Eclipse ExtensoHeat EH050 User manual

Eclipse ExtensoHeat
Lance Burners
Model EH050
Installation Guide 235
Version 1
5/23/2011

2
Copyright
Copyright 2007 by Eclipse, Inc. All rights reserved
worldwide. This publication is protected by federal
regulation and shall not be copied, distributed,
transmitted, transcribed or translated into any human or
computer language, in any form or by any means, to any
third parties, without the express written consent of
Eclipse, Inc.
Disclaimer Notice
In accordance with the manufacturer’s policy of continual
product improvement, the product presented in this
brochure is subject to change without notice or obligation.
The material in this manual is believed adequate for the
intended use of the product. If the product is used for
purposes other than those specified herein, confirmation
of validity and suitability must be obtained. Eclipse
warrants that the product itself does not infringe upon any
United States patents. No further warranty is expressed or
implied.
Liability & Warranty
We have made every effort to make this manual as
accurate and complete as possible. Should you find errors
or omissions, please bring them to our attention so that we
may correct them. In this way we hope to improve our
product documentation for the benefit of our customers.
Please send your corrections and comments to our
Marketing Communications Manager.
It must be understood that Eclipse’s liability for its product,
whether due to breach of warranty, negligence, strict
liability, or otherwise is limited to the furnishing of
replacement parts and Eclipse will not be liable for any
other injury, loss, damage or expenses, whether direct or
consequential, including but not limited to loss of use,
income, or damage to material arising in connection with
the sale, installation, use of, inability to use, or the repair
or replacement of Eclipse’s products.
Any operation expressly prohibited in this manual, any
adjustment, or assembly procedures not recommended or
authorized in these instructions shall void the warranty.
Document Conventions
There are several special symbols in this document. You
must know their meaning and importance.
The explanation of these symbols follows below. Please
read it thoroughly.
How To Get Help
If you need help, contact your local Eclipse representative.
You can also contact Eclipse at:
1665 Elmwood Rd.
Rockford, Illinois 61103 U.S.A.
Phone: [phone]
Fax: [phone]
http://www.eclipsenet.com
Please have the information on the product label available
when contacting the factory so we may better serve you.
Product Name
Item #
S/N
DD MMM YYYY
www.eclipsenet.com
This is the safety alert symbol. It is used to alert you to potential personal
injurt hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
Indicates a hazardous situation which, if not avoided, will result in death
or serious injury.
Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
Is used to address practices not related to personal injury.
Indicates an important part of text. Read thoroughly.
NOTE
NOTICE
CAUTION
WARNING

3
Eclipse Vortometric Burner, V3, Design Guide 248, 6/10/2010
Table of Contents
Introduction............................................................................................................................... 4
Product Description.............................................................................................................. 4
Audience .............................................................................................................................. 4
ExtensoHeat Documents ..................................................................................................... 4
Purpose................................................................................................................................ 4
Safety......................................................................................................................................... 5
Introduction .......................................................................................................................... 5
Safety ................................................................................................................................... 5
Capabilities........................................................................................................................... 5
Operator Training ................................................................................................................. 5
Replacement Parts...............................................................................................................5
Installation................................................................................................................................. 6
Introduction .......................................................................................................................... 6
Handling ............................................................................................................................... 6
Storage................................................................................................................................. 6
Position of Components ....................................................................................................... 6
Approvals of Components.................................................................................................... 6
Checklist Before Installation................................................................................................. 7
General Installation Conditions ............................................................................................ 7
Burner Installation ................................................................................................................ 7
Piping ................................................................................................................................... 9
Valve Installation .................................................................................................................. 9
Checklist After Installation....................................................................................................9
Adjustment, Start, and Stop .................................................................................................... 10
Introduction .......................................................................................................................... 10
Putting Into Operation ..........................................................................................................10
Adjustment Procedure.......................................................................................................... 10
Step 1: Initial Air Adjustment ......................................................................................... 10
Step 2: Fuel Gas Adjustment and Regulation ............................................................... 11
Step 3: Air Balancing Adjustment .................................................................................. 11
Step 4: Settings Verification .......................................................................................... 11
Operating Cycle ................................................................................................................... 12
Stop...................................................................................................................................... 12
Maintenance and Troubleshooting ......................................................................................... 13
Introduction .......................................................................................................................... 13
Maintenance......................................................................................................................... 13
Monthly Checklist ................................................................................................................. 13

4Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
Table of Contents
Yearly Checklist ................................................................................................................... 13
Troubleshooting ................................................................................................................... 14
Appendix ................................................................................................................................... i
Conversion Factors..............................................................................................................i
Key to System Schematics .................................................................................................. ii

4Eclipse Vortometric Burner, V3, Design Guide 248, 6/10/2010
Introduction
Product Description
The ExtensoHeat is a nozzle-mixing type burner intended
to operate in high-temperature firing kilns with very thick
walls and roof. It is also suitable for special applications in
which the flame must be developed away from the burner.
The ExtensoHeat is designed to inject the flame through
the thick wall in the combustion chamber, discharging a
strong jet of hot gases inside it.
The high speed of the combustion gases ensures
excellent temperature uniformity and high efficiency of the
system, which improves the product quality. The gas
velocity can reach 328 ft/sec (100 m/s). There are different
nozzle lengths ranging from 31 inches (800mm) to 55
inches (1,400mm).
Burner Specifications:
• Control options include on/off or group modulation
and pulse firing. Constant air flow.
• Self ignition by process temperature.
• Flame detection is not necessary (Temperature
above 1382ºF or 750ºC).
• Operability with other fuels.
• Designed to operate with excess gas in chambers
with an oxidizing atmosphere (O2> 12% vol.)
Figure 1.1. ExtensoHeat Burner
Audience
This manual has been written for people who are already
familiar with all aspects of a combustion system and its
add-on components, also referred to as “the burner
system.”
These aspects are:
• Design / Selection
• Installation
• Use
• Maintenance
The audience is expected to have previous experience
with this type of equipment.
ExtensoHeat Documents
Design Guide 235
• Used with Datasheet 235 to design the burner
system
Datasheet 235
• Required to complete design and selection
Installation Guide 235
• This document
Purpose
The purpose of this manual is to ensure the installation of
a safe, effective, and trouble-free combustion system.
1

5
Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
Safety
Introduction
In this section, you will find important notices about safe
operation of a burner system. Read this entire manual
before you attempt to start the system.
Safety
■The burners covered in this manual are designed
to mix fuel with air and burn the resulting mixture.
All fuel burning devices are capable of producing
fires and explosions when improperly applied,
installed, adjusted, controlled or maintained.
■Do not bypass any safety feature. Fires and
explosions can be caused.
■Never try to light the burner if the burner shows
signs of damage or malfunctioning.
■The burner and duct sections might have HOT
surfaces. Always wear protective clothing when
approaching the burner.
■This manual provides information in the use of
these burners for their specific design purpose. Do
not deviate from any instructions or application
limits described herein without written advice from
Eclipse.
■Read this entire manual before you attempt to start
the system. If you do not understand any part of
the information in this manualm contact your
Eclipse representative or the Eclipse factory
before you continue.
Capabilities
Adjustment, maintenance and troubleshooting of the
mechanical and electrical parts of this system should be
done by qualified personnel with good mechanical
aptitude and experience with combustion equipment.
Operator Training
The best safety precaution is an alert and trained
operator. Thoroughly instruct new operators so they
demonstrate an adequate understanding of the
equipment and its operation. A regular retraining schedule
should be administered to ensure operators maintain a
high degree of proficiency.
Replacement Parts
Order replacement parts from Eclipse only. All Eclipse
approved, customer supplied valves or switches should
carry UL, FM, CSA, CGA, and/or CE approval where
applicable.
DANGER
WARNING
NOTICE
2

Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
6
Introduction
In this section you will find important notices about the
safe operation of the burner.
Handling
• Make sure the area is clean.
• Protect the components from the weather, damage,
dirt and moisture.
• Protect the components from excessive
temperatures and humidity.
• Use the appropriate support equipment when lifting
the burner components.
Storage
• Make sure the components are clean and free of
damage.
• Store the components in a cool, clean, dry room.
• After you have made sure everything is present and
in good condition, keep the components in the
original package as long as possible.
Position of Components
The position and amount of components is determined by
the kind of control method chosen. All the control methods
can be found in Design Guide 235. Use the schematics in
the System Design section to build your system.
Approval of Components
Limit Controls & Safety Equipment
All limit controls and safety equipment must comply with
all applicable local codes and/or standards and must be
listed for combustion safety by an independent testing
agency. Typical application examples include:
• American: NFPA 86 with listing marks from UL, FM,
CSA
• European: EN 746-2 with CE mark from TuV,
Gastec, Advantica
Electrical Wiring
All electrical wiring must comply with all applicable local
codes and/or standards such as:
• NFPA Standard 70
• IEC60364
• CSA C22
• BS7671
Gas Piping
All gas piping must comply with all applicable local codes
and/or standards such as:
• NFPA Standard 54
• ANSI Z223
• EN 746-2
The gas piping must be accepted by local authorities.
Where to Get the Standards:
The NFPA Standards are available from:
National Fire Protection Agency
Batterymarch Park
Quincy, MA 02269
www.nfpa.org
The ANSI Standards are available from:
American National Standard Institute
1430 Broadway
New York, NY 10018
www.ansi.org
The UL Standards are available from:
333 Pfingsten Road
Northbrook, IL 60062
www.ul.com
The FM Standards are available from:
1151 Boston-Providence Turnpike
PO Box 9102
Norwood, MA 02062
www.fmglobal.com/approvals
Information on the EN standards and where to get
them is available from:
Comité Européen de Normalisation
Stassartstraat 36
B-1050 Brussels
Phone: [phone]
Fax: [phone]
www.cen.eu
Comité Européen de Normalisation Electronique
Stassartstraat 36
B-1050 Brussels
Phone: [phone]
Fax: [phone]
www.cenelec.org
Installation 3

7
Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
Checklist Before Installation
Intake
To admit fresh combustion air from outdoors, provide an
opening in the room of at least one square inch per 3,000
BTU/hr (5 cm2per 1 kW). If there are corrosive fumes or
materials in the air, supply the burner with clean air from
an uncontaminated area, or provide a sufficient air filtering
system.
Exhaust
Do not allow exhaust fumes to accumulate in the work
area. Provide some positive means for exhausting fumes
from the furnace and the building.
Access
Make sure you install the burner in such a way that you
can gain easy access for inspection and maintenance.
Environment
Make sure the burner operating environment matches the
original operating specifications. Check the following
items:
• Voltage, frequency and stability of the electrical
power
• Type and supply pressure of the fuel
• Availability of enough fresh, clean combustion air
• Adequate oxygen concentration for combustion on
the process gases
• Humidity, altitude and temperature of the air
• Presence of damaging corrosive gases in the air
General Installation Conditions
Mechanical
Connect the burner feedings with the corresponding
manifold using steel piping, or copper in special cases.
Weld in accordance with both the country’s regulation
where the equipment will be installed, and user specific
standards as applicable.
Check the following before installing the burner:
• Remove all dirt (dust and other particles) and avoid
further soiling during piping and accessory
installation.
• Check that there are no obstructions in the burner
duct or in the feed piping connections.
Electrical
Install the high-voltage transformer (as applicable) as
close to the burner as possible.
■Take special care with control and measurement
wiring installation and insulation, which must be
protected against moisture, electrical induction,
etc., while still insuring correct installation
grounding.
Burner Installation
Dimensions
For full information on the dimensions, refer to the specific
datasheet.
Chamber Wall
Make sure the chamber’s wall or roof is strong enough to
support the weight of the burner. If necessary, reinforce
the area where you plan to install the burner to support the
weight of the burner.
Avoid Losses
To make sure air does not go back to the casing of the
chamber, it is important that the joint between the roof and
the burner plate is sealed with some type of insulation,
such as ceramic fiber.
WARNING

8Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
Figure 3.1. ExtensoHeat Burner Installation on the
Chamber Roof (Dimensions in mm)
The front plate is supported on the roof and enables the
burner to be fixed in place with a retainer ring. The sliding
securing system allows each burner to be adapted to the
kiln wall or roof thickness where it is installed.
Figure 3.2. ExtensoHeat Burner Front Plate
The hole diameter through the kiln’s roof allows
ExtensoHeat burners to be installed in case of low
temperature level.
Figure 3.3. ExtensoHeat Burners Distribution
The front plate includes a flame viewport with manual
latch. There is a fixation option with a ball, which enables
the burner to be orientated within a ten degrees angle, that
is available under request.
Installation Conditions
• Check that the burner extension tube is at least 7.9”
(200mm) longer than the wall thickness to allow the
installation of the front supporting plate.
• Measure the kiln roof or wall thickness and then
install the retainer ring so the end of the nozzle is
even with interior surface of the kiln roof/wall, or
recessed up to a maximum of 2 inches (50mm).

9
Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
■Adjust the length of each burner seperately in arch
kilns.
• Settle the front plates on their housings.
• Install the burners in the kiln taking precaution to
firmly tighten the locking wing nuts in the neck of the
front plate.
• The securing rings on the side burners (horizontal
position) have to be replaced with sliding flanges
that are to be welded in place with a length suitable
to the wall thickness.
Piping
Layout
Install the piping as shown in the schematics. Refer to
Design Guide 235.
Support the Piping
Use bar supports with height adjustment to support each
group of gas and air piping. Consult your local gas
company with questions.
Pipe Connections
1. Install a pipe union in the gas line to the burner. This
simplifies removal of the burner.
2. The use of flexible pipe nipples in the gas line to the
burner is the most common. Flexible nipples can
absorb stress due to heat expansion and slight
misalignment.
■Flexible pipe nipples may cause higher pressure
drops than an equivalent standard pipe. Consider
this when you size the air and gas lines.
Avoid Large Pressure Drops
NOTE: The pressure drop of the gas in the piping is a
critical parameter. Make sure the size of all piping is large
enough to prevent excessive pressure losses.
Valve Installation
Valve Orientation
Install all the valves in such a way that the arrow (if
present) on the valve body points in the direction of flow.
Gas Cocks
Make sure the handle of the gas cock is at a right angle to
the valve body when the valve is in the closed position.
This is an important position indicator. If you do not do this,
somebody may think that the gas cock is in the closed
position, when it is actually in the open position.
Gas Balancing Valves
A gas balancing valve is typically the same as a manual
butterfly valve. For more information, refer to the section
below.
Manual Butterfly Valves
Install manual butterfly valves in accordance with Bulletin/
Info Guide 720.
Automatic Butterfly Valves
An automatic butterfly valve is driven by an actuator
(actuator and mounting bracket not illustrated). Install the
control valve in accordance with Bulletin/Info Guide 720.
Adjustable Limiting Orifices
Adjustable limiting orifice valves are used for fine
adjustment of gas flow. Install the control valve in
accordance with Bulletin/Info Guide 728/730.
Solenoid Valves
Install special solenoid valves for use in pulse control
systems in accordance with the manufacturers
information.
High Pressure Control Valves
Install high pressure gas control valves as specified in the
manufacturer’s installation manual.
Checklist After Installation
To verify proper system installation, do the following:
1. Make sure there are no leaks in the fuel lines or the air
lines.
2. Make sure all the components of the control system
are properly installed. This includes verifying that all
switches are installed in the correct location and that
the wiring, pressure lines and impulse lines are
properly connected.
3. Make sure the blower rotates in the correct direction. If
incorrect, have a qualified electrician rewire the blower
to reverse its rotation.
4. Make sure all valves are installed in their proper
location and correctly oriented relative to the gas or air
flow direction.
5. Make sure all safety components are installed and
working properly.
CAUTION
NOTICE

Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
10
Introduction
In this chapter you will find instructions on how to adjust a
system, start a system and stop a system.
■Do not bypass any safety features. This can cause
fires and explosions.
■Obey the safety precautions in the Safety chapter,
and read all of this chapter before starting your
system.
NOTE: Adjustment requires two guides: installation guide
235 and Datasheet 235. This chapter refers to the
component information explained in Design Guide 235.
Read this chapter thoroughly before proceeding with the
system implementation.
Putting into Operation
Preliminary Installation Checks
• Check that the main manual gas valve is closed and
then open it.
• Check that the control board temperature
parameters are correct.
• Check that the gas pressure is correctly regulated.
• Check that the main control panel switch is ON.
• Check that the kiln recirculation blower group(s) is
operating correctly.
• Check that the exhaust blower(s) is operating
correctly.
• Check that the chamber temperature is above
1382ºF (750ºC).
• Check that the kiln sweep and burner permissive
activation are correct.
• Reset the group control cabinet (general safeties) if
necessary. General safety solenoid valve opening
will take place.
NOTE: Eclipse authorized personnel should perform the
initial start of all Eclipse burners.
Adjustment Procedure
Follow these steps to adjust the ExtensoHeat system for
the first time:
1. Initial air adjustment
2. Fuel gas adjustment and regulation
3. Air balancing adjustment
4. Settings verification
■This burner requires continuous monitoring
during the startup process and while the
temperature is below 1382ºF (750ºC). It is always
recommended to operate at higher temperatures.
NOTE: In tunnel kiln installation, start adjusting the
burners located at the beginning of the firing area
Step 1: Initial Air Adjustment
1. Close all manual and automatic gas valves
2. Fully open manual air valves for each burner.
3. Verify that the air balancing valves are 100% open on
all burners.
4. Start the blower.
5. Close the manual balancing valves next to the burner
to get 4 – 6”w.c. (10 – 15 mbar) at the burner body (Tap
A) and to achieve 30-50% of stoichiometric air.
DANGER
NOTICE
Adjustment Start & Stop
4

11
Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
Figure 4.1. Air Adjustment
6. Using a manometer, adjust the low-pressure switch air
circuit to 50% of the blower pressure.
7. Adjust the air line bypass to maintain a minimum
cooling airflow when the air valve is closed
NOTE: Make sure the blower rotates in the correct
direction. If incorrect, have a qualified electrician rewire
the blower to reverse its rotation.
Step 2: Fuel Gas Adjustment and
Regulation
1. Check the gas pressure of selected nozzles on the
application.
2. Adjust the gas pressure at the entrance of the group of
burners so it corresponds with the pressure level stated
in Datasheet 235-1.
3. Adjust the low pressure switch of the gas line to 50-
70% of the required inlet pressure.
4. Adjust the high-pressure switch of the gas line to 20%
above the inlet pressure to the burners.
5. Fully open the manual gas valve.
6. Fully open the gas balancing valve to the burner.
Figure 4.2. Fuel Gas Adjustment
7. Use the gas curves from the appropriate ExtensoHeat
datasheet for the gas being used to find the gas
pressure needed at high fire. This is the target value for
high fire.
8. Adjust the gas pressure regulator to achieve the target
value.
9. Adjust the minimum pressure of the gas bypass to 10%
of the high fire pressure or lower if necessary to prevent
product damage during cycle advances (if it exists).
10. Repeat steps 3 and 4 for all burners of the group.
Step 3: Air Balancing Adjustment
Adjust the air balancing valve again for each burner to
keep the pressure at the selected value (4-6 “w.c. or 10-
15 mbar at Tap A)
Step 4: Settings Verification
After several operation cycles, check the chamber
temperature homogeneity, and, if necessary, adjust the
gas by adjusting the manual balancing valves for each
burner separately.
NOTE: When all the settings have been completed, mark
the position of the indicator, or lock the balancing valves
to hold the valve position.
■If simulated limits do not shut down the fuel
system within the required failure response time,
immediately correct the problem before
proceeding.
DANGER

12 Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
Operating Cycle
Firing Zone (in roof)
For each group:
• Manually start the combustion air blower
• Check that the air actuator is closed
• Open the manual air and gas valves for each burner
• Press the main group start button. Air is set to
maximum and the burner main group safety
solenoid valve opens
• Temperature regulation takes place according to
selected type and mode
NOTE: During burner operation, the air flow is always
constant. The regulation cycles only take place with “car
stopped”. During each “car advance” the main group
safety valve closes, and the air actuator closes.
Stop
• Press the group(s) stop button
• Close the main and burner manual gas valve (firing
zone in kiln’s roof)
• If the kiln is maintained in operation, remove the
burners and close the holes
• In case of kiln stop, do not switch off the combustion
blower until the kiln temperature is less than 572ºF
(300ºC) and then close the air valves for each
burner
• Switch off the electrical power
NOTE: Keep the blower running after the burner is turned
off to protect the burner and other components from any
back flow of hot gases.
■The following must be immediately carried out in
case of main power failure:
■Close all manual air valves so that the burners are
isolated from the distribution manifolds and
prevent the return of hot gases through the
burners.
■In case of a long power failure (more than 15
minutes), the burners should be removed from
their positions to prevent them from being
exposed to high temperatures for a prolonged
period.
■Select resistant material for air pipes if there is a
possibility of temporary reversal of hot gases.
WARNING

Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011 13
Introduction
This section is divided into two parts. The first part
describes the maintenance procedures. The second part
identifies problems that may occur and gives advice on
how to solve these problems.
Maintenance
Preventative maintenance is the key to a reliable, safe
and efficient system. The following are suggested
guidelines for periodic maintenance. Burners in severe
environments or operational conditions should be
checked more frequently.
NOTE: The monthly and yearly lists are an average
interval. If your environment is dirty, the intervals may be
shorter. Check with the local authorities that have
jurisdiction over recommended maintenance schedules.
■Turn off power to burner and controls before
proceeding with burner inspection.
Monthly Checklist
1. Test (leak test) safety shut-off valves for tightness of
closure.
2. Test air pressure switch settings by checking switch
movements against pressure settings and comparing
with actual impulse pressure.
3. Visually check ignition cable and connectors.
4. Inspect piping for leaks.
5. Remove, clean and inspect all burners.
6. Make sure the following components are not damaged
or distorted:
• Air tube
• Gas tube
• Gas Injector
• Nozzle
7. If applicable, remove and clean all orifice plates.
Yearly Checklist
Make all the verifications included in the monthly checklist
and:
1. Check for proper inlet air/gas ratios (refer to Datasheet
235-1).
2. Test all alarm systems for proper response signals.
3. Check valve motors and control valves for free, smooth
action and adjustment.
4. Check for proper operation of the ventilating
equipment.
5. Test the interlock sequence of all safety equipment;
manually make each interlock fail, ensuring that related
equipment closes or stops as specified by the
manufacturer.
CAUTION
Maintenance &
Troubleshooting
5

14 Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
Troubleshooting
Problem Possible Cause Solution
Cannot initiate startup
sequence
Air pressure switch has not made contact Check air pressure switch adjustment.
Check air filter. Check blower rotation from
blower
High gas pressure switch has tripped Check incoming gas pressure. Adjust gas
pressure if necessary. Check pressure
switch setting and operation
Low gas pressure switch has tripped Check incoming gas pressure. Adjust gas
pressure if necessary. Check pressure
switch setting and operation
Insufficient process temperature Check the temperature. Increase the
temperature if necessary. Check safety
thermostat settings and operation
Main power is off Make sure the power is on to the control
system
No power to control unit Call qualified electrician to investigate
Startup sequence runs but
burner does not light
Too much gas: Manual gas balancing
valves have been opened too far
Check pressures and settings against
start-up report and adjust as necessary
Too much gas: Gas pressure out of the
main gas pressure regulator is too high
Check start-up setting. If necessary,
remove regulator and investigate
Not enough gas: Gas pressure out of the
main gas pressure regulator is too low
Check start-up setting. Check regulator
and adjust if necessary
Not enough gas: Start gas solenoid valve
does not open
Check solenoid valve coil for proper
orientation. Replace if necessary
Not enough gas: Gas valve not open Check wiring to the automatic gas shut-off
valve
Not enough gas; pilot solenoid valve does
not open
Have a qualified electrician check power
supply to solenoid
Not enough pilot gas: Air in the gas line Check output from the flame safeguard.
Open gas cock. Purge gas line
Oxygen and/or temperature levels too low Stop the installation and verify the design
data
The low fire flame is weak
and unstable
Low fire adjusted too low Increase low fire gas setting
Not enough gas Check start-up settings and adjust to
increase low gas flow
Not enough air Check start-up settings. Investigate any
changes, i.e. blocked filter, loose
connections
The burner goes off when it
cycles to high fire
Insufficient air (flame too rich) Check start-up settings. Check that the air
filter is clean and replace if required
Insufficient oxygen level Stop the burner(s) and restore the
minimum conditions before putting it back
in service
Oxygen and/or temperature levels too low Stop the installation and verify the design
data
The burner is erratic and
does not respond to
adjustment
Internal damage to the burner. Some parts
inside the burner may be loose or dirty
Contact Eclipse

15
Eclipse ExtensoHeat Lance Burners, V1, Installation Guide 235, 5/23/2011
The burner is unstable or
produces soot or smoke
The air/gas ratio is out of adjustment Measure all gas pressures and air
pressures. Compare to initial start-up
settings and adjust where necessary
Cannot achieve full capacity Gas pressure is too low into the main gas
pressure regulator
Adjust gas pressure
Gas nozzles clogged Check and clean
Poor piping practices Contact Eclipse
Problem Possible Cause Solution

i
Conversion Factors
Metric to English
Metric to Metric
English to Metric
From To Multiply By
actual cubic meter/hr (am³/h) actual cubic foot/hr (acfh) 35.31
normal cubic meter/hr (Nm³/h) standard cubic foot /hr (scfh) 38.04
degrees Celsius (°C) degrees Fahrenheit (°F) (°C x 9/5) + 32
kilogram (kg) pound (lb) 2.205
kilowatt (kW) Btu/h 3415
meter (m) foot (ft) 3.281
millibar (mbar) inches water column ("w.c.) 0.402
millibar (mbar) pounds/sq in (psi) 14.5 x 10-3
millimeter (mm) inch (in) 3.94 x 10-2
MJ/Nm³ Btu/ft³ (standard) 26.86
From To Multiply By
kiloPascals (kPa) millibar (mbar) 10
meter (m) millimeter (mm) 1000
millibar (mbar) kiloPascals (kPa) 0.1
millimeter (mm) meter (m) 0.001
From To Multiply By
actual cubic foot/hr (acfh) actual cubic meter/hr (am³/h) 2.832 x 10-2
standard cubic foot /hr (scfh) normal cubic meter/hr (Nm³/h) 2.629 x 10-2
degrees Fahrenheit (°F) degrees Celsius (°C) (°F - 32) x 5/9
pound (lb) kilogram (kg) 0.454
Btu/h kilowatt (kW) 0.293 x 10-3
foot (ft) meter (m) 0.3048
inches water column ("w.c.) millibar (mbar) 2.489
pounds/sq in (psi) millibar (mbar) 68.95
inch (in) millimeter (mm) 25.4
Btu/ft³ (standard) MJ/Nm³ 37.2 x 10-3
Appendix

ii
Key to System Schematics
Symbol Appearance Name Remarks
Bulletin/
Info Guide
ExtensoHeat Burner 235
Main Gas Shut-Off Valve Train Eclipse strongly endorses NFPA
as a minimum 756
Combustion Air Blower
The combustion air blower
provides the combustion air
pressure to the burner(s)
610
Air Pressure Switch
The air pressure switch gives a
signal to the safety system when
there is not enough air pressure
from the blower
610
Gas Cock
Gas cocks are used to manually
shut off the gas supply on both
sides of the main gas shut-off
valve train
710
Solenoid Valve (Normally Closed)
Solenoid valves are used to
automatically shut off the gas
supply on a bypass gas system or
on small capacity burner systems
760
Manual Butterfly Valve
Manual butterfly valve are used to
balance the air or gas flow at each
burner, and/or to control the zone
flow
720
Automatic Butterfly Valve
Automatic butterfly valves are
typically used to set the output of
the system
Motorized Gas Control Valve
A motorized gas control valve
adjusts the gas flow to the
burner(s) based on the control
system requirements
Adjustable Limiting Orifice
Adjustable limiting orifices are
used for fine adjustment of gas
flow
728/730
Pressure Taps The schematics show the advised
positions of the pressure taps
Main Gas
Shut-Off
Valve Train
P
NC
M

Installation Guide 235, 5/23/2011
