other end of high pressure hose (B) to
spray gun (H) by screwing collar over gun inlet. Hand
tighten (turning clockwise) until tight. Hose is now
securely attached to the spray gun.
Note: High pressure hose (B) is tted to the hose reel
and ready to use. It only needs to be attached to the
spray gun (H).
Slip tab of stabilizer foot (E) into slot on bottom
righ, when facing the unit, of power washer unit (A).
Secure with screw (AA).
5
B
H
To release the hose (B) from spray gun (H), turn black
collar counterclockwise. Remove gun.
Screw x 1
AA
AA
Screw
Qty. 2
Hardware Used:
7
ASSEMBLY INSTRUCTIONS
3
E
AA
A
4
B
H
High Pressure Hose Assembly
Connect the other end of high pressure hose (B) to
spray gun (H) by screwing collar over gun inlet. Hand
tighten (turning clockwise) until tight. Hose is now
securely attached to the spray gun.
Note: High pressure hose (B) is tted to the hose reel
and ready to use. It only needs to be attached to the
spray gun (H).
Slip tab of stabilizer foot (E) into slot on bottom
righ, when facing the unit, of power washer unit (A).
Secure with screw (AA).
5
B
H
To release the hose (B) from spray gun (H), turn black
collar counterclockwise. Remove gun.
Screw x 1
AA
AA
Screw
Qty. 2
Hardware Used:
Screw 1X
AA
AA
Screw
Qty. 2

14
ASSEmbLy
Locking Spray Gun (before Lance
installation)
To lock the trigger of the spray gun (I), aim
the gun away from you and push the lock
button from right to left. After doing so,
squeeze or pull the trigger to make sure it is
locked and will not move. Always leave lock
button in locked position when not in use.
This ensures the gun is in “safe” mode until
it is ready for use.
Lance Installation
While spray gun (H) is in the locked posi-
tion, insert lance (G) into the end of spray
gun by inserting and turning clockwise until
fully in place. To remove turn counterclock-
wise.
Attach nozzles (F) into end of lance (G) by
pressing selected nozzle into place. It will
make a “click” sound when firmly in place.
Note: Always push safety lock button to
lock trigger when changing lances and
nozzles to ensure that they do not acciden-
tally eject with force during removal.
To remove nozzle (F), pull back on collar of
lance (G) and pull out nozzle.
8
PREPARATIONASSEMBLY INSTRUCTIONS
6
H
I
H
Lock
Unlock
I
Locking Spray Gun (before Lance installation)
To lock the trigger of the spray gun (I), aim the gun
away from you and push the lock button from right to
left. After doing so, squeeze or pull the trigger to make
sure it is locked and will not move. Always leave lock
button in locked position when not in use. This ensures
the gun is in “safe” mode until it is ready for use.
Lance Installation
While spray gun (H) is in the locked position, insert
lance (G) into the end of spray gun by inserting and
turning clockwise until fully in place. To remove
turn counterclockwise.
2
1
7
G
H
8
G
F
Attach nozzles (F) into end of lance (G) by pressing
selected nozzle into place. It will make a “click” sound
when rmly in place.
Note: Always push safety lock button to lock trigger
when changing lances and nozzles to ensure that they
do not accidentally eject with force during removal.
9
G
F
1
2
To remove nozzle (F), pull back on collar of lance (G)
and pull out nozzle.
8
PREPARATIONASSEMBLY INSTRUCTIONS
6
H
I
H
Lock
Unlock
I
Locking Spray Gun (before Lance installation)
To lock the trigger of the spray gun (I), aim the gun
away from you and push the lock button from right to
left. After doing so, squeeze or pull the trigger to make
sure it is locked and will not move. Always leave lock
button in locked position when not in use. This ensures
the gun is in “safe” mode until it is ready for use.
Lance Installation
While spray gun (H) is in the locked position, insert
lance (G) into the end of spray gun by inserting and
turning clockwise until fully in place. To remove
turn counterclockwise.
2
1
7
G
H
8
G
F
Attach nozzles (F) into end of lance (G) by pressing
selected nozzle into place. It will make a “click” sound
when rmly in place.
Note: Always push safety lock button to lock trigger
when changing lances and nozzles to ensure that they
do not accidentally eject with force during removal.
9
G
F
1
2
To remove nozzle (F), pull back on collar of lance (G)
and pull out nozzle.
8
PREPARATIONASSEMBLY INSTRUCTIONS
6
H
I
H
Lock
Unlock
I
Locking Spray Gun (before Lance installation)
To lock the trigger of the spray gun (I), aim the gun
away from you and push the lock button from right to
left. After doing so, squeeze or pull the trigger to make
sure it is locked and will not move. Always leave lock
button in locked position when not in use. This ensures
the gun is in “safe” mode until it is ready for use.
Lance Installation
While spray gun (H) is in the locked position, insert
lance (G) into the end of spray gun by inserting and
turning clockwise until fully in place. To remove
turn counterclockwise.
2
1
7
G
H
8
G
F
Attach nozzles (F) into end of lance (G) by pressing
selected nozzle into place. It will make a “click” sound
when rmly in place.
Note: Always push safety lock button to lock trigger
when changing lances and nozzles to ensure that they
do not accidentally eject with force during removal.
9
G
F
1
2
To remove nozzle (F), pull back on collar of lance (G)
and pull out nozzle.
8
PREPARATIONASSEMBLY INSTRUCTIONS
6
H
I
H
Lock
Unlock
I
Locking Spray Gun (before Lance installation)
To lock the trigger of the spray gun (I), aim the gun
away from you and push the lock button from right to
left. After doing so, squeeze or pull the trigger to make
sure it is locked and will not move. Always leave lock
button in locked position when not in use. This ensures
the gun is in “safe” mode until it is ready for use.
Lance Installation
While spray gun (H) is in the locked position, insert
lance (G) into the end of spray gun by inserting and
turning clockwise until fully in place. To remove
turn counterclockwise.
2
1
7
G
H
8
G
F
Attach nozzles (F) into end of lance (G) by pressing
selected nozzle into place. It will make a “click” sound
when rmly in place.
Note: Always push safety lock button to lock trigger
when changing lances and nozzles to ensure that they
do not accidentally eject with force during removal.
9
G
F
1
2
To remove nozzle (F), pull back on collar of lance (G)
and pull out nozzle.

15
M
10
ASSEmbLy
Attach garden hose to the collar of garden
hose adapter.
Note: Flush out garden hose before con-
necting to garden hose adapter.
You have now completed assembly and
are ready to begin using your electric
power washer. Read and observe all
safety instructions.
Return the nozzle back to the nozzle
holder (M) for storage.
Note: The nozzle holder can be at-
tached on the machine using the
carabiner.
11
A

16
oPERATIng
Operating Instructions
• Turn on water supply at the faucet to
completely open.
• Make sure the “ON/OFF” switch is in
the “OFF” position. The power switch
has international symbols for ‘on’ and
‘off’: On (|) Off (O).
• Unwind the power cord completely
and plug the GFCI into a grounded
120 volt outlet.
• Release safety push trigger lock up
and back into trigger. While pointing
the spray gun in a safe direction, squeeze the trigger on the spray gun
until there is a steady stream of water, letting the water and air out of
the hose. Push trigger lock back down to lock back into place.
• Turn the power switch to the “ON”
(|) position. The unit will turn on for
1 - 2 seconds and shut off. This is a
normal function of the auto start fea-
ture. Squeeze the spray gun trigger
to begin pressure washing.
• Begin power washing by squeezing
the trigger on the spray gun all the
way into the handle.
• Release the spray gun trigger to stop the power washer
• Allow the motor to come to a complete stop before squeezing the trig-
ger again.
• Squeezing rapidly will cause the auto start feature to miss an on/off
cycle that may prevent it from turning on while squeezing trigger after
rapid squeezing. Use slow deliberate
trigger pulls to avoid such symptoms.
Always test a small area to avoid
chance of damaging the surface.
10
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• Turn on water supply at the faucet to completely
open.
• Make sure the “ON/OFF” switch is in the “OFF”
position. The power switch has international symbols
for ‘on’ and ‘off’: On (|) Off (O).
• Unwind the power cord completely and plug the GFCI
into a grounded 120 volt outlet.
• Release safety push trigger lock up and back into
trigger. While pointing the spray gun in a safe
direction, squeeze the trigger on the spray gun until
there is a steady stream of water, letting the water
and air out of the hose. Push trigger lock back down
to lock back into place.
OFF/0
ON/I
OFF/0
ON/I
• Turn the power switch to the “ON” (|) position. The
unit will turn on for 1 - 2 seconds and shut off. This is
a normal function of the auto start feature. Squeeze
the spray gun trigger to begin pressure washing.
• Begin power washing by squeezing the trigger on the
spray gun all the way into the handle.
• Release the spray gun trigger to stop the power
washer
• Allow the motor to come to a complete stop before
squeezing the trigger again.
• Squeezing rapidly will cause the auto start feature to
miss an on/off cycle that may prevent it from turning
on while squeezing trigger after rapid squeezing. Use
slow deliberate trigger pulls to avoid such symptoms.
• Always test a small area to avoid chance of damaging
the surface.
10
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• Turn on water supply at the faucet to completely
open.
• Make sure the “ON/OFF” switch is in the “OFF”
position. The power switch has international symbols
for ‘on’ and ‘off’: On (|) Off (O).
• Unwind the power cord completely and plug the GFCI
into a grounded 120 volt outlet.
• Release safety push trigger lock up and back into
trigger. While pointing the spray gun in a safe
direction, squeeze the trigger on the spray gun until
there is a steady stream of water, letting the water
and air out of the hose. Push trigger lock back down
to lock back into place.
OFF/0
ON/I
OFF/0
ON/I
• Turn the power switch to the “ON” (|) position. The
unit will turn on for 1 - 2 seconds and shut off. This is
a normal function of the auto start feature. Squeeze
the spray gun trigger to begin pressure washing.
• Begin power washing by squeezing the trigger on the
spray gun all the way into the handle.
• Release the spray gun trigger to stop the power
washer
• Allow the motor to come to a complete stop before
squeezing the trigger again.
• Squeezing rapidly will cause the auto start feature to
miss an on/off cycle that may prevent it from turning
on while squeezing trigger after rapid squeezing. Use
slow deliberate trigger pulls to avoid such symptoms.
• Always test a small area to avoid chance of damaging
the surface.
10
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• Turn on water supply at the faucet to completely
open.
• Make sure the “ON/OFF” switch is in the “OFF”
position. The power switch has international symbols
for ‘on’ and ‘off’: On (|) Off (O).
• Unwind the power cord completely and plug the GFCI
into a grounded 120 volt outlet.
• Release safety push trigger lock up and back into
trigger. While pointing the spray gun in a safe
direction, squeeze the trigger on the spray gun until
there is a steady stream of water, letting the water
and air out of the hose. Push trigger lock back down
to lock back into place.
OFF/0
ON/I
OFF/0
ON/I
• Turn the power switch to the “ON” (|) position. The
unit will turn on for 1 - 2 seconds and shut off. This is
a normal function of the auto start feature. Squeeze
the spray gun trigger to begin pressure washing.
• Begin power washing by squeezing the trigger on the
spray gun all the way into the handle.
• Release the spray gun trigger to stop the power
washer
• Allow the motor to come to a complete stop before
squeezing the trigger again.
• Squeezing rapidly will cause the auto start feature to
miss an on/off cycle that may prevent it from turning
on while squeezing trigger after rapid squeezing. Use
slow deliberate trigger pulls to avoid such symptoms.
• Always test a small area to avoid chance of damaging
the surface.

17
oPERATIng
When using the detergent, fill it with a
properly formulated detergent or cleaner
with water ratio according to instructions
on the container.
DO NOT use thick gel-like detergents, as
they will clog the power washer and can
cause damage.
The power washer will pull a ratio of water to detergent of 10:1 or 10
parts water to 1 part detergent.
• When removing the detergent tank, remove
lid and place finger on both sides of the
bottle and squeeze to get past the knobs
on each side and pull out. Press down
firmly when putting it back in place.
Operating Tips
• If you hear the motor run intermittently when the trigger is not being
squeezed, that is normal. The pump is priming itself so it is ready to
operate when the trigger is squeezed. Turn off the power washer if not
being used after five minutes.
• Keep the nozzle cleaning wire for use in unclogging the lance nozzle. If
you lose the cleaning wire, a straightened paper clip also works.
11
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• When using the detergent, ll it with a properly
formulated detergent or cleaner with water ratio
according to instructions on the container.
• DO NOT use thick gel-like detergents, as they will clog
the power washer and can cause damage.
• When removing the detergent tank, remove lid and
place nger on both sides of the bottle and squeeze
to get past the knobs on each side and pull out. Press
down rmly when putting it back in place.
The power washer will pull a ratio of water to detergent
of 10:1 or 10 parts water to 1 part detergent. The
detergent concentration can be adjusted by turning the
detergent knob on the front of the machine. Turn it right
for more concentration or turn it left for
less concentration.
11
OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS
• When using the detergent, ll it with a properly
formulated detergent or cleaner with water ratio
according to instructions on the container.
• DO NOT use thick gel-like detergents, as they will clog
the power washer and can cause damage.
• When removing the detergent tank, remove lid and
place nger on both sides of the bottle and squeeze
to get past the knobs on each side and pull out. Press
down rmly when putting it back in place.
The power washer will pull a ratio of water to detergent
of 10:1 or 10 parts water to 1 part detergent. The
detergent concentration can be adjusted by turning the
detergent knob on the front of the machine. Turn it right
for more concentration or turn it left for
less concentration.

18
oPERATIng
How to Avoid Damaging Surfaces
Damage to surfaces being cleaned occurs because the impact force of
the water pressure exceeds the durability of the surface. Bare wood can
be penetrated; paint can be peeled off, etc. You can vary the force of your
power washer by controlling:
1. The angle of the surface being cleaned
2. The distance of the nozzle from the surface being cleaned
NEVER use a narrow high pressure stream of water on soft surfaces
susceptible to damage.
Use the 25°angle quick connect nozzle when cleaning windows. Be sure
to place the nozzle approximately four to five feet away from the window
with the nozzle at forty five degree angle. Squeeze the trigger and vary
the spray pattern and angle until optimum cleaning efficiency is achieved.
Detergents
• Use detergents designed for power washers. Contact your local ECHO
Bear Cat dealer to purchase an appropriate detergent. Hardware stores
or home centers also have power washer detergents for different clean-
ing projects. The cleaning solution should be the consistency of water in
order to prevent clogging your detergent bottle and nozzle.
• This system applies detergent under low pressure. The cleaning power
of the detergents is enhanced when applied with low pressure and
enough time is given to break down dirt and grime. The combination of
low pressure and chemical action is very effective and can be better
than scrubbing if applied properly. ALWAYS spray detergent on a dry
surface. DO NOT pre-soak area. Wetting the surface first dilutes the
detergent and reduces its cleaning ability. DO NOT allow detergent to
dry on surface. On vertical surfaces being cleaned, apply detergent to
lower surfaces and work your way up to prevent detergent from causing
streaks in the dirt and grime. Rinse detergent by pressure washing from
bottom up for same reason.
• If a stain is particularly tough, it may be necessary to reapply the de-
tergent and use a bristled brush to scrub the stain. Subsequent power
washing after brushing should successfully complete your cleaning job.
mAInTEnAnCE

19
mAInTEnAnCE
Cleaning Garden Hose Adapter
• The screens inside the garden hose
adapter should be cleaned periodically.
Rinse it with clean water, and then place
it back in the adapter.
Cleaning Nozzles
• A clogged or partially clogged nozzle
can cause significant reduction of water
pressure coming out of the nozzle and/or
cause the unit to pulsate while spraying.
• Turn off the unit.
• Turn off the water supply to the unit.
• Relieve any pressure trapped in the hose
by squeezing the trigger 2-3 times, and
then lock the spray gun.
• Using the nozzle tip cleaner provided
(or an unfolded paper clip), insert the
wire into the nozzle hole and move
back and forth until debris is dislodged.
• Back flush water through the nozzles
using garden hose and highest pres-
sure available.
Storage
• When your pressure washing ses-
sion has been completed, turn off the
power switch located on the front of
the power washer. Unplug the power cord from the outlet. Turn off the
water supply. Pull the trigger on the spray gun 2-3 times to drain out the
excess water and to release any remaining water pressure. Disconnect
the garden hose adapter from the water inlet. DO NOT allow the power
washer to run with no water flowing through it.
• Remove detergent bottle and clean completely. Residual chemical will
stick to the container and can cause the detergent injector to clog and
not function properly.
• Remove high pressure hose from spray gun.
• Remove lance from the gun. Place the gun in the holder on the side.
Lances are placed into any of the slots in the back of the unit. Make
sure to discard any remaining detergent from the bottle. Flush the bottle
and nozzle head with fresh water to prevent clogging.
• Hook the power cord around the L-shaped tab on the right side of the
machine when facing it.
13
OPERATING INSTRUCTIONS
13
OPERATING INSTRUCTIONSCARE AND MAINTENANCE
Cleaning Garden Hose Adapter
• The screens inside the garden hose adapter should
be cleaned periodically. Rinse it with clean water, and
then place it back in the adapter.
Cleaning Nozzles
• A clogged or partially clogged nozzle can cause
signicant reduction of water pressure coming out
of the nozzle and/or cause the unit to pulsate while
spraying.
• Turn off the unit.
• Turn off the water supply to the unit.
•Relieve any pressure trapped in the hose by
squeezing the trigger 2-3 times, and then lock the
spray gun.
• Using the nozzle tip cleaner provided (or an unfolded
paper clip), insert the wire into the nozzle hole and
move back and forth until debris is dislodged.
• Back ush water through the nozzles using garden
hose and highest pressure available (either standard
water nozzle or use your thumb over the nozzle to
create water pressure for back ush).
Storage
• When your pressure washing session has been
completed, turn off the power switch located on the
front of the power washer. Unplug the power cord
from the outlet. Turn off the water supply. Pull the
trigger on the spray gun 2-3 times to drain out the
excess water and to release any remaining water
pressure. Disconnect the garden hose adapter from
the water inlet. DO NOT allow the power washer to
run with no water owing through it.
• Remove detergent bottle and clean completely.
Residual chemical will stick to the container and can
cause the detergent injector to clog and not function
properly.
• Remove high pressure hose from spray gun.
• Remove lance from the gun. Place the gun in the
holder on the side. Lances are placed into any of the
slots in the back of the unit. Make sure to discard
any remaining detergent from the bottle. Flush the
bottle and nozzle head with fresh water to prevent
clogging.
•Hook the power cord around the L-shaped tabs on
the right side of the machine when facing it.
A

20
mAInTEnAnCE
Servicing of a Double-Insulated Appliance
Ground Fault Circuit Interrupter Protection:
This pressure washer is provided with a ground-fault circuit-interrupter
(GFCI) built into the plugs of the power-supply cord. This device
provides additional protection from the risk of electric shock. Should
replacement of the plug or cord become necessary, use only identical
replacement parts that include GFCI protection.
In a double-insulated product, two systems of insulation are provided
instead of grounding. Grounding means are not provided for a double
insulated product, nor should grounding means be added to the product.
Servicing a double-insulated product requires extreme care and
knowledge of the system, and should only be done by qualified
service personnel.
Replacement parts for a double-insulated product must be identical to
the original parts.
A double-insulated product is marked with the words “Double Insulation”
or “Double Insulated”. Product may also be marked with symbol shown
here.
5
SAFETY INFORMATION
Double Insulated Product
SAFETY INFORMATIONSAFETY INFORMATION
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
detergent. Dish or laundry soap is too thick and will clog
the nozzle of your detergent bottle.
IMPORTANT: Store the power washer indoors to prevent
the water in the unit from expanding under freezing
conditions. When the water freezes and expands, your
power washer will be damaged and become inoperable.
Or, if storing outdoors, it is recommended you use pump
saver (not included) to protect pumps.
26. NEVER use hot water with your power washer. It will
overheat and damage the high pressure pump.
27. NEVER leave the power washer unattended while it
is powered “ON”.
28. ALWAYS turn the water supply “ON ” before turning
the power washer power to “ON”. Running the pump
dry will cause damage to the internal components.
29. NEVER use a water supply to your power washer
that exceeds 150 PSI maximum.
30. NEVER disconnect the high pressure hose from the
power washer while the system is pressurized.
31. NEVER permanently engage the trigger mechanisms
on the spray gun.
32. NEVER operate the power washer unless all
components are properly and securely connected.
33. NEVER allow the power washer pump to run for
more than one minute after you have turned o the
water supply. This can cause the motor and pump to
overheat and fail.
34. NEVER use lances or other parts that are not
35. NEVER use an extension power cord since it defeats
the eectiveness of the GFCI and increases the
chance of electrocuting the operator.
36. NEVER spray any electrical outlet with your power
washer.
37. Inspect the power cord before using. DO NOT use it if
it is damaged.
Servicing of a Double-Insulated Appliance
Ground Fault Circuit Interrupter Protection:
This pressure washer is provided with a ground-fault
circuit-interrupter (GFCI) built into the plugs of the
power-supply cord. This device provides additional
protection from the risk of electric shock. Should
replacement of the plug or cord become necessary,
use only identical replacement parts that include GFCI
protection.
In a double-insulated product, two systems of insulation
are provided instead of grounding. Grounding means
are not provided for a double insulated product, nor
should grounding means be added to the product.
Servicing a double-insulated product requires extreme
care and knowledge of the system, and should only be
Replacement parts for a double-insulated product must
be identical to the original parts.
A double-insulated product is marked with the words
“Double Insulation” or “Double Insulated”. Product may
also be marked with symbol shown here.
15ANR014 AR390SS_200PSI ENG-FR-SP_V2.pdf 1 2017-01-13 9:33 AM
