Eclipse CD1200 User manual

2
For your safety in using the CD1200
For your safety in using the CD1200
Introduction
Warnings and caution signs, illustrated below, are posted throughout this manual as well as on the
CD1200. They show safe and correct ways to handle the product so as to prevent personal injury to
you, others and to avoid property damage.
Before reading through the manual, take time to read through and learn the important information listed
in this section.
Please read all materials such as manuals and warranties that have come with the product.
Eclipse will not be held liable for unsatisfactory product performance due to failure to follow these
instructions.
Warning This “Warning” sign indicates a situation in which incorrect
handling or disregard of this sign might result in death or
serious personal injury.
Caution This “Caution” sign indicates a situation in which incorrect
handling or disregard of this sign might result in personal
injury or may result solely in damage to property.
WARNING
1
2
●Do not modify this system for use other than that specified herein. Also, do not deviate
from the installation procedures described herein; ECLIPSE will not be held liable for
damages including, but not limited to serious injury, death or property damage resulting
from installations that enable unintended operation.
●This main unit requires 12V DC and should only be installed in a vehicle with a 12V negative
ground electrical system. Any other installation may cause a fire or other severe damage
to the main unit and the vehicle.
●Never install this main unit where it will interfere with safe operation of the vehicle. Never
block the drivers' view. Do not install main unit where it may interfere with operation of the
brakes, the steering or any safety equipment, including seat belts and air bags.
●Before drilling holes in a vehicle for installation, you must confirm the locations of pipes,
tanks, electrical wiring, and other vehicle systems and components to ensure that there will
be no interference or contact. In addition, you must also apply rust prevention and leak
prevention measures at the drilling area. Otherwise, fire or electric shock could occur.
●When installing main unit do not remove or alter existing vehicle fasteners, including nuts,
bolts, screws, clips, and fittings. Never detach, move or alter existing vehicle wiring,
including electrical grounds and straps. Alteration of existing vehicle components may
make vehicle unsafe to operate.
●Before installation, remove the negative (-) battery terminal to prevent shocks, electrical
arcing, fires, and damage to vehicle wiring and the main unit you are installing.
●Secure wiring with tape or plastic ties so that wires do not interfere with vehicle operation,
including brake pedal, gear shifter and steering. Position wires so that they will not be
rubbed, abraded, or damaged by moving vehicle components, including power seats.
●To avoid main unit and vehicle damage, including fire, never supply power to the installed
main unit in a way which will overload the capacity of an existing vehicle circuit. Never
leave a power supply wire or connection uninsulated. Always install supplied fuses, circuit
breakers, and relays.

For your safety in using the CD1200
3
I
WARNING
1
2
●Air bags are vital safety equipment. Never install the main unit in a way which will alter air
bag wiring or interfere with air bag deployment. Air bags must function properly in the
event of an accident.
●When installation is complete, test all vehicle electrical systems for proper operation,
including lights, horn, brake lights, and emergency flashers.
●For your protection, never use a power drill without safety glasses or goggles. Debris or
broken drill bits may cause severe eye injuries, including blindness.
●Use electrical tape to insulate the ends of all wires, even if not used. Proper insulation
prevents arcs, shocks and fires.
●Some equipment or devices require the use of batteries. Never install or place this type of
equipment where young children can get access to batteries. If a battery is swallowed,
seek medical attention immediately.
●When vehicle is moving, never take your eyes off the road to make adjustments to the main
unit. You must pay attention to the road to avoid accidents. Do not let the operation or
adjustment of the main unit distract you from proper vehicle operation.
●The driver should not look at the screen while driving. Accidents may result if you are not
paying attention to the forward direction.
●Do not put foreign objects in the loading slot of disc or USB input terminal. Fires or shocks
may result.
●Do not disassemble or alter this main unit. Accidents, fires or shocks may result.
●Do not let water or foreign objects enter the internal parts of this main unit. Smoke, fires or
shocks may result.
●Pay attention to where the remote control is left. Traffic accidents or problems with driving
may result if the remote control makes its way under the foot pedals etc. when the vehicle
is in motion.
●Do not use when abnormal operation occurs (the screen is not lit or no sound comes out).
Accidents, fires or shocks may result.
●Always replace fuses with fuses of identical capacity and characteristics. Never use a high
capacity fuse than the original. Using incorrect fuse specifications may cause a fire or
severe damage.
●If foreign objects or water enters the main unit, smoke comes out, or there is a strange
odor, stop using it immediately, and contact your dealer. Accidents, fires, or shocks may
result if you continue to use it in these conditions.
●The driver should not change the CD or USB memory while driving. As accidents may
result if you are not paying attention to the forward direction, first stop the vehicle at a safe
location and then proceed.
●Plastic bags and wrappings may cause suffocation and death. Keep away from babies and
children. Never put bag over your head or mouth.

4
For your safety in using the CD1200
CAUTION
1
2
●Wiring and installing this main unit requires expertise and experience. Professional
installation is recommended. Consult with your dealer or a professional installer. Incorrect
wiring may damage the main unit or interfere with safe vehicle operation.
●Use only the accessory parts as specified. Using other parts may cause damage to the
main unit or cause parts to dislodge and/or detach unexpectedly.
●Do not install the main unit in places where it may get dew condensation on (around the air
conditioning hose, etc.), come in contact with water, or in condition of high moisture, dust
or oily smoke. If water, moisture, dust or oily smoke enters this main unit, smoke, fires or
malfunctions may result.
●Avoid installing in places where it cannot be fastened securely or where there are strong
vibrations. Also, if you installed the main unit with double-sided tape, first wipe away dirt
and wax from the installation area. Otherwise, the main unit may come loose due to
vibration while driving, causing problems for driving and resulting in traffic accidents or
injuries.
●Do not install in places with direct sunlight or where it will be hit directly by hot air from the
heater. This may increase the temperature of the interior of this main unit, resulting in fires
and malfunctions.
●Do not obstruct the air flow of the heat sink or vents of this main unit. When the air flow of
the heat sink or vents are obstructed, the interior overheats, and fires may result.
●Connect as specified in the installation manual. If not connected normally, fires or
accidents may result.
●When installing in vehicles equipped with air bags, check the manufacturer's cautions
regarding operation to ensure proper operation of the airbags.
●Install wiring in a manner that will not allow them to be pinched by moving parts, damaged
by screws, or damaged by metal parts. Accidents, fires and shocks may result from
disconnection and electrical shorts.
●Avoid hot surfaces when wiring main unit. High temperatures may damage wiring, causing
shorts, arcing and fires.
●When changing the installation location for this main unit, please consult the dealer where
you bought it for safety reasons. Expertise is necessary for removal and installation.
●Keep volume to a reasonable level so that you can hear sounds from outside the vehicle,
including warning sounds, voices, and sirens. Failure to do so may cause an accident.
●When an external amplifier is connected, the guide tone will not sound.
●Do not put your hands or fingers into the loading slot of disc or USB input terminal. Injuries
may result.
●Do not touch the heat dissipating part of the amp. Burns may result from the heat of this
part.
●Do not recharge dry batteries. Dry batteries may rupture, resulting in injuries.
●Do not use batteries other than those specified. Also, do not mix old and new batteries.
Injuries or pollution to the surroundings may result from battery ruptures and leakage.

For your safety in using the CD1200
5
I
CAUTION
1
2
●When inserting batteries into the remote control, be careful with the polarity (positive/
negative), and insert them as indicated. If the battery polarities are incorrect, injuries and
pollution to the surroundings may result from battery ruptures and leakage.
●Replace used batteries as soon as possible; they may leak and damage the remote control.
Battery leakage can burn your skin or your eyes. Wash hands after handling.
●If alkaline solution from alkaline dry batteries makes contact with your skin or clothes,
flush with clean water. If any of the solution gets in your eyes, also flush clean with water
and then seek medical attention.
●Do not short, disassemble or heat the batteries, or place them in fire or water. Fire and
injuries may result from battery rupture and leakage.
●Store the remote control in a place away from direct sunlight, high temperatures, and high
moisture levels. The outer case may change shape, and the batteries may rupture and leak.
●Do not use this main unit except for in-vehicle use. Shocks or injuries may result.
●Be careful of the position of the volume when turning the power source ON. Hearing
damage may result if very loud noise is emitted when the power is turned ON.
●Do not operate under abnormal conditions such as when the sound is broken or distorted.
Fires may result.
●This main unit uses invisible laser light. Do not disassemble or alter this main unit. If
trouble occurs, contact the dealer where you bought the main unit.Altering this main unit
may cause exposure to laser emissions (worsening eyesight), or result in accidents, fires
or shocks.
●If the main unit is dropped or the cosmetics appear broken, turn off the power to the main
unit and contact your dealer. If used in this condition, fires or shocks may result.

6

7
I
II
III
VI
IV
V
VII
XII
VIII
IX
X
XI
XIII
XIV
Table of Contents
For your safety in using the CD1200 ...........................................2
Operating precautions ................................................................12
Names of controls and parts .....................................................13
How to operate the CD/MP3/WMA/AAC player .........................16
How to operate the USB music file player ................................26
How to operate the tuner ............................................................31
How to use the optional remote control ...................................34
How to operate the AUDIO CONTROL ......................................36
Making changes with Function Mode .......................................38
How to operate the main unit with an optional Direct Cable for iPod ......................40
Others ..........................................................................................44
If you have a question: ...............................................................45
Specifications ..............................................................................48
How to contact customer service ..............................................50

8
Table of Contents
For your safety in using the CD1200.................................................... 2
Operating precautions......................................................................... 12
Notes on operation....................................................................................................... 12
Names of controls and parts............................................................... 13
Turning the power on and off........................................................................................ 14
Switching Audio Modes................................................................................................ 14
Adjusting volume .......................................................................................................... 14
Setting time (Clock Adjust) ........................................................................................... 14
Detaching the front panel ............................................................................................. 15
Using the detachable panel.................................................................................... 15
How to remove the detachable panel..................................................................... 15
How to attach the detachable panel....................................................................... 15
How to operate the CD/MP3/WMA/AAC player.................................. 16
About compact discs .................................................................................................... 16
About brand new CDs............................................................................................ 16
About CD accessories............................................................................................ 17
About borrowed CDs.............................................................................................. 17
How to remove CDs............................................................................................... 17
About irregularly-shaped CDs................................................................................ 17
About cleaning a CD..................................................................................................... 17
About MP3/WMA/AAC.................................................................................................. 18
What is MP3/WMA/AAC?....................................................................................... 18
Playable MP3 file standards................................................................................... 18
Playable WMA file standards ................................................................................. 18
Playable AAC file standards................................................................................... 19
ID3/WMA tag.......................................................................................................... 19
Media ..................................................................................................................... 19
Format of discs....................................................................................................... 20
File names.............................................................................................................. 20
Multi-sessions ........................................................................................................ 21
Precautions during MP3/WMA/AAC playback ....................................................... 21
MP3/WMA/AAC playing time display ..................................................................... 21
Display order of MP3/WMA/AAC file/folder names................................................ 21
Listening to CD............................................................................................................. 22
TRACK (FILE) UP/DOWN............................................................................................ 22
Skip forward and backward by 10 files......................................................................... 22
FAST FORWARD/REWIND ......................................................................................... 22
SCAN/REPEAT/RANDOM........................................................................................... 23
Searching for a music file............................................................................................. 24
FOLDER REPEAT/RANDOM....................................................................................... 25
DISPLAYING TITLE..................................................................................................... 25
Ejecting the disc ........................................................................................................... 25

Table of Contents
9
How to operate the USB music file player......................................... 26
About playable USB memory standards....................................................................... 26
Playable MP3 file standards................................................................................... 26
Playable WMA file standards ................................................................................. 26
Playable AAC file standards................................................................................... 26
Format of USB memory ......................................................................................... 27
How to operate the USB music file player.................................................................... 28
Listening to music files in USB memory................................................................. 29
Searching for a music file....................................................................................... 29
Disconnecting USB memory......................................................................................... 30
How to operate the tuner..................................................................... 31
Listening to the tuner.................................................................................................... 31
Tuning to a station........................................................................................................ 31
Automatically storing stations into memory (The automatic preset mode: ASM) ......... 32
Manually storing stations into memory......................................................................... 32
Changing the reception sensitivity................................................................................ 33
Changing the radio band location................................................................................. 33
How to use the optional remote control ............................................ 34
Precautions in use of the remote control...................................................................... 34
Cleaning the remote control ......................................................................................... 34
Replacing the battery.................................................................................................... 35
How to operate the AUDIO CONTROL ............................................... 36
Switching audio control modes..................................................................................... 36
Making changes with Function Mode ................................................ 38
Switching the Function Mode ....................................................................................... 38
Making changes with Equalizer Mode.......................................................................... 38
Setting guide tone (Guide Tone) .................................................................................. 38
Switching demonstration screen display (Demo) ......................................................... 38
Changing illumination color .......................................................................................... 39
How to operate the main unit with an optional Direct Cable
for iPod ................................................................................................. 40
Listening to iPod music files (If an iPod is not connected) ........................................... 40
Listening to iPod music files (If an iPod is connected) ................................................. 40
Advancing to the next music file or returning to the beginning of the music file being
played........................................................................................................................... 41
Fast Forward/Rewind ................................................................................................... 41
Searching for a music file............................................................................................. 41
Repeating the same music file (REPEAT).................................................................... 42
Playing music files in random order (SHUFFLE).......................................................... 42
Displaying text .............................................................................................................. 42

10
Table of Contents
Others.................................................................................................... 44
Connecting portable audio players to the AUX jack ..................................................... 44
Switching the AUX mode on and off ...................................................................... 44
If you have a question:........................................................................ 45
Displayed information (for troubleshooting).................................................................. 45
Specifications....................................................................................... 48
How to contact customer service....................................................... 50

11

12
Operating precautions
Operating precautions
Introduction
<Your CD1200 will perform well over a long period of time through correct handling and care.>
Notes on operation
• For your safety, play only at volume levels that allow outside sounds to be heard.
• Discs with the logo shown to the left can be played.
• You can play music CDs (CD-R/CD-RW) on this player. Be sure to
use discs that have been properly processed.
Depending on the editing format and software used, some discs may
not play properly.
• Do not insert anything other than a CD into the main unit.
Do not insert any foreign objects, such as coins or credit cards, into
the disc slot.
• Avoid severe mechanical shock.
When the player is subjected to severe vibration while traveling over a
rough surface, playback may be intermittent. When a situation like
this occurs, resume playback after returning to a smoother road.
• About dew condensation.
In cold or rainy weather, just as the interior glass surface gets fogged,
dew (water condensation) may also settle on the main unit. When this
occurs, disc playback may become intermittent or impossible.
Dehumidify the air in the vehicle for a while before resuming
playback.
• Cleaning the disc slot.
The disc slot tends to get dusty. Clean it occasionally to prevent
accumulated dust from scratching the discs.
* Commercially available cleaning discs may not be used with this
main unit.
TEXT

Names of controls and parts
13
III
Names of controls and parts
Introduction
Front view
No. Button Name/Function
a
[MUTE/PWR] button
Activates and
deactivates mute.
Turns deck power ON/
OFF.
b[SOURCE] button
Switches audio mode.
c[VOL] button
Adjusts volume.
d[SELECT] button
Recalls and switches the
audio control modes.
e[FUNCTION] button
Switches to function
mode.
fDisc slot
Inserts compact discs.
g[e] button
Ejects CD.
No. Button Name/Function
h
Buttons [1] to [6]
Audio mode :
Carries out SCAN,
REPEAT and RANDOM
playback of tracks (files)
and skips back or forth
by 10 tracks (files).
Tuner mode :
Selects radio preset
channels and performs
disc mode functions.
i
[TRACK/SEEK] button
Selects radio station and
CD tracks.
j[DISP] button
Switches the display
details.
k
[Detach] button
Detach the left end of the
front panel from the body
of the main unit.
l
[BAND/ASM] button
Switches radio band,
ASM action.
Recalls and switches the
search mode.
II

14
Introduction
Turning the power on and off
When the power is turned on, the state used
when the power was turned off such as CD and
tuner playback is restored.
The power will come ON.
ATTENTION
When the main unit's power is turned on for
the first time or if the battery terminals have
been disconnected because of a reason such
as vehicle maintenance and the power is then
turned back on, the main unit will start up in
FM1 mode. After this, the broadcast stations
will be searched for automatically and stored in
buttons [1] to [6].
The power will go OFF and the main
unit will be in Standby.
Switching Audio Modes
Press the button to switch modes in
the following sequence:
FM/AM →CD (MP3/WMA/AAC)*2→
USB*1→iPod*1→AUX*3 →FM/AM www
*1:Cannot be selected if the corresponding
device is not connected to the main unit.
*2:Not displayed if no disc is inserted.
*3:Cannot be selected if the AUX mode is not set
to ON. For details, refer to "Switching the AUX
mode on and off" on page 44.
Adjusting volume
Turn to the right:
Increases the volume.
Turn to the left:
Decreases the volume.
ATTENTION
Press the [MUTE/PWR] button for less than
one second to cut the volume or restore it
instantly.
Setting time (Clock Adjust)
This main unit uses the 12-hour display notation.
When the clock display is flashing.
Right:
The minutes will advance.
Left:
The hours will advance.
11 When power is OFF, press the
[MUTE/PWR] button.
22 When power is ON, press and hold
the [MUTE/PWR] button until you
hear a beep.
11 Press the [SOURCE] button.
11 Turn the [VOL] button.
CAUTION
1
2
Do not adjust the volume or other controls
while driving the vehicle. Do so only while
parked in a safe location.
11 Check that the main unit is in
standby (When the clock is
displayed).
22 Press and hold the [DISP] button.
3Turn the [VOL] button to adjust the
time.
4Press the [DISP] button briefly.

Names of controls and parts
15
III
Detaching the front panel
Using the detachable panel
The front panel of the main unit can be
removed.
By removing this panel when you leave the
vehicle, you can prevent the theft of the main
unit.
How to remove the detachable panel
The left end of the front panel
detaches from the body of the main
unit.
Hold the front panel and pull it toward
you to remove it.
Push to open the front panel case and
put the front panel in it.
How to attach the detachable panel
Engage the catch at the right end of
the front panel with the lock on the
main unit itself.
Press the left end of the front panel
until it clicks into place.
11 Press the [Detach] button.
22 Remove the front panel.
33 Put the front panel into the case.
11 Insert the right end of the front
panel into the main unit.
22 Insert the front panel.
CAUTION
1
2
• If you drop the detachable panel or
subject it to impact, it may be damaged
or malfunction.
• Do not attempt to detach or attach the
detachable panel while driving since this
could cause an accident.
• Store the detachable panel at a location
free from humidity, dust, and water.
• Do not leave the detachable panel in
locations that are likely to become hot,
like the dashboard and surroundings.

16
Operation
How to operate the CD/MP3/WMA/AAC player
Operation
About compact discs
• The signal recorded on a compact disc is read by a laser beam, so nothing touches the disc surface.
A scratch on the recorded surface or a badly warped disc may cause deteriorated sound quality or
intermittent playback. Observe the following precautions to ensure high quality sound performance:
About brand new CDs
• Do not leave an ejected disc in the disc slot for very long; the disc may
warp. Discs should be stored in their cases and kept away from high
temperature and humidity.
• Do not adhere of paper or tape. Do not write on or scratch either side
of a disc.
• Discs spin at a high speed inside the main unit. Keep cracked or
warped discs out of the player to avoid damaging the main unit.
• Avoid touching the recorded surface when handling a disc; handle
discs by their edges.
• You may notice that some brand new discs are rough around the
center hole or outside edge. Remove the rough edges with the side of
a ballpoint pen, etc. Rough edges may prevent proper loading in the
main unit. Flakes from the rough edges may also stick to the recorded
surface and interfere with playback.
Rough Edges
Ballpoint pen
Rough Edges
Flakes
Recorded surface

How to operate the CD/MP3/WMA/AAC player
17
IV
About CD accessories
About borrowed CDs
• Do not use a CD with glue or remnants of adhesive tape or labels. They may cause the CD to get
stuck inside or damage the main unit.
How to remove CDs
About irregularly-shaped CDs
About cleaning a CD
• Do not use accessories (stabilizers, protective seals, laser lens
cleaners, etc.) sold for “improving sound performance” or “protecting
CDs.” The changes in CD thickness or outside dimensions made by
these accessories may cause problems in the player.
• Please be sure NOT to attach any ring-shape protector (or other
accessory) to your discs. Those protectors are commercially available
and said to protect disc and to improve sound quality (and
antivibration effect), but they can do more harm than good in regular
uses. The most common problems are disc insertion, disc ejections,
and won't play problems due to the protector ring that came off in the
disc mechanism.
• When removing the ejected disc, pull it straight out along the slot.
Removing the disc in a downward or upward angle may scratch the
recorded surface of the disc.
• Specially-shaped CDs, like heart-shaped or octagonal CDs, cannot be
played. Do not attempt to play them, even with an adapter, since they
may damage the player.
• Use a commercially available compact disc cleaner to clean a CD,
wiping gently from the center to the edge.
OKAY
NO GOOD

18
Operation
About MP3/WMA/AAC
ATTENTION
The making of MP3/WMA/AAC files by recording from sources such as broadcasts, records,
recordings, videos and live performances without permission from the copyright holder for uses
other than personal enjoyment is prohibited.
What is MP3/WMA/AAC?
MP3 (MPEG Audio Layer III) is a standard format for audio compression technology. By using MP3
a file can be compressed to one-tenth the size of the original.
WMA (Windows MediaTM Audio) and AAC (Advanced Audio Coding) are formats for audio
compression technology. WMA files can be compressed to a size smaller than MP3 files. AAC is
said to have a high rate of compression which is about 1.4 times that for MP3 files with the same
audio quality.
This main unit has limitations on MP3/WMA/AAC file standards and recorded media and formats
that can be used.
Playable MP3 file standards
• Supported standards:
MPEG-1 Audio Layer III, MPEG-2 Audio Layer III, MPEG-2.5 Audio Layer III
• Supported sampling frequencies:
8, 11.025, 12, 16, 22.05, 24, 32, 44.1, 48 (kHz)
• Supported bit rate:
8~320 (kbps)
* Supports VBR (8~320kbps)
* Does not support free format.
• Supported channel modes:
monaural, stereo, joint, dual
Playable WMA file standards
• Supported standards:
WMA Ver. 7 , WMA Ver. 8 , WMA Ver. 9
• Supported sampling frequencies:
8, 11.025, 12, 16, 22.05, 24, 32, 44.1, 48 (kHz)
• Supported bit rate:
3~320 (kbps)
* Supports VBR (3~320kbps).
* Does not support lossless compression.
• Do not use benzine, thinner, LP record spray or other cleaners on
CDs. They may damage a CD' s finish.
XXXX
XXXX
XXXX

How to operate the CD/MP3/WMA/AAC player
19
IV
* Does not support WMA files recorded at a frequency of 48kHz with a bit rate of 96kbps.
Playable AAC file standards
• Supported standards:
AAC-LC(MPEG-4)
• Supported sampling frequencies:
8, 11.025, 12, 16, 22.05, 24, 32, 44.1, 48 (kHz)
• Supported bit rate:
3~320 (kbps)
* Supports VBR (3~320kbps).
• Supported channel modes:
monaural, stereo, joint, dual
ATTENTION
Depending on the encoding method used, this device may not be able to play back some types of
AAC file.
ID3/WMA tag
MP3/WMA files have an “ID3 / WMA Tag” that allows input of information so that data such as song
title and artist can be saved.
This main unit supports ID3v. 1.0, 1.1, and WMA tags.
ATTENTION
Tags for AAC files cannot be displayed.
Media
Media capable of playing MP3/WMA/AAC includes CD-R and CD-RW discs. Compared to CD-ROM
media commonly used for music discs, CD-R and CD-RW discs are fragile in high temperature/high
humidity environments and one section of the CD-R and CD-RW may become incapable of
playback. Fingerprints or scratches on the disc may prevent playback or cause skipping during
playback. Sections of a CD-R and CD-RW may deteriorate if left inside a vehicle for long periods of
time. It is also recommended that CD-R and CD-RW discs be kept in a light-blocking case because
the discs are vulnerable to ultra-violet light.

20
Operation
Format of discs
The format of discs to be used must be ISO9660 Level 1 or Level 2.
Control items for this standard are as follows:
• Maximum directory layers: 8 layers
• Maximum characters for folder names/file names:
128 (including “.” and 3 letter file extension)
• Allowable characters for folder names/file names:
A~Z, 0~9, _ (underscore)
• Number of files possible on a single disc:
512
• Maximum folders this main unit can recognize:
512*
*: A root directory is counted as one folder.
File names
Only files with the MP3/WMA/AAC file extension “.mp3”, “.wma” , “.m4a” can be recognized as MP3/
WMA/AAC and played. Be sure to save MP3 files with the “.mp3” file extension. Be sure to WMA
files with the “.wma” file extension. Be sure to save AAC files with the “.m4a” file extension. The
“MP” letters of the file extension will be recognized whether entered as uppercase letters or
lowercase letters.
CAUTION
1
2
If the “.mp3”, “.wma”, “.m4a” file extension is attached to a file other than an MP3/WMA/AAC file,
that file will be mistakenly recognized by the main unit as an MP3/WMA/AAC file and played,
resulting in loud noise output that can damage the speakers. Be sure to avoid attaching the “.mp3”,
“.wma”, “.m4a” file extension to files that are not MP3/WMA/AAC files.
F2
Root directory (F1)
F158
Folder 2
Folder 158
Folder 159
F255 Folder 255
001.mp3
002.mp3
003.mp3
004.txt
005.mp3
001.mp3
002.mp3
F159
[Configuration example for CD supporting MP3/WMA/AAC]
Number of files possible on a single disc is 512. Files aside from MP3/WMA/AAC
files (Example: 004.txt) also count as single files.
