Eclipse ExtensoJet EJ025 User manual

Eclipse ExtensoJet
Burners
Models EJ025–EJ075
Version 2
Installation Guide 230
9/17/2008

Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
2
Co p y r i g h t
Di s C l a i m e r No t i C e
li a b i l i t y a N D
Wa r r a N t y
Copyright 2007 by Eclipse, Inc. All rights reserved worldwide.
This publication is protected by federal regulation and shall not be
copied, distributed, transmitted, transcribed or translated into any
human or computer language, in any form or by any means, to any
third parties, without the express written consent of Eclipse, Inc.
In accordance with the manufacturer’s policy of continual product
improvement, the product presented in this brochure is subject to
change without notice or obligation.
The material in this manual is believed adequate for the intended
use of the product. If the product is used for purposes other than
those specied herein, conrmation of validity and suitability must
be obtained. Eclipse warrants that the product itself does not
infringe upon any United States patents. No further warranty is
expressed or implied.
We have made every effort to make this manual as accurate and
complete as possible. Should you nd errors or omissions, please
bring them to our attention so that we may correct them. In this
way we hope to improve our product documentation for the benet
of our customers. Please send your corrections and comments to
our Marketing Communications Manager.
It must be understood that Eclipse’s liability for its product, whether
due to breach of warranty, negligence, strict liability, or otherwise
is limited to the furnishing of replacement parts and Eclipse will not
be liable for any other injury, loss, damage or expenses, whether
direct or consequential, including but not limited to loss of use,
income, or damage to material arising in connection with the sale,
installation, use of, inability to use, or the repair or replacement of
Eclipse’s products.
Any operation expressly prohibited in this Guide, any adjustment,
or assembly procedures not recommended or authorized in these
instructions shall void the warranty.

3
Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
This manual has been written for people who are already familiar
with all aspects of a nozzle-mix burner and its add-on
components, also referred to as “the burner system”.
These aspects are:
Installation•
Use•
Maintenance•
The audience is expected to have had previous experience with
this kind of equipment.
Installation Guide No. 230
This document•
Datasheet No. 230-1 through 230-3
Available for individual EJ models•
Required to complete installation•
Design Guide No. 230
Used with Datasheet to design burner system•
Price List No. 230
Used to order burners•
Related Documents
EFE 825 (Combustion Engineering Guide)•
Eclipse bulletins and Info Guides:•
610, 710, 720, 730, 742, 744, 760, 930, I-354
Purpose
The purpose of this manual is to make sure that you carry out the
installation of a safe, effective and trouble-free combustion system.
ex t e N s o Je t Do C u m e N t s
au D i e N C e
About This Manual

Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
4
There are several special symbols in this document. You must
know their meaning and importance.
The explanation of these symbols follows below. Please read it
thoroughly.
Danger:
Indicates hazards or unsafe practices which WILL
result in severe personal injury or even death.
Only qualied and well trained personnel are allowed
to carry out these instructions or procedures.
Act with great care and follow the instructions.
Warning:
Indicates hazards or unsafe practices which could
result in severe personal injury or damage.
Act with great care and follow the instructions.
Caution:
Indicates hazards or unsafe practices which could result
in damage to the machine or minor personal injury, act
carefully.
Note:
Indicates an important part of the text. Read thoroughly.
If you need help, contact your local Eclipse representative.
You can also contact Eclipse at:
1665 Elmwood Rd.
Rockford, Illinois 61103 U.S.A.
Phone: [phone]
Fax: [phone]
http://www.eclipsenet.com
Do C u m e N t
Co N v e N t i o N s
ho W toge t he l p

5
Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
Table of Contents
Introduction.................................................................... 6
Product Description ......................................................... 6
Safety.............................................................................. 7
Introduction...................................................................... 7
Safety .............................................................................. 7
Capabilities...................................................................... 7
Operator Training............................................................. 7
Replacement Parts.......................................................... 7
Installation...................................................................... 8
Introduction...................................................................... 8
Handling and Storage...................................................... 8
Position of Components .................................................. 8
Approvals of Components ............................................... 8
Checklist Before Installation ............................................ 9
Preparing the Burner ....................................................... 10
Burner Installation............................................................ 11
Piping............................................................................... 12
Valve Installation.............................................................. 13
Checklist After Installation ............................................... 14
Prepare for Adjustment.................................................... 14
Adjustment, Start & Stop.............................................. 15
Introduction...................................................................... 15
Modulating Gas and Air Ratio System............................. 15
Step 1: Reset the System........................................... 15
Step 2: Set High Fire Air ............................................. 16
Step 3: Set Low Fire Air.............................................. 16
Step 4: Verify the Air Settings ..................................... 16
Step 5: Ignite the Burners........................................... 17
Step 6: Set High Fire Gas........................................... 17
Step 7: Set Low Fire Gas ........................................... 18
Step 8: Verify the Gas Settings................................... 18
Fixed-Air System ............................................................. 18
Step 1: Reset the System........................................... 18
Step 2: Set High Fire Air ............................................. 18
Step 3: Ignite the Burners........................................... 19
Step 4: Set High Fire Gas........................................... 20
Step 5: Set Low Fire Gas ........................................... 20
Step 6: Verify the Gas Settings................................... 20
Set the Bypass Pilot Gas (Optional)................................ 21
Start Procedure ............................................................... 21
Stop Procedure................................................................ 21
Maintenance & Troubleshooting .................................. 22
Introduction...................................................................... 22
Maintenance.................................................................... 22
Monthly Checklist ............................................................ 22
Yearly Checklist ............................................................... 23
Troubleshooting Procedures ........................................... 24
Illustrated Parts Lists ....................................................... 26
Appendix ........................................................................ 28
Conversion Factors ......................................................... 28
1
2
3
4
5

6Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
Introduction
pr o D u C t De s C r i p t i o N The ExtensoJet is a nozzle-mix burner that is designed to re an
intense stream of hot gases through a silicon tipped extended
combustor using ambient combustion air.
The high velocity of the gases improves temperature uniformity,
product quality and system efciency. The gas velocity can be as
high as 500 ft/s. The combustor comes in varying lengths from 20
inches to 56 inches.
The burner is designed for:
On-Ratio Control•
Direct Spark Ignition•
Flame Rod Supervision•
Multiple Fuel Capability•
Figure 1.1 The ExtensoJet Burner
1

7
Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
Safety
In this section you will nd important notices about safe operation
of a burner system.
Danger:
The burners covered in this manual are designed to
mix fuel with air and burn the resulting mixture. All
fuel burning devices are capable of producing res
and explosions when improperly applied, installed,
adjusted, controlled or maintained. Do not bypass any
safety feature. You can cause res and explosions.
Never try to light the burner if the burner shows signs
of damage or malfunctioning.
Warning:
The burner might have HOT surfaces. Always wear
protective clothing when approaching the burner.
Note:
This manual gives information for the use of these burners
for their specic design purpose. Do not deviate from any
instructions or application limits in this manual without
written advice from Eclipse.
Read this entire manual before you attempt to start the
system. If you do not understand any part of the
information in this manual, then contact Eclipse before you
continue.
Adjustment, maintenance and troubleshooting of the mechanical
and the electrical parts of this system should be done by
qualied personnel with good mechanical aptitude and experience
with combustion equipment.
The best safety precaution is an alert and competent operator.
Thoroughly instruct new operators so they demonstrate an
adequate understanding of the equipment and its operation.
Regular retraining must be scheduled to maintain a high degree of
prociency.
Order replacement parts from Eclipse only. Any customer-supplied
valves or switches should carry UL, FM, CSA, CGA and/or CE
approval where applicable.
iN t r o D u C t i o N
sa f e t y
2
Ca p a b i l i t i e s
op e r a t o r tr a i N i N g
re p l a C e m e N t pa r t s

8Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
Installation
In this section you will nd the information and instructions needed
to install the burner and system components.
Handling
Make sure the area is clean•
Protect the components from weather, damage, dirt and•
moisture
Protect the components from excessive temperatures and•
humidity
Storage
Make sure the components are clean and free of damage•
Store the components in a cool, clean, dry room•
After making sure everything is present and in good condition,•
keep the components in original packages as long as possible
The position and amount of components are determined by the
kind of control method chosen. All the control methods can be
found in Design Guide 230, Chapter 3 “System Design”. Use the
schematics in that chapter to build your system.
Limit Controls and Safety Equipment
All limit controls and safety equipment must comply with the
current following standards:
NFPA Standard 86•
NFPA Standard 86C•
UL•
FM•
CGA•
EN 746-2•
All applicable local codes and/or standards•
Electrical Wiring
All electrical wiring must comply with all applicable local codes
and/or standards, which may include:
NFPA Standard 70•
ANSI-C11981•
EN 746-2•
Gas Piping
All gas piping must comply with all applicable local codes and/or
standards, which may include:
NFPA Standard 54•
ANSI Z223•
EN 746-2•
iN t r o D u C t i o N
ha N D l i N g a N D
st o r a g e
3
ap p r o v a l s o f
Co m p o N e N t s
po s i t i o N o f
Co m p o N e N t s

9
Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
Where To Get Standards:
The NFPA Standards are available from:
National Fire Protection Agency
Batterymarch Park
Quincy, MA 02269
The ANSI Standards are available from:
American National Standard Institute
1430 Broadway
New York, NY 10018
The UL Standards are available from:
333 Pngsten Road
Northbrook, IL 60062
The FM Standards are available from:
1151 Boston-Providence Turnpike
P.O. Box 9102
Norwood, MA 02062
The CGA Standards are available from:
55 Scarsdale Road
Toronto, Ontario
Canada M3B 2R3
Information on the EN standards, and where to get the standards
is available from:
Comité Européen de Normalisation
Strassartstraat 36
B-1050 Brussels
Comité Européen de Normalisation Electronique
Strassartstraat 36
B-1050 Brussels
Intake
To admit fresh combustion air from outdoors, provide an opening
in the room of at least one square inch per 4,000 BTU/hr.
If there are corrosive fumes or materials in the air, then supply the
burner with clean air from an uncontaminated area.
Exhaust
Do not allow exhaust gases to accumulate in the work area.
Provide some positive means for exhausting them from the
furnace and the building.
Access
Make sure that you install the burner in such a way that you can
get easy access for inspection and maintenance.
Environment
Be sure the burner operating environment matches the original
operating specications. Check the following items:
voltage, frequency, and stability of electrical power•
fuel type and fuel supply pressure•
adequate fresh, clean, combustion air•
humidity, altitude, and temperature of the supply air•
presence of damaging corrosive gases in the air•
Ch e C k l i s t be f o r e
iN s t a l l a t i o N
ap p r o v a l s o f
Co m p o N e N t s
(Co n t i n u e d )

Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
10
Several components must be installed on a burner before it can
operate. Installation instructions follow:
It is possible to change the relative position of the gas inlet with
respect to the air inlet. This can be convenient for the routing of
the piping.
To rotate the rear cover, do the following steps:
Disconnect the piping at a union in the piping or the inlet1.
anges provided on the burner.
Note:
Be careful not to lose or damage the orice plate or the
O-rings.
Remove the four bolts2. .
Remove the rear cover3. from the burner housing .
Rotate the rear cover4. to the position that you want.
Put the rear cover in position against the burner housing5. .
Install the four bolts6. .
Reconnect the piping. Make sure that the O-rings show no7.
signs of damage.
Installing the Flame Sensor
Install the ame sensor into the 1/2" NPT opening in the rear 1.
cover.
Make sure that you connect the ame sensor of a burner to 2.
the electrical circuit of that burner.
Danger:
If you connect the ame sensor of a burner to the
electrical circuit of the wrong burner, then you can
cause res and explosions.
pr e p a r e t h e bu r N e r
1
2
43
2
43
Rotate the Rear Cover (Optional)
Installing the Flame Sensor
Flame Rod
Spark Plug

11
Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
Flame Rod
For detailed information on how to install and connect a ame rod,
refer to Bulletin/Info Guide 832.
Installing the Spark Plug
Install the spark plug into the opening in the rear cover.
Note:
Do not apply any grease to the threads of the spark plug.
You can cause bad grounding of the spark plug if you
apply grease to it. Bad grounding of the spark plug results
in a weak spark.
Dimensions
The burner attaches to the wall of the chamber with bolts or studs
welded to chamber wall through holes “C”. For full information on
the dimensions, refer to specic datasheets.
Figure 3.1 Burner Attachment
Chamber Wall
Make sure that the wall of the chamber is strong enough to carry
the weight of the burner. If necessary, reinforce the area where
you plan to install the burner to support the weight of the burner.
Avoid Losses
To make sure that heat does not go back to the casing of the
chamber, it is important that the radial clearance around the
combustor is lled with ceramic ber.
pr e p a r e t h e bu r N e r
(Co n t i n u e d )
Flame Rod
Spark Plug
bu r N e r iN s t a l l a t i o N
C

Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
12
Ø88.9
Optional
Adapter
(11mm Thick)
Gasket
Customer Supplied
Ceramic Fiber Support
Furnace
Wall
300
250
110
Wall Thickness
Min Ø120
Max Ø180
Min 10
Max 50
Ø106
Figure 3.2 Silicon Carbide Tube - Installation (Dimensions in mm)
Make sure the gasket is installed between the mounting ange and the chamber wall. Locate the end of
the ceramic combustor between 10mm and 50mm inside furnace wall. Clearance hole in the chamber
wall must be between 120mm and 180mm in diameter. Pack the gap with ceramic ber as stated above
to the dimensions shown.
Layout
Install the piping as shown in the schematics. Refer to
chapter 3 of the ExtensoJet Design Guide No. 230.
Support the Piping
Use brackets or hangers to support the gas piping. If you have
questions, consult your local gas company.
Straight Run of Pipe Before a Metering Orice
Note:
There must be a run of pipe with a straight length of at
least 10 pipe diameters before the burner metering orice.
If you do not do this, the pressure readings will be
inaccurate.
Pipe Connections
Install a pipe union in the gas line to the burner. This simplies 1.
removal of the burner.
The use of exible pipe nipples in the gas line to the burner is 2.
optional. Flexible nipples can absorb stress due to heat
expansion and slight misalignment.
Note:
Flexible pipe nipples will cause inaccurate metering orice
readings and may cause higher pressure drops than
equivalent standard pipe. Consider this when you size the
gas lines.
Avoid Large Pressure Drops
Note:
The pressure drop of the gas in the piping is a critical
parameter. Make sure that the size of all the piping is large
enough to prevent excessive pressure losses.
pi p i N g
Pipe
Union
Bracket
Piping

13
Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
va l v e iN s t a l l a t i o N Valve Orientation
Install all the valves in such a way that the arrow (if present) on the
valve body points in the direction of ow.
Gas Cocks
Make sure that the handle of a gas cock is at a right angle to the
valve body when the valve is in the closed position. This is an
important position indicator. If you do not do this, somebody may
think that the gas cock is in the closed position, while it is actually
in the open position.
Gas Balancing Valves
A gas balancing valve is typically the same as a manual buttery
valve. For more information, refer to the section below.
Manual Buttery Valves
Install manual buttery valves in accordance with Bulletin/Info 1.
Guide 720.
Install manual buttery valves in the gas line to the burner 2.
(optional).
Note:
It is recommended that there is a run of pipe with a length
of at least 10 pipe diameters between any ow altering
device and the metering orice on the burner.
Automatic Buttery Valve
An automatic buttery is driven by an actuator (actuator and
mounting bracket not illustrated). Install the control valve in
accordance with Bulletin/Info Guide 720.
Ratio Regulator
Connect an impulse line to the ratio regulator and to the air•
supply line.
Install the ratio regulator in accordance with Bulletin/Info Guide•
742.
CRS Valve
Install the CRS valve in accordance with Bulletin/Info Guide 744.

Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
14
Ch e C k l i s t af t e r
iN s t a l l a t i o N
To verify proper system installation, do the following:
Make sure that there are no leaks in the gas lines and the air1.
lines.
Make sure all the components of the ame monitoring control 2.
system are properly installed. This includes verifying that all
switches are installed in correct locations and all wiring,
pressure and impulse lines are properly connected.
Make sure components of spark ignition system are installed3.
and functioning properly.
Make sure that the blower rotates in the correct direction. If4.
incorrect, then have a qualied electrician rewire the blower to
reverse its rotation.
Make sure all valves are installed in proper location and5.
correctly oriented relative to the gas or air ow direction.
After installation of the burner system components is complete, the
following steps should be followed in order to prepare for
adjustment:
Set the air pressure switch so that it drops out at 4" w.c. (10 1.
mbar) below the pressure rating of the blower.
Set the low gas pressure switch at 4" w.c. (10 mbar) below the 2.
gas pressure measured at the inlet to the main gas valve train.
Set the high gas pressure switch so that it comes on at 4" w.c. 3.
(10 mbar) above the gas pressure measured at the inlet to the
main gas valve train.
Close all the burner gas cocks.4.
Try to light a burner before the purge and other timers have5.
nished their cycles. Make sure that the ame monitoring
system indicates a ame failure.
Trip out pressure switches and other limit interlocks. Make6.
sure that the main gas valve train closes.
Danger:
If simulated limits or simulated ame failures do not
shut down the fuel system within the required failure
response time, immediately correct the problem
before proceeding.
pr e p a r e fo r
aD J u s t m e N t

15
Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
Adjustment, Start &
Stop
In this chapter you will nd instructions on how to adjust a system,
and how to start and stop a system. The chapter starts with
general instructions that are useful for adjustment.
Danger:
Do not bypass any safety feature. You can cause res
and explosions.
Obey the safety precautions in Chapter 2.
Adjustment
There are two adjustment procedures. To adjust a modulating
gas and air ratio system, refer to “Modulating Gas and Air Ratio
System” on page 15. For a xed-air system, refer to “Fixed-air
System” on page 18.
If you adjust an on-ratio system for the rst time, you must follow
these steps (Refer to Figure 3.1 and Figure 3.3 in the ExtensoJet
Design Guide No. 230):
Reset the system1.
Set high re air2.
Set low re air3.
Verify the air settings4.
Ignite the burners5.
Set high re gas6.
Set low re gas7.
Verify the gas settings8.
Close these valves: the automatic gas valves and the gas1.
cocks.
Fully open the manual air buttery valve at each burner.2.
Drive the automatic zone air control valve to high re.a.
Adjust the automatic zone air control valve so that it is fullyb.
open. The automatic zone air control valve can be either a
buttery valve or a CRS valve.
Start the blower.3.
Caution:
Make sure that the blower rotates in the correct direction.
If incorrect, have a qualied electrician rewire the blower
to reverse its rotation.
iN t r o D u C t i o N
4
mo D u l a t i N g ga s a N D
ai r ra t i o sy s t e m
Step 1: Reset the System

Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
16
Set the system to high re, but 1. DO NOT ignite the burner(s).
Use the air curves from the appropriate ExtensoJet Datasheet2.
to nd the differential air pressure needed at high re. This is now
the target value for high re.
Set high re air.3.
Note:
A pressure tap is open when the screw inside the tap is
unscrewed approximately half a turn.
To set high re air on a single burner system:
Make sure that pressure taps A and C are open.a.
Connect the manometer to taps A and C (across the airb.
orice).
Adjust the manual buttery valve until the high-re c.
differential air pressure is at the target value.
Remove the manometer.d.
Close the pressure taps.e.
To set high re air on a multiple burner system:
Make sure that pressure taps A and C of the rst burner a.
are open.
Connect the manometer to taps A and C of the rst burner b.
(across the air orice).
Adjust the zone air manual buttery valve to achieve the c.
target value for the rst burner.
Measure and note the differential air pressure across thed.
next burner in the zone.
Repeat d for all the other burners in the zone (if any).e.
If all the measured differential pressures are within 0.3" f.
w.c. (0.75 mbar) of each other, then proceed to the next
section. If the variation is greater than 0.3" w.c. (0.75
mbar) it will be necessary to adjust the manual air buttery
valve at each burner to improve the balance.
Make sure that all the pressure taps are closed.g.
Repeat step 3 for other zones (if any).4.
Set the system to low re.1.
Connect the manometer to tap A (air inlet pressure tap).2.
Adjust the automatic zone air control valve until the3.
low-re static air pressure is 0.2" w.c. This is the initial setting
only. Further adjustment may be required.
Repeat 2 and 3 for the other zones (if any).4.
Make sure all the settings are still the same after you cycle the
system several times between high and low re.
Step 2: Set High Fire Air
Set High Fire Air
Manometer
Tap A
Tap C
Step 3: Set Low Fire Air
Step 4: Verify the Air
Settings

17
Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
Step 5: Ignite the Burners Warning:
This procedure assumes that a ame monitoring
control system is installed and is serviceable. It also
assumes that normal low re start is being used. If
low re gas is too low to be used for ignition, refer
to options in “Set the bypass pilot gas (optional)” on
page 21.
Drive the zone air automatic control valve to low re.1.
Make sure the combustion air blower is running.2.
Set the manual gas buttery valve at each burner to 50% 3.
open.
Set the adjusting screw on the ratio regulator six full (360°)4.
turns down from the top (initial setting).
Open zone manual gas cock.5.
Open manual gas cock at each burner.6.
Initiate the ignition sequence through the ame monitoring 7.
control system.
Check that all the burners in the zone have ignited.a.
If safety shut-off solenoid valves are installed at eachb.
burner, then repeat 6 and 7 for all the burners in the zone.
If all the burners have ignited, drive the zone air buttery valve 8.
to high re. Verify ame is present at each burner. If burners
do not light, add a 1/2 turn down on the proportionator, repeat
steps 7 through 11.
Verify that air pressure drops have remained the same.9.
If air pressure drop is too high, close down the zone manual10.
air buttery valve.
If air pressure drop is too low, open the zone manual air11.
buttery valve.
Use the gas curve from the appropriate ExtensoJet Datasheet1.
for the gas being used to nd the differential gas pressure
needed at high re. This is the target value for high re.
Connect the manometer to taps B and D (across the gas2.
orice).
Measure the high re differential gas pressure for the rst 3.
burner.
Adjust the gas buttery valve at the burner until the gas ow is 4.
at the target value.
Repeat 3 thru 4 for the other burners in the zone.5.
Check the gas pressure at the inlet to the zone ratio6.
regulator. This should be at least 5" w.c. (12.5 mbar) higher
than the loading line pressure. It should not exceed the
maximum pressure rating of the ratio regulator.
Warning:
Insufcient gas inlet pressure may cause the
proportionator to remain fully open as the burner
system turns down from high re, causing excess fuel
operation and the possible accumulation of unburned
fuel in the chamber. In extreme cases, this may cause
explosions or res.
Step 6: Set High Fire Gas
Tap D
Tap B
Manometer

Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
18
Drive the system to low re.1.
Use the gas curve from the appropriate ExtensoJet datasheet2.
for the gas being used to determine the differential gas
pressure required for low re. This is your target value for low
re.
Measure the gas pressure at the rst burner.3.
Adjust the ratio regulator until the gas ow is on the target 4.
value. (Refer to Bulletin 742 for adjustment.)
Note:
It is very difcult to measure the very low pressures
experienced at low re, and it may be necessary to rely
on visual inspection. This is especially true when gas
turndowns in excess of 10 to 1 are being used. The main
intent is to provide a clean stable ame with a good ame
signal that will not cause the furnace temperature to
overshoot.
If the pressure required is too low to be measured, then
adjust the ratio regulator until a gas ow is obtained that
will provide a clean stable ame with a strong ame
signal.
Make sure that all settings are still the same after cycling the
system several times between high and low re.
Note:
When all the settings have been completed, mark the
position of the indicator on the buttery valves to indicate
valve position.
When you adjust a xed-air system for the rst time, you must
follow these steps:
Reset the system1.
Set high re air2.
Ignite the burners3.
Set high re gas4.
Set low re gas5.
Verify the gas settings6.
Close the automatic gas valves and the gas cocks.1.
Fully open the manual air buttery valve at each burner.2.
Drive the automatic zone air control valve to high re.a.
Adjust the automatic zone air control valve so that it is fullyb.
open. The automatic zone air control valve can be either a
buttery valve or a CRS valve.
Set the manual gas buttery valve at each burner to 50% 3.
open.
Start the blower.4.
Note:
Make sure that the blower rotates in the correct direction.
If incorrect, then have a qualied electrician rewire the
blower to reverse its rotation.
Set the system to high re, but 1. DO NOT ignite the burner(s).
Use the air curves in “Orice Curves” from the appropriate 2.
ExtensoJet datasheet to nd the differential air pressure
needed at high re. This is now the target value for high re.
Set high re air.3.
Step 7: Set Low Fire Gas
Step 8: Verify the Gas
Settings
fi x e D ai r sy s t e m
Step 1: Reset the System
Step 2: Set High Fire Air

19
Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
Step 2: Set High Fire Air
(Continued)
Note:
A pressure tap is open when the screw inside the tap is
unscrewed approximately half a turn.
Single Burner System:
Make sure that pressure taps A and C of the burner area.
open.
Connect the manometer to taps A and C (across the airb.
orice).
Adjust the manual buttery valve until the high-re c.
differential air pressure is at the target value.
Remove the manometer.d.
Close the pressure taps.e.
Multiple Burner System:
Make sure that pressure taps A and C of the rst burner are a.
open.
Connect the manometer to taps A and C of the rst burner b.
(across the air orice).
Adjust the manual buttery valve for the zone, until the c.
high-re differential air pressure is at the target value for the
rst burner.
Measure the differential air pressure across the next burnerd.
in the zone.
Repeat stepe. dfor all the other burners in the zone (if any).
If all the measured differential pressures are within 0.3" w.c f.
(0.75 mbar) of each other, then proceed to the next section.
If the variation is greater than 0.3"w.c. (0.75 mbar) it will be
necessary to adjust the manual air buttery valve at each
burner to improve the balance.
Make sure that all the pressure taps are closed.g.
Repeat 3 for other zones (if any).4.
Warning:
This procedure assumes that a ame monitoring
control system is installed and is serviceable. It also
assumes that normal low re start is being used. If
low re gas is too low to be used for ignition, refer to
options in “Set the Bypass Pilot Gas (Optional)”.
Drive the zone gas automatic buttery valve to low re.1.
Make sure the combustion air blower is running.2.
Set the burner manual gas buttery valve to low re.3.
Set the adjusting screw on the ratio regulator six full (360°)4.
turns down from the top (initial setting).
Select the valve according to the control method:5.
With high/low control:a.
Set the gas bypass buttery valve 25% open.
With modulating gas control:b.
Set the zone gas automatic buttery value to
approximately 10% open. Stroke the valve to the open
position to ensure 100% open. Readjust if necessary.
Open the zone gas manual gas cock.6.
Open the manual gas cock at each burner.7.
Step 3: Ignite the Burners
Tap C
Tap A
Manometer

Eclipse ExtensoJet v2 Installation Guide No. 230, 9/17/2008
20
Step 4: Set High Fire Gas
Initiate the ignition sequence through the ame monitoring 8.
control system.
Check that all the burners in the zone have ignited.9.
If shut-off solenoid valves are installed at each burner, then10.
repeat 6 and 7 for all the burners in the zone.
If all the burners have ignited, drive the zone to high re. Verify 11.
ame is present at each burner.
Use the gas curves from the appropriate ExtensoJet datasheet1.
for the gas being used to nd the differential gas pressure
needed at high re. This is the target value for high re.
Connect the manometer to taps B and D (across the gas2.
orice).
Measure the high re differential gas pressure for the rst 3.
burner.
Adjust the gas buttery valve at the burner until the gas ow is 4.
at the target value.
Repeat 3 and 4 for the other burners in the zone.5.
Check the gas pressure at the inlet to the zone ratio6.
regulator. This should be at least 5" w.c. (12.5 mbar) higher
than the loading line pressure. It should not exceed the
maximum pressure rating of the ratio regulator (optional).
Drive the system to low re.1.
Measure the gas pressure drop at the rst burner.2.
Select the valve according to the control method:3.
With high/low control:a.
Adjust the gas bypass buttery valve (see ExtensoJet
Design Guide No. 230) until the minimum re that will still
maintain a strong ame signal is obtained.
With modulating gas control:b.
Adjust the zone gas automatic buttery valve (see
ExtensoJet Design Guide No. 230) until the minimum re
that will still maintain a strong ame signal is obtained.
Note:
It is very difcult to measure the very low pressures
experienced at low re, and it may be necessary to rely
on visual inspection. This is especially true when gas
turndowns in excess of 10 to 1 are being used. The main
intent is to provide a clean stable ame with a good ame
signal that will not cause the furnace temperature to
overshoot.
Make sure that all the settings are still the same after you
have cycled the system several times between high and low
re.
Note:
When all the settings have been completed, mark the
position of the indicator on the buttery valves to indicate
valve position.
Manometer
Tap B
Tap D
Step 3: Ignite the Burners
(Continued)
Step 5: Set Low Fire Gas
Step 6: Verify the Gas
Settings
