Echogear EGAV-CMIWP2 User manual
Outlet Height
Up to 6 feet
Up to 6 feet
#YourGearUpgraded
IN-WALL TV Power Kit
Model EGAV-CMIWP2
Installation Instructions
Confuzzled? Contact the ECHOGEAR Pros:
helpmehelpy[email protected]1-855-428-2490
"Phil wants
his tools back"
Grab Your Tools
Stud Finder
Pencil
Drywall
Saw
Level
Phillips
Screwdriver Slotted
Screwdriver
Tape
Measure
TOY
SURPRISE
Inside Every Box
FREE
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ ENTIRE MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS
CAUTION: Avoid potential personal injuries and property damage!
●RISK OF FIRE AND SHOCK - Only intended for use on 15 amp branch circuits.
●RISK OF FIRE - DO NOT install power supply cord within the wall cavity.
●RISK OF FIRE AND SHOCK - DO NOT connect this box with any other circuits or outlets.
●Do not use this product for any purpose not explicitly specified by manufacturer.
●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
●If you do not understand these instructions or have doubts about the safety of the installation, assembly
or use of this product, contact The Echogear Pros at 855-428-2490 or www.echogear.com.
Legrand electrical products conform to and should be properly grounded in compliance with requirements of the
current National Electrical Code or codes administered by local authorities. All electrical products may present a possible
electric shock or fire hazard if improperly installed or used. Legrand electrical products may bear the mark of a Nationally
Recognized Testing Laboratory and should be installed in conformance with current local and/or the National Electrical Code.
